SAFETY INFORMATION
Warning! This product is for professional use only, not for domestic use.
Read this manual before powering up or installing the CLS Miriam. Follow the instructions
listed below and observe all warnings in this manual.
INTRODUCTION
Thank you for selecting the CLS Miriam. The CLS Miriam is an universal luminary that uses 37 Luxeon I LEDs
to create an even light-output. The CLS Miriam can be used indoor and outdoor through its waterproof (IP65)
housing. With these qualities the CLS Miriam is mountable almost everywhere.
NOTE: It is important to read this manual before you install this product.
CLS Miriam
Included items
The CLS Miriam is shipped in one package containing the following items:
• 1 x CLS Miriam
• 1 x user manual
Available Miriam spots
• CLS Miriam RGB fixture, DMX. 37pcs Luxeon-I, medium frosted (item nr. 140000)
• CLS Miriam RGB fixture, DMX. 37pcs Luxeon-I, narrow clear (item nr. 140005)
Protection from electric shock
• Disconnect the power supply from AC power before installing, dismounting or maintaining the unit.
• Make sure all connectors are connected properly.
• Use only a source of AC power that complies with local building and electrical codes and has both
overload and ground-fault protection.
• Refer all service to a qualified technician.
Protection from injury due to falls
• Verify that all covers and mounting hardware is securely fastened.
• Block the access around the work area whenever installing or removing the unit.
Protection from burns and fire
• Do not install the CLS Miriam near a heat source.
• Do not install the CLS Miriam in a corrosive, flammable or explosive area.
• Do not modify the CLS Miriam, or install other than genuine parts.
• Do not operate the CLS Miriam if the ambient temperature exceeds 40º C.
ATTENTION!
ThE CLS MIrIAM IS AN IP65 OuTdOOr uNIT, buT uNdEr
NO CIrCuMSTANCES CAN bE uSEd uNdEr wATEr!
WARNING
The CLS Miriam can be installed by using
the mounting hole. Drill a hole to secure it
in the wall, floor, ceiling, etc. Drill a second
hole for the power wire and DMX cables.
Adjust the Miriam to the preferred
position by turning the unit towards
or away from the wall.
Connect the DMX cables to the DMX
controller, then put the power wire in the
earthed socket
The CLS Miriam is ready to use.
270o
OFFFCNCH %
123456
270o
OFFFCNCH %
123456
INSTALLATION
This section shows how to install the CLS Miriam.
Optional accessories
• 140010 CLS Miriam Barndoor
• 140025 CLS Miriam RGB extension cable IP65 5 mtrs
• 140027 CLS Miriam RGB extension cable IP65 10 mtrs
• 140030 CLS Miriam RGB connection cable XLR3-connector 5mtr
• 140040 CLS Miriam RGB DMX cable outdoor
• 140050 CLS Miriam RGB connector set male/female IP65
• 707028 CLS Zense DMX controller + built in 4 amp RGB dimmer
• 707030 CLS ACX60 DMX controller for max. 60 channels

CLS Manuals
CLS Atmosphere LED-panel
www.cls-led.com www.cls-led.com
- 5 - - 6 -
CLS Manuals
CLS Miriam
TECHNICAL SPECIFICATIONS
LED: 37 x Luxeon®I
Lenses: Medium frosted or narrow clear
Colour: RGB
Power supply: 110 ~ 240 VAC
Power consumption: Max. 75 VA
Housing: Aluminum
IP rating: IP65
Cable length: 3 meter (power and DMX)
DMX input: DMX512
DMX output channels: 512 channels
Weight: 4,8 kg
Measurements: ø 225 mm x 310 mm (d)
Ambient temperature: -10 ºC to +40 ºC
Multiple connection
Possiblities on a fixture
Installation depth
In centimeters
Swivel
Fixture is horizontally rotatable,
indicated in degrees
Swivel
Fixture is vertically rotatable,
indicated in degrees
Mounting hole
In centimeters
Application area
Indoor or outdoor
Application area
Floor, wall or ceiling
Protection class
One, two or three
Cable length
Maximum cable attached
on the fixture in centimeters
Lifespan
Of the light source in hours
Driver
Inclusive or exclusive
Pressure
Maximum pressure on
the fixture per kg/cm2
Weight
In gram/kilogram
Curve
Minimal bending curve
in centimeters
LED pitch
Pitch between the
LEDs in millimeters
Cutting length
Indicated by the
cutting marks
DMX channels
DMX channels on
a product
DMX OPERATION
The CLS Miriam is controlled via DMX512. To configure the address, use the up and down buttons on the
back of the CLS Miriam. When the address is selected, the miriam stores it automatically. Next time the
Miriam is powered on, the address is restored to the address that was previously selected. The range of pos-
sible addresses is 1-510. The CLS Miriam uses 3 DMX-channels to control colour and intensity.
DMX-channel [N]: RED
DMX-channel [N+1]: GREEN
DMX-channel [N+2]: BLUE
Note: N is the address that is selected
Master/Slave operation
The CLS Miriam can operate in a master/slave mode. The CLS Miriam has a built-in programme with two
speed selections P1 (fast) and P2 (slow). To select the master/slave mode, press the up or down button on the
back of the CLS Miriam. This selection is also stored. When the master slave/mode is selected, there can only
be one master. All other Miriams must be addressed as slave on address 1.
Test mode operation
To check if all colours work properly, it is possible to put the CLS Miriam in a test mode. Simply adjust the
address to 0. The Miriam will show all colours in a stepping order. Make sure to reset the address when
testing is done.
MEASUREMENTS
ø 225 mm 310 mm
