Club Car DS Gold Standard 2008 User manual

Owner’sManual
2008
DSGoldStandard
Vehicles
Electric
GolfCar
Handyman
4-Passenger
LynxBoxBed
Lynx4-Passenger

P. O. Box 204658
Augusta, Georgia 30917-4658 USA
Telephone [phone]
Service Parts Fax [phone]
www.clubcar.com
2008 DS Electric Gold Standard Vehicle Owner’s Manual Page 1
NOTICE
Warranty information appears at the end of this manual. No other warranties, expressed or implied, are con-
tained herein. Your authorized representative checked the vehicle before it was delivered to you and will pro-
vide you a copy of the completed vehicle warranty registration form.
Club Car is not liable for errors in this manual or for incidental or consequential damages that result from the
use of the material in this manual.
Golf cars covered in this manual conform to the current American National Standards Institute’s Z130 Safety
and Performance Requirements for Golf Cars. This standard, which promotes safety in the design, applica-
tion, and operation of golf cars, defines a golf car as “a vehicle used to convey a person or persons and equip-
ment to play the game of golf in an area designated as a golf course.” Throughout this manual, the words “golf
car” are used in reference to golf cars only. The word “vehicle” is used in reference to any other vehicles cov-
ered in this manual, or may be used when referring to all vehicles, including golf cars, categorically.
This manual contains proprietary information that is protected by copyright. All rights are reserved. No part of
this manual may be photocopied, reproduced, or translated to another language without the written consent
of Club Car, Inc.
The information contained in this document is subject to change without notice.
Club Car reserves the right to make design changes to vehicles without obligation to make these changes on
units previously sold.
These vehicles do not conform to Federal Motor Vehicle Safety Standards for automobiles or to FMVSS 500
for low-speed vehicles, and are not equipped for operation on public streets, roads, or highways.
Copyright © 2007 Club Car, Inc.
Club Car, Carryall, Intellitrak, and Precedent are
registered trademarks of Club Car, Inc.
This manual effective August 1, 2007.

Page 2 2008 DS Electric Gold Standard Vehicle Owner’s Manual
FOREWORD
Thank you for choosing Club Car, the name most widely recognized as the industry leader in vehicle efficiency
and long-lasting value. You have chosen the finest vehicle on the market. Please protect your investment and
ensure that your Club Car vehicle(s) provides years of reliable, superior performance by reading and following
the maintenance instructions in this manual.
Your comfort and safety are important to us, so we urge you to read and follow the step-by-step operating
instructions and safety procedures in this manual. These instructions must be followed in order to avoid the
risk of severe personal injury. If you rent or loan your vehicle to others, we recommend that you ask them to
read this manual before they operate the vehicle.
Club Car products are backed by a customer support system designed to offer you fast, courteous service. In
the event that your Club Car vehicle needs repairs or service, we recommend that your local authorized Club
Car representative perform them. For the name and address of the Club Car representative nearest you,
logon to our web site at www.clubcar.com or call 1-800-ClubCar (258-2227). If you would prefer to write to us,
direct your letter to: Club Car, Attention: Marketing Services, P.O. Box 204658, Augusta, Georgia 30917-4658
USA. Your local authorized Club Car representative can also provide technical advice, parts, and service
manuals.
We hope you will consider this owner’s manual a permanent part of your Club Car vehicle. If you sell the vehi-
cle, please include the manual so that the next owner will have the important operating, safety, and mainte-
nance information it contains.

2008 DS Electric Gold Standard Vehicle Owner’s Manual Page 3
TABLE OF CONTENTS
Safety Decal and Feature Identification ..................................................................................................... 4
Practice Safety .......................................................................................................................................... 7
Proposition 65 – State of California ........................................................................................................... 7
Safety Details ............................................................................................................................................ 8
General Warnings ...................................................................................................................................... 8
General Information ................................................................................................................................... 10
Model Identification .................................................................................................................................... 10
Controls and Indicators .............................................................................................................................. 11
Pre-Operation and Daily Safety Checklist ................................................................................................. 16
Performance Inspection ............................................................................................................................. 16
Driving Instructions .................................................................................................................................... 17
Loading and Unloading – Box Bed Vehicles ............................................................................................. 19
Towing with the Vehicle – Golf Car and Handyman Vehicles ................................................................... 20
Towing the Vehicle .................................................................................................................................... 21
Transporting on a Trailer ........................................................................................................................... 22
Storage ...................................................................................................................................................... 22
Maintenance .............................................................................................................................................. 23
Periodic Service Schedule ......................................................................................................................... 24
Periodic Lubrication Schedule ................................................................................................................... 26
Vehicle Controller ...................................................................................................................................... 28
Batteries .................................................................................................................................................... 28
Battery Charger ......................................................................................................................................... 30
Cleaning the Vehicle .................................................................................................................................. 33
Accessories ............................................................................................................................................... 34
Subsequent Owner Registration ................................................................................................................ 34
Specifications – Golf Car, 4-Passenger, and Handyman .......................................................................... 35
Specifications – Lynx 4-passenger and Box Bed Vehicle ......................................................................... 36

Safety Decal and Feature Identification
Page 4 2008 DS Electric Gold Standard Vehicle Owner’s Manual
SAFETY DECAL AND FEATURE IDENTIFICATION
The following pages contain safety decal and feature identification information. For detailed information on
specific features, read the appropriate section in this manual.

Safety Decal and Feature Identification
2008 DS Electric Gold Standard Vehicle Owner’s Manual Page 5
ELECTRIC VEHICLE
1 101825101 Decal, On/Off Key Switch (above key switch) 11 Brake Pedal
2 101959902 Decal, Motor Braking Notice (below instrument panel) 12 Park Brake Pedal
3 101960601 Decal, Rollover Warning (on instrument panel) 13
4 102075801 Decal, Young Driver Warning (below instrument panel) 14
5 102228701 Decal, Private Speed Notice (below instrument panel)
(with private speed option) 15
6 102519201 Decal, Operating Instructions (on steering wheel) 16
7 SVP147801 Decal, Vehicle Loading Instructions (below instrument
panel) (Handyman and Lynx box bed vehicles) 17
8 Battery Warning Light 18
9 Serial Number 19
10 Accelerator Pedal 20
275
4
6
5
2
3
8
9
12 11
7
10
1

Safety Decal and Feature Identification
Page 6 2008 DS Electric Gold Standard Vehicle Owner’s Manual
ELECTRIC VEHICLE
1 101553901 Decal, Bed Loading Warning (on cargo bed) (Handy-
man and Lynx box bed vehicles) 11
2 101610901 Decal, Wiper Switch Cover Notice (on wiper switch
cover) (Wiper switch vehicles) 12
3 101705701 Decal, Falling Off Warning (on rear-facing hand rail
(4-passenger vehicles) 13
4 101908601 Decal, Tow Switch Warning (on Tow/Run switch plate,
under seat) 14
5 101931501 Decal, Component Cover Notice (on electrical compo-
nent cover) 15
6 Forward/Reverse Control 16
7 Forward/Reverse Control 17
818
919
10 20
276
Club Car
FNR
OR
13
4
2
5
76

Practice Safety
2008 DS Electric Gold Standard Vehicle Owner’s Manual Page 7
PRACTICE SAFETY
Safety signs like you see above may at first seem shocking, but their impact is mild compared with the reality
of severe personal injury.
Your safety and satisfaction are of the utmost importance to us. That is why before operating the vehicle, we
urge you to review the information in this manual. Understand and become familiar with the DANGER,
WARNING, and CAUTION statements and procedures it contains, along with the safety decals that are affixed
to your vehicle.
Take time to understand the language of safety. It is a language that can save your life.
PROPOSITION 65 – STATE OF CALIFORNIA
ý WARNING
• This product contains or emits chemicals or substances that have been determined by the
state of California to cause cancer and birth defects or other reproductive harm.
Figure 1 Practice Safety

Safety Details
Page 8 2008 DS Electric Gold Standard Vehicle Owner’s Manual
SAFETY DETAILS
ý WARNING
• This owner’s manual should be read completely before attempting to drive or service the
vehicle. Failure to follow the instructions in this manual could result in property damage,
severe personal injury, or death.
It is important to note that some vital statements throughout this manual and on the decals affixed to the vehi-
cle are preceded by the words DANGER, WARNING, or CAUTION. For your protection, we recommend that
you take special notice of these safety precautions. Safety precautions are essential and must be followed.
Throughout this manual and on the operation and safety decals affixed to the vehicle, the words “golf car” are
used in reference to golf cars only. The word “vehicle” is used in reference to any other vehicles covered in
this manual, or may be used when referring to all vehicles, including golf cars, categorically.
If any of the operation or safety decals on the vehicle become damaged, have been removed or cannot be
easily read, they should be replaced immediately to avoid possible property damage, personal injury, or
death. Contact your distributor/dealer.
ý DAN GER
• A DANGER indicates an immediate hazard that will result in severe personal injury or death.
ý WARNING
• A WARNING indicates an immediate hazard that could result in severe personal injury or
death.
ý CAUTION
• A CAUTION with the safety alert symbol indicates a hazard or unsafe practice that could
result in minor personal injury.
CAUTION
• A CAUTION without the safety alert symbol indicates a potentially hazardous situation that
could result in property damage.
GENERAL WARNINGS
The following safety statements must be heeded whenever the vehicle is being operated, repaired, or ser-
viced. See Safety Decal and Feature Identification on page 4. Other specific safety statements appear
throughout this manual and on the vehicle.
ý DAN GER
• Battery – Explosive gases! Do not smoke. Keep sparks and flames away from the vehicle and
service area. Ventilate when charging or operating vehicle in an enclosed area. Wear a full
face shield and rubber gloves when working on or near batteries.
• The vehicle will not provide protection from lightning, flying objects, or other storm-related
hazards. If caught in a storm while driving a Club Car vehicle, exit the vehicle and seek shelter
in accordance with applicable safety guidelines for your location.

General Warnings
2008 DS Electric Gold Standard Vehicle Owner’s Manual Page 9
ý WARNING
• Follow the procedures exactly as stated in this manual, and heed all DANGER, WARNING, and
CAUTION statements in this manual as well as those on the vehicle and battery charger.
• Do not leave children unattended on vehicle.
• Prior to leaving the vehicle unattended or servicing the vehicle, set the park brake, place the
Forward/Reverse handle or switch in the NEUTRAL position, turn the key switch to the OFF
position, and remove the key. Chock the wheels when servicing the vehicle.
• Improper use of the vehicle or failure to properly maintain it could result in decreased vehicle
performance, severe personal injury, or death.
• Any modification or change to the vehicle that affects the stability or handling of the vehicle,
or increases maximum vehicle speed beyond factory specifications, could result in severe
personal injury or death.
• Check the vehicle for proper location of all vehicle safety and operation decals and make sure
they are in place and are easy to read.
• Only trained technicians should service or repair the vehicle or battery charger. Anyone doing
even simple repairs or service should have knowledge and experience in electrical and
mechanical repair. The appropriate instructions must be used when performing maintenance,
service, or accessory installation.
PowerDrive Plus and IQ System vehicles:
• Place Tow/Run switch in the TOW position before disconnecting or connecting the batteries.
Failure to heed this warning could result in a battery explosion or severe personal injury.
All electric vehicles:
• To avoid unintentionally starting the vehicle, disconnect the batteries as shown (Figure 1 or
Figure 2).
IQ System vehicles:
• After disconnecting the batteries, wait 90 seconds for the controller capacitors to discharge.
PowerDrive System 48 and PowerDrive Plus vehicles:
• After disconnecting the batteries, discharge the controller capacitors as follows:
- Turn key switch to the ON position and place the Forward/Reverse handle in the REVERSE
position.
- Slowly press the accelerator pedal and keep it pressed until the reverse warning buzzer can no
longer be heard. When the buzzer stops sounding, the controller capacitors are discharged.
All electric vehicles:
• Wear safety glasses or approved eye protection when servicing the vehicle or battery charger.
Wear a full face shield and rubber gloves when working on or near batteries.
• Do not wear loose clothing or jewelry such as rings, watches, chains, etc., when servicing the
vehicle or battery charger.
• Use insulated tools when working near batteries or electrical connections. Use extreme
caution to avoid shorting of components or wiring.

General Information
Page 10 2008 DS Electric Gold Standard Vehicle Owner’s Manual
GENERAL INFORMATION
This manual features the following Gold Standard electric vehicles:
•Golf car
•4-passenger vehicle
•Handyman (see following NOTE)
•Lynx vehicle
•Lynx 4-passenger vehicle
The electric vehicles have one of several possible powertrain configurations: PowerDrive System 48, Power-
Drive Plus, and IQ System. It is important that you know which powertrain your vehicle has.
NOTE: Throughout this manual, the term “Handyman vehicle” is used when referring to the Golf Car vehi-
cle equipped with a box bed. The Lynx also has a box bed, but it has larger tires, a lifted chassis,
and a brush guard.
There is also a Lynx 4-passenger vehicle; unless noted otherwise, the term 4-passenger vehicle
refers to both the 4-passenger Golf Car and Lynx models.
Throughout this manual, important features unique to each model are highlighted. We urge the owner/operator
to read and understand this manual and to pay special attention to the features specific to his/her vehicle(s).
MODEL IDENTIFICATION
The serial number of the vehicle is printed on a bar code decal mounted on the frame directly above the accel-
erator pedal (Example: 2A0601-123456) (Figure 3). There is also a second serial number decal mounted on
the front body frame behind the center dash panel. The center dash panel must be removed to view this decal.
See following NOTE.
Figure 1 PowerDrive System 48 Vehicle Figure 2 PowerDrive Plus and IQ System Vehicles
(Viewed from driver side of vehicle)
1. Remove negative battery cable.
2. Remove positive battery cable.
Connect battery cables in reverse order.
(Viewed from driver side of vehicle)
1. Place TOW/RUN Switch in TOW before disconnecting or
connecting battery cables.
2. Remove negative battery cable.
3. Remove positive battery cable.
Connect battery cables in reverse order.
2
1
(+)
(–)
1
2
3
4
6
5
3
2
(+)
(–) 1
2
3
4
6
5
1

Controls and Indicators
2008 DS Electric Gold Standard Vehicle Owner’s Manual Page 11
NOTE: Have the vehicle serial number available when ordering parts or making inquiries.
The model year designation of a Gold Standard vehicle is the year that the vehicle was remanu-
factured, rather than the year that it was originally manufactured.
CONTROLS AND INDICATORS
See General Warnings on page 8.
ý WARNING
• If loaning the vehicle, make sure the driver is familiar with all controls and operating
procedures before allowing the vehicle to be driven.
• Any modification or change to the vehicle that affects the stability or handling of the vehicle,
or increases maximum vehicle speed beyond factory specifications, could result in severe
personal injury or death.
• Do not shift the Forward/Reverse handle or switch while the vehicle is moving. To avoid injury
to an unsuspecting passenger or damage to the vehicle, always bring the vehicle to a full stop
before shifting the Forward/Reverse handle or switch.
• Release the accelerator pedal and then press the brake pedal firmly until the vehicle stops. To
avoid unintentionally starting or rolling the vehicle, set the park brake, place the Forward/
Reverse handle or switch in the NEUTRAL position, turn the key switch to the OFF position,
and remove the key when leaving the vehicle.
Figure 3 Serial Number Decal
SERIAL NUMBER
AQ0601-123456
P O BOX 204658
AUGUSTA GA 30917
Club Car
R
1

Controls and Indicators
Page 12 2008 DS Electric Gold Standard Vehicle Owner’s Manual
KEY SWITCH
The key switch is mounted on the dash to the right of the steering column (Figure 4). It has two positions,
OFF and ON, which are clearly labeled. See following NOTE.
NOTE: The key can be removed only when the key switch is in the OFF position.
FORWARD/REVERSE CONTROL
PowerDrive System 48 Vehicles
The Forward/Reverse handle is located on the seat support panel, below and to the right of the driver’s right
knee (Figure 5). The Forward/Reverse handle has three distinct positions: F(FORWARD), R(REVERSE), and
N(NEUTRAL). Rotate the handle towards thedriver (FORWARD) to operatethe vehicle in the forward direction,
or towards the passenger (REVERSE) to operate vehicle in reverse. When the handle is in the straight up posi-
tion (NEUTRAL), the vehicle will not operate. Club Car vehicles operate at reduced speed in reverse. The
reverse buzzer will sound as a warning when the Forward/Reverse handle is in the REVERSE position.
PowerDrive Plus and IQ System Vehicles
The Forward/Reverse rocker switch is located in the same place as the Forward/Reverse handle on all other
models: on the seat support panel below and to the right of the driver’s right knee. The F(FORWARD) and R
Figure 4 Key Switch
Figure 5 Forward/Reverse Handle Figure 6 Forward/Reverse Rocker Switch

Controls and Indicators
2008 DS Electric Gold Standard Vehicle Owner’s Manual Page 13
(REVERSE) positions are clearly marked. Push down the FORWARD side of the switch to operate the vehicle
in the forward direction, or push down the REVERSE side of the switch to operate the vehicle in reverse.
When the rocker switch is positioned in NEUTRAL, with neither side down, the vehicle will not operate if the
accelerator pedal is pressed (Figure 6). The reverse buzzer will sound as a warning when the Forward/
Reverse switch is in the REVERSE position.
ACCELERATOR PEDAL
The accelerator pedal is the pedal on the right, with the word GO molded into it (Figure 7). The operation of
the accelerator pedal differs from that of an automobile. When the key switch is in the ON position, and the
Forward/Reverse handle or switch is in either the FORWARD or REVERSE position, pressing the accelerator
pedal will automatically release the park brake and start the vehicle moving in the direction selected (forward
or reverse). As the accelerator pedal is pressed, speed will increase until full speed is reached. When the
accelerator is released, power will be cut off and the motor will stop running.
BRAKE PEDAL
The brake pedal is the large pedal on the left with the word STOP molded into it (Figure 7). To slow or stop
the vehicle, press the brake pedal with your foot (Figure 8).
PARK BRAKE PEDAL
The park brake pedal is the small raised portion in the upper left corner of the brake pedal. It has the word
PARK molded into it and the words PARK BRAKE marked on top of it (Figure 8). To set the park brake, press
the brake pedal firmly and tilt the park brake portion of the pedal forward with your foot (Figure 9). See fol-
lowing WARNING.
ý WARNING
• The park brake will release automatically when either the accelerator or brake pedal is
pressed. The park brake has multiple locking positions and should be firmly pressed and
locked to prevent the vehicle from rolling.
Figure 7 Accelerator and Brake Pedals

Controls and Indicators
Page 14 2008 DS Electric Gold Standard Vehicle Owner’s Manual
BATTERY WARNING LIGHT
Electric vehicles feature a dash-mounted warning light (above steering column) that, when the vehicle is in
operation, indicates low battery voltage or, when the vehicle is being charged, indicates a charging problem.
The battery warning light is controlled by the onboard computer.
When the vehicle is in operation, the warning light will illuminate and remain illuminated if:
•Batteries’ voltage drops below 48 volts when there is no load on the batteries (the vehicle is stopped
and there are no accessories on).
•Batteries have discharged to less than 25% of rated capacity.
If the warning light illuminates when the vehicle is operating, there will be enough power remaining to drive the
vehicle for approximately 30 minutes. However, the vehicle should be charged at the first opportunity. If the
warning light illuminates and the vehicle is unable to operate for 30 minutes, have your Club Car distributor/
dealer check the vehicle for a possible battery or electrical system problem.
When the batteries receive an incomplete charge because 1) the DC power cord is disconnected, 2) AC
power to the charger is interrupted, 3) automatic charger shut-off occurs after 16 hours of operation, 4) the
charger malfunctions, or 5) the wrong charger is used, the warning light will indicate as follows:
•The warning light will not illuminate if the charge is 90% or more complete. The onboard computer will
retain in memory the amount of charge needed to fully replenish the batteries and will complete the
charge during the next charge cycle.
•When the charger is unplugged, the warning light will illuminate and remain illuminated for 10 seconds
if the charge is less than 90% complete but the vehicle has enough power for approximately 30 min-
utes of operation. This will alert the operator that the vehicle may be used, but that it must be charged
to completion as soon as possible.
•The warning light will repeatedly illuminate for 10 seconds, with 4 second intervals if the charger times
out at 16 hours and the batteries are not sufficiently charged. See the battery charger owner’s man-
ual. This indicates an abnormal charge cycle. The charger and batteries should be checked by your
Club Car distributor/dealer.
•The warning light will repeatedly illuminate for 10 seconds, with 4 second intervals during a charge
cycle (DC plug is still connected) if AC power to the charger is interrupted. The light will go out when
AC power is restored.
LED Light: In addition to the warning light, there is an infrared LED in the dash light assembly, which trans-
mits an infrared signal from the onboard computer. This signal is received by the optional Communication Dis-
play Module (CCI P/N 101831801), which provides information on the condition of the vehicle and batteries.
Figure 8 Brake Pedal Figure 9 Park Brake Pedal

Controls and Indicators
2008 DS Electric Gold Standard Vehicle Owner’s Manual Page 15
TOW/RUN SWITCH
PowerDrive Plus and IQ System Vehicles
ý WARNING
• Place Tow/Run switch in the TOW position before disconnecting or connecting the batteries.
Failure to heed this warning could result in a battery explosion or severe personal injury.
• When the Tow/Run switch is in the TOW position, all motor braking functions, including zero
speed detect, are disabled.
PowerDrive Plus and IQ System vehicles are equipped with a Tow/Run switch, located under the seat just
above the Forward/Reverse switch (Figure 10). The switch must be in the RUN position in order to operate
the vehicle. When the switch is in the TOW position, power to the vehicle electrical components is turned off
and the vehicle will not operate. See following NOTE.
NOTE: After placing the Tow/Run switch in the TOW position, allow 10 seconds to elapse before switching
back to the RUN position.
After placing the Tow/Run switch in the RUN position, allow 10 seconds to elapse before operating
the vehicle.
The Tow/Run switch should be placed in the TOW position under the following conditions:
• Before Towing the Vehicle: Place the Tow/Run switch in the TOW position to disable all motor braking
functions, thus preventing possible damage that could occur to the vehicle or electrical components if
the vehicle is towed while the zero speed detect motor braking function is operating.
• Before Disconnecting or Connecting Battery Cables: Place the Tow/Run switch in the TOW posi-
tion to turn off power to the vehicle electrical system, thus preventing severe arcing and possible bat-
tery explosion as the battery cables are disconnected.
• For Long-Term Storage: Place the Tow/Run switch in the TOW position to turn off power to the vehi-
cle electrical system, thus preventing vehicle electrical components from discharging the batteries.
Figure 10 Tow/Run Switch

Pre-Operation and Daily Safety Checklist
Page 16 2008 DS Electric Gold Standard Vehicle Owner’s Manual
PRE-OPERATION AND DAILY SAFETY CHECKLIST
Each Club Car vehicle has been thoroughly inspected and adjusted at the factory; however, upon receiving
your new vehicle(s), you should become familiar with its controls, indicators, and operation. Carefully inspect
each vehicle to ensure that it is in proper working condition before accepting delivery.
Use the following checklist as a guide to inspect the vehicle. This checklist should be used daily to ensure that
the vehicle is in proper working condition and in conjunction with the Periodic Service Schedule on page 24.
Any problems should be corrected by a Club Car distributor/dealer or a trained technician.
• General: All the parts should be in place and properly installed. Be sure that all nuts, bolts, and screws
are tight.
• Safety and information decals: Check to ensure that all safety and information decals are in place.
See Safety Decal and Feature Identification on page 4.
• Tires: Check for proper tire pressure. Visually inspect tires for wear, damage, and proper inflation on a
daily basis. See Specifications – Golf Car, 4-Passenger, and Handyman on page 35 or Specifica-
tions – Lynx 4-passenger and Box Bed Vehicle on page 36.
• Batteries: Check electrolyte to ensure that it is at the proper level (Figure 14, Page 29). Check battery
posts. Wires should be tight and free of corrosion. On electric vehicles, charge batteries fully before
first use of vehicle.
• Charger cord, plug, and receptacle: Visually inspect for cracks, loose connections, and frayed wir-
ing. See Plug and Receptacle on page 32.
• Wiper switch: Be sure wiper switch cover is properly secured prior to operating the vehicle.
ý WARNING
• Be sure the plastic has been removed from the seat bottom before operating the vehicle.
Failure to do so may result in a fire, property damage, personal injury, or death.
PERFORMANCE INSPECTION
After you have familiarized yourself with the vehicle controls and have read and understood the driving
instructions, take the vehicle for a test drive.
Use the following checklist as a guide to inspect the vehicle and check daily for proper operation. Any prob-
lems should be corrected by a Club Car distributor/dealer or a trained technician.
All Vehicles
• Forward/Reverse control: Check for proper operation. See Controls and Indicators on page 11.
• Brakes: Be sure the brakes function properly. When brake pedal is fully pressed under moderate pres-
sure, it should not go more than halfway to the floor, and vehicle should come to a smooth, straight
stop. If the pedal goes more than halfway to the floor, or if the vehicle swerves or fails to stop, have the
brake system checked and adjusted as required. Brake adjustment must be maintained so that the
brake pedal cannot be pressed to the floor under any circumstance.
• Park brake: When latched, the park brake should lock the wheels and hold the vehicle stationary (on
an incline of 20% or less). It should release when either the accelerator or brake pedal is pressed.
• Reverse buzzer: The reverse buzzer should sound as a warning when the Forward/Reverse handle or
switch is in the REVERSE position.
• Steering: The vehicle should be easy to steer and should not have any play in the steering wheel.

Driving Instructions
2008 DS Electric Gold Standard Vehicle Owner’s Manual Page 17
• Accelerator: With the key switch in the ON position and the Forward/Reverse switch in the FOR-
WARD position, as the accelerator pedal is pressed, the motor should start and the vehicle should
come up smoothly to full speed. When the pedal is released it should return to the original position and
the motor should rotate freely. All Club Car vehicles operate at reduced speed in reverse.
PowerDrive Plus and IQ System vehicles: When the pedal is released it should return to the original
position and the motor should rotate freely or go into motor braking mode. See Pedal Up Motor Brak-
ing below.
• General: Listen for any unusual noises such as squeaks or rattles. Check the vehicle’s ride and perfor-
mance. Have a Club Car distributor/dealer or a trained technician investigate anything unusual.
PowerDrive Plus and IQ System Vehicles
• Zero Speed Detect: With the vehicle parked on level ground and the park brake disengaged, place the
Tow/Run switch in the RUN position and attempt to push the vehicle. Motor braking should engage and
cause resistance to rolling (moving at no more than 1 to 3 mph) (1.5 or 4.8 km/h) with the Forward/
Reverse switch in any position. IQ System vehicles: When zero speed detect motor braking is
engaged, the reverse buzzer should emit a distinct pattern of beeps. See following WARNING.
ý WARNING
• Zero speed detect will not limit vehicle speed to 1 mph (1.6 km/h) on very steep grades. Do not
operate vehicle on slopes exceeding 20% grades.
• Pedal Up Motor Braking (adjustable on IQ System vehicles): Accelerate the vehicle to full speed
and then release the accelerator pedal. Motor braking should quickly and smoothly slow the vehicle to
approximately 11 mph (17.7 km/h). Motor braking will disengage when vehicle slows to 11 mph (17.7
km/h). This feature is adjustable for IQ System vehicles only. Contact your local Club Car dealer/distrib-
utor to inquire about this adjustable feature.
• Pedal Down Motor Braking: Accelerate down an incline with the accelerator pedal pressed. When the
vehicle reaches maximum designed speed, motor braking should engage and limit the vehicle to its
maximum designed speed. On very steep grades, the vehicle may slightly exceed its maximum
designed speed, requiring use of the brake pedal.
DRIVING INSTRUCTIONS
ý WARNING
• Only licensed drivers should be allowed to drive the vehicle.
• If renting or loaning the vehicle, make sure the driver is familiar with all controls and
operating procedures before allowing the vehicle to be driven.
• No more than two people should be on the vehicle at one time, except for the 4-passenger
vehicle, which can carry four people.
• The vehicle is not specially equipped for handicapped persons:
- Be sure all persons can properly operate the vehicle prior to allowing them to drive the
vehicle.
- Be sure all passengers are capable of securing themselves in a vehicle before allowing
them to ride in one.
WARNING CONTINUED ON NEXT PAGE...

Driving Instructions
Page 18 2008 DS Electric Gold Standard Vehicle Owner’s Manual
ý WARNING
• For night use, the vehicle must be equipped with headlights, taillights and reflectors.
• Stop the vehicle before shifting the Forward/Reverse handle. Failure to do so may result in
injury to an unsuspecting passenger and (or) damage to the vehicle.
• To help avoid being struck, do not stand in front of or behind the vehicle.
• Operate the vehicle from the driver seat only.
• To help prevent falls from the vehicle, remain seated in a moving vehicle and hold on to hand
holds or handrails at all times. Driver should keep both hands on the steering wheel when the
vehicle is in motion.
• To help prevent the possibility of serious injury, keep your entire body inside the vehicle.
• Do not leave children unattended on vehicle.
• To help prevent overturning the vehicle, drive slowly straight up and down slopes. Avoid
driving the vehicle on slopes exceeding 20% incline.
• To help avoid possible injury to an inattentive passenger and (or) damage to the vehicle, avoid
sudden starts, sudden stops, and abrupt turns.
• To help avoid the possibility of losing control of or overturning the vehicle, reduce speed for
adverse driving conditions such as wet grass or rough terrain.
• Do not use the vehicle on public roads. It is not designed or intended for street use and
should not be licensed for use on public roads.
• Where applicable, obey all local rules concerning golf cars and off-road vehicles.
• The vehicle should be driven in only specified areas by trained drivers.
• Do not drive while under the influence of alcohol, drugs, or medications.
• To prevent overturning the vehicle, drive slowly in turns.
• Use brakes to reduce speed when coasting downhill.
No one should drive the vehicle without first being instructed in the proper operation and use of the vehicle’s
controls. An experienced operator should accompany each first-time driver on a test drive before allowing
him/her to operate the vehicle alone.
To ensure safe operation of the vehicle, follow exactly and in order, all of the following procedures. Read and
understand all instructions prior to driving the vehicle.
Starting the vehicle
1. Study and understand controls.
2. Read safety warnings located on dash and above pedals.
3. For vehicles with cargo beds: Make sure load is secure.
4. Make sure everyone is seated and holding onto seat hand holds or handrails.
5. Make sure wheels are turned in desired direction and that nothing is in your path.
6. Turn key to the ON position.
7. Select direction by placing the Forward/Reverse handle or switch in desired position (F = forward or R
= reverse). A buzzer will sound as a warning when the Forward/Reverse handle or switch is in the
REVERSE position.
8. Place both hands on the steering wheel.
9. Slowly press accelerator pedal. The park brake will release automatically and the vehicle will start to
move. As the accelerator pedal is pressed, speed will increase until full speed is reached. See following
WARNING and NOTE.
