CMA Dishmachines H-1X Manual

08-2021
3
STEP
4
STEP
1
STEP
H-1X
Quick Setup
Instructions
WARNING: Electrical and
plumbing connections need
to be made by a qualified
service person who will
comply with all available
Federal, State and Local
Health, Electrical, Plumbing
and Safety codes.
LINE 1
LINE 2
208/230V GROUND
2
STEP
FLOOR DRAIN
1"AIR GAP
WALL DRAIN
ELECTRICAL CONNECTIONS
LOCATED INSIDE FRONT
PANEL
Level dishmachine by adjusting leveling legs.
Dishmachine must be level front to back and
side to side ensure proper performance.
Connect lines 1 and 2 to electrical block located
inside front panel.
Connect dishmachine to hot water source, minimum
temperature 120F, better results at 140F.
LEVELING
LEGS 3
1/2" WATER
INLET 4
3/4" DRAIN
OUTLET 2
1
Connect the drain hose to wall or floor drain. The
floor drain must have a 1 inch air gap between
drain hose and floor drain.
PN: 00000.00
THE DRAIN HOSE IS LOOPED
AND CLAMPED AND MUST
NOT BE CHANGED. ALTERING
THE DRAIN HOSE ROUTING
MAY RESULT IN THE MACHINE’S
INABILITY TO DRAIN OR MAY
CAUSE THE MACHINE TO
SIPHON THE WATER OUT OF
THE MACHINE.
! VERY IMPORTANT !
The dishwasher will not drain
correctly if it is connected to a
disposer.
H-1X

H-1X FRONT VIEW
5
STEP
START
POWER 5
7
6
TEMP GUAGE
08-2021
6
STEP
H-1X
Quick Setup
Instructions
WARNING: Electrical and
plumbing connections need
to be made by a qualified
service person who will
comply with all available
Federal, State and Local
Health, Electrical, Plumbing
and Safety codes.
DETERGENT
RINSE/PRIME
The chemical pumps must be primed (using the
prime switch) before the dishmachine is operated . Push the "START" button to start the
dishmachine cycle.
7
STEP
BOOSTER FILL PROCEDURE
1. DO NOT TURN THE DISHMACHINE POWER
SWITCH ON.
2. Turn the water supply to the machine on.
3. Turn the breaker or disconnect on.
4. PRESS and HOLD the dishmachine GREEN
start switch for 3 seconds to activate the fill
solenoid.
5. Continue to hold the start switch until water
enters the wash tank.
6. Release the start switch.
7. Booster pre-fill is complete.
The Spirit of Excellence
an Ali Group Company
H-1X
H-1X H-1X H-1X
POWER
ON
