CMA Dishmachines UC60E Manual

TO PRIME CHEMICAL PUMPS
ALLOW THE DISHWASHER TO
RUN 3 TO 4 CYCLES WITH THE
CHEMICAL LINES IN THE
CONTAINERS.
3-2016
UC60e
Quick Setup
Instructions
1
STEP
WARNING: Electrical and plumbing
connections need to be made by a
qualified service person who will
comply with all available Federal, State
and Local Health, Electrical,Plumbing
and Safety codes.
208/230V
L-1
L-2
GROUND
Connect the drain hose to wall or floor drain. The
floor drain must have a 1-inch air gap between
drain hose and floor drain.
2
STEP
FLOOR DRAIN
1"AIR GAP
WALL DRAIN
THE GREEN AND CLEAR
CHEMICAL FEED LINES ARE
SHIPPED INSIDE THE BACK
OF THE DISHWASHER.
REMOVE THE FILTER AND
FEED THE LINES THROUGH
THE RUBBER PROTECTIVE
GROMMETS AT THE BOTTOM
REAR LEFT-HAND CORNER
OF THE DISHWASHER.
Level dishmachine by adjusting “leveling legs”.
Dishmachine must be level, front and back, to
ensure proper performance and prevent door leaks.
Connect Main power lines L-1 & L-2, and Ground to the
proper terminals, located on electrical block inside the
front panel. After connecting main power, make sure all
terminals, “used” and “unused” on the block, are tight.
Connect dishmachine to hot water source,
recommended 140°F.
00 00
1
START
2
3
LEVELING
LEGS 3
DRAIN 2
1/2" WATER
INLET 4
EQUIP
4
STEP
3
STEP
EQUIP
EQUIP
ELECTRICAL
BLOCK 1
ELECTRICAL
INLET
GREEN
TUBE
CLEAR
TUBE
800-854-6417
PN: 10130.27

00 00
1
START
2
3
3-2016
UC60e
Quick Setup
Instructions
WARNING: Electrical and plumbing
connections need to be made by
a qualified service person who will
comply with all available Federal, State
and Local Health, Electrical, Plumbing
and Safety codes.
To initially fill dishwasher with water, push and
hold the power button until water valve activates;
then release and the unit starts filling with water.
To start cycle press START button. To change cycle
press and hold START button for 5 seconds. Total
cycles 60/120/180/300 seconds.
CYCLE SELECTION
LIGHTS
WASH TANK
TEMPERATURE
RINSE
TEMPERATURE
7
START 6
DRAIN
5
POWER
7
OVERFLOW TUBE
6
STEP
00 00
1
START
2
3
00 00
1
START
2
3
5
STEP
FILL
00 00
1
START
2
3
FILL
FILL
To drain the dishwasher, turn the main power off; the light will turn orange. Open the front door and remove
the overflow drain-stopper. Press and hold the drain button for three seconds or until the drain pump
activates. Allow the dishwasher to drain; the unit will turn off when done. Note: do not drain the dishwasher
without the scrap screen in place.
7
STEP
WATER SUPPLY MUST NOT
EXCEED 150 DEGREES.
OTHERWISE, “VAPOR”
WILL CAUSE ELECTRONIC
COMPONENT DAMAGE!
CAUTION!
800-854-6417
