Coaster 205111T User manual

ASSEMBLY INSTRUCTIONS
COASTER FINE FURNITURE
Fine Furniture for every stage of life
205111
T (B
1-B3
)
Twin Storage Bed
REVISION 0 : 11/26/
2019
PAGE 1 OF 6 COASTERFURNITURE.COM

ITEM:205111T
(B1-B3)
ASSEMBLY INSTRUCTIONS
ASSEMBLY TIPS:
1. Remove hardware from box and sort by size.
2. Please check to see that all hardware and parts are present prior to start of assembly.
WARNING!
2. This product is for home use only and not intended for commercial establishments.
ASSEMBLY TIME
B1 ( BOX 1)
AHEADBOARD
PANEL 1PC C RIGHT
HEADBOARD
LEG 1PC
B FOOTBOARD 1PC D LEFT HEADBOARD
LEG 1PC
B2 ( BOX 2)
E BED RAIL 2PCS H DRAWER BOTTOM
TRESTLE BAR 1PC
FCONCEAL
PANEL 3PCS I DRAWER SUPPORT RAIL 2PCS
G BED SLAT 5PCS J DRAWER SUPPORT LEG
WITH LEVELER 1PC
B3 ( BOX 3)
K DRAWER BOX 1PC
1. Don’t attempt to repair or modify parts that are broken or defective. Please contact the store
immediately.
3. Please follow attached instructions in the same sequence as numbered to assure fast & easy assembly.
PARTS IDENTIFICATION
20 MINUTES
PAGE 2 OF 6 COASTERFURNITURE.COM
205111T(B1)
FROM BOX 1
HEADBOARD
COMPLETE
HB 1PC
B205111T(B1) FROM BOX 1
FOOTBOARD 1PC

ITEM:205111T
(B1-B3)
ASSEMBLY INSTRUCTIONS
1. Remove hardware from box and sort by size.
2. Please check to see that all hardware and parts are present prior to start of assembly.
WARNING!
2. This product is for home use only and not intended for commercial establishments.
HARDWARE IDENTIFICATION
Z-B1 (BOX 1) - HARDWARE PACK IS LOCATED IN 205111T (B1)
1BOLT
(M6 x 30mm - BLK) 6PCS 3 FLAT WASHER
(1/4"ID x 13mm - BLK) 6PCS
2LOCK WASHER
(1/4" - BLK) 6PCS 4 ALLEN WRENCH
(M4 x 60mm - BLK) 1PC
Z-B2 (BOX 2) - HARDWARE PACK IS LOCATED IN 205111T (B2)
5FLAT HEAD SCREW
(M4 x 32mm - RBW) 13PCS 9 LOCK WASHER
(1/4" - BLK)
6PAN HEAD SCREW
(M3.5 x 20mm - BLK) 15PCS 10 FLAT WASHER
(1/4"ID x 13mm - BLK)
7SHORT BOLT
(M6 x 35mm - BLK) 1PC 11 SMALL ALLEN
WRENCH
(M4 x 60mm - BLK) 1PC
8LONG BOLT
(M6 x 50mm - BLK) 1PC 12 BIG ALLEN WRENCH (M5 x 65mm - BLK) 1PC
NOTE:
Phillips head screw driver is required in the assembly process; however, manufacturer does not provide this item.
PAGE 3 OF 6
3. Please follow attached instructions in the same sequence as numbered to assure fast & easy assembly.
1. Don’t attempt to repair or modify parts that are broken or defective. Please contact the store
immediately.
ASSEMBLY TIPS:
COASTERFURNITURE.COM
1PC
1PC

ITEM:205111T (B1-B3)
STEP 1
STEP 3 STEP 4
COASTERFURNITURE.COM
PAGE 4 OF 6
ASSEMBLY INSTRUCTIONS
STEP 2
4
2
A
E
12
C
B
J
H
E
H
1
3
D
C
E
C
E
Note : Please take note of the marking
sticker (L&R) on the leg.
**BACK VIEW**
5
11
E
8
RIGHT
LEFT
A
12
2.1
2.2
H

ITEM:205111T (B1-B3)
STEP 5 STEP 6
STEP 7
COASTERFURNITURE.COM
PAGE 5 OF 6
ASSEMBLY INSTRUCTIONS
I
I
I
10
G
6.1
K
5
9
11
E
5
7
6.2
G
I

ITEM:205111T (B1-B3)
ASSEMBLY INSTRUCTIONS
STEP 8
STEP 9
COMPLETE
COASTERFURNITURE.COM
PAGE 6 OF 6
G
6
B
F
F
MARKING LINE
G
HEADBOARD
FOOTBOARD
TIGHTEN THE PANHEAD SCREW (6) BY FOLLOW THE ARROW AS SHOWN
F
MARKING LINE

ITEM:205111T (B1-B3)
Note : Dimension tolerence ± 5%
COASTERFURNITURE.COM
PAGE 6 OF 6
50.20"
78.42"
15.55"
41.54"
42.13"
30.31"
36.42"
5.70"
INNER SIZE: 54.60" x 75.98"
19.88"
75.98"
2.76"
2.76"
30.71"
INNER SIZE OF DRAWER : 3.94"x14.96"x20.11"
