Coaster 603332PP User manual

ASSEMBLY INSTRUCTIONS
COASTER FINE FURNITURE
Fine Furniture for every stage of life
REVISION 0: 04/03/2019
603332PP
Power Loveseat & Power Headrest
PAGE 1 OF 3
COASTERFURNITURE.COM
REVISION 1: 12/30/2019

ITEM :
603332 P P
ASSEMBLY INSTRUCTIONS
ASSEMBLY TIPS:
1.Remove hardware from box and sort by size.
2.Please check to see that all hardware and parts are present prior to start of assembly.
3.Please follow attached instruction in the same sequence as numbered to assure fast & easy assembly.
WARNING!
1.Don't attempt to repair or modify parts that are broken or defective. Please contact the store immediately.
2.This product is for home use only and not intended for commercial establishment.
PARTS IDENTIFICATION
A LEFT BACK 1PC
D BASE 1PC
B RIGHT BACK 1PC
E LEFT ARM 1PC
C MIDDLE BACK 1PC
COASTERFURNITURE .COM
ASSEMBLY TIME 10 MINUTES
PAGE 2 OF 3
F RIGHT ARM 1PC
G POWER CABLE 1PC
HARDWARD PAKAGE
1 BOLT(5/16” x 2”)
1PC SRARE PARTS 5PCS
2 INSERT Spare Parts 2PCS

ITEM :
60333 2PP
ASSEMBLY INSTRUCTIONS
STEP 1
STEP 2
STEP 3
STEP 4
COASTERFURNITURE.COM
PAGE 3 OF 3
950mm(37.5")
1910mm(75'')
1100mm(43.5'')
673mm(26.5'')
540mm(21.5)
533mm(21'')
500mm(20")
650mm(26")
Note : Dimension tolerance ±5%
