Coaster 300007Q User manual

300007Q
QUEEN SIZE BED
ASSEMBLY INSTEUCTIONS
COASTER FINE FURNITURE
2014-5-8
1 OF 4

ITEM: 300007QB1 ASSEMBLY INSTRUCTION
ASSEMBLY TIPS:
1. Remove hardware from box and sort by size.
2. Please check to see that all hardware and parts are present prior to start of
assembly.
3. Please follow attached instructions in the same sequence as numbered to assure
fast & easy assembly.
warning
1. Don't attempt to repair or modify parts that are broken or defective please contact
the store immediately.
2. This product is for home use only and not intended for commercial establishment.
PARTS IDENTIFICATION
Headboard 1PC
A
Headboard
1PC
Wood legs 2 PCS
B
HARDWARE PACKAGE
5*23*67mm Allen wrench 1 PC
Ø5/16 * Ø16 * Ø1.5 mm Flat washer 2 PCS
1
2
HARDWARE
PACKAGE
Long bolt 2 PCS
All above hardware pack is located in 300007Q B1
3
2 OF 4

ITEM: 300007QB2 ASSEMBLY INSTRUCTION
PARTS IDENTIFICATION
Wood legs 2 PCS
B
Bed rail 2 PCS
Footboard 1 PC
C
D
Slat 3 PCS
Support leg 3 PCS
E
F
Q'TY
1 1 PC
Allen wrench 5*23*67mm
DESCRIPTION FIGURE
HARDWARE PACKAGE
2 Flat washer Ø5/16 * Ø16 * Ø1.5 mm 2 PCS
32 PCS
41 PC
5
1PC
Long bolt
Headboard corner bracket - Left (facing)
Headboard corner bracket
-
Right (facing)
5
1
PC
62 PCS
7 18 PCS
8 18 PCS
Short bolt
Headboard
corner
bracket
Right
(facing)
Footboard corner bracket
Flat washer Ø6.5 * Ø19 * Ø2 mm
9 6 PCS
10 1 PC
Wood screw
Allen wrench 4*23*60mm
All above hardware pack is located in 300007Q B2
3 OF 4

S
TEP 1
IT NEEDS TWO PERSONS AND TAKES ABOUT THIRTY MINUTES TO ASSEMBLE
THE ITEM.
STEP
1
STEP 2
Attach the wooden foot(B) to the headboard(A) and footboard(D)
Align and attach the left and right brackets (4 and 5) to the bed rails (C) using flat
washer (7) bolt (8) and tighten with allen wrench (10). Then align and attach the
footboard brackets (6) to the footboard (D) and bed rails (C) using flat washer (7) bolt
(8) and tighten with allen wrench (10). Finally hang the bed rails (C) to the headboard
STEP 3
(A). Now tighten all corner brackets.
Set up support legs on the slats first, then attach slats on the side rails using wood
screw(9) tighten with screw driver (not included) .
4 of 4
