Coaster 300379Q B1 User manual

300379Q (B1 & B2)
QUEEN SIZE BED WITH SOFT PU
ASSEMBLY INSTRUCTIONS
COASTER FINE FURNITURE
www.coastercompany.com
PAGE 1 OF 5 REVISION 0 : 12/06/2012
REVISION 1 : 06/0 /2013

ITEM : 300379Q(B1 & B2) A EMBLY IN TRUCTION
ASSEMBLY TIPS:
1.Remove hardware from box and sort by size.
2.Please check to see that all hardware and parts are present prior to start of assembly.
3.Please follow attached instructions in the same sequence as numbered to assure fast & easy assembly.
Warning!
1. Don't attempt to repair or modify parts that are broken or defective. Please contact the
store immediately.
2. This product is for home use only and not intended for commercial establishment.
PARTS IDENTIFICATION
HARDWARE IDENTIFICATION
www.coastercompany.com
PAGE 2 OF 5
!
A
B
C
D
HEADBOARD
PANEL
FOOTBOARD
PANEL
BED RAIL
CENTER RAIL
1 PC
1 PC
2 PCS
1 PC
E
F
G
H
A
BED SLAT
BED SLAT
SUPPORT
CENTER
SUPPORT
BED LEG
12 PCS
PCS
2 PCS
PCS
1PCS
15
6
7
ALLEN WRENCH
SHORT BOLT
LONG BOLT
SHORT SCREW
LONG SCREW
FLAT WASHER
2
3
LEVELER
1 PC
12 PCS
PCS
26 PCS
16 PCS
8 PCS
PCS
B1(BOX 1 )
B2(BOX 2 )
Z(B2)-BOX 2
HEADBOARD
PANEL

ASSEMBLY INSTRUCTIONS
www.coastercompany.com
PAGE 3 OF 5
ITEM : 300379Q(B1 & B2)
H
A
Lay down the headboard panel on a soft surface.
Align and fasten bed leg to the pre-marking on the
bottom of headboard panel using long screw(as per
diagram shown). Then tighten with screw driver(not
included).
Place footboard panel upside down on a soft
surface. Align and fasten the bed leg to the pre-
marking on the bottom of footboard panel using
long screw (as per diagram shown). Then tighten
with screw driver. (not included).
STEP 3
Align and fasten bed rails to headboard panel and footboard panel using short bolts and flat washer.
Tighten with Allen wrench.
300379Q(B1) – BOX 1 300379Q(B1 & B2) – BOX 1 & BOX 2
B
B
5
5
H
STEP 1 STEP 2

STEP
.1) Align & fasten center support to the center of headboard panel & footboard panel using long bolt.
Tighten with Allen wrench.
.2) Align & fasten center rail onto center support using short screw. Tighten with screw driver
(not included)
.3) Align & fasten leveler to bed slat support by turning leveler clockwise.
. ) Align & fasten bed slat support to center rail using short bolt. Tighten with Allen wrench.
Then adjust leveler to touch the floor
STEP 5
5.1) Align and fasten bed slat to bed rail using short screw. Tighten with screw driver(not included).
5.2) Pull out headboard's hidden night stand & unfold the shelf as per diagram shown.
ITEM : 300379Q(B1 & B2) ASSEMBLY INSTRUCTIONS
Unfold the shelf at
the pre-marking line
www.coastercompany.com
PAGE OF 5
31
G
4

Maintenance Notice:
Back
Headrest
www.coastercompany.com
* When the headrest is st cked while moving:
1 . Slide out half of the drawers. Open the back cover of the headboard which is
secured with velcro tape .
2. Loosen nut from the bolt of headrest with wrench.
3. Fold down the headrest.
PAGE 5 OF 5
4. Tighten the nut with wrench, push back the drawer and close the back cover.
