Coaster 300529KW User manual

300529KW
C KING SIZE BED
2015-6-29
ASSEMBLY INSTRUCTIONS
COASTER FINE FURNITURE
1 OF 4

ITEM: 300529KWB1 ASSEMBLY INSTRUCTION
ASSEMBLY TIPS:
1. Remove hardware from box and sort by size.
2. Please check to see that all hardware and parts are present prior to start of
assembly.
3. Please follow attached instructions in the same sequence as numbered to assure
fast & easy assembly.
warning
1. Don't attempt to repair or modify parts that are broken or defective please contact
the store immediately.
2. This product is for home use only and not intended for commercial establishment.
Headboard 1PC
Wood legs 2 PCS
5*23*67mm Allen wrench 1 PC
Ø5/16 * Ø16 * Ø1.5 mm Flat washer 2 PCS
Long bolt 2 PCS
All above hardware pack is located in 300529KW B1
PARTS IDENTIFICATION
2 OF 4
A
B
1
2
3
HARDWARE PACKAGE

ITEM: 300529KWB2 ASSEMBLY INSTRUCTION
Wood legs 2 PCS
Bed rail 2 PCS
Footboard 1 PC
Slat 5 PCS
Support leg 10 PCS
Q'TY
1 1 PC
2 Flat washer Ø5/16 * Ø16 * Ø1.5 mm 2 PCS
3 2 PCS
4 1 PC
5 1 PC
6 2 PCS
7 18 PCS
8 18 PCS
9 10 PCS
10 1 PC
C
D
3 OF 4
Long bolt
Allen wrench 5*23*67mm
E
F
DESCRIPTION FIGURE
Short bolt
Wood screw
Allen wrench 4*23*60mm
Headboard corner bracket - Left (facing)
Headboard corner bracket - Right (facing)
Footboard corner bracket
Flat washer Ø6.5 * Ø19 * Ø2 mm
All above hardware pack is located in 300529KW B2
PARTS IDENTIFICATION
HARDWARE PACKAGE
B

STEP 1
STEP 2
STEP 3
4 of 4
