Cochlear True Wireless Mini Microphone 2 User manual

1
POCKET GUIDE
COCHLEAR™TRUEWIRELESS™
MINIMICROPHONE2& 2+
Mini Microphone 2 Mini Microphone 2+

2
Welcome to Cochlear™
True Wireless™Technology.
No Strings Attached.
Index
3. Overview
4. Getting Started
5. Product Diagram
6. Pairing
8. Using
11. Care & Maintenance
Visit us online for helpful tips,
how-to videos and more:
www.Cochlear.com/US/N6wireless
Recipients.MyCochlear.com

The Cochlear™Wireless Mini Microphone
2 & 2+ are designed to allow you to
hear better over a distance and in noisy
listening situations, such as:
How to use:
In meetings
When traveling by car, bus or train
Dining at a restaurant
Participating in a class at the gym
Give the Mini Microphone to the person
you want to listen to and ask them to
position it close to their mouth by placing
it vertically on their clothing using the clip
on the back. Then activate streaming on
your CP900 Series Sound Processor.
Place your Mini Microphone on a table
to listen to multiple speakers in a group/
conference setting (2+ only).
3
Up to
82 feet
Mini Microphone Sound Processor
Place vertically 4-16 inches
between mouth and microphone
Mini Microphone 2+
used as a table mic
for group discussions

Getting Started
Charging the battery
Plug one end of the included micro USB
charging cable into the Mini Microphone
and the other into a computer, or into a
power outlet via the supplied adapter.
When the LED indicator on top
of the Mini Microphone turns green
with a red blink every 2 seconds
charging is complete.
Before you use your Mini Microphone
you should allow it to charge for at
least 3 hours, even if the indicator light
shows a full charge. The battery cannot
be overcharged.
Note: On average, the Mini Microphone will
operate for up to 10 hours between charges.
4

5
Product Diagram
Status indicator (LED)
Line input (2+) FM connector (2+)
ON/OFF button
Mute button
Clip
Volume down control
Volume up control
Micro-USB connector
for charging (2)
Micro-USB connector
for charging (2+)

6
Pairing
Follow the four steps below to pair your
Nucleus®6 Sound Processor to the
Cochlear Wireless Mini Microphone
2Press and hold the ON/OFF
button on the Mini Microphone for
2 seconds until the LED turns green,
then release.
Status indicator (LED)
ON/OFF button
1Switch off your CP900 Series
Sound Processor.
Remove the Sound
Processor from your ear.
Disconnect the battery.
Press and hold Kanso
button until the light
is a steady orange.
OR

7
Press the pairing button on the
(A) Mini Microphone 2 or (B) Mini
Microphone 2+ once using the tip
of a pen or similar object.
3
Note: The LED will flash yellow every
2 seconds and the Mini Microphone will
now be in pairing mode for 20 seconds.
Have more than one Wireless Accessory?
Consult the User Guide to pair up to three
devices to your sound processor(s).
Pairing button
A. B.
While pairing mode is active (20
seconds), attach the battery to the
Nucleus 6 Sound Processor (CP910/920)
or Press the button on the Kanso Sound
Processor (CP950) to turn on.
4
A blue indicator light flashes to show that
pairing has been successful.

8
Using
Now that the Cochlear Wireless Mini
Microphone is paired you are ready to
start streaming. There are several ways
to do this.
Start streaming using your
sound processor
1Turn on your sound processor
and Mini Microphone.
Press*and hold the upper
button on your sound processor
for 2 seconds, then release.
The sound processor flashes a
blue light to indicate audio is streaming.
*Not available if sound processor buttons
are in advanced mode.
Press†and hold button for
2 seconds then release to
stream audio.
†Press and release again if
you need to cycle to the next
audio source.This is necessary
if your audiologist enabled
the Telecoil as this is the first
streaming audio source.
OR

9
2To stop streaming.
Tap the upper button.
Tap the button.
Start streaming using your
CR210 Remote Control
1Turn on your sound processor and
Mini Microphone. Turn on your
CR210 Remote Control.
Press and hold the
Telecoil button for 2
seconds, then release.
Audio will start
streaming through the
Mini Microphone.
2To stop streaming.
Tap the Telecoil button.
OR

10
Start streaming using your CR230
Remote Assistant
Method 1: Turn on your sound
processor and Mini Microphone.
Turn on your CR230 Remote Assistant.
From the Home screen, press
the right arrow button until
you see the Stream screen.
Scroll down the list to the
channel you want to use and
press OK.
When your audio device is turned on, audio will
start streaming through the Mini Microphone.
To stop streaming, select Off on the Stream
selection screen.
Method 2: Turn on your sound processor
and Mini Microphone. Turn on your
CR230 Remote Assistant.
Press and holdthe Telecoil button
for 2 seconds, then release.
Audio will start streaming
through the Mini Microphone.
To stop streaming, tap the
Telecoil button.

Care and Maintenance
• Clean the Cochlear Mini Microphone
using a damp cloth. Never use
household cleaning products
(washing powder, soap, etc.)
or alcohol to clean the device.
• When the Cochlear Mini Microphone
is not in use, turn it off and store
it safely.
• Protect the Cochlear Mini
Microphone from excessive moisture
(bathing, swimming) and heat
(radiator, car dashboard).
• Protect it from excessive shock
and vibration.
• Protect the microphone and charger
sockets from debris and dirt.
11
