Cochlear Baha 5 SuperPower User manual

© Cochlear Bone Anchored Solutions ABLimited, 1
Cochlear™Baha® 5
Power Sound Processor
User manual part A
ZONE 3
EN-GB English 3
SV Svenska 17
DA Dansk 31
FI Suomi 45
NO Norsk 59
IS Íslenska 73

1
23 4
5 6
8 10
9
11
1
25
3
4
7
1 2 3
1
6
7
8
2
7
2
12
1 2
1 2

Welcome
Congratulations on your choice of the Cochlear™ Baha®5 Power Sound Processor.
You are now ready to use Cochlear’s highly advanced bone conduction sound
processor, featuring sophisticated signal processing and wireless technology.
This manual is full of tips and advice on how to best use and care for your Baha sound
processor. By reading this manual and then keeping it handy for future reference, you
will ensure that you get the most benefit out of your Baha sound processor.
Key to device
See figure 1
1. Visual indicator
2. Microphones
3. Battery compartment door
4. Tamper proof lock
5. Attachment point for the safety line
6. Volume rocker
7. Program button, Wireless audio
streaming button
8. Plastic snap connector
Note on figures: The figures included
on the cover correspond to information
specific to this model of sound processor.
Please reference the appropriate figure
when reading. The images shown are not
to scale.
Introduction
To ensure optimal performance, your
hearing care professional will fit the sound
processor to suit your needs. Be sure to
discuss any questions or concerns that
you may have regarding your hearing or
use of this system with your hearing care
professional.
Warranty
The warranty does not cover defects or
damage arising from, associated with,
or related to the use of this product with
any non-Cochlear processing unit and/
or any non-Cochlear implant. See the
“Cochlear Baha Global Limited Warranty
card” for more details.
3
English

Contacting Customer Service
We strive to provide you with the best
possible products and services. Your views
and experiences with our products and
services are important to us. If you have
any comments you would like to share,
please contact us.
Customer Service – Cochlear Americas
10350 Park Meadows Drive, Lone Tree
CO 80124, USA
Toll free (North America) 1800 523 5798
Tel: [phone],
Fax: [phone]
E-mail: [e-mail]
Customer Service – Cochlear Europe
6 Dashwood Lang Road, Bourne Business
Park, Addlestone, Surrey KT15 2HJ, United
Kingdom
Tel: [phone],
Fax: [phone]
E-mail: [e-mail]
Customer Service – Cochlear Asia Pacific
1 University Avenue, Macquarie University,
NSW 2109, Australia
Toll free (Australia) 1800 620 929
Toll free (New Zealand) 0800 444 819
Tel: [phone],
Fax: [phone] or
Toll free Fax [phone]
E-mail: [e-mail]
4

Key to symbols
The following symbols will be used
throughout this document. Please refer to
the list below for explanations:
“Caution” or “Caution,
consult accompanying
documents”
ACMA symbol (Australian
Communications and Media
Authority) compliant
Audible signal Temperature limitation
2797
CE mark and Notified Body
number Interference risk
Manufacturer Date of manufacture
Batch Code By prescription
MD
Medical device Bluetooth®
Catalogue number
Refer to instructions/
booklet.
Note: Symbol is blue.
Serial Number Recyclable material
Unique device identifier
Made for iPod, iPhone, iPad
Keep dry Waste of Electrical and
Electronic Equipment
Radio compliance
certification for Korea
Radio compliance
certification for Brasil
Radio compliance
certification for Japan
5
English

On/off
See figure 2
1. To turn on your sound processor close
the battery door completely.
2. To turn off your sound processor
gently open the battery door until you
feel the first “click”.
When your sound processor is turned off
and then back on again, it will return to
Program 1 and default volume level.
Status indicator
See figure 3
Visual indicators and beeps will alert you
of changes to your sound processor.
For a complete overview see the Visual
indicators and beeps chart at the end of
the section.
Change program/streaming
See figure 4
Your sound processor can be fitted with
up to four programs suitable for different
listening environments. The program
button lets you choose from these pre-set
programs and enable/disable wireless
streaming.
• To change program press the program
button located on the top of your
sound processor.
• To activate audio wireless streaming
press and hold the program button.
Press the program button again to
end wireless streaming and return to
the previous program.
If you are a bilateral user, program
changes you make to one device will
automatically apply to the second device.
This function can be enabled or disabled
by your hearing care professional.
NOTE:
You can also change program and
adjust the volume using the optional
Cochlear Baha Remote Control or
Cochlear Wireless Phone Clip or
directly from iPhone, iPad or iPod
touch (see MFi for more information).
Adjust volume
See figure 5
You can adjust the volume level of your
sound processor using the volume
rocker located on the side of the sound
processor.
• To increase the volume, press the top
of the volume rocker.
• To decrease the volume, press the
bottom of the volume rocker.
Keylock
You can use the Keylock function to
prevent inadvertent changes to your
sound processor settings (such as
program choice or volume level). This
function can be enabled or disabled by
your hearing care professional and is
an important feature when the sound
processor is being used by a child.
6

Wireless Accessories
Your sound processor is compatible with
a range of Cochlear Wireless Accessories
that can enhance your listening
experience. Ask your hearing care
professional to learn more about your
options or visit www.cochlear.com.
Flight mode
See figure 6
Wireless functionality must be deactivated
when boarding a flight.
1. To turn on Flight mode first turn off
the sound processor by opening the
battery door.
2. Press and hold the program button
and at the same time, close the
battery door.
To turn off Flight mode simply turn the
sound processor off and back on again.
Made for iPhone (MFi)
Your sound processor is a Made for
iPhone (MFi) hearing device. This allows
you to control your sound processor
and stream audio directly from iPhone,
iPad or iPod touch. For full compatibility
details and more information visit
www.cochlear.com.
1. To pair your sound processor turn
on Bluetooth on your iPhone, iPad or
iPod touch.
2. Turn off your sound processor and go
to Settings > General > Accessibility on
your iPhone, iPad or iPod touch.
3. Turn on your sound processor and
select Hearing Aids in the Accessibility
menu.
4. When displayed, tap on the sound
processor name under “Devices” and
press Pair when prompted.
Talk on the phone
See figure 7
For best results, use a Cochlear Wireless
Phone Clip or stream the conversation
directly from your iPhone. When using
a normal handheld phone, place the
receiver near the microphone inlet of your
sound processor instead of near your
ear. Ensure the receiver does not touch
the sound processor as this may result in
feedback.
7
English

Replace the battery
See figure 8
The visual indicators and beeps will alert
you when there is approximately one hour
of battery power remaining. At this time
you may experience lower amplification.
If the battery runs down completely the
sound processor will stop working.
Use one of the batteries (zinc-air, non-
rechargeable) included in the sound
processor kit as a replacement. The
batteries included in the kit reflect
Cochlear’s latest recommendations.
Contact your hearing care professional for
additional batteries.
1. To replace the battery hold the sound
processor with the front facing up.
2. Gently open the battery door until it is
completely open.
3. Remove the old battery and dispose of
it according to local regulations.
4. Remove the new battery from the
packet and peel away the sticker on
the + side.
5. Insert the battery into the battery
compartment with the + side facing
up.
6. Gently close the battery door.
Tips
• To maximise battery life, switch off the
sound processor when it is not in use.
• Battery life decreases as soon as the
battery is exposed to air (when the
plastic strip is removed) so be sure to
only remove the plastic strip directly
prior to use.
• Battery life depends on daily use,
volume levels, wireless streaming,
sound environment, program setting,
and battery strength.
• If a battery leaks, replace it
immediately.
Lock and unlock the battery door
See figure 9
You can lock the battery door to prevent it
from opening accidentally (tamper-proof).
This is particularly useful to prevent
children, and other recipients in need of
supervision, from accidentally accessing
the battery.
1. To lock the battery door, close the
battery door completely and place the
Locking tool into the battery door slot.
Slide the locking pin up into place.
2. To unlock the battery door, place the
Locking tool into the battery door slot.
Slide the locking pin down into place.
8

WARNING:
Batteries can be harmful if swallowed,
put in the nose or in the ear. Be sure
to keep your batteries out of reach
of small children and other recipients
in need of supervision. Before use,
verify that the battery door is properly
locked. In the event a battery is
accidentally swallowed, or stuck in the
nose or in the ear, seek immediate
medical attention at the nearest
emergency centre.
Attach the Safety line
See figure 10
To use the Safety line, simply attach it to
the sound processor and clip it on to your
shirt or jacket.
Cochlear recommends connecting the
Safety line when engaging in physical
activities. Children should use the Safety
line at all times.
General care
Your sound processor is a delicate
electronic device. Follow these guidelines
to keep it in proper working order:
• Turn off and store the sound
processor free from dust and dirt.
• Remove the battery when storing the
sound processor for long periods.
• Avoid exposing your sound processor
to extreme temperatures.
• Remove your sound processor before
applying hair conditioners, mosquito
repellent or similar products.
• Secure your sound processor with a
Safety line during physical activities. If
the physical activity involves contact,
Cochlear recommends removing your
sound processor.
• Your sound processor is not
waterproof. Do not use it when
swimming and avoid exposing it to
heavy rain
• For cleaning your sound processor
and snap coupling use the
Baha sound processor Cleaning kit.
If the sound processor becomes very
wet
1. Immediately open the battery door
and remove the battery.
2. Put your sound processor in a
container with drying capsules such
as a Dri-Aid Kit. Leave it to dry out
overnight. Drying kits are available
from most hearing care professionals.
9
English

Feedback (whistling) problems
See figure 11
• Check to ensure that your sound
processor is not in contact with items
such as glasses or a hat or in contact
with your head or ear.
• Check that the battery compartment
is closed.
• Check that there is no external
damage to the sound processor.
Contact you hearing care professional if
problems persist.
Share the experience
See figure 12
Family members and friends can “share
the experience” of bone conduction
hearing using the test rod.
1. Turn on your sound processor and
attach it on the test rod by tilting it
into place.
2. Hold the test rod against the skull
bone behind an ear. Plug both ears
and listen.
10
