CoCo TPC-300 User manual

controlled comfort
TPC-300
EL
PT
ES
EN
DE
Quick installation guide
v1.0 Quick installation guide
Schnellinstallationshandbuch
Guía de instalación rápida
Manual de instalação rápida
Οδηγός γρήγορης εγκατάστασης

TPC-300 WIRELESS HOME CONTROL STATION
4
Congratulations on purchasing this COCO product!
To get the most out of your purchase, please take some time to register this product at:
www.coco-technology.com/register/ You will also nd more information, updates and online
support on our website.
EN
Συγχαρητήρια για την αγορά αυτού του προϊόντος COCO!
Για να αξιοποιήσετε στο έπακρο την αγορά σας, αφιερώστε λίγο χρόνο προκειμένου
να καταχωρίσετε αυτό το προϊόν στη διεύθυνση: www.coco-technology.com/register/ Στην
ιστοσελίδα μας θα βρείτε επίσης περισσότερες πληροφορίες, ενημερώσεις και διαδικτυακή
υποστήριξη.
Parabéns por ter adquirido este produto COCO!
Para tirar o máximo partido da sua compra, reserve algum tempo para registar este
produto no site: www.coco-technology.com/register/ Também encontrará mais informações,
actualizações, e assistência online no nosso website.
¡Enhorabuena por comprar este producto COCO!
Para sacar el máximo partido a su compra, por favor registre el producto en:
www.coco-technology.com/register/ También puede encontrar más información, actualizaciones
y apoyo en nuestra página web.
Herzlichen Glückwunsch zum Kauf dieses COCO-Produkts!
Um dieses Produkt optimal benutzen zu können, sollten Sie es unter folgender Adresse
registrieren: www.coco-technology.com/register/ Auf unserer Website nden Sie weitere
Informationen, Updates und Online-Support.
PT
ES
EL
DE

TPC-300 WIRELESS HOME CONTROL STATION
5
D
A
C
B
E
Receivers not included A: LED indicator
B: USB-B connection
C: USB A-B cable
D: Battey compartment
E: USB stick
EN

TPC-300 WIRELESS HOME CONTROL STATION
6
Getting readyGeneral information
1. Insert the USB stick into a USB port of your
computer. Run the installer,‘Setup.exe’, that is
stored on the USB stick. Follow the instructions to
nish installation.
2. Open the battery compartment of the TPC-300
and place two AA batteries in the holder. Please
keep in mind the correct polarity.
3. Connect the TPC-300 to the USB-connection
of a computer. If you are running Windows XP®
or higher, the TPC-300 will automatically be
recognized and after a few seconds the notication
“New hardware is ready to use” will appear.
The TPC-300 is a computer controlled transmitter
with built-in timer with the following capabilities:
• A programmable timer for automatically
activating or deactivating COCO receivers.
• The timer can be synchronized with sunset and
sunrise time settings for numerous cities in
various countries.
• Automatic transition from standard time to
daylight saving time.
• COCO receivers can also be controlled manually,
as long as the TPC-300 is programmed and
connected to a PC with software.
EN

TPC-300 WIRELESS HOME CONTROL STATION
7
COMPATIBILITY
This transmitter works with all COCO receivers.
FUNCTIONALITY
On/o, dim function (only if the receiver is a dimmer),
and timer function.
TECHNICAL SPECIFICATIONS
• Batteries
• RF frequency
• RF range
• Timer function
2x 1,5 Volt AA alkaline
433.92 MHz
Up to 30 m indoor/70 m outdoor (optimal conditions)
yes
INFORMATION
WIRELESS RADIO SIGNAL
• The 433.92 MHz radio signal passes through walls, windows and doors.
• Indoor range: up to 30 m. Outdoor range: up to 70 m. (optimal conditions)
• The range is strongly dependent on local conditions, such as the presence of metals. For example, the thin
metal coating in Low-emissivity (Low-E) glass has a negative impact on the range of radio signals.
• There may be restrictions on the use of this device outside the EU. If applicable, check whether this device
complies with local directives.
EN

TPC-300 WIRELESS HOME CONTROL STATION
8
BATTERIES
Remove the batteries if the product will not be used for
an extended period. Extreme temperatures reduce the
capacity and lifetime of the battery.
Replace the 1,5 Volt AA alkaline batteries when the
transmit indicator no longer lights when sending an ON
or OFF signal.
Do not crush, burn or shred batteries. Dispose of
batteries according to local regulations. Please recycle
when possible. Do not dispose as household waste.
LIFE-SUPPORT
Never use COCO products for life-support systems or
other applications in which equipment malfunctions
can have life-threatening consequences.
INTERFERENCE
All wireless devices may be subject to interference,
which could aect performance. The minimum distance
between 2 receivers should be at least 50 cm.
REPAIRING
Do not attempt to repair this product. There are no
user-serviceable parts inside.
WATER-RESISTANCE
This product is not water-resistant. Keep it dry. Moisture
will corrode the inner electronics.
CLEANING
Use a dry cloth to clean this product. Do not use harsh
chemicals, cleaning solvents, or strong detergents.
HANDLING
Do not drop, knock, or shake the device. Rough
handling can break internal circuit boards and ne
mechanics.
ENVIRONMENT
Do not expose the product to excessive heat or cold,
as it can damage or shorten the life of electronic circuit
boards and batteries.
Read these simple guidelines. Not following them may be dangerous and faulty installation will invalidate any
warranty that may apply to this product.
SAFETY
EN

TPC-300 WIRELESS HOME CONTROL STATION
9
Main menu
The main screen appears when you run the TPC-300 software. If
you use the software for the rst time, there will be no rooms or
devices visible yet.
Add rooms
Use this menu to add a room to your setup. You can add a
maximum of 16 rooms.
Add devices
Use this menu to add devices to your setup. It is possible
to program up to 16 dierent devices (each with their own
receiver) per room.
EN

TPC-300 WIRELESS HOME CONTROL STATION
10
Extra
Use this menu to congure some basic settings of your TPC-300.
For example, you can set your location, send your settings to
the TPC-300, save your settings on your PC or open/switch to
previously saved settings on your PC. If you use receivers with
code wheels, you can activate code wheel support here.
Scenes
Combine dierent commands for dierent receivers in one
scene. For example“Watch a movie”, in which the lights will dim
and the sunblinds will automatically close.
Timer
Program dierent timer settings to automatically activate or
deactivate devices or scenes. It is also possible to program
sunset and sunrise time settings for your place of residence (or
a nearby city)
Main menu controls
Manually control your COCO receivers when theTPC-300 is
connected to a PC.
EN

TPC-300 WIRELESS HOME CONTROL STATION
11
EN

TPC-300 WIRELESS HOME CONTROL STATION
12
Add a room
Before you can program receivers/devices, you need to add a room. Double-click on the black box in the “rooms”
section of the main menu to add a room. You can create 16 dierent rooms.
By double-clicking a black box, you have entered the submenu“rooms”. Here you will see 32 example images of
various rooms.
Single-click on one of the available images to select it, or double-click on an image to replace it by your own
photo (for example a photo of your own living room).
Then, add a room description and press OK to save the room, or press cancel to return to the main menu without
saving any modications. If you want to delete the selected room, press delete.
You can browse through all
available images by clicking
on the small tiles in the top
left corner.
EN

TPC-300 WIRELESS HOME CONTROL STATION
13
EN

TPC-300 WIRELESS HOME CONTROL STATION
14
Add devices
Single-click on one of the available images to select that image, or double-click an image to replace it by your
own photo. Then, select whether the receiver a dimmer (yes or no) and add a device description. When you press
the cancel button, you will return to the main menu without saving any modications.
Depending on the type of receiver, there are now 2 necessary procedures to choose from:
1. Automatic code system receiver
Press learn code. The TPC-300 will start sending signals. Then, activate the learn-mode of a receiver (see manual
of the receiver). The receiver will now automatically receive and store the TPC-300 tranmission code. Press learn
o to stop sending transmission signals. Finally, press OK.
2. Codeswitch receiver
Click cancel to return to the main menu. From the main menu, choose extra, select yes for“code wheels”and
press OK. Then, add a device, select yes for codeswitch receiver and program the matching code (e.g. A-3).
Finally, press OK.
After you have added a room, you can add devices to that room. Double-click on the black box of “devices”in the
main menu, to add a device. A maximum of 16 dierent devices can be programmed, per room.
You can browse through all
available images by clicking
on the small tiles in the top
left corner.
EN

TPC-300 WIRELESS HOME CONTROL STATION
15
EN

TPC-300 WIRELESS HOME CONTROL STATION
16
Main menu: controls
The main screen now shows all the rooms and devices you have added.
Control devices directly with your computer
If you have programmed the receiver(s) correctly (see p. 11), you can select and control each receiver directly from
the main screen:
The dim value and +/- buttons can only be used for dimmer receivers. The dim value button allows you to send a
preset light level (1 to 16) to a dimmer receiver, which enables you to adjust the brightness of a lamp. For regular
receivers, you can use on and o to switch a device on or o.
Use timer settings to carry out commands
There are 2 ways to program commands with a timer:
1. Use the‘timer’menu to add a timer to a single device.
2. Create a scene (= several devices, each with their own command: on/o/dim value) and add a timer to that
scene.
Both options will be explained later on in this manual.
EN

TPC-300 WIRELESS HOME CONTROL STATION
17
EN

TPC-300 WIRELESS HOME CONTROL STATION
18
Extra
From the main menu, choose extra to change the following settings of the TPC-300:
Language
Change the language of the software.
Settings
Click save to save the current settings to the harddisk of your computer. Click load to open previously saved
settings.
Code wheels
Do you have one or more classic receivers with code wheels? Check yes, so you can set the matching code when
adding a device to your conguration. If you only work with automatic receivers, keep the box no checked.
Show hints
If yes is checked, short instruction hints will appear when you hover over an item, button or image.
Location
To use the timer function with sunrise/sunset settings for your geographic location, select the appropriate
country and city.
Send to TPC
Transfer the current settings to the internal memory of the TPC-300, by pressing the button send to TPC. By
sending the settings to the TPC-300, the TPC-300 will carry out all timer programs, even when the device is
disconnected from a PC.
EN

TPC-300 WIRELESS HOME CONTROL STATION
19
EN

TPC-300 WIRELESS HOME CONTROL STATION
20
Scenes
You can combine several devices from various rooms in one scene. A scene, such as“Watch a movie”, can contain
dierent commands for dierent devices, that can be executed simultaneously. For example: close the sunblinds
+ switch o a ceiling fan + dim the lights. By double-clicking on the black box in the scenes overview, you will
open the menu for scene 1, as displayed below.
You can now add a scene description. By
double-clicking on the black box again, you
will enter a menu in which you can select all
previously added rooms and devices.
As mentioned earlier, you can combine multiple
devices from multiple rooms into one scene.
You can program up to 16 dierent scenes.
EN
