Cole Parmer StableTemp 03405-00 User manual

StableTemp®Hotplates, Stirrers
and Stirring Hotplates
OPERATION MANUAL
AND PARTS LIST
Hotplates:
Catalog # Size Voltage Top Plate Material
03405-00 4x4 120 Ceramic
03405-05 4x4 240 Ceramic
03405-10 7x7 120 Ceramic
03405-15 7x7 240 Ceramic
03405-20 7x7 120 Aluminum
03405-25 7x7 240 Aluminum
03405-30 10x10 120 Ceramic
03405-35 10x10 240 Ceramic
Stirrers:
Catalog # Size Voltage Top Plate Material
03406-00 4x4 120 Ceramic
03406-05 4x4 240 Ceramic
03406-10 7x7 120 Ceramic
03406-15 7x7 240 Ceramic
03406-20 7x7 120 Aluminum
03406-25 7x7 240 Aluminum
03406-30 10x10 120 Ceramic
03406-35 10x10 240 Ceramic
Stirring Hotplates:
Catalog # Size Voltage Top Plate Material
03407-00 4x4 120 Ceramic
03407-05 4x4 240 Ceramic
03407-20 7x7 120 Aluminum
03407-10 7x7 120 Ceramic
03407-25 7x7 240 Aluminum
03407-15 7x7 240 Ceramic
03407-30 10x10 120 Ceramic
03407-35 10x10 240 Ceramic
LT1921X1 • 3/26/07

Safety Information ..............................................................................................................................................3
Warnings ......................................................................................................................................................3
Specifications ......................................................................................................................................................5
Environmental Conditions ............................................................................................................................6
Declaration of Conformity..............................................................................................................................6
Unpacking and Installation ..................................................................................................................................7
General Usage ..............................................................................................................................................7
Unpacking ....................................................................................................................................................7
Installation ....................................................................................................................................................7
Operation ............................................................................................................................................................8
Setting the Stirring Speed ............................................................................................................................8
Setting the Temperature................................................................................................................................8
Maintenance and Troubleshooting ......................................................................................................................9
General Cleaning Instructions ......................................................................................................................9
Error Codes ..................................................................................................................................................9
Replacement Parts............................................................................................................................................10
Warranty ............................................................................................................................................................11
2
Table of Contents

Your Cole-Parmer StableTemp Hotplate, Stirrer or
Stirring Hotplate has been designed with function, reli-
ability, and safety in mind. It is your responsibility to
install it in conformance with local electrical codes. For
safe operation, please pay attention to the alert signals
throughout the manual.
This manual contains important operating and safety
information. The user must carefully read and under-
stand the contents of this manual prior to the use of
this equipment.
Warnings
To avoid electrical shock, always:
1. Use a properly grounded electrical outlet of
correct voltage and current handling capacity.
2. Disconnect from the power supply prior to
maintenance and servicing.
To avoid personal injury:
1. Do not use in the presence of flammable or
combustible materials — fire or explosion
may result. This device contains components
which may ignite such materials. Not rated
for use in hazardous atmospheres.
2. Use caution when heating volatile materials;
top surface and element can reach the “Flash
Point Temperature” of many chemicals.
These stirring hotplates are not explosion
proof. Fire or explosion may result. Unit con-
tains components which may ignite such
materials.
3. Keep top surface clean. Use a non-abrasive
cleaner. Alkali spills, hydrofluoric acid spills or
phosphoric acid spills may damage top and
lead to thermal failure. Unplug unit and
remove spills promptly. Do not immerse unit
for cleaning.
4. Replace the top immediately if damaged by
etching, scratching or chipping. A damaged
top can break in use.
3
Safety Information
Warning
Warnings alert you to a possibility of
personal injury.
Alert Signals

5. Do not use metal foil on hotplate which may
block air flow. Overheating will result.
6. Check and tighten the removable cord periodi-
cally making sure it is secure. If loosened, the
cord could become hot and/or spark and be a
potential fire hazard. If cord appears damaged,
replace immediately.
7. Do not remove or modify grounded power plug.
Use only properly grounded outlets to avoid
shock hazard.
8. Use appropriate hand and eye protection when
handling hazardous chemicals.
9. Gross weight of items placed on top of stirring
hotplates should not exceed 35 lbs. (15.9 kg.)
on the 10” x 10” models, 25 lbs. (11.3 kg) on the
7” x 7” models, and 15 lbs. (6.8 kg.) on the 4” x
4” models.
10. The top plate of the unit can remain hot for
some time after use. A “CAUTION - HOT TOP”
light will remain on until top plate temperature
cools to below 50°C.
11. Note that the exterior housing will be hot during
and for a period of time after use.
12. Refer servicing to qualified personnel.
4
SAFETY INFORMATION

5
Specifications
Electrical Temperature Speed Top Plate
Catalog # (Volts/Amps/Watts/Freq./Phase) Range Range Capacity
Hotplates:
03405-00 120/3.2/385/60/1 5-540°C N/A 1L flask - 15 lbs.
03405-05 230/1.7/420/50-60/1 5-540°C N/A 1L flask - 15 lbs.
03405-10 120/8.8/1060/60/1 5-540°C N/A 4L flask - 25 lbs.
03405-15 230/4.8/1150/50-60/1 5-540°C N/A 4L flask - 25 lbs.
03405-20 120/5.5/660/60/1 5-300°C N/A 4L flask - 25 lbs.
03405-25 230/2.9/690/50-60/1 5-300°C N/A 4L flask - 25 lbs.
03405-30 120/11.7/1410/60/1 5-400°C N/A 6L flask - 35 lbs.
03405-35 230/6.4/1530/50-60/1 5-400°C N/A 6L flask - 35 lbs.
Stirrers:
03406-00 120/0.37/20/60/1 N/A 60-1200 1L flask - 15 lbs.
03406-05 230/0.17/20/50-60/1 N/A 60-1200 1L flask - 15 lbs.
03406-10 120/.037/20/60/1 N/A 60-1200 4L flask - 25 lbs.
03406-15 230/0.17/20/60/1 N/A 60-1200 4L flask - 25 lbs.
03406-20 120/0.5/35/60/1 N/A 60-1200 4L flask - 25 lbs.
03406-25 230/0.3/35/50-60/1 N/A 60-1200 4L flask - 25 lbs.
03406-30 120/0.37/20/60/1 N/A 60-1200 6L flask - 35 lbs.
03406-35 230/0.17/20/50-60/1 N/A 60-1200 6L flask - 35 lbs.
Stirring Hotplates:
03407-00 120/3.3/395/60/1 5-540°C 60-1200 1L flask - 15 lbs.
03407-05 230/1.8/440/50-60/1 5-540°C 60-1200 1L flask - 15 lbs.
03407-10 120/8.9/1070/60/1 5-540°C 60-1200 4L flask - 25 lbs.
03407-15 230/4.9/1170/50-60/1 5-540°C 60-1200 4L flask - 25 lbs.
03407-20 120/5.7/680/60/1 5-300°C 60-1200 4L flask - 25 lbs.
03407-25 230/3.0/720/50-60/1 5-300°C 60-1200 4L flask - 25 lbs.
03407-30 120/12/1440/60/1 5-400°C 60-1200 6L flask - 35 lbs.
03407-35 230/6.5/1550/50-60/1 5-400°C 60-1200 6L flask - 35 lbs.
* This stirring hotplate does not cool. The minimum temperature is 5°C if used in a cold room.

6
Environmental Conditions
Operating: 17°C to 27°C; 20% to 80% relative humidity, non-condensing. Installation category II
(overvoltage) in accordance with IEC 664. Pollution degree 2 in accordance with IEC 664.
Altitude Limit: 2,000 meters.
Storage: -25°C to 65°C
10% to 85% relative humidity
Declaration of Conformity
(for 230 volt)
We hereby declare under our sole responsibility that this product conforms with the technical requirements of
the following standards:
EMC: EN 61000-3-2 Limits for harmonic current emissions
EN 61000-3-3 Limits for voltage fluctuations and flicker
EN 61326-1 Electrical equipment for measurement, control, and laboratory use;
Part l: General Requirements
Safety: EN 61010-1 Safety requirements for electrical equipment for measurement,
control, and laboratory use; Part I: General Requirements
EN 61010-2-010 Part II: Particular requirements for laboratory equipment for the
heating of materials (Hotplates and Stirring Hotplates)
EN 61010-2-051 Part II: Particular requirements for laboratory equipment for mixing
and stirring (Stirrers and Stirring Hotplates)
per the provisions of the Electromagnetic Compatibility Directive 89/336/EEC, as amended by 92/31/EEC and
93/68/EEC, and per the provisions of the Low Voltage Directive 73/23/EEC, as amended by 93/68/EEC.
The authorized representative located within the European Community is:
Thermo Fisher Scientific
419 Sutton Road
Southend On Sea
Essex SS2 5PH
United Kingdom
Copies of the Declaration of Conformity are available upon request.
SPECIFICATIONS

General Usage
Do not use this product for anything other than its
intended usage.
Unpacking
Remove your hotplate, stirrer or stirring hotplate from
the carton. Inspect to ensure that the unit has not been
damaged during shipment. If the unit appears to have
sustained shipping damage contact Cole-Parmer
Customer Service at 800-323-4340.
The following items are included in the shipment:
Hotplate, Stirrer or Stirring Hotplate
Cord
Stir Bar (Stirring models only)
Knob
Operator’s Manual
Installation
Set the unit on a flat stable surface at least 12" away
from combustible materials, and plug the cordset into a
properly grounded electrical outlet of correct voltage
and current handling capacity.
7
Unpacking and Installation
Warning
Use a properly grounded electrical
outlet of correct voltage and current
handling capacity.

8
Setting the Stirring Speed
To set the speed, turn the STIR knob to the desired
setting. Turn the knob clockwise to increase the speed
or counter-clockwise to decrease the speed. To discon-
tinue stirring, turn knob counter-clockwise to OFF.
Setting the Temperature
To set the temperature, turn the HEAT knob to the
desired setting. Turn the knob clockwise to increase
the temperature or counter-clockwise to decrease the
temperature. To discontinue heating, turn knob count-
er-clockwise to OFF.
The temperature will display in °C. When choosing a
setpoint, the display will indicate the setpoint for 5 sec-
onds, after which the display will flash until the desired
setpoint is reached.
The “CAUTION - HOT TOP” indicator illuminates when
the plate reaches 50°C. When the heating is turned off,
the indicator will continue to flash until the plate tem-
perature drops below 50°C.
Operation
Warning
Use caution when heating volatile
materials; top surface and element
can reach the “Flash Point
Temperature” of many chemicals.
These hotplates and stirring hotplates
are not explosion proof. Fire or explo-
sion may result. Unit contains compo-
nents which may ignite such materials.
Use appropriate hand and eye protec-
tion when handling hazardous chemi-
cals.
“Caution: Hot Top. Avoid Contact.” The
top plate of the unit can remain hot for
some time after use. A “CAUTION -
HOT TOP” light will remain on until top
plate temperature cools to below
50°C.

9
General Cleaning Instructions
Wipe exterior surfaces with lightly dampened cloth containing mild soap solution.
Error Codes - Hotplates and Stirring Hotplates only
The following errors should not be addressed by the user. If any of the errors appear, contact Cole-Parmer
Technical Service at 800-323-4340.
Displayed Message Intended to Detect Cause Solution
E01 Thermocouple Thermocouple not connected. Replace element
Call Tech. Service out of range. assembly (attached to
thermocouple).
Thermocouple open circuit.
E02 Excessive heat-up time. Thermocouple short circuit. Remove short.
Call Tech. Service
Failure of element. Replace element
assembly (attached to
thermocouple).
Failure of element circuit. Replace Element.
Replace Control Board.
E11 Alternating current Failure to detect alternating Replace Control Board.
Call Tech. Service measurement failure. current.
E12 Motor system failure. Locked rotor condition. Free locked rotor.
Call Tech. Service
Failure of motor. Replace motor.
Failure of motor circuit. Replace Control Board.
Failure of motor sensor. Replace motor sensor.
Notes:
Errors E01 and E02 are heating errors. Heating functions will be locked out. Stirring functionality is unaffect-
ed.
Maintenance and Troubleshooting

10
Replacement Parts
4x4 Ceramic 7x7 Ceramic 7x7 Aluminum 10x10 Ceramic
Part No. Part No. Part No. Part No. Description
261575 261575 261575 261575 PC Board Fuse - 220-240V
PCX118 PCX118 PC1895X1 PC1886X1 Control Board - 120V (SHP)
PCX119 PCX119 PC1895X2 PC1886x2 Control Board - 220-240V (SHP)
PC1887X1 PC1887X1 PC1893X1 PC1884X1 Control Board - 120V (HP)
PC1887X2 PC1887X2 PC1893X2 PC1884X2 Control Board - 220-240V (HP)
PC1888X1 PC1888X1 PC1888X1 PC1885X1 Control Board - 120V (S)
PC1888X2 PC1888X2 PC1888X2 PC1885X2 Control Board - 220-240V (S)
266058 266058 266058 266058 PC Board Fuse - 120V
PCX113 PCX113 PCX113 PCX113 Display Board
PC1363X3 PC1363X3 PC1363X3 PC1363X3 Speed/Heat Adjustment Board (2)
KBX111 KBX111 KBX111 KBX111 Knob (2)
CRX106 CRX106 CRX106 CRX106 Cord Set - 120V
CRX104 CRX104 CRX104 CRX104 Cord Set - 220-240V
KBX78 KBX78 KBX78 KBX78 Knob
ZSX122A ZSX65A ZSX65A ZSX65A Stir Bar
MT1313X3 MT1313X3 MT1313X3 MT1316X3 Motor - 120V
MT1313X4 MT1313X4 MT1313X4 MT1316X4 Motor - 220-240V
ELX41 ELX44 ELX77 ELX47 Heating Element - 120V - w/thermocouple
ELX43 ELX46 ELX79 ELX49 Heating Element - 220-240V - w/thermocouple
540-0033 710-0117 CT1420X1 719-0073 Ceramic or Aluminum Top
EL1310X1 EL1313X1 EL1895X1 EL1316X1 Hot Plate Top Assembly - 120V
EL1310X3 EL1313X3 EL1895X3 EL1316X3 Hot Plate Top Assembly - 220-240V
---- ----- TC1895X1 ----- Thermocouple

11
Warranty
625 East Bunker Court
Vernon Hills, IL 60061-9872
1-800-323-4340
1-847-549-7600
www.coleparmer.com
Cole-Parmer Company warrants to the direct purchaser that the representation made accurately reflect the
manufacturer’s representations. To the extent permissible, we will make available to its direct purchaser the
manufacturer’s warranty.
The Company agrees, at its election, to correct by repair, by replacement, or by credit to purchaser, any
defect of material or workmanship which develops within two years after delivery of the product to the original
purchaser by the Company or by an authorized dealer of the Company provided that investigation or factory
inspection by the Company discloses that such defect developed under normal and proper use.
The warranty is limited to the country in which the product is sold.
