Coleman 4348 series User manual

Fig. 10

Fig. 9

Carefully read all instructions before use and save for future reference.

TO CHARGE BATTERY

When the battery is fully discharged, it will take 16 to 18 hours to fully recharge. To obtain

maximum performance, charge for 18 hours for the first three cycles. Always charge the battery

immediately after use whenever possible. Charge indoors using household source. On a full

charge, the continuous run time is up to 6 hours. Total run time will increase if the unit is turned

on and off intermittently.

Do not leave the table lamp turned on after the battery has stopped, as overdischarging the battery

can cause problems in recharging the battery to a full charge. If this does occur, immediately switch

the table lamp off and recharge for 40 hours. After an extended period of storage (more than 6

months), recharge for the full 16 hours or more.

The 120-volt AC adaptor is stored inside the base of the unit. There is a small door that is accessible

on bottom of base. To open, push in on the tab and lift door. (Fig. 1)

To recharge battery, plug the “L” shaped end on the plug into the AC jack located on the botton of the

table lamp base (Fig. 2) and then plug the AC adaptor into a 120-volt wall outlet (Fig. 3).

This table lamp is equipped with a charging light feature. While charging, light will glow “red”. When

light turns to “green” the Table lamp is fully charged.

NOTE: The switch must be turned to the “OFF”

position while charging (Fig. 5). Light will not operate

when plugged into AC wall outlet.

TO CHANGE FLUORESCENT TUBE (continued)

3. Lift up on fluorescent tube to remove. (Fig. 8)

4. Insert new fluorescent tube.

5. Insert locking slots on edges of top cover into tabs on edges

of lighting cavity and turn clockwise to lock. (Fig. 7)

NOTE: Grasp handle as shown in Fig. 7 to prevent damage to the

lamp when removing top.

OPERATING INSTRUCTIONS FOR REMOTE CONTROL

NOTE: Remote transmitter is stored on bottom of lamp base.

1. To operate table lamp with remote control, move switch

ON BASE to the “REMOTE” SETTING. (Fig. 9)

2. Press button on transmitter to turn lamp “ON”. Press

a second tine to turn table lamp “OFF”.

3. To change battery in remote, remove 3 screws from

back of transmitter and install new 12v, 23AE alkaline

battery. (Fig. 10)

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This

device may not cause harmful interference, and (2) This device must accept any interference received, including

interference that may cause undesired operation.

Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance

could void the user’s authority to operate this equipment.

However, there is no guarantee that interference will not occur in a particular installation. If this equipment does

cause harmful interference to radio or television reception, which can be determined by turning the equipment off

and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that which the receiver is needed.

• Consult the dealer or an experienced radio/TV technician for help.

NAM

C ® NA

LOC

ELB

OIT

P ®

RECHARGEABLE

PATIO & TABLE LAMP

How to Use and Enjoy Your Coleman

Model 4348 Series

Modèle de la série 4348

RECHARGEABLE BATTERY MUST BE RECYCLED OR DISPOSED OF PROPERLY.

See recyling information that came with your Coleman Battery Table Lamp.

Fig. 4

Charging Light

12/2006 Rev

For products purchased in Canada:

Sunbeam Corporation (Canada) Limited

DBA Jarden Consumer Solutions

5975 Falbourne Street

Mississauga, Ontario, Canada L5R 3V8

5-Year Limited Warranty

The Coleman Company, Inc. (“Coleman”) warrants that for a period of five years from the date of original retail purchase,

this product will be free from defects in material and workmanship. Coleman, at its option, will repair or replace this productor

any component of the product found to be defective during the warranty period. Replacement will be made with a new or

remanufactured product or component. If the product is no longer available, replacement may be made with a similar product

of equal or greater value. No warranty is provided for batteries and light bulbs. This is your exclusive warranty.

This warranty is valid for the original retail purchaser from the date of initial retail purchase and is not transferable. Keepthe

original sales receipt. Proof of purchase is required to obtain warranty performance. Coleman dealers, service centers or retail

stores selling Coleman

® products do not have the right to alter, modify or in any way change the terms and conditions of this

warranty.

What This Warranty Does Not Cover

This warranty does not cover normal wear of parts, parts that are not genuine Coleman

® parts, or damage resulting from any

of the following: negligent use or misuse of the product; use on improper voltage or current; commercial use of the product;

use contrary to the operating instructions or disassembly, repair or alteration by anyone other than Coleman or an authorized

service center. Further, the warranty does not cover Acts of God, such as fire, flood, hurricanes and tornadoes. Warranty voidif

damage to product results from the use of a part other than a genuine Coleman

® part.

COLEMAN SHALL NOT BE LIABLE FOR DEFECTS THAT ARE CAUSED BY THE USE OF UNAUTHORIZED PARTS OR

SERVICE. COLEMAN SHALL NOT BE LIABLE FOR ANY INCIDENTAL OR CONSEQUENTIAL DAMAGES CAUSED BY THE

BREACH OF ANY EXPRESS OR IMPLIED WARRANTY OR CONDITIONS. EXCEPT TO THE EXTENT PROHIBITED BY

APPLICABLE LAW, ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE IS

LIMITED IN DURATION TO THE DURATION OF THE ABOVE WARRANTY OR CONDITIONS. SOME STATES, PROVINCES,

OR JURISDICTIONS DO NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES

OR LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY LASTS, SO THE ABOVE LIMITATIONS OR EXCLUSION MAY

NOT APPLY TO YOU. THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, AND YOU MAY ALSO HAVE OTHER

RIGHTS THAT VARY FROM STATE TO STATE OR PROVINCE TO PROVINCE.

How to Obtain Warranty Service

Take the product to an authorized Coleman service center.

You can find the nearest authorized Coleman service center by visiting www.coleman.com or calling 1-800-835-3278 or

TDD 316-832-8707 in the United States or 1 800 387-6161 in Canada. If a service center is not conveniently located, attach to

the product a tag that includes your name, address, daytime telephone number and description of the problem. Include a copy

of the original sales receipt. Carefully package the product and send either by courier or insured mail with shipping and

insurance prepaid to:

For products purchased in the United States:

The Coleman Company, Inc.

3600 North Hydraulic

Wichita, KS 67219

The costs of transporting the product to Coleman or an authorized service center for warranty service is the responsibility of

the purchaser.

DO NOT RETURN THIS PRODUCT TO THE PLACE OF PURCHASE.

If you have any questions regarding this warranty please call 1-800-835-3278 or

TDD 316-832-8707 in the United States or 1 800 387-6161 in Canada.

Coleman

, , and are registered trademarks of The Coleman Company, Inc.

AME

C ® N

TEE

ARR

MAL

LBA

&OI

P ®

Fig. 3

Fig. 2

Fig. 1

Fig. 5

TO CHANGE FLUORESCENT TUBE

NOTE: This lantern uses a 9-watt Fluorescent U-Tube

(See Parts List for replacement #).

1. Make sure lantern is in “OFF” position. (Fig. 6)

2. With table lamp in normal upright position, remove

top cover by lifting up the handle and turning top

counterclockwise to loosen. (Fig. 7)

NOTE: Grasp handle as shown in Fig. 7 to prevent

damage to the lamp when removing top.

OPEN

Fig. 7

Fig. 6

Fig. 8

Locking Slot

Cavity Tabs

THINGS YOU SHOULD KNOW

1. Operating time for this lamp depends on whether it is run continuously or intermittently.

Intermittent operation extends the run time.

2. In cold temperatures, the fluorescent tube is more difficult to light and may be dim until it

warms up. Below 20°F (-7°C), the tube may not light.

3. When the fluorescent tube is not lit to full brilliance, the battery should be charged. If this is

not done and table lamp is used, the tube will become blackened.

4. To clean the outside of the table lamp globe, use only a damp cloth and mild dishwashing

liquid. Avoid excessive water and strong cleaner which can damage lamp.

5. The battery used in this unit is a high quality, sealed lead-acid 6V 4.5AH rechargeable battery.

This battery should never leak acid or corrosive materials. It is designed for slower drain and

longer operating time.

RECHARGEABLE

POUR TERRASSE ET TABLE

Profitez au maximum de votre lampe Coleman

4348-700.qxd 12/13/06 11:11 AM Page 1

This device complies with Part 18 of the FCC Rules.

Note: This product may cause interference to radio equipment and should not be installed near maritime safety

NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15

of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential

installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in

accordance with the instructions, may cause harmful interference to radio communications.

communications equipment or other critical navigation or communication equipment operating between 0.45-30 MHz.

The Responsible Party information as below:

• Applicant name in full: The Coleman Company, Inc.

• Address: 3600 N. Hydraulic, Wichita, KS 67219

• Contact in USA: Rex Weigand / Director of Product Safety & Compliance

• Phone: (316) 832-3056

• Fax: (316) 832-6193

• Email address: [email protected]
