Coleman 2000005512 Manual

STITCH LINE
TENT SETUP INSTRUCTIONS
MODEL 2000005512
Before you begin
Read all instructions before set up.
• Select a level site clear of rocks, branches, and other hard or
sharp objects, to install your tent.
WARNING: Keep clear of overhead power lines.
• Do not set up your tent under trees because of potential
lightning strikes or falling tree limbs in inclement weather.
• Secure with all stakes and guylines provided to prevent property
damage or personal injury.
• For best results in windy conditions, position narrow end of tent
into the wind.
• Do not drop tent.
• Do not bounce tent bag on its end to remove tent, as these
actions may damage the frame.
• THIS RECREATIONAL PRODUCT REQUIRES A MINIMUM OF TWO
PEOPLE TO ASSEMBLE.
• Under no circumstances should this product be used to cover
automobiles, marine products or similar items.
CAUTION: Avoid pinch points when opening and closing the
tent frame.
(continued on other side)
Extend the Tent Frame
Raise the Tent
• Stand the tent upright with the hub assembly at the top. (Fig. 1)
• Unfold the arms of the tent downward until they lay flat on the
ground. (Fig. 2)
• Unfold the arm joints located at each of the tent corners. The
tent will raise as the leg poles are extended. (Fig. 3 and 4)
• Extend each of the telescoping leg poles until they snap into
place. (Fig. 5 and 6)
1
2
Fig. 1
Fig. 5
Fig. 2
Fig. 3
3
Verify Connections
between Tent and
Frame Poles
Fig. 7
Fig. 6
• Verify the clips along the edges of the tent are properly attached to the
frame poles. (Fig. 7 and Fig. 8)
Fig. 4
Clip Pole
Fig. 8

STITCH LINE
4010007533 (20091204)
1. All stakes must be placed in the storage bag to prevent damage
to the fabric items placed in the carry case.
2. Make sure all components are clean and dry before placing in
carry case.
3. Store in a clean, dry area.
7
To Store
Things You Should Know:
• Under certain conditions (cold weather, high humidity, etc.)
condensation will form on the inside of your shelter. Condensation
is caused by water vapor from your breath, perspiration, or any wet
clothing inside the shelter. It is NOT LEAKAGE through the shelter fabric.
• Tree limbs, tree sap, bird droppings, or moisture steadily dripping
off tree limbs can cause damage to the shelter fabric and its coating
resulting in leaks or loss of flame-resistant properties.
• Never store tent, even for a short period of time, without drying it
thoroughly and brushing off caked dirt. Do not pack stakes inside your
tent. Use a separate storage bag.
• Stakes should be removed by pulling on the stake itself. NEVER
PULL ON THE TENT TO REMOVE STAKES AS THIS COULD RESULT IN
PROPERTY DAMAGE OR PERSONAL INJURY.
• Do not leave your tent set-up for weeks at a time. Be aware that
exposure to ultraviolet rays from the sun can seriously damage material
and/or cause it to become discolored.
• This product is not intended to be used during heavy rain, wind, hail,
snow or other inclement weather. Excess water build-up can cause
the frame system to be come unstable, and possibly collapse, causing
injury.
Disassembly
To take down the tent, follow the previous steps and illustrations
in the reverse order:
• Remove guylines and stakes. (Fig. 10 and 9)
• Lower the frame one leg pole at a time by pushing the lock
buttons and collapsing the telescoping leg poles. (Fig. 6)
• Fold the arm joints located at each of the tent corners. (Fig. 4)
• Collapse the tent by folding the arms upward until the tent
stands upright with the hub assembly at the top. (Fig. 2 and 1)
• Place the tent in the carry bag for storage.
TIP: After collapsing the tent, place it on its side, then roll it
multiple times with pressure to reduce its size. This will allow
the unit to slip into the carry bag.
6
The Coleman Company, Inc. • 3600 North Hydraulic • Wichita, Kansas 67219
1-800-835-3278 in the United States • www.coleman.com
MADE IN CHINA • PRINTED IN CHINA
© 2009 The Coleman Company, Inc. All rights reserved.
Coleman®, , and are registered trademarks of The Coleman Company, Inc.
This tent meets the flammability requirements of CPAI-84. The fabric
may burn if left in continuous contact with any flame source. The
application of any foreign substance to the tent fabric may render the
flame-resistant properties ineffective.
WARNING: Keep all flame and heat sources away
from this tent fabric.
• The tent should be taken down and placed in storage during windy
conditions to avoid damage to product or personal injury.
• DO NOT use gas or flame sources under or near this product.
Guyline
Stake
Fig. 10
Secure the Guylines
• Attach and stake out guylines. (Fig. 10)
• Adjust sliders to make guylines tight.
5
Stake the Tent
• Secure tent by driving stakes through the webbing loops sewn
to the tent base. (Fig. 9)
• Keep the floor taut.
4
Fig. 9
Tent
Stake
Webbing Loop
