Color imagination ProFollow 330 User manual

User Manual
KEEP THIS MANUAL FOR FUTURE NEEDS
tc100°C
LED 0.2m ta40°C
SI-181
ProFollow 330
ADD 3rd Floor, No. 288, Guangzhu East Line, Pingwen, Lanhe Town,
Nansha District,Guangzhou, China
Tel. [phone]
Fax [phone]
E-mail [e-mail]
Website www.color-imagination.com
www.facebook.com/color.imagination.1
www.youtube.com/user/colorimaginationj
twitter.com/colorimaginej
Follow
us on

.01.
If the device has been exposed to temperature changes due to environmental changes,
do not switch it on immediately. The arising condensation could damage the device.
Leave the device switched off until it has reached room temperature.
This device falls under protection-class I. Therefore it is essential that the device be
earthed.
The electric connection must carry out by qualified person.
The device shall only be used with rate voltage and frequency.
Make sure that the available voltage is not higher than stated at the end of this manual.
Make sure the power cord is never crimped or damaged by sharp edges. If this would
be the case, replacement of the cable must be done by an authorized dealer.
Always disconnect from the mains, when the device is not in use or before cleaning it.
Only handle the power cord by the plug. Never pull out the plug by tugging the power
cord.
During initial start-up some smoke or smell may arise. This is a normal process and
does not necessarily mean that the device is defective, it should decrease gradually.
Please don't project the beam onto combustible substances.
Fixtures cannot be installed on combustible substances, keep more than 50cm
distance with wall for smooth air flow, so there should be no shelter for fans and
ventilation for heat radiation.
If the external flexible cable or cord of this luminaire is damaged, it shall be exclusively
replaced by the manufacturer or his service agent or a similar qualified person in order
to avoid a hazard.
This device has left the factory in perfect condition. In order to maintain this
condition and to ensure a safe operation, it is absolutely necessary for the user to
follow the safety instructions and warning notes written in this user manual.
CAUTION
Becareful with your operations.With a dangerous voltage you cansuffer a
dangerous electric shock when touching wires!
IMPORTANT
Damages caused by the disregard of this user manual are not subject to warranty.
The dealer will not accept liability for any resulting defects or problems.
SAFETY INSTRUCTIONS
1
.03.
2
The ProFollow 330 is a professional high output long throw follow spot featuring the
included OSRAM SIRIUS 330W 7000K lamp, 1500 hours average lamp life, 15000
total lumens, 13000LUX@15m (4°) and high CRI(Ra≧86). The functions include 4°-
8°manual zoom, 5 dichroic colors plus white, mechanical dimming, manual focus,
IRIS and shutter. The fixture will come with a pro stand with 60° manually adjusting
angle. The optimum throw range is 15m-50m.
The ProFollow 330 is applicable for large scale live concert, theatre, TV studio, high
end wedding, etc.
INTRODUCE
Features
1*OSRAM SIRIUS 330W 7000K lamp
1500 Hours average lamp life and low power consumption (Lamp life may vary
depending on several factors including but not limited to: environmental conditions,
power/voltage, usage patterns (On-Off cycling), control, and dimming)
15000 Total lumens, 13000LUX@15m/4°
Color Rendering Index(CRI): Ra≥86
Optimized high definition optical system for improved photometric performance
and field uniformity
Projector-quality, high contrast aspheric lens
Manual zoom system from 4°-8°
Flat and even spot image
Smooth manual focus system with focus knob at the side
Beam edge continually adjustable hard-to-soft
Smooth and precise manual mechanical dimming
Friendly manual IRIS system
Manual shutter system
Color changer with 5 dichroic colors plus white (not including color filters)
3200K-6500K Color temperature adjustment
2” TFT LCD display to show usage time, lamp replacement warning, language
selection, full power/half power usage information
Highly efficient low noise multi-zone cooling of lamp house and oversized lamp
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
FEATURES & SPECIFICATIONS
3
.02.

holder heat-sinks for maximum reliability and durability
• Strong sheet metal construction for durability
• Friendly wrap-around handle with comfort, safety and practicality from all
operating positions
• Moving parts on top for easy access to all parts for cleaning and maintenance
• Fast locking parts for easy lamp assembly and replacement
• Pro stand included, with 60° manually adjusting angle and height adjustable
• Power switch available with fuse
• -20-45℃ Max ambient temperature
• IP20 protection rating
Specifications
Input Voltage:
LED Quantities:
Power Consumption:
Dimensions:
Packing Dimensions:
Net Weight:
AC90-240V 50/60Hz
1*OSRAM SIRIUS 330W 7000K lamp
2500W
840(D)*336(W)*212(H)mm
1150(D)*580(W)*550(H)mm
15kg
The following points have to be considered during the inspection:
1) All screws for installing the devices or parts of the device have to be tightly
connected and must not be corroded.
2) There must not be any deformations on the housing, color lenses, fixations and
installation spots (ceiling, suspension, trussing).
3) Mechanically moved parts must not show any traces of wearing and must not
rotate with unbalances.
4) The electric power supply cables must not show any damage, material fatigue or
sediments.
Further instructions depending on the installation spot and usage have to be
adhered by a skilled installer and any safety problems have to be removed.
In order to make the lights in good condition and extend the life time, we suggest a
regular cleaning to the lights.
1) Clean the inside and outside lens each week to avoid the weakneness of the lights
due to accumulation of dust.
2) Clean the fan each week.
3) A detailed electric check by approved electrical engineer each three month, make
sure that the circuit contacts are in good condition, prevent the poor contact of
circuit from overheating.
We recommend a frequent cleaning of the device. Please use a moist, lint- free cloth.
Never use alcohol or solvents.
There are no serviceable parts inside the device. Please refer to the instructions
under “Installation instructions”.
Should you need any spare parts, please order genuine parts from your local dealer.
MAINTENANCE AND CLEANING
4
Disconnect from mains before starting maintenance operation.
CAUTION
