CMB-170 Installation Guide
1
CMB-170
Mini Barebone system
Intel High Performance Platform
User’s Manual
Installation Guide
Edition 1.1
2012/01/09

CMB-170 Installation Guide
2
Document Content:
zPacking List
zProduct Specification
zHardware Installation
Packing List:
ACMB-170C Chassis x 1
(Including LP-170 Motherboard)
DSPD-080-12 80W AC-DC Adapter x 1
Power Code x 1
DC_IN Power Cable x 1
SATA Cable x 1
USB Cable x 1
Audio Cable x 1
PS/2 Keyboard & Mouse Cable x 1
Dual COM PORT cable x 1
DC_OUT Power Cable x 1
CMB-170

CMB-170 Installation Guide
3
CN_LPC
CN_USB1
CN_AUDIOCN_USB2
JAT
Hardware Installation:
Motherboard placement
Jum
p
er Connector
CN_LVDS
DC_IN
FAN
JFRNT
SATA
CN_COM1/2
MINI_CARD
JVLCD
JRTC

CMB-170 Installation Guide
4
CF
DC_OUT
DDRll
CN_INV

CMB-170 Installation Guide
5
I/O panel:
Front:
HD LED
Power LED
Power Button
USB
USB Mic / Ear-Phone

CMB-170 Installation Guide
6
Rear:
Power input : DSPD-080-12 80W AC-DC Adapter Input.
USBUSB
COMPORT
RJ45 PS2 CRT
DC_INDC_IN

CMB-170 Installation Guide
7
Chassis Setup procedure:
1 . Turn the screws and refer the picture A.
(A)

CMB-170 Installation Guide
8
2. CF card Setup Procedure:
Follow the Idiot-proof design then insert the CF card, Check connected
well. ( If you don’t have HD drive please direct to step 4 )

CMB-170 Installation Guide
9
3. Memory module Setup Procedure:
(A) Open the Dimm holder then check the pin number to match the socket
side well before installing memory module.

(B) Press down the memory module then check dimm holder hook well.

CMB-170 Installation Guide
11
4. HD driver Setup Procedure:
(A) Put on HD driver into HD holder then turn the HD drive screws to
tighten. ( If you don’t have HD drive please direct to step 2 )

CMB-170 Installation Guide
12
(B)Connect SATA cable and DC_OUT Power cable from motherboard to the
HD drive.

CMB-170 Installation Guide
13
5. Turn the chassis shield screws with the hanging holders to
tighten well.

CMB-170 Installation Guide
14

CMB-170 Installation Guide
15
