CommScope ION-U EU H 7P/80-85P/17P/19P User manual

ION®-U
H 7P/80-85P/17(E)P/19P
Remote Unit
Manual
MF0200A8D

Page 2 User’s Manual for ION
®
-U
DISCLAIMER:
This document has been developed by CommScope, and is intended for the use of its
customers and customer support personnel. The information in this document is subject to
change without notice. While every effort has been made to eliminate errors, CommScope
disclaims liability for any difficulties arising from the interpretation of the information
contained herein. The information contained herein does not claim to cover all details or
variations in equipment, nor to provide for every possible incident to be met in connection
with installation, operation, or maintenance. This document describes the performance of the
product under the defined operational conditions and does not cover the performance under
adverse or disturbed conditions. Should further information be desired, or should particular
problems arise which are not covered sufficiently for the purchaser’s purposes, contact
CommScope.
CommScope reserves the right to change all hardware and software characteristics without
notice.
COPYRIGHT:
© Copyright 2016 CommScope Inc. All Rights Reserved.
This document is protected by copyright. No part of this document may be reproduced,
stored in a retrieval system, or transmitted, in any form or by any means, electronic,
mechanical photocopying, recording, or otherwise without the prior written permission of
CommScope.
TRADEMARKS
All trademarks identified by ® or ™ are registered trademarks or trademarks, respectively, of
CommScope. Names of products mentioned herein are used for identification purposes only
and may be trademarks and / or registered trademarks of their respective companies.
Andrew Wireless Systems GmbH, 20-January-2017

Table of Contents
User’s Manual for ION
®
-U Page 3
TABLE OF CONTENTS
1.  GENERAL 6 
1.1.USED ABBREVIATIONS 6
1.2.HEALTH AND SAFETY 7
1.3.PROPERTY DAMAGE WARNINGS 7
1.4.COMPLIANCE 8
1.5.ABOUT COMMSCOPE 12
1.6.INTERNATIONAL CONTACT ADDRESSES FOR CUSTOMER SUPPORT 13
2.  INTRODUCTION 15 
2.1.PURPOSE 15
2.2.ION-U HIGH POWER REMOTE UNITS 15
3.  FUNCTIONAL DESCRIPTION 16 
4.  COMMISSIONING 17 
4.1.GENERAL 17
4.2.HIGH POWER RU MECHANICAL INSTALLATION 17
4.2.1.Health and Safety for mechanical installation 17
4.2.2.Property Damage Warnings for mechanical installation 17
4.2.3.Wall mounting procedure 19
4.2.4.Pole mounting procedure with screw bands 20
4.2.5.Pole mounting procedure with brackets 21
4.3.ELECTRICAL INSTALLATION 23
4.3.1.Health and Safety for electrical installation 23
4.3.2.Property Damage Warnings for electrical installation 23
4.3.3.Connections 24
4.3.4.Grounding (Earthing) 27
4.3.5.Connection of the antenna cable 28
4.3.6.Cleaning procedure for RF cable connectors 29
4.3.7.Antenna cable connector assembly 32
4.3.8.Mains power connection 33
4.3.8.1.Mains power connection AC 33
4.3.8.2.Mains power connection DC 35
4.3.9.Extension Unit port connection 37
4.3.10.External alarm In / Out port 38
4.3.11.RS 485 /+28 V port 38
4.3.12.Local interface port 39
4.3.13.Coupling probe 39
4.3.14.Optical-fiber cable connection 40
4.3.15.Assembly instructions for optical LC patch cables 42
4.3.15.1.Assemble optical Opus short plug components 43

Table of Contents
Page 4 User’s Manual for ION
®
-U
4.3.15.2.Connect Opus short plug to RU 45
4.3.15.3.Disconnect Opus short plug from RU 46
4.3.16.Optional equipment for optical fiber connection 46
4.4.COMMISSIONING FLOW-CHART 47
5.  ALARMS 49 
5.1.BITE AND ALARMS 49
5.2.TROUBLESHOOTING 49
5.3.STATUS LED ALARMS 49
5.4.EXTERNAL ALARM INPUTS AND OUTPUTS 50
6.  MAINTENANCE 51 
6.1.GENERAL 51
6.2.REPLACING THE FAN UNIT 52
6.3.CLEANING THE HEAT SINK 53
7.  APPENDIX 54 
7.1.ILLUSTRATIONS 54
7.2.SPECIFICATIONS 55
7.3.SPARE PARTS 55
7.4.LIST OF CHANGES 55
8.  INDEX 56 

Figures and Tables
User’s Manual for ION
®
-U Page 5
FIGURES AND TABLES
figure 3-1 ION-U High Power RU block diagram........................................................16

figure 4-1 Wall mounting - pitches..............................................................................19 
figure 4-2 Pole mounting - pitches..............................................................................20 
figure 4-3 Pole mounting - screw bands.....................................................................20 
figure 4-4 Pole mounting - fasten RU.........................................................................20 
figure 4-5 Pole mounting – max. diameter .................................................................21 
figure 4-6 Pole mounting – with brackets...................................................................21 
figure 4-7 Pole mounting - pitches..............................................................................22 
figure 4-8 Pole mounting - brackets ...........................................................................22 
figure 4-9 Pole mounting - fasten RU.........................................................................22 
figure 4-10 ION-U H 7P/80-85P/17(E)P/19P AC version connector flange...............24 
figure 4-11 ION-U H 7P/80-85P/17(E)P/19P DC version connector flange...............26 
figure 4-12 Grounding bolts........................................................................................27 
figure 4-13 Grounding bolt, schematic view...............................................................27 
figure 4-14 Mains power connector............................................................................34 
figure 4-15 Mains power cable - AC...........................................................................34 
figure 4-16 EU connector and cable bridge................................................................37 
figure 4-17 Mounting the EU cable bridge..................................................................37 
figure 4-18 Alarm connector.......................................................................................38 
figure 4-19 RS485 /+28 VDC connector.....................................................................38 
figure 4-20 Local interface connector.........................................................................39 
figure 4-21 Contents of the Opus short plug kit..........................................................42 
figure 4-22 LC/APC patch cable requirements...........................................................42 
figure 4-23 Opus short plug clamp and nut................................................................43 
figure 4-24 Simplex split gasket .................................................................................43 
figure 4-25 Duplex split gasket...................................................................................43 
figure 4-26 Simplex cavity A.......................................................................................44 
figure 4-27 Duplex cavity A & B..................................................................................44 
figure 4-28 Assemble Opus short plug.......................................................................44 
figure 4-29 Insert LC connector plug into plug body ..................................................44 
figure 4-30 Tighten Opus short plug adapter nut .......................................................45 
figure 4-31 Remove Opus short plug protective cap..................................................45 
figure 4-32 Insert Opus short plug into RU receptacle...............................................45 
figure 4-33 Disconnect Opus short plug from RU ......................................................46 
figure 4-34 Optional pigtail kit.....................................................................................46 
figure 5-1 Alarm inputs and outputs ...........................................................................50 
figure 7-1 ION-U H 7P/80-85P/17(E)P/19P required space.......................................54 
table 4-1 Specified torques.........................................................................................18

table 4-2 ION-U H RU connectors..............................................................................25 
table 4-3 AC power cable pinning ..............................................................................34 
table 4-4 Alarm connector pinning..............................................................................38 
table 4-5 RS485/+28V pinning ...................................................................................38 
table 4-6 Local interface connector pinning................................................................39 

1. General
Page 6 User’s Manual for ION
®
-U
1. General
1.1. Used Abbreviations
AC/DC Alternating current / Direct Current
AIMOS Andrew Integrated Management and
Operating System
ALC Automatic Level Control
BITE Built-In Test Equipment
BTS Base Transceiver Station
CDMA Code Division Multiple Access
CE "Conformité Européenne"
("European Conformity")
CFR Code of Federal Regulations
DL Downlink
DoC Declaration of Conformity
EP Extension Port
ESD Electrostatic Discharge
EU Extension Unit
GSM Global System for Mobile
Communication
GND Ground (Earth)
GUI Graphical User Interface
ICP3 Intercept Point 3rd order
ID No Identification Number
ION Intelligent Optical Network
LED Light Emitting Diode
LMT Local Maintenance Terminal
LTE Long Term Evolution
MIMO Multiple Input Multiple Output
MS Mobile Station
MU Main Unit
NF Noise Figure
OMC Operations and Maintenance Center
OTRx Optical Transceiver
PIM Passive Intermodulation
Pin Input power
Pout Output power
Rev Revision
RF Radio Frequency
RU Remote Unit
RX Receiver
SISO Single Input Single Output
SNMP Simple Network Management
Protocol
TX Transmitter
UL Uplink
UMTS Universal Mobile Telecommunication
System
UPS Uninterruptible Power Supply
VSWR Voltage Standing Wave Ratio
WCDMA Wideband Code Division Multiple
Access
WDM Wavelength Division Multiplex
XML Extensible Markup Language

1. General
User’s Manual for ION
®
-U Page 7
1.2. Health and Safety
1. Danger: Electrical hazard. Danger of death or fatal injury from electrical
current. Obey all general and regional installation and safety regulations
relating to work on high voltage installations, as well as regulations
covering correct use of tools and personal protective equipment.
2. Danger: Electrical hazard. Danger of death or fatal injury from electrical
current inside the unit in operation. Before opening the unit, disconnect
mains power.
3. Caution: Laser radiation. Risk of eye injury in operation. Do not stare into the
beam; do not view it directly or with optical instruments.
4. Caution: High frequency radiation in operation. Risk of health hazards associated
with radiation from the unit’s inner conductor of the antenna port(s). Disconnect
mains before connecting or replacing antenna cables.
5. Caution: High frequency radiation in operation. Risk of health hazards associated
with radiation from the antenna(s) connected to the unit. Implement prevention
measures to avoid the possibility of close proximity to the antenna(s) while in
operation.
1.3. Property Damage Warnings
1. Attention: Due to power dissipation, the Remote Unit may reach a very high
temperature. Do not operate this equipment on or close to flammable materials.
Use caution when servicing the unit.
2. Attention: Only authorized and trained personnel are allowed to open the unit
and get access to the inside.
3. Notice: Although the Remote Unit is internally protected against overvoltage, it is
strongly recommended to ground (earth) the antenna cables close to the antenna
connectors of the Remote Unit for protection against atmospheric discharge. In
areas with strong lightning, it is strongly recommended to install additional
lightning protection.
4. Notice: ESD precautions must be observed. Before commencing maintenance
work, use the available grounding (earthing) system to connect ESD protection
measures.
5. Notice: Only suitably qualified personnel are allowed to work on this unit and only
after becoming familiar with all safety notices, installation, operation and
maintenance procedures contained in this manual.
6. Notice: Keep operating instructions within easy reach and make them available
to all users.

1. General
Page 8 User’s Manual for ION
®
-U
7. Notice: Read and obey all the warning labels attached to the unit. Make sure that
all warning labels are kept in a legible condition. Replace any missing or
damaged labels.
8. Notice: Only license holders for the respective frequency range are allowed to
operate this unit.
9. Notice: Make sure the repeater settings are correct for the intended use (refer to
the manufacturer product information) and regulatory requirements are met. Do
not carry out any modifications or fit any spare parts, which are not sold or
recommended by the manufacturer.
1.4. Compliance
1. Notice: For installations which have to comply with European EN50385 exposure
compliance requirements, the following Power Density limits/guidelines (mW/cm²)
according to ICNIRP are valid:
o0.2 for frequencies from 10 MHz to 400 MHz
oF (MHz) / 2000 for frequencies from 400 MHz to 2 GHz
o1 for frequencies from 2 GHz to 300 GHz
2. Notice: For installations, which have to comply with FCC RF exposure
requirements, the antenna selection and installation must be completed in a way
to ensure compliance with those FCC requirements. Depending on the RF
frequency, rated output power, antenna gain, and the loss between the repeater
and antenna, the minimum distance D to be maintained between the antenna
location and human beings is calculated according to this formula:
]/[
][
][
2
4
cmmW
mW
cm
PD
P
D 

where
P (mW) is the radiated power at the antenna, i.e. the max. rated repeater
output power in addition to the antenna gain minus the loss between the
repeater and the antenna.
PD (mW/cm²) is the allowed Power Density limit acc. to 47 CFR 1.1310 (B)
for general population / uncontrolled exposures which is
oF (MHz) / 1500 for frequencies from 300MHz to 1500MHz
o1 for frequencies from 1500MHz to 100,000MHz
RF exposure compliance may need to be addressed at the time of licensing, as
required by the responsible FCC Bureau(s), including antenna co-location
requirements of 1.1307(b)(3).

1. General
User’s Manual for ION
®
-U Page 9
3. Notice: Installation of this equipment is in full responsibility of the installer, who
has also the responsibility, that cables and couplers are calculated into the
maximum gain of the antennas, so that this value, which is filed in the FCC Grant
and can be requested from the FCC data base, is not exceeded. The industrial
boosters are shipped only as a naked booster without any installation devices or
antennas as it needs for professional installation.
4. Notice: For installations which have to comply with FCC/Industry Canada
requirements:
English:
This device complies with FCC Part 15 and Industry Canada license exempt RSS
standard(s). Operation is subject to the following two conditions: (1) this device may not
cause interference, and (2) this device must accept any interference, including
interference that may cause undesired operation of the device.
This device complies with Health Canada’s Safety Code. The installer of this device
should ensure that RF radiation is not emitted in excess of the Health Canada’s
requirement. Information can be obtained at http:
//www.hc-sc.gc.ca/ewh-semt/pubs/radiation/radio_guide-lignes_direct-eng.php.
Changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
French:
Cet appareil est conforme à FCC Partie15 d’Industrie Canada RSS standard exempts de
licence (s). Son utilisation est soumise à Les deux conditions suivantes: (1) cet appareil
ne peut pas provoquer d’interférences et (2) cet appareil doit accepter Toute
interférence, y compris les interférences qui peuvent causer un mauvais fonctionnement
du dispositif.
Cet appareil est conforme avec Santé Canada Code de sécurité 6. Le programme
d’installation de cet appareil doit s’assurer que les rayonnements RF n’est pas émis au-
delà de I’exigence de Santé Canada. Les informations peuvent être obtenues:
http://www.hc-sc.gc.ca/ewh-semt/pubs/radiation/radio_guide-lignes_direct-fra.php
Les changements ou modifications non expressément approuvés par la partie
responsable de la conformité pourraient annuler l'autorité de l'utilisateur à utiliser cet
équipement.
5. Notice: Corresponding local particularities and regulations must be observed. For
national deviations, please refer to the respective documents included in the
manual CD that is delivered with the unit.

1. General
Page 10 User’s Manual for ION
®
-U
6. Notice:The unit complies with Overvoltage Category II. It also complies with the
surge requirement according to EN 61000-4-5 (fine protection); however,
installation of an additional medium (via local supply connection) and/or coarse
protection (external surge protection) is recommended depending on the
individual application in order to avoid damage caused by overcurrent.
For Canada and US, components used to reduce the Overvoltage Category shall
comply with the requirements of IEC 61643-series. As an alternative,
components used to reduce the Overvoltage Category may comply with
ANSI/IEEE C62.11, CSA Certification Notice No. 516, CSA C22.2 No. 1, or UL
1449. Suitability of the component for the application shall be determined for the
intended installation.
7. Note: For a Class A digital device or peripheral:
This equipment has been tested and found to comply with the limits for a Class A
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with
the instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at
his own expense.
8. Note: For a Class B digital device or peripheral:
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to
try to correct the interference.
9. Note: This unit complies with European standard EN60950.
10. Note: The Manufacturer's rated output power of this equipment is for single
carrier operation. For situations when multiple carrier signals are present, the
rating would have to be reduced by 3.5 dB, especially where the output signal is
reradiated and can cause interference to adjacent band users. This power
reduction is to be by means of input power or gain reduction and not by an
attenuator at the output of the device.

1. General
User’s Manual for ION
®
-U Page 11
Equipment Symbols Used / Compliance
Please observe the meanings of the following symbols used in our equipment and
the compliance warnings:
Symbol Compliance Meaning / Warning
--- FCC
Unit is for FCC Part 20 purposes - COMMERCIAL
MOBILE SERVICES – only.
WARNING: This is NOT a CONSUMER device. It is
designed for installation by FCC LICENSEES and
QUALIFIED INSTALLERS. You MUST have an FCC
LICENSE or express consent of an FCC Licensee to
operate this device. Unauthorized use may result in
significant forfeiture penalties, including penalties in
excess of $100,000 for each continuing violation.
CE
Alert sign to R&TTE
To be sold exclusively to mobile operators or
authorized installers – no harmonized frequency
bands, operation requires license. Intended use: EU
and EFTA countries
Indicates conformity with the R&TTE directive
1999/5/EC certified by the notified body no. 0700.

1. General
Page 12 User’s Manual for ION
®
-U
1.5. About CommScope
CommScope is the foremost supplier of one-stop, end-to-end radio frequency (RF)
solutions. Part of the CommScope portfolio are complete solutions for wireless
infrastructure from top-of-the-tower base station antennas to cable systems and
cabinets, RF site solutions, signal distribution, and network optimization. For patents
see www.cs-pat.com.
CommScope has global engineering and manufacturing facilities. In addition, it
maintains field engineering offices throughout the world.
Andrew Wireless Systems GmbH based in Buchdorf/ Germany, which is part of
CommScope, is a leading manufacturer of coverage equipment for mobile radio
networks, specializing in high performance, RF and optical repeaters. Our optical
distributed networks and RF repeater systems provide coverage and capacity
solution for wireless networks in both indoor installations and outdoor environments,
e.g. tunnels, subways, in-trains, airport buildings, stadiums, skyscrapers, shopping
malls, hotels and conference rooms.
Andrew Wireless Systems GmbH operates a quality management system in
compliance with the requirements of ISO 9001 and TL 9000. All equipment is
manufactured using highly reliable material. To maintain highest quality of the
products, comprehensive quality monitoring is conducted at all fabrication stages.
Finished products leave the factory only after a thorough final acceptance test,
accompanied by a test certificate guaranteeing optimal operation.
This product meets the requirements of the R&TTE directive and the Declaration of
Conformity (DoC) itself. A current version of the CE DoC is included in this manual
CD delivered *. Any updated version of the DoC is available upon request from the
local sales offices or directly from CommScope via the local Customer Support at
one of the addresses listed in the following chapter.
According to the DoC, our "CE"-marked equipment can be used in all member
states of the European Union.
Note: Exceptions of and national deviations from this intended use may be
possible. To observe corresponding local particularities and
regulations, please refer to the respective documents (also in
national language) which are included in the manual CD delivered.
* In case the Declaration of Conformity (DoC) for the product was not included in the manual CD
delivered, it is available upon request from the local sales offices or directly from CommScope at
one of the addresses listed in the following chapter.
To make the most of this product, we recommend you carefully read the instructions
in this manual and commission the system only according to these instructions.
For technical assistance and support, please also contact the local office or
CommScope directly at one of the addresses listed in the following chapter.

1. General
User’s Manual for ION
®
-U Page 13
1.6. International Contact Addresses for Customer Support
Canada
A
M
E
R
I
C
A
S
United States
CommScope Canada
A
ndrew LLC, A CommScope Company
Mail 505 Consumers Road, Suite 803
Toronto M2J 4V8, Canada Mail 620 North Greenfield Parkway
Garner, NC 27529, U.S.A.
Phone [phone] (Office)
[phone] (Cell) Phone [phone]
Fax [phone] Fax [phone]
E-mail [e-mail] E-mail [e-mail]
Caribbean & South American Region Caribbean & Central American Region
CommScope Cabos do Brasil Ltda. CommScope Mexico S.A. de C.V.
Mail
CALA Tech Support for Distributed
Coverage & Capacity Solutions (DCCS)
products:
Rua Guaporanga, 49
Praça Seca – Rio de Janeiro – RJ
ZIP: 21320-180, Brazil
Mail
CALA Tech Support for Distributed
Coverage & Capacity Solutions
(DCCS) products:
Av. Insurgentes Sur 688, Piso 6
Col. Del Valle, CP: 03100
Mexico City, Mexico
Phone [phone] (Cell)
[phone] (Office) Phone [phone] (Office)
Fax + 55-15-2102-4001 Fax [phone]
E-mail [email protected] E-mail [email protected]
China, India and Rest of Asia
A
P
A
C
Australia & New Zealand
Andrew International Corporation
A
ndrew Corporation (Australia) Pty Ltd.
Mail
Room 915, 9/F
Chevalier Commercial Centre
8 Wang Hoi Rd
Kowloon Bay, Hong Kong
Mail
Unit 1
153 Barry Road
Campbellfield
VIC 3061, Australia
Phone [phone] Phone [phone]
Fax [phone] Fax [phone]
E-mail [email protected] E-mail [e-mail]
Middle East & North Africa
Africa
&
Middle
East
South Africa
CommScope Solutions International Inc.
(Branch)
A
ndrew Wireless Solutions Africa
(PTY) LTD
Mail
PO Box 48 78 22
Unit 3206, Floor 32,
Jumeirah Business Center 5,
Jumeirah Lakes Towers,
Dubai, United Arab Emirates
Mail
11 Commerce Crescent West
Eastgate, Sandton
PO Box 786117
Sandton 2146
South Africa
Phone [phone] Phone + 27 11-719-6000
Fax [phone] Fax + 27 11-444-5393
E-mail [e-mail] E-mail [email protected]

1. General
Page 14 User’s Manual for ION
®
-U
United Kingdom
E
U
R
O
P
E
Scandinavia
Andrew Wireless Systems UK Ltd
A
ndrew Norway (AMNW)
Mail
Unit 15, Ilex Building
Mulberry Business Park
Fishponds Road
Wokingham Berkshire
RG41 2GY, England
Mail
P.O. Box 3066
Osloveien 10
Hoenefoss 3501
Norway
Phone [phone] Phone + 47 32-12-3530
Fax [phone] Fax + 47 32-12-3531
E-mail [email protected] E-mail [e-mail]
Germany France
Andrew Wireless Systems GmbH CommScope France
Mail Industriering 10 86675 Buchdorf
Germany Mail Immeuble Le Lavoisier
4, Place des Vosges
92052 Courbevoie, France
Phone [phone] Phone [phone]
Fax [phone] Fax [phone]
E-mail [email protected] E-mail [email protected]
Austria Switzerland
Andrew Wireless Systems (Austria) GmbH CommScope Wireless Systems AG
Mail Weglgasse 10 2320 Wien-Schwechat
Austria Mail Tiergartenweg 1
CH-4710 Balsthal
Switzerland
Phone [phone] Phone [phone]
Fax [phone] Fax [phone]
E-mail [email protected] E-mail [email protected]
Italy Iberia Region - Spain & Portugal
CommScope Italy S.r.l., Faenza, Italy
A
ndrew España S.A. A CommScope Company
Mail Via Mengolina, 20 48018 Faenza (RA)
Ital
y
Mail Avda. de Europa, 4 - 2ª pta.
Parque Empresarial de la Moraleja
Alcobendas, Madrid 28108, Spain
Phone [phone] Phone [phone]
Fax [phone] Fax [phone]
E-mail [email protected] E-mail [email protected]
Czech Republic
CommScope Solutions Czech Republic
C-Com, spol. s r.o
Mail U Moruší 888
53006 Pardubice, Czech Republic
Phone [phone] (Office)
[phone] (Mobile)
Fax [phone]
E-mail [email protected]

2. Introduction
User’s Manual for ION
®
-U Page 15
2. Introduction
2.1. Purpose
Mobile telephone systems transmit signals in two directions between base
transceiver station (BTS) and mobile stations (MS) within the signal coverage area to
carry voice and data traffic.
If weak signal transmissions occur within the coverage area because of indoor
applications, topological conditions or distance from the transmitter, extension of the
transmission range can be achieved by means of an optical distributed antenna
system (DAS).
Office buildings, sports arenas, college campuses, industrial parks, and other areas
of high demand require the specialized capacity boost that an optical DAS can
provide to meet increasing customer demands for voice and data.
An optical DAS contains optical Master Units and a sufficient number of Remote
Units to provide the necessary coverage. The number of the Remote Units depends
on the coverage requirements of the DAS. The Remote Units are connected to the
Master Unit with optical links.
The Master Unit is the connection to the Base Transceiver Stations. The
configuration of a Master Unit depends on the number of the Remote Units and the
frequency range.
RF signals are transported to and from the Remote Units via optical fibers.
2.2. ION-U High Power Remote Units
The ION-U is an optical fiber based DAS system that efficiently takes the outputs of
multiple Base Transceiver Stations (BTS) sectors and converts those RF signals to
optical to send them over fiber optic cables to Remote Units to provide coverage in
indoor and outdoor locations. The system supports both low power and high power
remotes units and SISO and MIMO operation.
The ION-U H 7P/80-85P/17(E)P/19P is a multi-band, multi-operator Remote Unit
used in conjunction with a Master Unit in the ION optical distribution system. This
system transports up to five frequency bands simultaneously (700 MHz, 800/850
MHz, 1700/2100 MHz, and 1900 MHz), providing a cost-effective solution for
distributing capacity from one or more base stations.
It has been specifically tested and optimized for GMSK, EDGE, CDMA, UMTS,
HSPA+, LTE, and other OFDM modulations. Furthermore it is provisioned for future
modulation scheme evolutions.
These Remote Units feature independent downlink and uplink gain adjustments and
an integrated channel power detector for in-band spectrum and PIM analysis and
end-to-end auto leveling.

3. Functional Description
Page 16 User’s Manual for ION
®
-U
The unit utilizes a single fiber to support multiple bands in both the uplink and
downlink directions. WDM (Wave Division Multiplex) filters are integrated in the
optical modules. For the UL, a wavelength within 1546 nm – 1550 nm is used. For
the DL, a wavelength of 1310 ±10 nm is used. The maximum optical output power for
the UL and DL is 6.7 mW.
3. Functional Description
figure 3-1 ION-U High Power RU block diagram
In the Downlink (DL) path, the Remote Unit provides:
Optical to RF conversion of the input optical signal
Automatic Gain Control (AGC) of each converted signal to compensate for
optical losses
RF amplification of the converted RF signal for transmission while maintaining
an excellent signal-to-noise ratio
RF filtering to reject spurious emissions
In the Uplink (UL) path, the Remote Unit provides:
RF amplification to boost the signals received by the antennas to maintain an
excellent signal-to-noise ratio
RF filtering to reject spurious emissions
Automatic Level Control (ALC) to adjust the RF signal level to meet blocking
requirements
RF-to-optical conversion of the signal, which is conveyed to the optical port
The Remote Unit can be paired with further EUs (Extension Unit) to provide
additional bands.

4. Commissioning
User’s Manual for ION
®
-U Page 17
4. Commissioning
4.1. General
Read and observe chapter 1.2 Health and Safety as well as the description carefully
to avoid mistakes and proceed step by step as described.
Do not operate the Remote Unit without terminating the antenna connectors.
The antenna connectors may be terminated by connecting them to their
respective antennas or to a dummy load.
Only qualified personnel should carry out the electrical, mechanical,
commissioning, and maintenance activities that require the unit to be powered
on when open.
When opening the Remote Unit do not damage the warranty labels on the
internal devices. The warranty is void if the seals are broken.
One of the three mounting kits has to be ordered separately. They are not
contained within the standard equipment. See chapter 7.3 Spare Parts.
Unless otherwise agreed to in writing by CommScope, CommScope’s general limited
product warranty (http://www.commscope.com/Resources/Warranties/) shall be the
warranty governing the Remote Units, including the installation, maintenance, usage
and operation of the Remote Units.
4.2. High Power RU Mechanical Installation
4.2.1. Health and Safety for mechanical installation
Read and observe chapter 1.2 Health and Safety.
1. Caution: Risk of injury by the considerable weight of the unit falling. Ensure there
is adequate manpower to handle the weight of the system.
2. Caution: Risk of serious personal injury by equipment falling due to improper
installation. The installer must verify that the supporting surface will safely
support the combined load of the electronic equipment and all attached hardware
and components. The screws and dowels (wall anchors) used should also be
appropriate for the structure of the supporting wall.
4.2.2. Property Damage Warnings for mechanical installation
1. Attention: Do not install the unit in a way or at a place where the specifications
outlined in the Environmental and Safety Specifications leaflet of the supplier are
not met.
2. Attention: Due to power dissipation, the Remote Unit may reach a very high
temperature. Ensure sufficient airflow for ventilation.
3. Notice: Exceeding the specified load limits may cause the loss of warranty.
4. Notice: When connecting and mounting the cables (RF, optical, mains, ...)
ensure that no water can penetrate into the unit through these cables.

4. Commissioning
Page 18 User’s Manual for ION
®
-U
5. Notice: Ensure that there is free access to the electrical connections as well as
to the cabinet. The approved bending radius of the connected cables must not be
exceeded. See chapter 7.1 for more details.
6. Notice: If any different or additional mounting material is used, ensure that the
mounting remains as safe as the mounting designed by the manufacturer. The
specifications for stationary use of the Remote Unit must not be exceeded.
Ensure that the static and dynamic strengths are adequate for the environmental
conditions of the site. The mounting itself must not vibrate, swing or move in any
way that might cause damage to the Remote Unit.
7. Notice: Observe all additional rules or restrictions regarding mounting that apply
to specific Remote Unit types. For details refer to the mechanical specifications in
the data sheet for the unit. Install the unit vertically with the fan unit at the top. A
maximum tilt angle of 25° from a vertical position must be maintained, as shown
in the following illustrations:
8. Notice: A spacing of 50 mm (1.97 inch) around the unit is required.
9. Notice: To ensure sufficient airflow when mounting the unit in enclosed spaces,
two lid openings (one for the air inlet and the other for the air outlet) must be
provided. Do not block these air inlets and outlets when mounting the Remote
Unit. The size of each opening must equal at least 18 x 18 cm (> 300 cm
2
).
Ensure that there is no thermal short circuit between the air inlet and air outlet.
Make sure free airflow is not deflected or otherwise obstructed.
Specified torques must be observed for certain mounting procedures according to the
following table:
Type Tallow-drop
screws Hex nuts Screw band lock Spacing bolts PG (plastic) PG (alum.)
Thread M 4 M 8 M 4 M 8 PG 13.5 PG 29
Specified
torques 3.3 N-m 27 N-m 6 N-m 2.3 N-m 27 N-m 3.75 N-m 10 N-m
table 4-1 Specified torques

4. Commissioning
User’s Manual for ION
®
-U Page 19
4.2.3. Wall mounting procedure
Notice: It is the responsibility of the installer to verify that the supporting surface will
safely support the combined load of the electronic equipment and all attached
hardware and components and to ensure that the RU is safely and securely
mounted.
1. Mark the position of the drilling
holes (for pitches refer to figure
4-1 Wall mounting). Drill four
holes at the marked positions and
insert dowels*.
2. Mount the brackets (A) to the wall
using the M8x80 screws (B), split
lock washers (C), and washers
(D).
figure 4-1 Wall mounting - pitches
3. Hang the Remote Unit into the upper
bracket, insert it to the lower bracket, and
fasten it to the lower bracket with the
M8x25 screws (E), split lock washers (F),
and washers (G).
* The dowels are not included with the delivery because the suitable type depends on the on-site
conditions (material of wall).

4. Commissioning
Page 20 User’s Manual for ION
®
-U
4.2.4. Pole mounting procedure with screw bands
Standard mounting hardware cannot be used to mount the Remote Unit to a pole, a
column, or other similar structures. Additional hardware must be used for this type of
installation. The pole-mounting kit includes
two mounting brackets with screw bands, (worm gear) clamps to mount the
brackets to the pole
and two M8x25 screws, flat washers, and split lock washers per bracket to
attach the Remote Unit to the bracket.
figure 4-2 Pole mounting
- pitches figure 4-3 Pole mounting - screw bands figure 4-4 Pole mounting - fasten RU
1. Use two screw bands (B) for the upper and one for the lower bracket to fasten the
two brackets (A) to the pole.
2. Place the bands around the pole or post and feed the loose end into the lock and
tighten the slotted screw securely. When the screw is turned clockwise, it acts as
a worm drive pulling the threads of the band causing the band to tighten around
the pole.
Note: When fastening the brackets make sure that they are installed
congruently and not at an angle to each other. To determine the distance
between the clamps refer to figure 4-2 Pole mounting - pitches.
775 min.
788 max.
A
B
C
DE
