Compool Pool-Spa Control System CP-2000 User manual

ONE YEAR LIMITED WARRANTY
Compool Corporation warrants to the purchaser of this electronic control system, for the
period of one year from the date of original purchase for use,that any defective product
proved to be caused by faulty workmanship or faulty material,will be repaired or replaced
at Compool'soption for no charge, providing the product is returned to Compool with all
transportation charges prepaid.
This warranty covers the CP-2000Controller. LX-10 Service Center, Valve Operators, and
optional Remote Controls including all components and parts.
It does not include Sensors, batteries or labor for calib~ation.
It extends to the first retail purchaser and any subsequent owners of the system
This limited warranty applies only to controls which have been installed and maintained in
strict accordance with installation and operating instructions provided by Compool
Corporation, using installation hardware supplied and/or recommended in writing by
Compool. and to controls which have been connected to the correct supply voltage.
This limited warranty does not apply to any controls wh~chhave been repaired or altered
by anyone other than Compool or a person authorized by it: or which have been subject
to misuse, neglect or accident; or which have been damaged by wind, rain,lightning,
freezingor other cause, thing, person,or act of God; or which have been subject to
damage in transit, during installation, or by someone other than Compool Corporation; or
which have been damaged because of a defect in a component or part which is not part
of the Compool Control System: or upon which the serial number or manufacture date
has been altered,effaced or removed.
This warranty gives you specific legal rights and you may also have other rights which
vary fromState to State.
Compool Corporation does not authorize any person to create any other obligation or
liability in connection with Compool controls.
Compool Corporation makes no warranty of merchantability or fitness for any use.
Any implied warranty applicable to Compool controls is limited in duration to the duration
of this written warranty.
Unless state law provides otherwise, Compool Corporation shall not be liable for
consequential or incidental damages resulting from breach of this written warranty or any
implied warranty, or for any inconvenience, loss of time. or incidental expenses such as
telephone calls.
Compool Corporation shall not be liable for any labor charges associated with the
removal or reinstallation of any so-claimeddefective products.
For informationon possible Authorized Service Centers within your vicinity, call Compool
Corporation at [phone].
To exercise this warranty, send defective unit, with copy of dated receiptand a brief
description of the problemsencountered, postage prepaid, to
:
COMPOOL CORPORATION
599 Fairchild Drive, MountainView. California 94043
CP-2000 POOL-SPA CONTROL SYSTEM
The CP-2000isan electronic control system which is designed to coordinate and operate
allof the equipment associated with your swimming pool and spa.
The system is comprised of three principal components
:
the CP-2000CONTROLLER, two VALVE OPERATORS, and the W-10 SERVICECENTER.
The Controller automatically controls and monitors the timing of all your pool and spa
equipment,and the temperature of your pool and spa; the Valve Operators switch the
filter and heater from pool to spa, and activate the solar system if applicable; and the
Service Center provides easy maintenance for your Pool Serviceperson.
Additionally, the CP-2000incorporates important safety features which protect your pool
equipment from accidental damage. (See Page 2).
Your system may also include additional Remote Controls and special options which
further add to the convenience, safety, and economy of operating your pool equipment.
Before usingthis electrical equipment, obtain a copyof the Installation Instructions and a
completed EQUIPMENT CHECKLISTfrom your Pool Builder.
Additionally, a 6-minute video (VHS fo~mat)is provided as an aid for the first-time user of
the Compool CP-2000Control System.
Cornpool Corporation
&m4000/ 599 Fairchild Drive
MountainView
computerizedpool systems California 94043

IMPORTANT SAFETY INSTRUCTIONS
MAINTENANCE
READ AND FOLLOW ALL INSTRUCTIONS.
Basic safety precautions should always be followed when operating
and servicing this electrical equipment.
WARNING
: To reduce the risk of injury, do not permit children to
use this product unless they are closely supervised at all times.
SAVE THESE INSTRUCTIONS.
SAFETY FEATURES
HEATER PROTECTION :
A built-inelectronic delay c~rcuitautorr~aticallyruns the f~lterpump for an additional four
minutes whenever the system is turned off.
This feature enables the heater to cool down,so that the heat exchanger and plumbing
are not damaged from overheating.
Fortesting and servicing purposes, itis possible to override this delay circuit bypushing
the DELAY CANCEL Button at the CP-2000 Controller.
POOLCLEANER PROTECTION :
If your system incorporatesan automatic pool cleaner, it will have been plumbed in
conjunction with the filter pumpso that it must have water circulation in order to operate.
The CP-2000incorporates the following protection features against possible pump
damage if there is nowater circulation:
1. Your poolcleaner will automatically be switched off whenever water is being circulated
to the Spa.
2. The filter pumpwill automatically be activated whenever the pool cleaner is running.
even if the filter pumphas not been switched on.
3. Additionally, whenever the pool cleaner is turned on: a built-inelectronic delay circuit
will prevent it from running until4 minutes have passed. This protectsthe pumpfrom
possible damage caused byair which may have entered the plumbing since the
system was last used.
For testing and servicing purposes, itis possibleto override this delaycircuit by
pushingthe DELAY CANCEL Button at the CP-2000 Controller.
4. If your system incorporates solar, the pool cleaner will automatically bedisabled for a
period of
4 minutes whenever the solar system turns on. This protects the pool
cleaner from possible damage caused by residual air within the solar panels.
BATTERY BACK-UP :
In case of a power failure, a long-life battery automatically maintains the program and
clock functions of your Control System This safeguards against the equipment
operating erratically once power has been restored, and also eliminates the need to
reprogram whenever there is a power failure
REPLACING THE BACK-UP BATTERY :
There is a small 3 volt lithium battery located on the backside of the CP-2000Controller.
In the absence of power, this battery will keep the clock running and retain the
programming in memory for approximately
48 hours.
While power is connected to the system, the battery will not be dra~ned.
However. it is not rechargeable.
To replace the battery
:
1. Remove the four mounting screws from CP-2000Controller (2 at each side)
2 Carefullyfold Controller out, still connected to cable.
3. Pry-out old battery from battery clip,and replace it w~tha new one.
Pay special attention to the polarity
(+ sign).
The Replacement battery is available directly from Compool (modelBAT-3), or can be
purchased at Radio Shack or your local drug store. (Type CR2032, or equivalent).
CLEANING THE SPA :
For cleaning or maintenance purposes, it is possible to use the Control System to
automatically empty your spa and then to refill with clean water from your pool.
At the LX-10 Service Center:
1. Set SYSTEM CONTROLSwitch to the "SERVICE position.
2. Set FLOW CONTROLSwitch to the "DRAIN' position.
3. At the MANUAL CONTROL, set FILTER Switch to the "ON"position.
4. The spa will begin to drain into the pool. Do not drain completely, or prime will be lost.
CAUTION:
Do notleave equipment unattended when draining or filling the spa.
5. When cleaning is complete. set FLOW CONTROLSwitch to the FILL" position.
The spa will beginto fill with clean water from the pool.
6. When the spa water level has returnedto normal, return FLOW CONTROL Switch to the
"POOL" position, FILTER Switch at the MANUALCONTROLto the "OFF" position,and
SYSTEM CONTROLSwitch to the "AUTO" position.
WINTERIZING THE SYSTEM :
During the winter season, it is possible to drain your pool and disable the pool equipment
from your control system. but still be able to use your spa. Consult a qualified service
company to drain your pool and protect the plumbing from freeze damage.
The following procedure will disable the pool equipment
:
1. At the LX-10Service Center, turn SYSTEM CONTROLSwitch to the "SERVICE" position.
and FLOWCONTROLSwitch to the "SPA" position.
2. Unplug cables from Valve Operators.
3. At the LX-10 Service Center, turn FLOWCONTROL Switch to the "POOL"position,and
SYSTEM CONTROL Switch to the "AUTO" position.
4. At the electrical supply panel,turn off the pool cleaner circuit breaker.
5. At the CP-2000 Controller, turn POOL Heat Select Switch to the "OFF'position.
6. If your control system incorporates solar, ensure that the panels are completely drained.
and, at the LX-10Service Center, turn SOLAR CONTROL Switch to the "OFF" position.
If your system is equipped with Recirculating Freeze Sensors, it may notbenecessary to
drain the pool. However, itis recommended that all Freeze Sensors betested byan
authorized Serviceperson beforethe onset of the winter season.

TEMPERATURE CONTROL :
Separate electronic controls are provided for POOLand SPA heating.
Each control incorporates the following
:
THERMOSTATDial :
Used to preset your desired water temperature.
As long as the Heat Select Switch is not in the "OFF'position, the water will heat upto the
preset temperature whenever the filter pump is running.
Heat Select Switch
:
It is possible to heat your spa and swimming pool using solar energy, conventional heat,
or a combination of both. However, no heating will take place unless the filter pumpis
running:
SOLAR Position: Allows heating with solar only.
S.PREF Position: Allows preferential heating with solar, but automatically switches to
conventional heating when solar energy is unavailable.
HEATER Position: Allows heating with gas or electric heater only.
Note: If you are heatingthe swimming pool (and also the spa in some
custom applications),the solar system may also contribute to the
conventional heat whenever solar energy is available.
OFFPosition: Allows no heating.
WATER TEMPERATURE Display
:
Whenever the filter pump is running, the precise water temperature will be displayed in
degrees Fahrenheit.
Pool temperature will be displayed during pool circulation, and spa temperature
displayed during spa circulation.
Note: Filter pumpmustberunning inorder to provide accurate temperature display.
VALVE OPERATORS
Your control system isdesigned to actuate two motorized valves,which automatically
rotate between pool and spa filtration whenever the SPA Button at the CP-2OMlis
activated.
A motorized valve may also be used to automatically divert the flow of water through your
solar panels whenever solar energy is available.
These Valve Operators are also activated by the FLOWCONTROLand SOLAR CONTROL
Switchesat the LX-10Service Center.
Your system may also include additional motorized valves for custom hydraulic
applications,such as a fountain or waterfall, or (in lieu of a booster pump) to activate your
poolcleaner.
SINGLE OCCURRENCE PROGRAM :
Occasionally, you may w~shto use your spa at a time which is different from your normal
daily program.
In this instance, it is poss~bleto enter a "once only" program step which will occur within
the following
24 hour period without having to reprogram the daily equipment sequence.
The "once only"programwill automatically be canceled once the Clock reaches its next
program step.
Push PROGRAM Buttonto put the Clock into
Program Mode.
"PROG"will appear on the right of the Display.
Continue to push PROGRAMButton until a
flashing "ONCE' appears.
Enter the time that you wish to activate the spa
(1
1:00pm in our example) by pushing HOURS
and MINUTESButtons.
Push SPA Equipment Button.
"ON"will appear directly above the SPA and
FILTER Buttons.
Push PROGWButton to lock-in program.
Remember to manually turn off the spa after use,otherwise it may run all night untilthe
Clock reaches its next program step.
I +
TIME CONTROL
Mill OUR SPA AUXI
\ I
EIGHT PROGRAM STEPS :
If the standard six program steps are insufficient for your particular programming
requirements,it is possible to modify the Clock so that eight program steps may be
entered.
Consultthe Installation Manualfor details.
TROUBLE-SHOOTING
GENERAL :
1. Check all circuit breakers at the electrical supply panel.
2. At the LX-10Service Center, ensure that SYSTEMCONTROLSwitch is in the "AUTO
position, all MANUALCONTROL Switches are in the "OFF"position, FLOWCONTROL
Switch is in the "POOLposition, SOLAR CONTROLSwitch is in the "AUTO"position,
and OUTDOORREMOTES Switch is in the "ON"position.
NOTHING OPERATES :
1. Check 3 amp circuit breaker which is located above faceplate in LX-10Service Center
Tripped circuit breaker is indicated by a white tab. Push to reset.
2. If circuit breaker continues to trip, refer to a qualified Service Company.
3. At the LX-10,turn OUTDOOR REMOTESSwitch to the "OFF"position.
If the equipment can now be operated, there may be malfunction at your Spa-side
Remote Control.

FILTER PUMP DOES NOT OPERATE :
1. At the CP-2000, check that FILTER Status Light is ON
2. At the LX-10,turn SYSTEM CONTROLSwitch to the "SERVICE" position, and FILTER
Switchat MANUALCONTROLto the "ON' position.
3. If filter pump operates, there is a possible malfunction at the LX-10 circuit board.
4. If filter pumpdoes not operate. pump may require servicing.
POOLCLEANER DOES NOT OPERATE :
1. At the CP-2000,check that CLNR is switched ON,and that four minute "pool cleaner on
delay" has expired.
2. At the LX-10,turn SYSTEM CONTROLSwitch to the "SERVICE" position,and CLNR
Switchat MANUALCONTROLto the "ON" pos~tion.
3. If poolcleaner pump operates, there is a possible nlalfunction at the LX-10circuit board
4. If poolcleaner does not operate, pump may require servicing.
5. If system incorporates a pool cleaner valve, check that cable has not been unplugged
from Valve Operator.
HEATER DOES NOT OPERATE :
1. At the CP-2000,make sure that POOLand SPA Heat Select Switches are in the
"HEATER" or "S. PREF" position, and that THERMOSTAT Dials are set correctly.
2. Check the WATER TEMPERATURE Display. Three dashes or an unreasonably high
temperature indicatesthat there is a malfunction at the Water Sensor.
3. Check that filter pump is running.
4. Check the filter pressure. If filter is clogged. the heater may not be getting sufficient
water flow.
5. Insidethe heater, check pilot light and heater controls. Heater must be turned on, and
its ownthermostat must be turned all the way up.
6. Heater mayrequire servicing.
SOURDOES NOT OPERATE :
Note: Ambient air temperature mustbeapproximately 5 degreeswarmer than the water
temperature before the solar system isactivated.
1. Check that filter pumpis running.
2. At the CP-2000, make sure that POOLand SPA Heat Select Switches are in the
"SOLAR"or "S.PREF position, and that THERMOSTAT Dials are set correctly.
3. Check that cable has not been unplugged from Solar Valve Operator.
4. At the W-10,turn SOLAR CONTROLSwitch to the "ONposit~on,andcheck to see if
Solar Valve rotates. Return Switch to "AUTO" position at completion of test.
SPA DOES NOTHEAT UP TO 104" F :
1. Insidethe heater, check that thermostat is turned all the way up.
2. Highlimit control on heater may need adjusting. Refer to a qualified Service Company.
3. If HEATER Status Lightat the CP-2000turns off before spa attains the maximum
temperature of 104" F,the Controller may need a calibration adjustment.
SPA DRAINS OR OVERFLOWS :
1. At the W-10,check that FLOWCONTROL Switch is not in "FILL"or "DRAIN" position.
2. Check that cables have not been unplugged from Valve Operators.
SPA WATER LEVELDROPS SLOWLY :
1. Valves may needservicing.
CONTROLLER
Installed in a convenient location inside your house,the CP-2000 CONTROLLER gives you
fingertip control of all the equipment associated with your swimming pool and spa.
TIME CONTROL '(; CP-2000 2)
rllrER CLVR $PA AUXI
i
--
TIME CONTROL :
The Controller houses an electronic time clock for programmingthe daily operating
cycles of your poolequipment.
There are four Equipment Buttonswhich are used for turning the equipment ON and OFF:
FILTER Button: Activates filter pumpand circulates water for pool filtration.
Enables poolto be heated.
CLNR Button: Activates pool cleaner (after
4 minute delay),and also filter pump if
FILTER Button is not already switched ON.
SPA Button: Activates filter pumpand rotatesvalves to spa circulation. Enables spa to
be heated. Disablesthe CLNR Button and turns poolcleaner OFF.
AUX
1 Button: Activates auxiliary equipment (suchas spa light).
The PROGRAM, HOURSand MINUTES Buttonsare used for setting the Clock and for
programming the daily operation of the pool equipment. (See Page
8).
The DELAY CANCEL Wonis used to override the "Filter Pump Off Delay" or "Pool
Cleaner On Delay"circuits (for testing and servicing purposes only).
REMOTE CONTROL :
Additional remotecircuits may have been added to your system to control more auxiliary
equipment (such as a pool light, air blower,jet pump,waterfall, etc.)
Note: Thesefunctions are not wntrolled bythe Programmable
Clock.
STATUS DISPLAY :
Status Lightsare provided for the various pieces of equipment controlled by the CP-2000.
The presence of a light indicates that the equipment has been activated. The absence of
a light indicates that the equipment is turned off.

REMOTE CONTROLS
SPA-SIDE REMOTE :
One or more 4-button waterproof Remote Controls (calledSUPERSWITCH) may be
located at your spa.
This will enable you to override the CP-2000Controller, and act~vateyour spa equipment
from the convenience of the sDa. It is ~ossibleto control the followine eaui~mentfrom
the Spa-side Remote Control
:
1. SPA Activates the filter pump,rotates valves to spa
circulation,and enables the spa to be heated.
(Overrides SPA Equipment Button at CP-2000).
2. AUX 1. Activatesauxiliary equipment such as spa light.
(OverridesAUX 1 Equipment Button at CP-2000).
3. AUX2. Activates auxiliary equipment such as pool light.
(OverridesAUX 2 Equipment Button at CP-2000).
4. AUX
3. Activatesauxiliary equipment such as air blower
(OverridesAUX 3 Equipment Button at CP-2000).
5. AUX 4. Activates auxiliary equipment such as jet pump.
AUX 4cannot be controlled from the CP-2000.
If an optional Expansion Module (model MOD-BOOST)has
been installed,it is additionally possibleto activate the following features from the
Spa-side Remote Control
:
6. HEAT BOOST. Overrides the spa thermostat, and activates the spa heater for a five
minute period. If the filter pump is not running,
th~sbutton will be inactive.
7. AUX 5. Activatesauxiliary equipment such as landscape lights.
8. AUX6. Activatesauxiliary equipment such as a fountain. This feature is only possible
if a pool cleaner valve is used, and there is no two-speed filter pump or electric heater
being used.
Astatus light is located in the center of each Spa-side Remote Control.
If an optional Status Light Module (modelMOD-SS4)has been installed,this light will
indicate either:
1)whenever the heater is enabled, or 2) whenever the spa is being circulated.
INDOOR REMOTE :
Your system may include a 3-button or 6-button lndoor Remote Control,which enables
you to operate the spa and auxiliary equipment from another remote location inside your
house. These lndoor Remotes include a status light for each piece of equipment.
The lndoor Remote Controlsare also available with a Digital Temperature Display, which
will additionally enable you to monitor your pool and spa temperatures from a convenient
indoor location.
OUTDOOR REMOTE :
The 3-buttonRemote (with status lights) is also available with a hinged raintight cover for
mounting inan outdoor location.
UNUSED PROGRAM STEPS :
Our sample program utilizes all six programs steps. However your personal program
may only require that you use three or four of the available program steps. In this event,
we recommend that you disable all unused proaram steps.
. -
To accomplish this, push PROGRAM Button
until unused program is displayed.
Pushand hold down HOURSand MINUTES
Buttons at the same time, and then release
simultaneously.
"OFF'will appear on the Display.
To reactivate any disabled program step,
simply push HOURSButtononce.
"OFF'will disappear, and the Clock can then
be programmed.
I 4
TIME CONTROL
I
WmI CUll SPA AUXq
. 4
REVIEWING PROGRAM :
After programming is complete, it is possible to rapidly advance the Clock through a 24
hour period in order to review your program.
Make sure that Clock is in Time Mode.
Push and hold down HOURSand MINUTESButtons at the same time, and then release
simultaneously.
The Clock will rapidly advance through your program, step by step, and the appropriate
STATUS DISPLAY Lights will turn ON and OFF as each program step is activated.
When the review is complete, the Clock will automatically return to the correct time of day
and will also return all equipment to its previous status.
DELAY CANCEL:
For testing and trouble-shooting purposes, occasionally jt may be necessary to
temporarily override the built-in"Filter Pump Off Delay"or "Pool Cleaner On Delay"
circuits.
To do this, simply pushthe DELAY CANCEL Button.
The Delay will automatically reoccur the next time the filter pump turns off or the pool
cleaner turns on.
TELEPHONE REMOTE :
If your system incorporates a Telephone Module (modelMODPHONE), it is possible to
accessthe control system and activate the equipment from any touch-tone phone.
Consult the MOD-PHONEManual for details.

CUSTOM CLOCK OPTIONS SERVICE CENTER
The standard CP-2000Controller is provided with the appropr~ateequipment interlock
and safety delays, and enables you to enter a total of six program steps.
Your Pool Builder may, however, have incorporated one or more of the following custom
features
:
COUNTDOWN TIMER :
This feature enables you to preset a 10 minute operating cycle for any piece of
equipment (FILTER,CLNR,SPA or AUX1).
Whenever that equipment is activated, it will run for 10 minutes and then it will
automatically switch off.
To better understand this feature, let us look at a typical application
:
For example, we are using the AUXl circuit to activate a spa jet pump,and we would like
the jets to run for a period of 10 minutes whenever they are activated.
Push PROGRAMButtonto put Clock into
Program Mode.
"PROGwill appear on the right of the Display.
Continue to push PROGRAME3utton until a
flashing "TIMER' appears.
Push the MINUTES httononce.
"0:10' will appear on the Display.
Push appropriate Equipment htton(AUX 1in
our example).
"ON"will appear directly above Equipment
Button
Push PROGRAM Buttonto lock-inthe program
I .
TIME CONTROL
OFF OFF OFF
WEl CU SPA AUXI
ADDITIONALAUXILIARY CONTROL :
If your Control System does not utilize a pool cleaner, your Pool Builder may have
overridden the built-in Pool Cleaner Protection Circuits, so that the CLNR Equipment
Buttoncan be used to activate an additional auxiliary function (such as landscape
lighting).
In this instance, the equipment will turn on
immediately (no
4 minute ON delay),and the
filter pump will not besimultaneously
activated.
I *
TlME CONTROL
CTr1.n CLM SPA AUX1
\
PROGRAMLOCK :
To safeguard against someone accidentally pushing the PROGRAMhttonand
inadvertently tampering with your daily program, your Pool Builder may have included a
Program Lock feature.
In this instance, you will need to push the PROGRAMButton quickly twice in order to put
the Clock into Program Mode.
Located in close proximityto your pool and spa equipment. the LX-10 SERVICE CENTER
provides your Pool Serviceperson with manual control of the system without having to
gain access to the CP-2000Controller.
CAUTION: To prevent possible water damage, the door of the U(-10 must be kept closed
at all times.
Equipment Service Switches are located inthe left-sidecompartment.
There are no user-serviceable components located behind service panel in the right-side
compartment.
Do not removeservice panel. Refer service to qualified personnel only.
SYSTEM CONTROL :
..,I", "0 1111 ,PI
This Switch should be kept in the "AUTO" position
for normal system operation.
The "SERVICE"position will disable the CP-2000
Controller and provide your Pool Serviceperson
with complete manual-overridecapability of all
pool equipment.
MANUALCONTROL :
Separate Service Switches are provided for
activating the filter pump,pool cleaner, and
auxiliary
1 circuit (lights,jet pump,etc.).
However,the SYSTEMCONTROL Switch must be
inthe "SERVICE"position before these Switches
can be turned ON.
Note: Always return MANUAL CONTROLSwitches
tothe 'OFF position after equipment has been
serviced.
FLOW CONTROL :
To enable this Switch,the SYSTEMCONTROL
Switch must be in the "SERVICE"position.
The "POOLand "SPApositions will automatically
rotate the motorized valves to the appropriate
water circulation.
The "FILLand "DRAIN"positions are used when
cleaning the spa. (See page 16).
Note:
It isadvisabletoreturn FLOWCONTROL
Switch
to 'POOL' positionafter use.
SYSTEM CONTROL
IWIIC" MYIS I/ I" IIR" Cl .OII1I"* 3"
0,lSAll ,,o1co*,.01 .*D *.I"., L"*IIDL l. Illt5
tOUlPMEN1 UNDER
COMPUTER CONTROL
EOUIPMENT UNDER
MANUAL CONlPOl
I,,,,,, <O*ISYL *",I
B, 8" ,,.",<, PO, I,*"
SOLAR CONTROL :
This Switch should be kept in the "AUTO" position for normal system operation.
The "OFFand "ON" positions provide manual-override of your solar system, and should
be usedfor servicing and testing purposes only.
OUTDOOR REMOTES :
This Switch should be kept inthe "ON' position for normal system operation.
The "OFF"position will disable any optional Remote Controls which may have been
added to your system.
This feature is particularly convenient if your system includes a Spa-side Remote Control,
and you wish to prevent the unauthorized use of your spa while you are away from home.

PROGRAMMING INSTRUCTIONS
The CP-2000Controller houses a 24 hour Clock with a digital display, which can be used
to program daily pool filtration, cleaning, and other auxiliary functions such as pool and
spa lights. It can also be used to program and preheat your spa. so that it is ready for
use when you arrive home.
The Clock hastwo operating modes:
1. TlME MODE :
In Time Mode (normaloperation), the Clock will display the actual time of day, and
"TIME'will appear on the right of the Display.
While the Clock is in Time Mode,the poolequipment can be manually activated by
simply pushing the appropriate EquipmentButton (FILTER,CLNR, SPA or AUXI).
This will temporarily override any preset program which may be in effect.
2. PROGRAMMODE :
In order to preselect daily filtration cycles, pool cleaning, spa use,and an auxiliary
function (suchas spa light),the Clock must be switched to Program Mode.
To achieve this, push PROGRAM Button once.
Whenever Clock is in Program Mode, "PROGwill appear on the right of the Display.
After programming iscomplete, the Clock will automatically return to Time Mode.
SETTING THE CLOCK
If the Clock is not already in Time Mode,push PROGRAMButton until "TIME appears on
the right of the Display.
This indicates that the Clock is in Time Mode.
Push the HOURSand MINUTESButtons until
A 1
the correct time of day is displayed
Payspecial attention to the AM/PM indicator.
PROGRAMMINGDAILY OPERATING CYCLES :
Programming the daily operating cycles of your pool equipment is a "set and forget"
procedure,which is normally implemented by your Pool Builder at the completion of the
installation.
Most systems only requirethat you program the filtration and (in some cases) the
cleaning cycles of the pool. However, it is possible to program the spa (if you plan to use
it at the same time every day),and also AUXl (if you are using this circuit to activate
lights or some other equipment which you wish to operate at the same times every day).
It is possible to preset six program steps during a 24 hour period.
Each of the six steps can be used for turning equipment ON or OFF.
Morethan one piece of equipment can be turned ON or OFF at each program step.
However,to turn the same piece of equipment ON and OFF requires two program steps
Oncethe programming is complete, the pool and spa equipment will operate at the
same times every day.
Before commencing programming, itisadvisableto determine at what time you would
likethe equipment to turn on, andfor how longyou would like each pieceof equipment
to run.
To better understandthe programming sequence, let's follow a sample program,step by
step. For demonstration purposes, our example assumes that we would like to activate
all four pieces of equipment on a daily basis, as follows
:
Filter the poolfrom 7:00 am until 12:00 pm.
Turnthe poolcleaner on from 10:00 amuntil 12:00pm.
Turn the spaonfrom 6:30 pmuntil8:00 pm.
Turn auxiliary 1 (spa light) onfrom 6:30 pmto 10:00 pm.
To begin programming,push PROGRAMButtononce.
"PROG 1"will appear on the right of the Display. This indicates that the Clock is in
Program Mode,and that the first oroaram step is readv to be entered.
~nterthe first program time (7:00'aminour
'
example) by pushing the HOURSand
MINUTES Buttons.
In Program Mode, minutes are advanced in
ten minute increments.
Push FILTEREquipment Button.
"ONshould appear directly above FILTER
Button.
If "ON" isdisplayed above any of the other
EQUIPMENTButtons, push appropriate Button
once, and "OFF'will appear.
You have now completed the first program step.
In order to lock-in the program,simply push the PROGRAM Button once
# b
TlME CONTROL
PROGRAM
7.)-4)-4AMPRffi :
OFF OFF
t
"PROG 2" will now appear on the right of the Display. This indicates that the second
program step is readyto be entered.
Enterthe second program time (10:OO am) by
pushing the HOURSand MINUTESButtons.
Push CLNR EquipmentButton.
"ONshould appear directly above CLNR
Button.
In our example, at 10:OO amthe filter pump
should still be running. However, itwill not be
necessaryto push the FILTEREquipment
Mon,because the built-in protection circuit
will automatically activate the filter pump
whenever the pool cleaner ison.
Make sure that "OFF' is still displayed above SPA and AUXl Equipment Buttons.
Push PROGRAMButton to lock-in the program.
# 9
TlME CONTROL
PRO-A"
RLTIR CUM SPA AUX1
4 I

"PROG 3 will now appear on the r~ghtof the Display. This indicatesthat the third
program step is ready to be entered.
Enter the third program time (12:OO pm)by
pushing the HOURSand MINUTES Buttons
Payspecial attention to the AM/PM indicator.
In our example, at 12:OO pmthe filter pump
and pool cleaner should turn off.
Make sure that "OFF' isdisplayed above each
Equipment Button.
You have now completed the third program step
Push PROGRAMButton to lock-in the program.
r 9
TlME CONTROL
FILTER CLMR SPA AUXI MINUTES
+ I
"PROG 4 will now appear on the right of the Display. This indicatesthat the fourth
program step is ready to be entered.
Enter the fourth program time (6:30pm)by
pushing the HOURSand MINUTESButtons.
In our example, at 6:30 pmthe spa and
auxiliary 1 (spa light) should turn on.
Push SPA Equipment Button.
"ONshould appear directly above the SPA
and FILTER Buttons.
Push AUXl Equipment Button.
"ON' should appear above AUXl Button
You have now completed the fourth program
step.
Push PROGRAMButton to lock-inthe program.
# 4
TlME CONTROL
RUIR CUR SPA AUXt
I
"PROG5"will now appear on the right of the Display. This indicates that the fifth
program step is ready to be entered.
Enter the fifth program time (8:OO pm)by
pushing the HOURSand MINUTES Buttons.
In our example,we would like to turn off the
spa at 8:00pm, but the spa light (AUX 1)
should still be on.
Push AUX 1Equipment Button.
"ON" will appear above AUXl Button.
You have now completed the fifth program step.
Push PROGRAMButton to lock in the program
# 9
TlME CONTROL
CfF OFF OFF
---•
RLTSR CLWR SPA AUXI
. I
"PROG 6 will now appear on the right of the Display. This indicatesthat the sixth
program step is ready to be entered.
Enter the sixth program time (10:OO pm) by
pushing the HOURSand MINUTES Buttons.
In our example, all of the equipment should be
turned off at 10:OO pm.
Therefore, make sure that "OFF'isdisplayed
above all of the Equipment Buttons.
To lock-inthe program and return Clock to
Time Mode, simply push the PROGRAM
Buttononce.
If this isforgotten, the Clock will automatically
returntoTime Mode after two minutes.
. 9
TIME CONTROL
RUII CU SPA AUX1
\ I
SYSTEM OPTIONS
TWO SPEED PUMP CONTROL :
If your system incorporates a Two Speed Filter Pump, the CP-2000has been designed to
provideyou with the maximum energy-efficient usage of this feature.
Although your Pool Builder may have adjusted the two speed control circuitry to your
specific requirements,the CP-2000typically switches the pumpto high speed under any
of the following conditions:
1. Fortwo minuteswhen the filter isfirst turned on. This features establishes proper flow
through the system, and packs the filter grids. After two minutes, the pump will
automatically switch to low speed.
2. Wheneverthe poolcleaner isrunning. This provides sufficient flow for the pool
cleaner to operate effectively.
3. During spa operation to increasethe jet action.
4. Wheneverthe heater ison. This feature will conserve energy by bringing your pool
and spa up to the desired temperature more quickly.
5. Whenever your solar system isoperating. This provides high flow rate through your
solar panels,which ensures the most efficient usage of the available solar energy.
SPA WATERFALL CONTROL :
If your spa water level is elevated above that of the pool,your Pool Builder may have
included a Spa Waterfall Control (model RLY-WRFL).
With this feature, you can circulate the pool water back to the spa, creating an overflow
(waterfall effect) from the spa to the pool. This effect will cease during spa circulation.
Depending upon which circuit has been used to connect the Spa Waterfall Control,either
the AUX1. AUX2 or AUX3 Button will activate this feature.
FREEZE PROTECTION :
Recirculating Freeze Sensors (modelFPSC)may have been added to your system.
These Sensors protect the plumbing and equipment from possible freeze damage by
running the filter pump whenever the temperature falls to approximately 41" F.
Similarly,Auxiliary Pump Freeze Sensors (modelFPSAUX) may have been added to
activate auxiliary equipment (such as a fountain or jet pump) during freezing conditions.
CAUTION
: FreezeSensorswill not provide circulation of water through your solar panels.
Solar freeze protection must be accomplished by draining the panels. (See below).
SOLAR PANELDRAINDOWN :
Ifyour control system incorporatessolar heating, it is advisable that a draindown feature
be included to protect the solar panels against potential freeze damage.
For conventional solar systems which permit gravity drainage of panels, the Compool
Solar Valve with built-in check valve (model SOL-2T)will automatically drain the panels
whenever the solar turns off and the filter pump is not running.
For solar systems with glazed panels. damage can occur from overheating ifthe solar
turns off and the filter pumw is still running.
In this instance, a motorized Draindown Valve (modelHW-5B)should be plumbed at the
solar feedline. This will automatically drain the panels whenever the solar is turned off,
even if the filter pump is still running.
This feature may also be incorporated if your solar system does not facilitate gravity
drainage of panels,or where panels are located below pool water level.
Consultyour Solar Companyfor moredetails.
