Preface
This manual provides information related to the installation and operation of this
device. The individual reading this manual is presumed to have a basic
understanding of telecommunications terminology and concepts.
If you find the product to be inoperable or malfunctioning, please contact technical
support for immediate service by email at INT[email protected]
For product update, new product release, manual revision, or software upgrades,
please visit our website at http://www.comtrend.com
Important Safety Instructions
With reference to unpacking, installation, use, and maintenance of your electronic
device, the following basic guidelines are recommended:
• Do not use or install this product near water, to avoid fire or shock hazard. For
example, near a bathtub, kitchen sink or laundry tub, or near a swimming pool.
Also, do not expose the equipment to rain or damp areas (e.g. a wet basement).
• Do not connect the power supply cord on elevated surfaces. Allow it to lie freely.
There should be no obstructions in its path and no heavy items should be placed
on the cord. In addition, do not walk on, step on, or mistreat the cord.
• Use only the power cord and adapter that are shipped with this device.
• To safeguard the equipment against overheating, make sure that all openings in
the unit that offer exposure to air are not blocked.
• Avoid using a telephone (other than a cordless type) during an electrical storm.
There may be a remote risk of electric shock from lightening. Also, do not use
the telephone to report a gas leak in the vicinity of the leak.
• Never install telephone wiring during stormy weather conditions.
CAUTION:
 To reduce the risk of fire, use only No. 26 AWG or larger
telecommunication line cord.
 Always disconnect all telephone lines from the wall outlet before servicing
or disassembling this equipment.
WARNING
 Disconnect the power line from the device before servicing.
 Power supply specifications are clearly stated in Appendix C -
Specifications.

2
FCC & ISED
User Information
Any changes or modifications not expressly approved by the party responsible for
compliance could void your authority to operate the equipment.
Aucune modification apportée à l’appareil par l’utilisateur, quelle qu’en soit la
nature. Tout changement ou modification peuvent annuler le droit d’utilisation de
l’appareil par l’utilisateur.
Note: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
—Consult the dealer or an experienced radio/TV technician for help.
This Class B digital apparatus complies with Canadian ICES-003.
To reduce potential radio interference to other users, the antenna type and
its gain should be so chosen that the equivalent isotropically radiated power
(e.i.r.p.) is not more than that permitted for successful communication.
This device complies with Industry Canada licence-exempt RSS standard(s).
Operation is subject to the following two conditions:
1. This device may not cause interference, and
2. This device must accept any interference, including interference that may
cause undesired operation of the device.
Cet appareil numérique de la classe B est conforme à la norme NMB-003
Canada.
Pour réduire le risque d’interférence aux autres utilisateurs, le type d’antenne
et son gain doivent être choisies de façon que la puissance isotrope
rayonnée équivalente (PIRE) ne dépasse pas ce qui est nécessaire pour une
communication réussie.
Cet appareil est conforme à la norme RSS Industrie Canada exempts de licence
norme(s). Son fonctionnement est soumis aux deux conditions suivantes:
1. Cet appareil ne peut pas provoquer d’interférences et
2. Cet appareil doit accepter toute interférence, y compris les interférences
qui peuvent causer un mauvais fonctionnement du dispositif.

3
Radiation Exposure
FCC ID: L9VNL3240U
IC: 4013C-NL3240U
US: 5SYDL01ANL3240U
REN: 0.1A
FCC
1. This Transmitter must not be colocated or operating in conjunction with any
other antenna or transmitter.
2. This equipment complies with FCC RF radiation exposure limits set forth for an
uncontrolled environment. This
equipment should be installed and operated with a minimum distance of 20
centimeters between the radiator and your
body.
ISED
This device complies with the ISED radiation exposure limit set forth for an
uncontrolled environment. This device should be installed and operated with
minimum distance 20cm between the radiator & your body. This transmitter must
not be co-located or operating in conjunction with any other antenna or
transmitter.
Cet équipement est conforme avec l'exposition aux radiations ISED définies pour
un environnement non contrôlé. Cet équipement doit être installé et utilisé à une
distance minimum de 20 cm entre le radiateur et votre corps. Cet émetteur ne doit
pas être co-localisées ou opérant en conjonction avec une autre antenne ou
transmetteur.
Operations in the 5.15-5.25Ghz band are restricted to indoor usage only.
Le fonctionnement sur la bande 5,15–5,25Ghz est limité à une utilisation
intérieure uniquement.
This radio transmitter (identify the device by certification number) has been
approved by Industry Canada to operate with the antenna types listed below with
the maximum permissible gain indicated. Antenna types not included in this list,
having a gain greater than the maximum gain indicated for that type, are strictly
prohibited for use with this device.
Model Name: AN2450-64D03BBF
Type: External
Gain:
2.4G: 1.2 dBi
5G: 2.5 dBi
Model Name: AN2450-64D02BBF
Type: External
Gain:

4
2.4G: 2.5 dBi
5G: 2.5 dBi
The REN statement is the following:
"The Ringer Equivalence Number (REN) indicates the maximum number of devices
allowed to be connected to a telephone interface. The termination of an interface
may consist of any combination of devices subject only to the requirement that the
sum of the RENs of all the devices not exceed five."
Copyright
Copyright©2016 Comtrend Corporation. All rights reserved. The information
contained herein is proprietary to Comtrend Corporation. No part of this document
may be translated, transcribed, reproduced, in any form, or by any means without
prior written consent of Comtrend Corporation.
This program is free software: you can redistribute it and/or modify it under the
terms of the GNU General Public License as published by the Free Software
Foundation, either version 3 of the License, or (at your option) any later version.
This program is distributed in the hope that it will be useful, but WITHOUT ANY
WARRANTY; without even the implied warranty of MERCHANTABILITY or FITNESS
FOR A PARTICULAR PURPOSE. See the GNU General Public License for more
details.
You should have received a copy of the GNU General Public License
along with this program. If not, see http://www.gnu.org/licenses/
NOTE: This document is subject to change without notice.
Protect Our Environment
This symbol indicates that when the equipment has reached the end of
its useful life, it must be taken to a recycling centre and processed
separate from domestic waste.
The cardboard box, the plastic contained in the packaging, and the parts that make
up this router can be recycled in accordance with regionally established regulations.
Never dispose of this electronic equipment along with your household waste; you
may be subject to penalties or sanctions under the law. Instead, please be
responsible and ask for disposal instructions from your local government.

5
Table of Contents
CHAPTER 1 INTRODUCTION...........................................................................................................8
CHAPTER 2 INSTALLATION.............................................................................................................9
2.1 HARDWARE SETUP...........................................................................................................................9
2.2 LED INDICATORS ..........................................................................................................................11
CHAPTER 3 WEB USER INTERFACE............................................................................................13
3.1 DEFAULT SETTINGS .......................................................................................................................13
3.2 IPCONFIGURATION........................................................................................................................14
3.3 LOGIN PROCEDURE........................................................................................................................16
CHAPTER 4 DEVICE INFORMATION...........................................................................................18
4.1WAN.............................................................................................................................................19
4.2 STATISTICS.....................................................................................................................................20
4.2.1LAN Statistics .................................................................................................................20
4.2.2WAN Service...................................................................................................................21
4.2.3XTM Statistics.................................................................................................................22
4.2.4xDSL Statistics................................................................................................................23
4.3 ROUTE...........................................................................................................................................28
4.4ARP...............................................................................................................................................29
4.5 DHCP ...........................................................................................................................................29
4.6 NAT SESSION ................................................................................................................................31
4.7 IGMPINFO....................................................................................................................................32
4.8 IPV6 ..............................................................................................................................................33
4.8.1 IPv6 Info................................................................................................................................33
4.8.2 IPv6 Neighbor .......................................................................................................................34
4.8.3 IPv6 Route.............................................................................................................................35
4.9 CPU &MEMORY...........................................................................................................................36
4.10 NETWORK MAP ...........................................................................................................................37
4.11 WIRELESS ....................................................................................................................................37
4.11.1 Station Info...........................................................................................................................37
4.11.2 Site Survey............................................................................................................................39
CHAPTER 5 BASIC SETUP...............................................................................................................40
5.1WAN SETUP ...................................................................................................................................41
5.1.1 WAN Service Setup ................................................................................................................42
5.2 NAT ..............................................................................................................................................43
5.2.1Virtual Servers................................................................................................................43
5.2.2Port Triggering...............................................................................................................45
5.2.3DMZ Host.......................................................................................................................47
5.2.4 IP Address Map...............................................................................................................48
5.2.5 ALG/Pass-Through.........................................................................................................49
5.3 LAN..............................................................................................................................................50
5.3.1 LAN IPv6 Autoconfig.............................................................................................................53
5.3.2 Static IP Neighbor.................................................................................................................56
5.3.3 UPnP.....................................................................................................................................57
5.4WIRELESS......................................................................................................................................58
5.4.1 Basic 2.4GHz.........................................................................................................................58
5.4.2 Security 2.4GHz.....................................................................................................................60
5.4.3 Basic 5GHz............................................................................................................................62
5.4.4 Security 5GHz........................................................................................................................63
5.5 PARENTAL CONTROL .....................................................................................................................64
5.5.1Time Restriction..............................................................................................................64
5.5.2URL Filter.......................................................................................................................65
5.6 HOME NETWORKING......................................................................................................................67
5.6.1 Print Server ...........................................................................................................................67
5.6.2 DLNA.....................................................................................................................................67
5.6.3 Storage Service......................................................................................................................68
5.6.4 USB Speed.............................................................................................................................69

6
CHAPTER 6ADVANCED SETUP.....................................................................................................70
6.1AUTO-DETECTION SETUP ...............................................................................................................70
6.2 SECURITY ......................................................................................................................................75
6.2.1IP Filtering.....................................................................................................................75
6.2.2 MAC Filtering.................................................................................................................79
6.3 QUALITY OF SERVICE (QOS)..........................................................................................................81
6.3.1QoS Queue......................................................................................................................82
6.3.1.1QoS Queue Configuration ..............................................................................................82
6.3.1.2Wlan Queue ....................................................................................................................86
6.3.2 QoS Classification..........................................................................................................87
6.3.3 QoS Port Shaping...........................................................................................................89
6.4 ROUTING .......................................................................................................................................90
6.4.1Default Gateway.............................................................................................................90
6.4.2Static Route.....................................................................................................................91
6.4.3Policy Routing ................................................................................................................92
6.4.4RIP..................................................................................................................................93
6.5 DNS..............................................................................................................................................94
6.5.1DNS Server.....................................................................................................................94
6.5.2Dynamic DNS.................................................................................................................95
6.5.3 DNS Entries....................................................................................................................96
6.5.4 DNS Proxy/Relay............................................................................................................97
6.6 DSL...............................................................................................................................................98
6.7 DSLBONDING...............................................................................................................................99
6.8 INTERFACE GROUPING.................................................................................................................100
6.9 IPTUNNEL...................................................................................................................................103
6.9.1 IPv6inIPv4...........................................................................................................................103
6.9.2 IPv4inIPv6...........................................................................................................................104
6.10 CERTIFICATE..............................................................................................................................105
6.10.1Local.............................................................................................................................105
6.10.2Trusted CA....................................................................................................................107
6.11 POWER MANAGEMENT ..............................................................................................................108
6.12 MULTICAST ...............................................................................................................................109
6.13WIRELESS..................................................................................................................................111
6.13.1 Basic 2.4GHz..................................................................................................................... 111
6.13.2 Security 2.4GHz.................................................................................................................113
6.13.3 WPS 2.4GHz......................................................................................................................116
6.13.4 MAC Filter 2.4GHz ...........................................................................................................119
6.13.5 Wireless Bridge 2.4GHz.....................................................................................................121
6.13.6 Advanced 2.4GHz..............................................................................................................122
6.13.7 Basic 5GHz........................................................................................................................125
6.13.8 WPS 5GHz.........................................................................................................................126
6.13.9 MAC Filter 5GHz ..............................................................................................................128
6.13.10 Advanced 5GHz...............................................................................................................129
CHAPTER 7 VOICE..........................................................................................................................130
7.1 SIPBASIC SETTING –GLOBAL PARAMETERS...............................................................................131
7.2 SIPBASIC SETTING –SERVICE PROVIDER ...................................................................................132
7.3 SIPADVANCED SETTING –GLOBAL PARAMETERS.......................................................................135
7.4 SIPADVANCED SETTING –SERVICE PROVIDER ...........................................................................136
7.5 SIPDEBUG SETTING –GLOBAL PARAMETERS.............................................................................139
7.6 SIPDEBUG SETTING –SERVICE PROVIDER..................................................................................140
7.7 TELEPHONE CALLS......................................................................................................................141
CHAPTER 8 DIAGNOSTICS...........................................................................................................143
8.1 DIAGNOSTICS –INDIVIDUAL TESTS .............................................................................................143
8.2 ETHERNET OAM.........................................................................................................................144
8.3 UPTIME STATUS ...........................................................................................................................146
8.4 PING ............................................................................................................................................147
8.5 TRACE ROUTE .............................................................................................................................148
CHAPTER 9 MANAGEMENT ........................................................................................................149
9.1 SETTINGS.....................................................................................................................................149

7
9.1.1Backup Settings.............................................................................................................149
9.1.2Update Settings.............................................................................................................150
9.1.3Restore Default.............................................................................................................150
9.2 SYSTEM LOG ...............................................................................................................................152
9.3 SNMPAGENT .............................................................................................................................154
9.4 TR-069 CLIENT ...........................................................................................................................155
9.5 INTERNET TIME ...........................................................................................................................157
9.6ACCESS CONTROL .......................................................................................................................158
9.6.1 Accounts ...........................................................................................................................158
9.6.2 Services.............................................................................................................................160
9.6.3 IP Address.........................................................................................................................161
9.7WAKE-ON-LAN...........................................................................................................................162
9.8 UPDATE SOFTWARE .....................................................................................................................163
9.9 REBOOT.......................................................................................................................................164
CHAPTER 10 LOGOUT...................................................................................................................165
APPENDIX A - FIREWALL .............................................................................................................166
APPENDIX B - PIN ASSIGNMENTS..............................................................................................169
APPENDIX C – SPECIFICATIONS................................................................................................170
APPENDIX D - SSH CLIENT ..........................................................................................................172
APPENDIX E - PRINTER SERVER................................................................................................173
APPENDIX F- CONNECTION SETUP..........................................................................................179

8
Chapter 1 Introduction
NexusLink 3240 is a Multi-DSL bonding solution with optional VoIP service (FXS
port x2) for high-performance Internet access. In addition, NexusLink 3240
supports high power (400mw) dual bands (802.11n 2.4GHz & 802.11ac 5GHz) to
create a large Wi-Fi footprint for the most seamless video experience as well as
blazing fast data speed.

9
Chapter 2 Installation
2.1 Hardware Setup
Follow the instructions below to complete the hardware setup.


Non-stackable
This device is not stackable – do not place units on top of each other, otherwise
damage could occur.
BACK PANEL
The figure below shows the back panel of the device.
Power ON
Press the power button to the OFF position (OUT). Connect the power adapter to the
power port. Attach the power adapter to a wall outlet or other AC source. Press the
power button to the ON position (IN). If the Power LED displays as expected then
the device is ready for setup (see section 2.2 LED Indicators).
Caution 1: If the device fails to power up, or it malfunctions, first verify that the
power cords are connected securely and then power it on again. If the
problem persists, contact technical support.
Caution 2: Before servicing or disassembling this equipment, disconnect all power
cords and telephone lines from their outlets.
Reset Button
Restore the default parameters of the device by pressing the Reset button for 10
seconds. After the device has rebooted successfully, the front panel should display
as expected (see section 2.2 LED Indicators for details).
NOTE: If pressed down for more than 60 seconds, the NexusLink 3240 will go
into a firmware update state (CFE boot mode). The firmware can then
be updated using an Internet browser pointed to the default IP address.

10
Phone Ports
For VoIP service, connect telephone(s) to these ports with RJ11 cables.
ETH WAN PORT
This port has the same features as the LAN ports described below with additional
Ethernet WAN functionality.
Ethernet (LAN) Ports
Use 1000-BASE-T RJ-45 cables to connect up to four network devices to a Gigabit
LAN, or 10/100BASE-T RJ-45 cables for standard network usage. These ports are
auto-sensing MDI/X; so either straight-through or crossover cable can be used.
USB Host Port (Type A)
This port can be used to connect the router to a printer, or supported USB devices.
DSL Port
Connect to an ADSL2/2+ or VDSL with this RJ11 Port. This device contains a micro
filter which removes the analog phone signal. If you wish, you can connect a
regular telephone to the same line by using a POTS splitter.
FRONT PANEL
2.4G WiFi On/Off & WPS Button
Press and release the WiFi-WPS button to activate WPS for the 2.4GHz WiFi
interface (make sure the WPS is enabled in Wireless->2.4GHz->Security page).
Press and hold WiFi-WPS button more than 10 seconds to enable/disable 2.4GHz
WiFi.
5G WiFi On/Off & WPS Button
Press and release the WiFi-WPS button to activate WPS for the 5GHz WiFi interface
(make sure the WPS is enabled in Wireless->5GHz->Security page).
Press and hold WiFi-WPS button more than 10 seconds to enable/disable 5GHz WiFi.

11
2.2 LED Indicators
The front panel LED indicators are shown below and explained in the following table.
This information can be used to check the status of the device and its connections.
LED Color Mode Function
POWER
GREEN On The device is powered up.
Off The device is powered down.
RED On
POST (Power On Self Test) failure or other
malfunction. A malfunction is any error of internal
sequence or state that will prevent the device from
connecting to the DSLAM or passing customer data.
PHONE 1 GREEN On An FXS port is off hook.
Off An FXS port is on hook.
PHONE 2 GREEN On An FXS port is off hook.
Off An FXS port is on hook.
ETH WAN
GREEN On WAN is connected in 1000 Mbps. Off Ethernet WAN is not connected.
Blink In TX/RX over 1000 Mbps
YELLOW On Ethernet is connected in 10/100 Mbps. Off Ethernet WAN is not connected.
Blink In TX/RX over 10/100 Mbps.
ETH 4 to 1
GREEN On Ethernet is connected at 1000 Mbps. Off Ethernet is not connected.
Blink In TX/RX over 1000 Mbps.
YELLOW On Ethernet is connected at 10/100 Mbps. Off Ethernet is not connected.
Blink In TX/RX over 10/100 Mbps.
WPS
GREEN
On WPS(2.4G) WPS enabled and client connected to
WLAN.
Off WPS(2.4G) WPS disabled.
Blink WPS(2.4G) WPS connection in progress, 120
seconds or until client connected.
YELLOW
On WPS(5G WPS enabled and client connected to
WLAN.
Off WPS(5G) WPS disabled.
Blink WPS(5G) WPS connection in progress, 120 seconds
or until client connected.

12
WiFi
2.4G GREEN
On The wireless module is ready.
(i.e. installed and enabled).
Off The wireless module is not ready.
(i.e. either not installed or disabled).
Blink Data transmitting or receiving over WLAN.
WiFi
5G GREEN
On The wireless module is ready.
(i.e. installed and enabled).
Off The wireless module is not ready.
(i.e. either not installed or disabled).
Blink Data transmitting or receiving over WLAN.
DSL 1 GREEN
On xDSL Link is established.
Off xDSL Link is not established.
Blink The xDSL link is training or some traffic is passing
through xDSL.
DSL 2 GREEN
On xDSL Link is established.
Off xDSL Link is not established.
Blink The xDSL link is training or some traffic is passing
through xDSL.
INTERNET
GREEN
On IP connected and no traffic detected. If an IP or
PPPoE session is dropped due to an idle timeout, the
light will remain green if an ADSL connection is still
present.
Off Modem power off, modem in bridged mode or ADSL
connection not present. In addition, if an IP or
PPPoE session is dropped for any reason, other than
an idle timeout, the light is turned off.
Blink IP connected and IP Traffic is passing thru the
device (either direction)
RED On
Device attempted to become IP connected and
failed (no DHCP response, no PPPoE response,
PPPoE authentication failed, no IP address from
IPCP, etc.)

13
Chapter 3 Web User Interface
This section describes how to access the device via the web user interface (WUI)
using an Internet browser such as Internet Explorer (version 5.0 and later).
3.1 Default Settings
The factory default settings of this device are summarized below.
• LAN IP address: 192.168.1.1
• LAN subnet mask: 255.255.255.0
• Administrative access (username: root, password: 12345)
• User access (username: user, password: user)
• Remote (WAN) access (username: support, password: support)
• WLAN access: enabled
Technical Note
During power on, the device initializes all settings to default values. It will then
read the configuration profile from the permanent storage section of flash memory.
The default attributes are overwritten when identical attributes with different values
are configured. The configuration profile in permanent storage can be created via
the web user interface or telnet user interface, or other management protocols.
The factory default configuration can be restored either by pushing the reset button
for more than ten seconds until the power indicates LED blinking or by clicking the
Restore Default Configuration option in the Restore Settings screen.

14
3.2 IP Configuration
DHCP MODE
When the NexusLink 3240 powers up, the onboard DHCP server will switch on.
Basically, the DHCP server issues and reserves IP addresses for LAN devices, such
as your PC.
To obtain an IP address from the DCHP server, follow the steps provided below.
NOTE: The following procedure assumes you are running Windows. However,
the general steps involved are similar for most operating systems (OS).
Check your OS support documentation for further details.
STEP 1: From the Network Connections window, open Local Area Connection (You
may also access this screen by double-clicking the Local Area Connection
icon on your taskbar). Click the Properties button.
STEP 2: Select Internet Protocol (TCP/IP) and click the Properties button.
STEP 3: Select Obtain an IP address automatically as shown below.
STEP 4: Click OK to submit these settings.
If you experience difficulty with DHCP mode, you can try static IP mode instead.

15
STATIC IP MODE
In static IP mode, you assign IP settings to your PC manually.
Follow these steps to configure your PC IP address to use subnet 192.168.1.x.
NOTE: The following procedure assumes you are running Windows. However,
the general steps involved are similar for most operating systems (OS).
Check your OS support documentation for further details.
STEP 1: From the Network Connections window, open Local Area Connection (You
may also access this screen by double-clicking the Local Area Connection
icon on your taskbar). Click the Properties button.
STEP 2: Select Internet Protocol (TCP/IP) and click the Properties button.
STEP 3: Change the IP address to the 192.168.1.x (1<x<255) subnet with subnet
mask of 255.255.255.0. The screen should now display as shown below.
STEP 4: Click OK to submit these settings.

16
3.3 Login Procedure
Perform the following steps to login to the web user interface.
NOTE: The default settings can be found in section 3.1 Default Settings.
STEP 1: Start the Internet browser and enter the default IP address for the device
in the Web address field. For example, if the default IP address is
192.168.1.1, type http://192.168.1.1.
NOTE: For local administration (i.e. LAN access), the PC running the browser
must be attached to the Ethernet, and not necessarily to the device.
For remote access (i.e. WAN), use the IP address shown on the Device
Information screen and login with remote username and password.
STEP 2: A dialog box will appear, such as the one below. Enter the default
username and password, as defined in section 3.1 Default Settings.
Click OK to continue.
NOTE: The login password can be changed later (see section 9.6.1 Accounts).

17
STEP 3: After successfully logging in for the first time, you will reach this screen.
You can also reach this page by clicking on the following icon located at the top of
the screen.

18
Chapter 4 Device Information
You can reach this page by clicking on the following icon located at the top of the
screen.
The web user interface window is divided into two frames, the main menu (on the
left) and the display screen (on the right). The main menu has several options and
selecting each of these options opens a submenu with more selections.
NOTE: The menu items shown are based upon the configured connection(s) and
user account privileges. For example, user account has limited access to
configuration modification.
Device Info is the first selection on the main menu so it will be discussed first.
Subsequent chapters will introduce the other main menu options in sequence.
The Device Info Summary screen displays at startup.
This screen shows hardware, software, IP settings and other related information.

19
4.1 WAN
Select WAN from the Device Info submenu to display the configured PVC(s).
Heading Description
Interface Name of the interface for WAN
Description Name of the WAN connection
Type Shows the connection type
VlanMuxId Shows 802.1Q VLAN ID
IPv6 Shows WAN IPv6 status
Igmp Pxy Shows Internet Group Management Protocol (IGMP)
proxy status
Igmp Src Enbl Shows the status of WAN interface used as IGMP source
MLD Pxy Shows Multicast Listener Discovery (MLD) proxy status
MLD Src Enbl Shows the status of WAN interface used as MLD source
NAT Shows Network Address Translation (NAT) status
Firewall Shows the status of Firewall
Status Lists the status of DSL link
IPv4 Address Shows WAN IPv4 address
IPv6 Address Shows WAN IPv6 address
