Congratulations on your purchase of laser distance meter CONDTROL XP3.
Safety instructions can be found in the end of this user manual and should be
carefully read before you use the product for the first time.
INTENDED USE
Laser distance meter XP3 is intended to measure distance, to calculate area and
volume of measured objects as well as perform calculations by tilt sensor and
Pythagoras’ Theorem. The product is suitable for use at both indoor and outdoor
building areas.
SET
1. Laser distance meter– 1pc.
2. Carry pouch with a strap - 1 pc.
3. User manual – 1 pc.
4. Batteries (AAA) – 3 pcs.
5. USB charger– 1 pc.
TECHNICAL SPECIFICATIONS
Working range 0,05– 100 m*
Measuring accuracy ± 1,5 mm**
Smallest unit displayed 1 mm
Automatic shutdown
Laser
Instrument
Adjustable
Adjustable
Display backlight +
Reference point setting +
Continuous measurement (tracking) +
Max./min. value +
Addition/subtraction +
Area/volume/triangle area/trapezium area +
Calculations by tilt sensor +
Calculations by Pythagoras’ Theorem +
Digital vial +
Timer +
Memory up to 50 values
Laser type Class II, 635 nm, power <1 mW
Working temperature 0 °С ... +40 °С
Storage temperature –20 °С ... +60 °С
Dust and water protection IP54
Dimensions 136х59х28 mm
Weight 170 g
Power supply 3 х battery AAA 800 mAh 1.2V
Ni-MH
* Use a reflector to increase the measurement range during daylight or if the
target has poor reflection properties.
** Accuracy can decrease in unfavorable conditions, such as intense sunshine or
when measurements are made against glossy or transparent surfaces, moving
objects, objects with rough surface.
In unfavourable conditions or when measured distance is over 100 m the
maximum permissible accuracy is calculated in the following way:
± (Y + 0,25хDх10-3) mm, where
D (mm) - measured distance
Y (mm) - permissible accuracy according to technical data.
