Connection Cubbi User manual

Cubbi
Assembly Instructions
connection.uk.com

Assembly Instructions
Cubbi Assembly
The Cubbi product is delivered to you in component form. Before starting the assembly please separate the
boxes into each finished piece.
The labels on the boxes identify the finished piece that the components relate to, SCE..., etc.
The process to assemble the units starts from the floor up and the following images will assist.
The fixings needed for the generic pieces of Cubbi are contained in fixings kits included with the product. All
fixings will be located in a box marked as such. Please note as this is a general fixing kit, parts made be left
over after assembly for your specific piece.
Cubbi can be specified in either bench or task chair variant, with a number of positions, and the choice of this
determines the assembly method used.
The first step in any configuration is the assembly of the Cubbi screens.
The Cubbi screens come in various sizes dependant
on the unit specified. On all units the process is
the same.
1 With the screens unwrapped attach the fixing
plates to ends of the screens.
2 The screens are then placed parallel to each
other and the fixings secured into place. Please
note that depending on the fabric the unit is
upholstered in, the pin will need to be screwed in
further to ensure the join is tight.
3 Once the units have been joined tightly they are
secured by the addition on a foot rail to the base
on the screen. These are secured using the M8
button head bolts.
4 Once attached the foot rails will hold the
completed screens together and these can then
be set aside for use later.
Specifications ordered
Assembly of Cubbi screens
Preparation
1
2 3 4

Assembly Instructions
Cubbi Assembly
Depending on the configuration chosen the benches will either be single or double sided.
The Task chair option utilises plinths to create divisions
between the seating positions.
1 Attach the foot plate and adjustable foot to the
base of the unit and secure with M8 button head
bolts. These are positioned at either end of
the unit.
2 The plinth is now complete, and can be set aside.
Please note that any power cables should be
feed through the plinth before assembly.
1 With the back unit inverted attach the leg rails to
the units using the M8 button head bolts.
2 With the foot rails attached to both ends of the
back, offer up the bench unit and secure with M8
button head bolts.
3 The unit can now be placed upright and stored to
one side.
Assembling the base and back where specified
Bench variant Cubbi
Task chair variant Cubbi
2
2
3
1
1

Assembly Instructions
Cubbi Assembly
The image above shows the format of the linking
piece without the screen supports
Irrespective of the variant the middle and separating screens are attached in the same way.
1 Insert the screen supports into the glides at the ends of the back or plinth units. Note that the arrow on
the support needs to point downwards. When in position the support will click into the holder in the
back/plinth.
2 Position the backs/plinths into the configuration required. This will be dependent on the configuration you
have chosen.
3 Place the aluminium workrails over the screen supports.
4 When joining two workrails together, they are linked by inserting joining piece between the two workrails. A
carriage bolt is then passed through the linked piece into a nut, to hold the join securely.
5 If the workrail is to be linked with a table then you need to ensure that the tool rail plates with pins are
inserted into the work rails before the end caps are attached. A tool rail plate must also be fitted to link
the perpendicular back/plinths. The number of tool rail plates inserted will be dependent on the table/
accessory being attached.
6 Connect the end caps to end of the work rails, aligning into the screen supports, these are secured using
the smaller M8 button headed bolt.
Attaching the workrails
1 3
4 5
6

Assembly Instructions
Cubbi Assembly
Attaching the workrails
7 When connecting the workrail into the thinner Cubbi screen, then the end caps with a through hole needs
to be used. A bolt passes through this hole to be fixed into the Cubbi screen. The Cubbi screen will be
secured in two positions though the work rail levels.
7
8
9 10 11
8 To connect a workrail at a right angle add a workrail plate as shown in step 8a. Then take an end cap with
hole and affix to workrail plate using bolt shown in step 8b.
8b
8a
9 Once all the first level of workrails have been
attached and secured, the screens can be
lowered onto the supports. Please note where
power units are fitted then the cables should be
passed through the screens to the lower levels.
10 The second level of workrails is then attached
and secured in exactly the same way.
11 The top screen can then be layered into place.
Please note where power units are fitted then
the cables should be passed through the screens
to the lower levels.

Assembly Instructions
Cubbi Assembly
1 The table support brackets should be attached to the Cubbi screens using the fixings provided. A
minimum of two brackets are required each table, fitted to the internal sides of the screen.
Fixing the tables
2 The table is secured to the workrail using the pins and tool rail plates which had been previously inserted
into the work rail. The table top will have the have cams inserted.
1
2
3
3 The table is offered up to the pins and these are inserted into the pre drilled holes which locate into the
engineered cams within the table top. Once the table is in the correct position, the pins are secured by
turning the cams clockwise.
Once all the tables have been attached, the unit is now complete.
