Connection Tubes Series User manual

www.connection.uk.com
Tubes
Assembly Instructions

Assembly Instructions
Tubes Bench
Components & Fixing Kit
Tubes benches will always be supplied with
2 leg frames, 2 support rails, seat pad and
fixing kit.
If Tubes benches have been ordered with
writing tablet option then leg frames will
differ, as shown (A), and writing tablets will
be supplied (B).
Support rails for Tubes benches will vary
in size depending on bench size. Wide
benches will use large support rails (C). Slim
benches will use small support rails (D). You
will not receive both.
Fixing kit will come with all components in
plastic bag. Components will include:
E. M8x50 CSK bolt x 10
F. M6x16 CSK bolt x 6 – Tablets
G. Bench foot moulding x 2
H. M5x20 CSK bolt x 4
I. Half saddle washer x 6
J. M10 glide x 4
Please note, not all fixings will be required
depending on Tubes item purchased.
1. Connect bench foot moulding (G) to side of frame in which the writing tablet turns off. Screw M5x20 CSK
(H) bolt into bench foot leveller and placement holes in tubing.
A
BC D
E
H
G
F
J
I
1
2
2. For any legs without a writing tablet, insert
adjustable M10 glide (J) into bung and screw until
level. This can be adjusted to match floor level
later on.

Assembly Instructions
Tubes Bench
3. Connect 2 x support rails to one of the frames, with M8x50 CSK bolts (E). Face off second leg frame to
adjacent and add M8x50 CSK bolts (E) to connect. Tighten all bolts until counter sunk into tubing.
4. Face 6 x half saddle washers (I) onto tube frame. Place seat board above half saddle washers and
connect through underside of Tubes frame. Tighten all M8x50 CSK bolts (E) in place. Adjust M10 glides, if
necessary, at this stage to level out seating.
If no writing tablets are being added, then your Tubes bench is complete.
Attaching Writing Tablets (Optional)
5. Place tablets over metal place holders. Insert 3 x M6x16 CSK bolts (F) per tablet to secure. Repeat for
second writing tablet if necessary.
Your Tubes bench is now complete.
3
4
5

Assembly Instructions
Tubes Table
Components & Fixing Kit
Tubes tables will always be supplied with 2 leg
frames, 2 table support frames, table top, 2
table top support rails and fixing kit.
If Tubes table have been ordered with
undershelf option then additional undershelf
table top (A) and undershelf support rail (B).
Undershelf brackets (G) will be supplied to
connect together, as shown in fixing kit.
Fixing kit will come with all components in
plastic bag. Components will include:
C. M8x50 CSK bolt x 24
D. Half saddle washer x 10
E. Double saddle washer x 10
F. M10 glide x 4
G. Shelf bracket x 4
H. Wood screw x 8
Please note, not all fixings will be required
depending on Tubes item purchased.
1. Screw insert adjustable M10 glides (D) into bung in leg frame and screw until level. Complete this on all 4 legs.
This can be adjusted to match floor level later on.
When connecting table support frames, table top support rails and table legs, ensure that screws are hand
tight only, to start.
1
C
A
D
B
E
F
G
H

Assembly Instructions
Tubes Table
2. Connect table top support rails to table support frames along flat tube, with bent side facing down, with
M8x50 CSK bolt (C). Ensure that table top support rails mould around the tubing. Connect both table top
support rails to the one table support frame initially and then attached the second table support frame
afterwards.
3. Before attached table legs to the frame, ensure double saddle washers (E) are added in-between the
bottom of the two support frames. Loosely insert M8x50 CSK screws (C) to hold in place. Once both
double saddle washers are in place, flip frame upside down so that table support rails are on the floor.
4. Add 8 x double saddle washer (E) along edges of support frame and loosely screw in place. This will hold the
table legs in place. Face legs up to double saddle washers (E) and tighten. Now that legs are connected to the
frame, ensure that all screws are now tightened. Once complete, flip table onto feet.
2
3
4

Assembly Instructions
Tubes Table
5. Position half saddle washers (D) on top of table frame over pre-cut holes. Align underside of table top, with
screw holes over the half saddle washers and place on top. Securely insert M8x50 CSK bolts (C) and tighten
securely to fix the table top in place.
If additional undershelf is included in your Tubes order and assembly, please proceed to step 6. If not, then your
Tubes table is complete.
5

Assembly Instructions
Tubes Table
8. Once centralised, hook shelf brackets (G) to frame and use 2 x wood screws (H) to attach to the undershelf.
This needs to be repeated 4 times, twice per end, to securely fasten the undershelf
Your Tubes table with undershelf is now complete
Attaching the Undershelf (Optional)
6. Position 4 x half saddle washers (D) above pre-cut holes on underside of the undershelf. Place undershelf
support rail on top of spacers and connect with 4 x M8x50 CSK bolts (C).
7. Position undershelf and support rail on top of adjacent table legs. Ensure that undershelf table top is central
to frame. Locate pre-cut holes on either side of undershelf for where shelf brackets (G) need to be connected.
6
8
7
