Connection Platforms User manual

Platforms
Assembly Instructions
connection.uk.com

Assembly Instructions
Platforms Assembly
Assembling the modules
1 2
3
4
1 Remove all packaging from corresponding high
and low tier boxes, taking care not to damage
any fabric/upholstery
2 The lower tier of the straight units are opened
simply by lifting upwards at the front cut-outs,
with gas struts holding the top panel open
3 Remove the top panel of the units by lifting
directly upwards with an even force from both
ends. This will unclip the button fix connectors
(pictured)
4 Position the two/three boxes as shown, aligning
the holes in the back of the low tier with the high

Assembly Instructions
Platforms Assembly
5
6
8
7
5 Take 3x thumb turn wheels,
long M8 bolts and washers
from the fixing kit
6 Push a long M8 bolt through
the hole in the lower tier into
the slot in the higher tier and
attach a thumb turn wheel
until tight
7 Repeat for all three fixing points
8 Finally, replace the higher tier
upholstery panel by aligning
all button fix connectors
and pushing down until all
connectors are engaged

Assembly Instructions
Platforms Assembly
Connecting the modules
1 Platform modules are attached together via the slotted holes in the side of each end panel with a M8 x
50 bolt, washer and thumb turn wheel
2 Align the two modules and place a M8 x 50 bolt and washer through the front slotted holes on the lower
tier, attaching the thumb turn wheels and tightening
3 Repeat this process for the higher units

Assembly Instructions
Finishing the assembly
3
1 2
1 Replace the seat cushions and top panels by lifting directly above the corresponding module and
dropping down vertically
2 Once positioned correctly, push down firmly until the button fix connectors click into place. Ensure all
button fix connectors are aligned before pressing down firmly.
Your Platforms assembly is now complete
