MOTORIZEDCARD READER MODULE
Page 1 of 9

USER MANUAL
QU-CM-5510/-2
USER MANUAL
Ⅰ
.BRIEF INTRODUCTION
It is the first dual shutter protection card reader in the world. The first shutter is mechanical with
dust and foreign things prevention function, and the other one is for motor protection. The main body
is composite plastic with high temperature, abrasion and aging resistance, and two sides of card
movement channel are embedded with stainless steel metal. It makes product with advancement in
strength and precision. Module installation structure is convenient for customers to maintain product.
Elaborate design and part combination makes product with fresh appearance and its precision meets or
overpass the same product all over the world. Excellent circuit design takes multiple protection
functions into consideration. It is a card reading equipment that can read or write many types of cards,
supporting 8 pieces SIM card operation.
※
Model Name Rules
Card Type
Model Name
IC Card
（R&W）
Mag-Card
RFID Card
（R&W）（Encryption）
SIM Card
（R）
QU-CM-5510/-2-A
QU-CM-5510/-2-C
Support any one of the three types card
N.A
R
Support any two of the three types
Support all the three types
Or any one with
SIM card encryption
Or any two with
SIM card encryption
Support all the three types with SIM card encryption
QU-CM-5510/-2-D
※
R&W: Read&Write
Picture without SIM card slot
Picture with SIM card slot
Page 2 of 9

USER MANUAL
QU-CM-5510/-2
Ⅱ
.FEATURES& SPECIFICATIONS
Subject
Specification
Magnetic card Reading
Accordance with ISO7810 7811 standard card
IC card Reading & Writing
EMV、7816 PBOC 3.0
RF card Reading & Writing
S50、S70、ID card
SIM card operation
Card entry method
Motor shutter
8 SIM card ports
Magnetic signal, Optoelectronic signal and rear card insert
Allow or enabled card to insert
Mechanical shutter
Alert Lamp
Prevent dust and foreign things
Card entry alert, power on alert, IC card power on alert
Multiple card stop position
Card stop position
Input voltage detection
have protection alert when voltage is above 13v or below
11V
Input voltage protection in negative direction
Not above 40V
Ⅲ
.PARAMETERS
DC 12 V ( MAX CURRENT 3A, Static current 100mA),
Recommend ：12V/3A
Operation Power
Operation Te-mp.&Humi.
0 ℃～50 ℃，30～90% （Relative Humidity）
RS232 serial port ，
Support 2400～38400BPScommunication rate
Interface
Card width：54±0.5mm
Card size ：
Card length：85±0.5mm
Card thickness：0.2-2.0mm
Card material：
Weight ：
Paper card or polyester card
about 1.3kg
Magnetic card type
ISO7810 ，ISO7811 (1-6－) ，ISO7812 ，ISO7813 And ISO15457
ISO7816 normal storage card,logic encryption card,
and smart card(CPU card), reading and writing support
contact IC card type
ISO14443 TYPEA TYPEB 1、5693 contactless card reading and
writing
contactless IC card type
Dimensions
Net weight
145.5(L) x 84.1(W) x 47.4 (H) mm
1.5KG
Magnetic head:800，000 times
Lifespan
IC card contact point:500，000 times
Trans. Equipment:500，000 times
Page 3 of 9

USER MANUAL
QU-CM-5510/-2
Ⅳ
.INTERFACE EXPLANATION AND CONNECTION
NOTE: TO AVOID sudden high power damage, please do connect
the communication wire before connect the Power cable.
4
PIN
3
PIN
3
PIN
Communication Interface
RS232
4
PIN
DC12V POWER Interface
Rear of the Machine
RS232 Interface
DB9 tocomputer serial port
3PIN RS232 Socket
The other port of theMachine
Rear
T RS232 Cable
RS232-ZIP
Input
Requirement
RS232 CABLE
PIN-NO.
TO
TO
PC
1
Pin(Right)
TXD
3PIN
CONN.
RS232 level
RS232 level
2
Pin(Middle) RXD
3
Pin(Left)
GND Connect with Ground
Page 3 of 9

USER MANUAL
QU-CM-5510/-2
Power supply interface
POWER CABEL
TO DC12V
POWER
TO MACHINE
POWER SOCKET
POWER-ZIP
PIN-NO.
INPUT
REQUIREMENT
（
）
PIN 2&3
GND
Connect with Ground
Black Wire
VCC
DC12V Current over 1.5A
（
）
PIN 1&4 Red Wire
Power cable connector
DC12V±5%
DNG
DNG
DC12V±5%
Page 4 of 9

USER MANUAL
QU-CM-5510/-2
Page 5 of 9

USER MANUAL
QU-CM-5510/-2
Ⅴ
.COMPONENTS AND PARTS INTRODUCTION
②
①
③
④
⑦
⑤
⑥
①
②
③
⑤
⑥
⑦
Top Part of the Main Body
Top Cover
Front transmitting wheel
Another Part of the Main Body
Card Bezel series
Back transmitting wheel
Transmitting belt
④
Page 5 of 9

USER MANUAL
QU-CM-5510/-2
Ⅵ
.OPERATION GUIDE
CARD INSERTION NOTE:
Magnetic card:
The magnetic area under the right side of the card, as picture indicated
Contact IC card: Hold the card, the chip IC at the front of the card to insert, as picture indicated.
Non-contact IC card: Both side and direction is available for reading and writing.
※CARD INSERT DIRECTION AS BELOW
Chip IC CARD
Non-contact IC
Magnetic Card
(magnetic stripe at the other side)
Page 6 of 9

USER MANUAL
QU-CM-5510/-2
Ⅶ
.INSTALLATIONAND STRUCTURE DRAWING
Page 7 of 9

USER MANUAL
Ⅷ
.CAUTION DURING OPERATION
1
) When connecting interface, please connect with communication interface first, then power
interface. And then power on.
2
3
4
) To make your product safe, the input voltage please not above 40V.
) Please set BPS rate correct. EX-work set is 9600bps.
) During operation, card insert direction should be correct
a) When inserting magnetic card, magnetic stripe should face down and insert on the right side.
b) When inserting IC card, chip should face up. If insert from the front, the end close to chip
should be inserted into card reader first. If insert from the rear, the end away from chip should
be inserted into card reader first.
c) When inserting RF card, directions are not considered. But it can only be operated at RF
position.
5
) When there is card in the machine, error message will be given if inserting card again. And motor
door will not open.
6
7
) When shutting off power, power interface should be shut off first, then communication interface.
) Power off during operation or other abnormal reason lead to card staying in the machine and
cannot be taken out, please take out card by pulling belts manually.
8
) Disassembly method Drawing
2
. Tap down lower
main body
3
.
Pull backward
lower main body
with right hand
1
. Push and open the clips
beside the card mouth to
take off card mouth
4
. Pull forward upper
main body with left
hand
Page 8 of 9
QU-CM-5510/-2

Ⅸ.Mantainace
1
. Transmitter maintenance
a) Select “Check transmitter status” in “card reader control command screen”.
b) In normal condition, information of 5 transmitters in text box will all show “No card”.
c) If one or several transmitters show “Have card”, maybe they are covered with dirt.
d) Should disassembly card reader and clean it.
drawing”.
2
. Magnetic head maintenance
Use cleaning card to clean magnetic head in card reader.
3
. Detecting pin contact maintenance
Dirt on the detecting pin of IC card makes machine not connect well with IC card chip. You
should disassembly machine to clean it. Please refer to “disassembly method drawing”.
4
. Gear maintenance
Check gear periodically and clean dirt with alcohol.
