Contemporary Controls CTRLink EISK8-100T User manual

EISK8-100T
Plug and Play Switching Hub for Automation Systems
Installation Guide
The EISK8-100T Skorpion-8 switching hub is designed for the automation environment.
Like all Ethernet switches from Contemporary Controls, it features non-blocking (full
wire-speed) operation. It divides an Ethernet network into eight collision domains —
―bridging‖ data links to create larger network diameters than possible with repeating
hubs. Each port automatically negotiates its data rate to either 10 Mbps or 100 Mbps
—controlling data flow with the PAUSE function in full-duplex links or with the
backpressure method in half-duplex links.
The switch provides preamble regeneration with symmetry and amplitude compensation
—retiming signals to eliminate jitter. Digital pre-emphasis compensates for inherent
signal strength roll-off. Link integrity is monitored, verifying that a working adapter or
hub is on the distant end of a segment.
Port assignments are learned by reading Ethernet frames and logging the source
addresses to a table. Throughput is improved by restricting traffic to those ports party
to a data exchange —while other data is simultaneously exchanged on other ports.
Store-and-forward operation is implemented and broadcast, multicast, or unicast
transmissions are received by all ports.
The EISK8-100T has eight Auto-MDIX ports for attaching local devices. In addition to
a power LED, each port has one LED showing link/activity/rate and one showing
duplex status.
The unit operates from a wide range of low-voltage AC or DC power.
The EISK8-100T is provided with a writeable label for easy identification of the remote
device attached to each cable.

Specifications
Electrical
INPUT DC AC
Voltage: 10–36 V 24 V
Power: 5 W 7 VA
Frequency: N/A 47–63 Hz
Class 2 Circuits Only
Environmental
Operating Temperature: 0°C to +60°C
Storage Temperature: –40°C to +85°C
Humidity, non-cond.: 10% to 95%
Protection: IP 30
Mounting TS-35 DIN-rail
Shipping Weight 1 lb (0.45 kg)
Regulatory Compliance
CE Mark; CFR 47 Part 15, Class A
UL508 Industrial Control Equipment
Functional
Compliance: ANSI/IEEE 802.3
Data Rates: 10 and 100 Mbps
Signalling: 10BASE-T and
100BASE-TX
Connectors: Shielded RJ-45
Segment length: 100 m (maximum)
LED Indicators
Power green
Activity/Link green or yellow
Duplex green
RJ-45 Connector Pin Assignments
Pin Function
1 TD+
2 TD–
3 RD+
6 RD–
(All other pins are unused.)
Mechanical

Power Options
Power Considerations
Voltage in the range of 10–36 VDC or 24 VAC must deliver current commensurate with
power consumption. Recommended size for solid power conductors is 16–22 AWG; for
stranded conductors, use 16–18 AWG. Ground is directly connected to zero volts and
the chassis is isolated from zero volts. Input connections are reverse-polarityprotected.
Network Connections
The switch employs Auto-MDIX technology so that either straight-through or crossover
cables can be used to connect to network interface adapters or to another hub.
LED Indicators
The ―PWR‖ LED glows solid green when the switch is properly powered. To aid in
troubleshooting, each port has two LEDs. The Port 2 LED labelled ―L‖ glows solid if a
link exists, flashes to show activity and shows data rate by colour: green for 100 Mbps
and yellow for 10 Mbps. The LED labelled ―D‖ glows solid green if full-duplex is on or
is unlit when that port is operating in half-duplex mode —but in half-duplex operation it
will flash if a collision occurs. The other port LEDs are unlabeled but work the same.

Need more help installing this product?
For more information, visit www.ccontrols.com. If contacting our office, ask for
Technical Support.
Warranty
Contemporary Controls (CC) warrants this product to the original purchaser for five
years from the shipping date. If it fails to operate in compliance with its specification
during this period, CC will, at its option, repair or replace the product at no charge. The
customer is responsible for shipping the product; CC assumes no responsibility for the
product until received. This limited warranty covers products only as delivered. If user
modification damages the product, repair or replacement are not covered. Damage
from abuse, accident, disaster, misuse, or incorrect installation are not covered. This
warranty in no way warrants suitability of the product for any specific application. More
warranty information can be found at www.ccontrols.com.
Warning: This is a Class A product.In a domestic environment this product may cause radio
interference in which case the user may be required to take adequate measures.
Returning Products for Repair
Return the product to the location where it was purchased by following the instructions
at the URL below: www.ccontrols.com/rma.htm
Declaration of Conformity
Information aboutthe regulatory compliance of this product can be found at the URL below:
www.ccontrols.com/compliance.htm
January 2011 TD040700-0IE
