Continental Hydraulics Installation Manual
Page 1 of 27 CEM-SA-B CHI 1020687 01/2016
CEM-SA-B
Description:
This closed loop position module has been developed for controlling hydraulic positioning drives.
Proportional valves with integrated or external electronics can be controlled with the differential
output. Output is an analog signal of either voltage, 0 to +/- 10v or current 4-20mA, suitable for
directly driving a proportional directional valve with on board electronics.
The internal profile generation is optimized for stroke-dependent deceleration or the NC control
mode. The controller and the controller settings are factory preset to typical requirements and can
be optimized for the control behavior as required. The optimized control function offers a high
degree of precision together with high stability for hydraulic drives. The movement cycle is
controlled via the external position and speed inputs.
The high resolution of the analogue signals ensures good positioning behavior. A wide range of
analog signals are accepted. User may select either voltage or current input mode. These inputs
are easily scaled to match system requirements.
Forward and Reverse “jog” inputs allow for manual load control. A user definable window for “in
position” triggers an output for communication to the next machine function.
This module is easily adapted to a variety of system requirements. All variables are user adjusted
with easy to use CHI-PC software on your Microsoft Windows laptop. Control variables are
stored in non-volatile memory internal to the module. All variables can be read by the laptop, and
reproduced exactly on other modules.

Continental Hydraulics Installation Manual
Page 2 of 27 CEM-SA-B CHI 1020687 01/2016
Table of Contents
Information Description Page #
Technical Data - ……………………………………….…………………….………..…………… 3
Functional Diagram …….…….…………………….……………………………………………... 4
Wiring Example…………………………………………………………………………………… 4
Dimensions …………………………………………….…………………………………………… 4
Terminal Identification …………………………………………………………………………….. 5
Steps to install and configure a new application ……………………….………………………. 6
Module Mounting Location ………………………………………….…………………………….. 7
Power Supply ………………………………………………………………………………….…… 7
Wiring to valve ……………………………………………………………………………………… 7
Parameter List …………………………………………….…………………………..…………… 8
LED Indications ……………………….…………………………………………………………… 9
Command Parameter Descriptions
LG (Language)…………………………………………………………………………… 10
MODE……………………………………………………………………………………... 10
SENS ……………………..……………………………………………………. ………... 10
EOUT …………………………………………………………………………………… 11
ENABLE…………………………………………………………………………………. 11
START (RUN)…………………………………………………………………………… 11
HAND:A / HAND :B……………………………………………………………………… 12
INPOS ……………………………………………………………………………………. 12
SYS_RANGE ……………………………………………………………………………. 12
SIGNAL: W/X/V.………………………………………………………………………… 13
N_RANGE:X …………………………………………………………………………….. 13
OFFSET:X ……………………………………………………………………………….. 13
Using SYS_RANGE, N_RANGE and OFFSET ……………………………………… 14
Speed Commands SIGNAL:V …………………………………………………………. 15
VELO ………………………………………………………………………………………15
VRAMP …………………………………………………………………………………… 15
VMODE ……………………………………………………………………………………16
ACCEL …………………………………………………………………………………….16
VMAX ……………………………………………………………………………………. 16
A:A and A:B………………………………………………………………………………. 17
D:A / D:B / D:S ……………………………………………………………………………17
V0:A / V0:B / V0:RES …………………………………………………………………… 18
PT1 ……………………………………………………………………………………….. 18
CTRL ………………………………………………………………………………………19
MIN:A / MIN:B …………………………………………………………………………….20
MAX:A / MAX:B …………………………………………………………………………. 20
TRIGGER ………………………………………………………………………………… 20
OFFSET ………………………………………………………………………………….. 21
SIGNAL:U …………………………………………………………………………………21
Special Command descriptions ……………………………………………………….. 22
DC:AV ……………………………………………………………………………………. 23
DC:DV ……………………………………………………………………………………. 23
DC:I ………………………………………………………………………………………. 23
DC:CR ……………………………………………………………………………………. 23
Process Data (Monitoring) …………………………………………………………….. 23
AINMODE………………………………………………………………………………… 24-25
Troubleshooting …………………………………………………………………………………… 26-27

Continental Hydraulics Installation Manual
Page 3 of 27 CEM-SA-B CHI 1020687 01/2016
Technical data
Supplyvoltage [VDC] 12… 30 (incl. ripple)
Current requirement [mA] <100
External protection [A] 1 medium time lag
Digital inputs [V] logic 0: <2
[V] logic 1: >10
Input resistance [kOhm] 25
[V] logic 0: <2
[V] logic 1: >12 (50 mA)
Analogue inputs (sensor and
demand value signal)
[V] 0… 10; 25 kOhm
[mA] 4… 20; 240 Ohm
Signal resolution [%] 0,003 incl. Oversampling
(maximum resolution 1 µm )
Speed input [V] 0… 10; 90 kOhm
[mA] 4… 20; 240 Ohm
[%] 0,003
Analogue outputs
Voltage [V] 2 x 0… 10; differential output
[mA] 10 (max. load)
Signal resolution [%] 0,006
Current [mA] 4… 20; 390 Ohm maximum load
Signal resolution [%] 0,006
Controller sample time [ms] 1
USB in RS 232C Emulation
(9600… 57600 Baud, 1 stop bit,
no parity, echo mode)
Snap-on module to EN 50022
PA6.6 polyamide
Flammabilityclass V0 (UL94)
Weight [kg] 0,170
Protection class IP20
Temperature range [°C] -20… 60
Storage temperature [°C] -20… 70
Humidity [%] < 95 (non-condensing)
USB-B
4 x4-pole terminal blocks
PE: via the DIN mounting rail
EN 61000-6-2: 8/2005
EN 61000-6-4: 6/2007 ; A1:2011
Connections
EMC
Digital outputs
Serial interface
Housing

Continental Hydraulics Installation Manual
Page 4 of 27 CEM-SA-B CHI 1020687 01/2016
Functional Diagram:
Wiring Example:
Power
Supply
15
16 Differential
Input on
Control Valve
+
-
3
4
12
1
2
Ready
In Pos
5Start (Run)
Hand + (jog)
6
7
8
Hand - (jog)
Analog Position Feedback
Analog Command Position
Analog Speed (optional)
+24v
14/11
13/11
10/9 Gnd
+24v
Gnd
Valve out +
Enable
Speed
Command
Feedback
Valve out -
Dimensions:
4.5"
3.9" 0.9"

Continental Hydraulics Installation Manual
Page 5 of 27 CEM-SA-B CHI 1020687 01/2016
CEM-SA-B Input and output Terminal Identification
Connection Supply
PIN 3 Power supply(see technical data)
PIN 4 0 V(GND) connection.
Connection Analogue signals
PIN 9 / 10 External speed demand (V), range 0… 10 V or 4… 20 mA (scalable)
PIN 13 Position demand value (W), range 0… 10 V or 4… 20 mA (scalable)
PIN 14 Analogue position actual value (X), range 0… 10 V or 4… 20 mA (scalable)
PIN 11 / PIN 12 0 V(GND) connection for analogue signals
Valve control Output signal.
Type of signal and polaritycan be selected bythe parameter SIGNAL:U.
Connection Digital inputs and outputs
Enable input:
This digital input signal initializes the application and error messages are deleted. The
controller and the READYsignal are activated. The output signal to the control element is
enabled.
The actual position is accepted as the command position and the drive remains
stationaryunder control at this position.
If the input is disabled, the output (control signal) is switched off(disabled). Take care of
the EOUT-command!
START (RUN) input:
The position controller is active and the external analogue demand position is accepted
as the demand value. Ifthe input is disabled during the movement, the system is
stopped within the set emergencystopping distance (D:S).
HAND+ input:
Manual operation (START = OFF):the drive moves at the programmed speed in the
programmed direction. After deactivation, the actual current position is accepted as the
demand position. The START (RUN) input has priorityover the HAND+ input.
Ifthe sensor signal is missing (external ENABLE signal = ON), the drive can be operated
in manual mode.
HAND- input:
Manual operation (START = OFF); the drive moves with the programmed speed in the
programmed direction. After deactivation, the actual current position is accepted as the
required position. The START (RUN) input has priorityover the HAND- input.
Ifthe sensor signal is missing (external ENABLE signal = ON), the drive can be operated
in manual mode.
READYoutput:
ON:The module is enabled; there are no discernable errors.
OFF:Enable (PIN 8) is disabled or an error (sensor or internal error) has been detected.
STATUS output:
ON:INPOS message. The axis is within the INPOS window.
OFF:INPOS message. The axis is outside the INPOS window.
PIN 2
PIN 15 / 16
PIN 8
PIN 7
PIN 6
PIN 5
PIN 1

Continental Hydraulics Installation Manual
Page 6 of 27 CEM-SA-B CHI 1020687 01/2016
Steps to install and configure a new application:
All parameters are adjusted using VEA-BUSB programming cable and CHI-PC Microsoft
Windows application.
1. Mount the module in a suitable location
2. Connect the power supply and valve solenoids
3. Down load and open the GUI program (www.continentalhydraulics.com/wp-
content/uploads/2015/01/setup-CEWMPC-10-v3.5.0.zip )
4. Connect to Laptop via USB to USB Type B communication cable.
5. Open the Options and check setting make sure the correct com port, full-Duplex and
57.6K Baud rate are selected.

Continental Hydraulics Installation Manual
Page 7 of 27 CEM-SA-B CHI 1020687 01/2016
Module Mounting Location:
This module is to be mounted in a cabinet for protection from the local environment.
Ensure there is adequate free space around the module to allow for cooling air flow.
This module is designed to snap onto an industry standard 35mm DIN rail.
Do not mount near other modules that emit high power electrical interference, such as motor
controllers and high power contactors.
Power Supply:
This module is designed to operate on DC power from a regulated power supply ranging from 12
to 30 volts. Match valve solenoid voltage rating to power supply, typically 12 or 24 volts.
A 1 amp medium action fuse is recommended in the “+” power supply line.
Wiring to Valve:
Two conductors are required for each solenoid. There is no need for shielding on these power
conductors.
Wire size is chosen to provide an acceptable voltage drop between the module and the valve
solenoid. The following chart is based on 5% drop for 12v and 24v applications. The listed cable
length is distance from module to valve, and includes the voltage drop of the return conductor.
Wire size 2.6A 12v 1.6A 24v 0.86A 24v
12 gauge 66 ft. max 215 ft. max 400 ft. max
14 gauge 49 ft. max 159 ft. max 295 ft. max
16 gauge 31 ft. max 100 ft. max 186 ft. max
18 gauge 19 ft. max 63 ft. max 117 ft. max
20 gauge 13 ft. max 39 ft. max 73 ft. max
22 gauge 8 ft. max 25 ft. max 46 ft. max

Continental Hydraulics Installation Manual
Page 8 of 27 CEM-SA-B CHI 1020687 01/2016
Ref Page Command Parameter Help / Description STD EXP-SDD EXP-NC
10 LG EN EN English X X X
10 MODE EXP Standard / Expert mode X X X
10 SENS ON Malfunction monitoring [ON / OFF /AUTO] X X X
11 EOUT 0 Output signal if not ready [0.01%] X X
12 HAND:A 3333 Manual speed [0.01%] X X X
12 HAND:B -3333 Manual speed [0.01%] X X X
12 INPOS 200
In-position-window [µm] X X X
12 SYS_RANGE 100 Axis working Stroke [mm] X X X
13 SIGNAL:X U0-10 Type of Input X X X
13 N_RANGE:X 100 sensor nominal length [mm] X X X
13 OFFSET:X 0 sensor offset [µm] X X X
13 SIGNAL:W U0-10 Type of Input X X X
15 SIGNAL:V OFF Type of Input X X X
15 VELO 10000 Internal speed limitation [0.01%] X X X
15 VRAMP 200
Ramp time for the external speed [ms] [SINGNAL:V - ON] X
16 VMODE SDD Method of positioning X X
16 ACCEL 250
Acceleration [mm/s^2] X
16 VMAX 50 Maximum speed [mm/s] X
17 A:A 100 Acceleration time [ms] X X
17 A:B 100 Acceleration time [ms] X X
17 D:A 25 Deceleration stroke [mm] X X
17 D:B 25 Deceleration stroke [mm] X X
17 D:S 10 Overtravel [mm] X X
18 V0:A 25 Loop gain [1/s] X
18 V0:B 25 Loop gain [1/s] X
18 V0:RES 1 Loop gain resolution X
18 PT1 1 PR1-filter time constant [ms] X X
19 CTRL SQRT1 Control characteristic X X X
20 MIN:A 0 Compensation of the Deadband in 0.01% X X X
20 MIN:B 0 Compensation of the Deadband in 0.01% X X X
20 MAX:A 10000 Output Scaling in 0.01% X X X
20 MAX:B 10000 Output Scaling in 0.01% X X X
20 TRIGGER 200 Trigger point of the MIN function in 0.01% X X X
21 OFFSET 0 Output offset [0.01%] X X X
21 SIGNAL:U U+-10 Type and polarity of the output signal X X X
23 DC:I 2000 Drift compensator, I-gain [ms] X X
23 DC:AV 0 Drift compensator, activation value [0.01%] X X
23 DC:DV 0 Drift compensator, deactivation value [0.01%] X X
23 DC:CR 500 Drift compensator, control range [0.01%] X X
CEM-SA-B Function Parameter layout
MODE

Continental Hydraulics Installation Manual
Page 9 of 27 CEM-SA-B CHI 1020687 01/2016
LED Indications
LEDs Description of the LED function
Identical to the READYoutput.
OFF: No power supplyor ENABLE is not activated
ON: System is readyfor peration
Flashing: Error discovered
Onlyactive when SENS = ON
Identical to the STATUS output.
OFF: The axis is outside the INPOS window.
ON: The axis is within the INPOS window.
1. Chasing light (over all LEDs): The boot loader is active. No normal functions
are possible.
2. All LEDs flash shortlyevery 6 s: An internal data error was detected and corrected
automatically!The module still works regularly.
To acknowledge the error the module has to have power cycled.
YELLOW A +
YELLOW B
Both yellow LEDs flash oppositelyevery1 s: The nonvolatile stored parameters are
inconsistent! To acknowledge the error, the data have to be saved with the SAVE
command or the corresponding button in the CHI-PC. Ifthe function of the module has
changed via the FUNCTION parameter, all parameters are deleted purposelyand set to
default values. In this case the LEDs indicate no error, but a desired state. To
acknowledge please save.
GREEN
YELLOW A
GREEN +
YELLOW A+B

Continental Hydraulics Installation Manual
Page 10 of 27 CEM-SA-B CHI 1020687 01/2016
Parameter Descriptions
LG (Changing the language)
Command
Parameters
Unit
Group
LG x
x= DE|EN
-
STD
Either English or German can be selected for the displayed texts.
After changing the language settings, the ID button in the menu bar (CHI-PC) must be pressed
(module identification).
MODE (Switching between parameter groups)
Command
Parameters
Unit
Group
MODE x
x= STD|EXP
-
STD
This command changes the operating mode. Various commands (defined via STD/EXP) are
blanked out in Standard Mode. The commands in Expert Mode have a more significant influence
on system behavior and should accordingly be changed with care. (see page 8)
SENS (monitoring of the modul functions)
Command
Parameters
Unit
Group
SENS x
x= ON|OFF|AUTO
-
STD
This command is used to activate/deactivate the monitoring functions (4… 20 mA sensors, output
current, signal range and internal failures) of the module.
ON: All monitoring functions are active. Detected failures can be reset by deactivating the
ENABLE input PIN 8.
OFF: No monitoring function is active. The READY output will not function in OFF.
AUTO: Auto reset mode. All monitoring functions are active. If the failure doesn’t exist
anymore, the module automatically resumes to work without deactivating the ENABLE
input PIN 8.
Normally the monitoring functions are always active because otherwise no errors are
detectable via the READY output. Deactivating is possible mainly for troubleshooting.

Continental Hydraulics Installation Manual
Page 11 of 27 CEM-SA-B CHI 1020687 01/2016
EOUT (Output signal: READY = OFF)
Command
Parameters
Unit
Group
EOUT x
x= -10000… 10000
0.01 %
EXP
Output value in case of a detected error or a deactive ENABLE input. A value (degree of valve
opening) for use in the event of a sensor error (or the module is disabled) can be defined here.
This function can be used if, for example, the drive is to move to one of the two end positions (at
the specified speed) in case of a sensor error.
|EOUT| = 0 The output is switched off in the event of an error. This is normal behavior.
CAUTION! If the output signal is 4… 20 mA, the output is switched off when |EOUT| = 0. If a null
value = 12 mA is to be output in the event of an error, EOUT must be set to 1
1
.
The output value defined here is stored permanently (independently of the parameter set). The
effects should be analyzed by the user for each application from the point of view of safety.
Do not use the manual mode in conjunction with the EOUT command. After the deactivation of
the HAND input the output is set to the EOUT value.
ENABLE (pin 8) digital input:
ENABLE is a digital input that is active high.
When the ENABLE input is low, there is no output to the valve. Command input and feedback
input values are ignored. All other inputs are also ignored. To activate the HAND function,
ENABLE must be held active.
If ENABLE is removed during an active motion profile, the output to the valve is instantly brought
to zero.
START (RUN) (pin 7) digital input:
START (RUN) is a digital input that is active high.
Bringing pin 7 high (while holding pin 8 (ENABLE) high), forces the module into closed loop
position control mode.
If RUN is removed during an active motion profile, the output to the valve is ramped to zero.
1
This is necessary if using valves without error detection for signals lower than 4 mA. If the valve has an
error detection, it moves into a defined position after switching off the output.

Continental Hydraulics Installation Manual
Page 12 of 27 CEM-SA-B CHI 1020687 01/2016
HAND (Manual speed)
The Hand functions are not active when Start PIN 7 is active, to use the Hand manual speed
functions the Start function must be deactivated.
Command
Parameters
Unit
Group
HAND:i x
i= A|B
x= -10000… 10000
0.01%
STD
The manual speeds are set with these parameters. The drive moves in a controlled manner in the
defined direction when the manual signal is active. The direction is defined by the sign of the
parameters. After the manual signal has been disabled, the drive remains under control in the
current position.
In case of a fault (position sensor fault), the drive can still be moved with the manual function. The
output will be switched off when hand signals are turned off.
The manual speed is also limited by the (internal or external) speed demand (MIN evaluation).
Caution! Do not use the manual mode in conjunction with the EOUT command. After the
deactivation of the HAND input the output is set to the EOUT value.
INPOS (In position range)
Command
Parameters
Unit
Group
INPOS x
x= 2… 200000
µm
STD
This parameter is entered in µm.
The INPOS command defines a range for which the INPOS message is generated. This function
monitors the failure between the command and actual position. If the failure is less than the
programmed value a INPOS message at the status output (see Pin description). The positioning
process is not influenced by this message.
PIN 7 (START) must be activated to generate the INPOS messages.
SYS_RANGE (Working stroke)
Command
Parameters
Unit
Group
SYS_RANGE...................................................................................................................................................x
x= 10… 10000
mm
STD
This command defines the full stroke, which corresponds to 100 % of the input signal. If the
demand is set incorrectly, this leads to incorrect system settings, and the dependent parameters
such as speed and gain cannot be calculated correctly.

Continental Hydraulics Installation Manual
Page 13 of 27 CEM-SA-B CHI 1020687 01/2016
SIGNAL (Type of input)
Command
Parameter
Unit
Group
SIGNAL:i x
i= W|X|V
x= OFF
U0-10
U10-0
I4-20
I20-4
-
EASY
This command can be used to change the type of input signal (voltages or current) and to define
the direction of the signal. This command is available for all analog inputs (W, X, and V).
OFF= Deactivation of the input
2
.
See ANIMODE section (page 24-25) if the Signals used are not listed above, for re-scaling as
required.
N_RANGE: X (Nominal range of the sensor)
Command
Parameter
Unit
Group
N_RANGE:X
x
x= 10… 10000
mm
EASY
N_RANGE (nominal range or nominal stroke) is used to define the length of the sensor. This
value should be always higher than SYS_RANGE. The control parameter cannot be calculated
correctly in case of wrong values.
OFFSET: X (Sensor offset)
Command
Parameter
Unit
Group
OFFSET:X x
x= -100000… 100000
µm
EASY
Adjustment of the zero point of the sensor.
2
The deactivation can be used to deactivate the velocity (speed) input PIN_9/10 (the VELO value is active).

Continental Hydraulics Installation Manual
Page 14 of 27 CEM-SA-B CHI 1020687 01/2016
Using of the commands SYS_RANGE, N_RANGE: X and OFFSET: X
If the Cylinder stroke and the feedback device are matched, the standard factory settings will not
require any changes.
In systems where these are not matched, the commands SYS_RANGE, N_RANGE: X and
OFFSET: X must be scaled to match. The application scaling will be done by these three
commands.
In this example (Figure 1) the system is defined by a length of 120 mm of the sensor, a working
stroke of 100 mm of the cylinder and an offset of 5 mm. These parameters have to be typed in
and the axis is driving between 5 mm and 105 mm of the sensor stroke and between 0 mm and
100 mm of the cylinder stroke.
Correct scaling:
SYS_RANGE = 100 (mm)
N_RANGE: X = 120 (mm)
OFFSET: X = -5000 (µm)
120,00 mm
100,00 mm
5,00 mm
Figure 1 (Input scaling of the sensor)

Continental Hydraulics Installation Manual
Page 15 of 27 CEM-SA-B CHI 1020687 01/2016
Speed commands
The SIGNAL: V command is used to switch over between external or internal speed limitations.
SIGNAL: V = OFF Internal speed limitation (VELO command)
SIGNAL: V = U0-10 External speed limitation (0-10 Volt)
PIN 9/10 is used for external speed limitation
3
.
See ANIMODE section (page 24-25) if the Signals used are not listed above, for re-scaling as
required.
VELO (Internal speed demand value)
Command
Parameters
Unit
Group
VELO x
x= 1… 10000
0.01 %
SIGNAL:V =
OFF
Specification of the internal speed limitation.
VRAMP (Ramp time for external speed demand)
Command
Parameters
Unit
Group
VRAMP x
x= 10… 5000
ms
SIGNAL:V
The rate of change of the external speed demand can be limited by this ramp time. The command
is only active if external speed demand (SIGNAL:V <> OFF) has been parameterized.
3
The output signal is directly limited in SDD mode (default mode). In NC mode the speed profile of the
generator is limited. The lowest adjustable speed is 0.01 mm/s (VMAX = 1 mm/s and VELO = 1 %).

Continental Hydraulics Installation Manual
Page 16 of 27 CEM-SA-B CHI 1020687 01/2016
VMODE (Methode of positioning)
Command
Parameters
Unit
Group
VMODE x
x= SDD|NC
EXP
The fundamental control structure can be changed with this parameter.
SDD: Stroke-Dependent Deceleration. In this mode, stroke-dependent deceleration is
activated. This mode is the default mode and is suitable for most applications. With
stroke-dependent deceleration, the drive comes to a controlled stop at the target
position. From the deceleration setpoint, the drive then switches to closed loop control
mode and moves accurately to the desired position. This control structure is very
robust and is insensitive to external influences such as fluctuating pressures. One
disadvantage is that the speed varies with the fluctuating pressure as the system runs
under open-loop control.
NC: Numerically Controlled. In this mode a position profile is generated internally. The
system always works under control and uses the following error to follow the position
profile. The magnitude of the following error is determined by the dynamics and the
closed loop gain. The advantage is that the speed is constant (regardless of external
influences) due to the profile demand. Because of continuous control, it is necessary
to run at less than 100 % speed, as otherwise the errors cannot be corrected. 70… 80
% of the maximum speed is typical although especially the system behavior and the
load pressure should be taken into account when specifying the speed.
ACCEL (Acceleration in NC mode)
Command
Parameters
Unit
Group
ACCEL x
x= 1… 20000
mm/s²
VMODE=NC
This command is used to define the acceleration rate in NC mode. The command is only active if
the VMODE has been parameterized to NC.
VMAX (Maximum speed in NC mode)
Command
Parameters
Unit
Group
VMAX x
x= 1… 2000
mm/s
VMODE=NC
Specification of the maximum speed in NC mode. This value is defined by the drive system and
should be specified as precisely as possible (not too high under any circumstances). The speed
is scaled by means of the VELO value or via the external speed demand (PIN 10 and 9). The
command is only active if the VMODE has been parameterized to NC.

Continental Hydraulics Installation Manual
Page 17 of 27 CEM-SA-B CHI 1020687 01/2016
A:A and A:B (Acceleration (ramp) time)
Command
Parameters
Unit
Group
A:i x
i= A|B
x= 1… 5000
ms
VMODE=SDD
Ramp function for the 1st (A solenoid) and 3rd (B solenoid) acceleration quadrants only.
The acceleration time for positioning is dependent on the direction. “A” corresponds to connection
15 and “B” corresponds to connection 16 (if POL = +).
Normally A = flow P-A, B-T and B = flow P-B, A-T.
For quadrants 2 and 4, parameters D:A and D:B are used as the deceleration distance demand
when the SDD funcion is in control.
D:A / D:B / D:S (Deceleration / braking distance)
Command
Parameters
Unit
Group
D:i x
i= A|B|S
x= 1… 10000
mm
VMODE = SDD
This parameter is specified in mm
4
.
The deceleration stroke is set for each direction of movement (A or B). The control gain is
calculated internally depending on the deceleration distance. The shorter the deceleration
distance, the higher the gain. A longer deceleration distance should be specified in the event of
instability.
Parameter D:S is used as the stopping ramp when disabling the START (PIN 7) signal. After
disabling, a new target position (current position plus D:S) is calculated in relation to the speed
and is specified as a command value.
i
Intern D
STROKE
G
Calculation of control gain
CAUTION: If the maximum stroke (SYS_RANGE command) is changed, the deceleration
distance must also be adjusted. Otherwise this can result in instability and uncontrolled
movements.
4
CAUTION! In older modules this parameter was specified in % of the maximum stroke. Since data
specification for this module has now been converted to mm, the relationship between the stroke
(SYS_RANGE command) and these parameters must be taken into account.

Continental Hydraulics Installation Manual
Page 18 of 27 CEM-SA-B CHI 1020687 01/2016
V0:A / V0:B (Loop gain setting)
Command
Parameters
Unit
Group
V0:i x
i= A|B
x= 1… 400
s-1
VMODE = NC
This parameter is specified in s-1 (1/s).
In NC Mode normally the loop gain is specified rather than the deceleration stroke
5
.
The internal gain is calculated from this gain value together with the parameters VMAX and
SYS_RANGE.
i
Intern
i
D
STROKE
G
V
v
D


0
max
Calculation of the internal control gain
In NC Mode the following error at maximum speed is calculated by means of the loop gain. This
following error corresponds to the deceleration stroke with stroke-dependent deceleration. The
conversion and therefore also the correct data demands related to the closed loop control system
are relatively simple if the relationship described here is taken into account.
V0:RES (Scaling of the loop gain)
Command
Parameters
Unit
Group
V0:RES x
x= 1|100
-
VMODE = NC
V0:RES = 1 loop gain in s-1 (1/s) units.
V0:RES = 100 loop gain in 0.01 s-1 units
6
.
The increased resolution should be used in case of V0 < 4.
PT1 (Timing of the controller)
Command
Parameter
Unit
Group
PT1 x
x= 0… 300
ms
EXP
This parameter can be used to change the internal timing of the control function.
Hydraulic drives are often critical to control especially in case of high speeds and very fast valves.
The PT1 filter can be used to improve the damping rate and allows therefore higher loop gains.
Requirements for the use are: The natural frequency of the valve should be equal or higher than
the natural frequency of the drive.
5
The loop gain is alternatively defined as a KV factor with the unit (m/min)/mm or as V0in 1/s. The
conversion is
KV = V0/16,67.
6
In case of very low loop gains (1 s-1 to 3 s-1) the better resolution of the adjustment should be selected.

Continental Hydraulics Installation Manual
Page 19 of 27 CEM-SA-B CHI 1020687 01/2016
CTRL (Deceleration characteristics)
Command
Parameters
Unit
Group
CTRL x
x=
LIN|SQRT1|SQRT2
-
STD
The deceleration characteristic is set with this parameter. In case of positively overlapped
proportional valves the SQRT function should be used. The non-linear flow function of these
valves is linearized by the SQRT
7
function.
In case of zero lapped valves (control valves and servo valves) the LIN or SQRT1 function should
be used regardless of the application. The progressive characteristic of the SQRT1 function has
better positioning accuracy but can also lead to longer positioning times in individual cases.
LIN: Linear deceleration characteristic (gain is increased by a factor of 1).
SQRT1: Root function for braking curve calculation. The gain is increased by a factor of 3 (in
the target position). This is the default setting.
SQRT2: Root function for braking curve calculation. The gain is increased by a factor of 5 (in
the target position). This setting should only be used with a significantly progressive
flow through the valve.
7
The SQRT function generates constant deceleration and thus reaches the target position faster. This is
achieved by increasing the gain during the deceleration process.
Figure 2 (Braking function with respect to stroke and time)
Stroke
Velocity
Braking stroke
D:Aor D:B
CTRL = LIN
CTRL = SQRT
Time
Velocity
Deceleration time
D:Aor D:B
CTRL = LIN
CTRL = SQRT

Continental Hydraulics Installation Manual
Page 20 of 27 CEM-SA-B CHI 1020687 01/2016
MIN:A / MIN:B (Dead band compensation)
MAX:A / MAX:B (Output scaling)
TRIGGER (Response threshold for the MIN parameter activation)
Command
Parameters
Unit
Group
MIN:i x
MAX:i x
TRIGGER x
i= A|B
x= 0… 6000
x= 3000… 10000
x= 0… 4000
-
0.01 %
0.01 %
0.01 %
STD
The output signal to the valve is adjusted by means of these commands. A kinked volume flow
characteristic is used instead of the typical overlap step for the position controls. The advantage
is better and more stable positioning behavior. At the same time, kinked volume flow
characteristics can also be adjusted with this compensation
8
.
If there should also be adjustment options for deadband compensation on the valve or valve
amplifier, it must be ensured that the adjustment is performed either at the power amplifier or in
the module.
If the MIN value is set too high, this has an effect on the minimum speed, which can then no
longer be adjusted. In extreme cases this leads to oscillation around the controlled position.
MAX:A
MIN:A
MIN:B
MAX:B
Input
Output
non lineare Flow
compensation
Standard deadband
compensation
TRIGGER
8
Various manufacturers have valves with a defined nonlinear curve: e.g. a kink at 40 or 60 %
(corresponding to 10 % input signal) of the nominal volume flow. In this case the TRIGGER value should be
set to 1000 and the MIN value to 4000 (6000).
If zero lapped or slightly underlapped valves are used, the volume flow gain in the zero range (within the
underlap) is twice as high as in the normal working range. This can lead to vibrations and jittery behavior. To
compensate this, the TRIGGER value should be set to approximately 200 and the MIN value to 100. The
gain in the zero point is thus halved and an overall higher gain can often be set.
