Converters.TV 1 by 8 HDMI to CAT6 Splitter User manual

1 by 8 HDMI to CAT6
Splitter ID #743
Operation Manual

Introduction
The 1 by 8 HDMI to CAT6 1.3 splitter when used with CAT6 to HDMI receivers it will
allows user to distribute a HDMI source throu h CAT6 cable over 45 meters. This
solution provides a direct input of one HDMI to a looped output of HDMI and 7
CAT6 outputs – a smart way to link and display a sin le source to 8 different
screens simultaneously. Alternatively, the HDMI output can also be treated as an
extender to connect to another HDMI splitter or cascade with other unit in
multiple layers. This unit allows user to transmit HDMI si nal via CAT6 without
compression over lon distance. The HDMI to CAT6 splitter also incorporates
functions like EDID, System Reset, Deep color and IR systems.
Applications
 One HDMI extension source with multi CAT6 to HDMI displays and one
HDMI loop throu h output
 Home entertainment inte ration
 Multi-task project presentation
 Showroom Display
 Advertisin display control
 System installation control
System
Requirements
 Input source equipment(s) with HDMI Cable(s).
 Output display device(s) with HDMI cables and or CAT 6 to HDMI receiver
with HDMI cable to display.
Features
●HDMI 1.3, HDCP1.1 and DVI1.0 compliant
 Deep color video up to 12bit, 1080p@60Hz
 One HDMI source connection to one HDMI output and seven CAT6 to
HDMI - allowin users to link up to ei ht displays simultaneously
 HDCP keysets allows each output to work independently when
connectin to a HDMI display
 Supports DVI source and DVI display by usin HDMI to/from DVI adaptor
cable
 Supports LPCM 7.1CH, Dolby TrueHD, Dolby Di ital Plus and DTS-HD
Master Audio transmission (32-192kHz Fs sample rate)
 Supports a wide ran e of PC and HDTV resolutions from VGA to SXGA
(1280 x 1024) and 480i to 1080p.
 Selects EDID from TV mode or STD mode (this splitter)
 Deep color settin of 8 bit or 12 bit
 IR remote control
 System Reset function
 CEC Bypass

Operation
Controls and
Functions
Front Panel
1. HDMI/DVI indicators: When LED illuminate this means the input source
is with HDMI content and when the input source is DVI the LED will not
illuminate.
2. HDC indicators: When the input source is with the HDCP protection the
HDCP LED will illuminate.
3. SYNC Indicator: The LED will illuminate when the device detected source's
si nal.
4. Output LED1~8: The LED will illuminate when output display is connected with
power on.
5. ower LED: The LED will illuminate when power is on.
Rear Panel
1. IR IN: This slot is to connect with the IR receiver cable included in the
packa e and use the existin source’s remote controls to control source
equipments.
2. IR OUT: This slot is to connect with the IR blaster cable included in the
packa e and place it in front of the sources for infrared si nal sendin .
3. EDID Control Switcher: Switch the EDID between STD & TV. Switch to STD
to use built-in EDID or switch to TV to use TV’s EDID. Default factory settin
is on TV, leave as it is when picture is displayed properly.
Note:
1. When EDID switch to TV, the unit will detect the first HDMI output
sink’s EDID and record in the unit. If the first detected output sink is DVI it will pass
to next source until the first HDMI source been detected. The detection priority is
HDMI v1.3 > HDMI v1.2 > DVI.
2. When EDID switch to STD the unit will use built-in EDID which supports:
Video → 1080p 8-bit or 12-bit (max)

Audio → PCM 2CH
3. The EDID selection will only activate when the unit is re-plu and power on.
4. System Reset: Switch to “ON”, the system will send the internal CEC to the
display within 8~10 minutes to force all the displays to switch to HDMI 1
input port. Meanwhile, the source’s CEC will not functional to the system.
When switch to “OFF”, the system reset function will be terminate. Factory
default is on “OFF”.
5. HDMI input: This slot is for connectin the source equipment with HDMI
cables.
6. HDMI output: This slots is for connectin the display with HDMI Cable.
Note:
A. Cable tested with CAT-6E / 23AWG / Solid and therefore, cable with
different specification may result in different distance.
B. Cable distance tested with equipment PS3 40G, and 37" SamSun 12 bit
LCD TV.
C. Fi ures provided in this manual are reference fi ures only, actual
fi ures may depend on source and display use with cable specification.
7. Video/DDC 2~8: These slots allow you connect to the HDMI displays with
CAT6 to HDMI receiver. When more than one output are connected, the
HDMI outputs play identical video si nal simultaneously.
8. ower: This slot is to plu the 5VDC power supply included in the packa e
into the unit and connect the adaptor to an AC wall outlet.
IR Pin
Definitions
Note: The frequency on both IR Receiver & Blaster can support 20~60KHz.

RJ-45 Pin
Definitions
Installation

Specifications
Frequency Bandwidth 2.25Gbps (single link)
Input Ports 1 x HDMI female port (Type A onne tor)
Output Ports 7 x CAT6 output Video/7 x CAT6 output DDC
1 x HDMI female port (Type A onne tor)
DID STD / TV
HDMI Audio Output PCM2, 5.1, 7.1, Dolby 5.1, DTS 5.1, DD+, D-
TrueHD, DTS-HD
HDMI Cable In 1080p 8-bit (15M), 12-bit (10M)
HDMI Cable Out 1080p 8-bit (15M), 12-bit (10M)
CAT6 Cable Out 1080p 8-bit (45M), 12-bit (15M)
HDMI Resolution 480i, ~ 1080p 50/60, 1080p 24, VGA ~ SXGA
IR Frequency 20 ~ 60KHz
SD Protection Human body model:
± 8kV (air-gap dis harge)
± 4kV ( onta t dis harge)
Power Supply 5VDC/6A (US/EU standards, CE/FCC/UL
ertified)
Dimensions (mm) 436(W) x160(D) x 44(H)
Weight(g) 2130
Chassis Material Metal
Silkscreen Color Bla k
Power Consumption 20W
Operating Temperature 0˚C ~ 40˚C / 32˚F ~ 104˚F
Storage Temperature -20˚C ~ 60˚C / -4˚F ~ 140˚F
Relative Humidity 20~90% RH (non- ondensing)
