Converters.TV HDMI v1.3 over CAT6 Distributor User manual

HDMI v1.3 over CAT6
Distributor 8 out ID #745
Operation Manual

Introduction
The HDMI v1.3 over CAT6 Distributor 8 out splitter when used with HDMI to CAT6
transmitter it will allows user to distribute a HDMI source to HDMI displays
located 40 meters away through two CAT6 cables. This solution provides a direct
input of one CAT6 to a looped output of CAT6 and HDMI outputs – a smart way
to link and display a single source to 8 different screens simultaneously.
Alternatively, the CAT6 output can also be treated as an extender to connect to
another CAT6 splitter or cascade with other unit in multiple layers. This unit allows
user to transmit HDMI signal via CAT6 without compression over long distance.
The CAT6 to HDMI splitter also incorporates functions like EDID, System Reset,
Deep color and IR systems.
Applications
 One CAT6 extension source with multi HDMI displays and one CAT6 loop
through output
 Home entertainment integration
 Multi-task project presentation
 Showroom Display
 Advertising display control
 System installation control
System
Requirements
 Need to work with a HDMI to CAT6 transmitter on the other end.
 Output display device(s) with HDM cables and or CAT6 to HDM receiver
with HDM cable to display.
Features
●HDMI 1.3, HDCP1.1 and DVI1.0 compliant
 Deep color video up to 12bit, 1080p@60Hz
 One CAT6 source connection to one CAT6 and seven HDM - allowing
users to link up to eight displays simultaneously
 HDCP keysets allows each output to work independently when
connecting to a HDM display
 Supports DV source and DV display by using HDM to/from DV adaptor
cable
 Supports LPCM 7.1CH, Dolby TrueHD, Dolby Digital Plus and DTS-HD
Master Audio transmission (32-192kHz Fs sample rate)
 Supports a wide range of PC and HDTV resolutions from VGA to SXGA
and 480i to 1080p.
 Selects ED D from TV mode or STD mode (this splitter)
 Deep color setting of 8 bit or 12 bit
 R remote control
 System Reset function
 CEC Bypass

Operation
Controls and
Functions
Front Panel
1. HDMI/DVI indicators: When LED illuminate this means the input source
is with HDMI content and when the input source is DVI the LED will not
illuminate.
2. HDCP indicators: When the input source is with the HDCP protection the
HDCP LED will illuminate.
3. S NC Indicator: The LED will illuminate when the device detected source's
signal.
4. Output LED1~8: The LED will illuminate when output display is connected with
power on.
. Power LED: The LED will illuminate when power is on.
Rear Panel
1. IR IN: This slot is to connect with the IR receiver cable included in the
package and use the existing source’s remote controls to control source
equipments.
2. IR OUT: This slot is to connect with the IR blaster cable included in the
package and place it in front of the sources for infrared signal sending.
3. EDID Control Switcher: Switch the EDID between STD & TV. Switch to STD to
use built-in EDID or switch to TV to use TV’s EDID. Default factory setting is
on TV, leave as it is when picture is displayed properly.
Note:
1. When EDID switch to TV, the unit will detect the first HDMI output
sink’s EDID and record in the unit. If the first detected output sink is DVI it will pass
to next source until the first HDMI source been detected. The detection priority is
HDMI v1.3 > HDMI v1.2 > DVI.
2. When EDID switch to STD the unit will use built-in EDID which supports:

Video → 1080p 8-bit or 12-bit (max)
Audio → PCM 2CH
3. The ED D selection will only activate when the unit is re-plug and power on.
4. System Reset: Switch to “ON”, the system will send the internal CEC to the
display within 8~10 minutes to force all the displays to switch to HDMI 1 input
port. Meanwhile, the source’s CEC will not functional to the system. When
switch to “OFF”, the system reset function will be terminate. Factory default is
on “OFF”.
. Video/DDC input: These slots are for connecting the Video/DDC input to
the Video/DDC output of the transmitter unit with CAT6 cables.
6. Video/DDC output: These slots are for connecting the Video/DDC output
to the Video/DDC input of the receiver unit with CAT6 cables.
Note:
A. Cable tested with CAT-6E / 23AWG / Solid and therefore, cable with
different specification may result in different distance.
B. Cable distance tested with equipment PS3 40G, 3 " Philips 8 bit LCD
TV and 3 " SamSung 12 bit LCD TV.
C. Figures provided in this manual are reference figures only, actual
figures may depend on source and display use with cable specification.
7. HDMI Outputs 2~8: These slots allow you connect to the HDMI displays with
HDMI cables. When more than one output are connected, the HDMI outputs
play identical video signal simultaneously.
8. Power: This slot is to plug the 5VDC power supply included in the package
into the unit and connect the adaptor to an AC wall outlet.
IR Pin
Definitions
Note: The frequency on both IR Receiver & Blaster can support 20~60KHz.

RJ-45 Pin
Definitions
Installation

Specifications
Frequency Bandwidth 2.25Gbps (single link)
Input Ports 1 x CAT6 input Video/1 x CAT6 input DDC
Output Ports 1 x CAT6 output Video/1 x CAT6 output DDC
7 x HDM female ports (Type A connector)
EDID STD / TV
HDMI Audio Output PCM2, 5.1, 7.1, Dolby 5.1, DTS 5.1, DD+, D-
TrueHD, DTS-HD
HDMI Cable Out 1080p 8-bit (15M), 12-bit (6M)
CAT6 Cable In 1080p 8-bit (45M), 12-bit (20M)
CAT6 Cable Out 1080p 8-bit (45M), 12-bit (20M)
HDMI Resolution 480i, ~ 1080p 50/60, 1080p 24, VGA ~ SXGA
IR Frequency 20 ~ 60KHz
ESD Protection Human body model:
± 8kV (air-gap discharge)
± 4kV (contact discharge)
Power Supply 5VDC/5A (US/EU standards, CE/FCC/UL
certified)
Dimensions (mm) 436(W) x160(D) x 44(H)
Weight(g) 2130
Chassis Material Metal
Silkscreen Color Black
Power Consumption 20W
Operating Temperature 0˚C ~ 40˚C / 32˚F ~ 104˚F
Storage Temperature -20˚C ~ 60˚C / -4˚F ~ 140˚F
Relative Humidity 20~90% RH (non-condensing)
