Converters.TV 489 User manual

HDMI to HDMI Splitter
1 input : 8 output ID#489
Operation Manual

Introduction
HDMI to HDMI Splitter 1 input : 8 output is a High Performance HDMI
Distribution Amplifier.
It allows one HDMI source to output to 8 HDMI displays simultaneously.
Features
1. Solid and durable metal housing with all connections labeled and lined
up on the bac .
2. Built-in HDCP ey-sets allows each output to wor independently when
connecting to a HDMI display.
3. Splits a HDMI source to 8 outputs, all at 1080p, without signal loss.
4. Supports DVI source and DVI display by using HDMI to/from DVI
adapter cable.
5. Supports a wide range of PC and HDTV resolutions, from VGA to
UXGA and 480p to 1080p. Maximum resolution bandwidth-165MHz.
6. Can be cascaded to another HDMI to HDMI Splitter for more outputs.
7. Each of the buffered outputs can operate on a cable length of up to 15
meters @ 1600x1200, or 1080p.
8. Support multi-channel compressed & uncompressed HDMI audio.
9. Full HDCP compliant.
10.Enhance function for signal pre-emphasis.
11. Fast handsha ing reduces pre-picture blac out time to 5 seconds.
Operating Functions
and Controls
Front Panel
1. Power Switch: Press the switch to power on the unit.
2. Power LED Indicator: The LED will illuminate when the unit is
operating.
3. Sync LED: The LED will illuminate when the HDMI source signal is
connected to the input and is detected by the unit.

4. Signal Enhancement/Indicator: Press the "Enhance" button to turn on
this feature to improve signal quality over long distance transmission.
Press again to turn off. The LED will illuminate when the signal is
enhanced.
Output LEDs: When a display TV is connected to one of the
output ports its corresponding LED will illuminate.
Rear Panel
1. HDMI input: Connect to the HDMI or DVI output of your source
equipment such as DVD play or set-top-box.
2. HDMI output 1/2/3/4/5/6/7/8: Connect each of these output ports to the
HDMI input of a HDMI display.
3. Power input: Plug the supplied 5VDC power supply into the unit.
Installation

Specifications
–Frequency bandwidth: 1.65Gbps(single lin )
–Input/Output: 1 in to 8 out HDMI female
port
–5VDC universal power supply
–Operating temperature range: 0° - 70° C
–Operating humidity range: 30 to 80% R
–Dimensions: 434(W)x1 16(D)x44(H)mm
–Weight: 2.1 gs
