Convision CC-5400 User manual

Manual CC 5400 1
Manual
CC-5400
Date: January 2011 Convision Systems GmbH

Manual CC 5400 2
The lightning flash with an arrowhead symbol, within an equilateral
triangle is intended to alert the user to the presence of uninsulated
dangerous voltage within the product's enclosure that may be of
sufficient magnitude to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert
the user to the presence of important operating and maintenance
(servicing) instructions in the literature accompanying the appliance.
INFORMATION - This equipment has been tested and found to comply with
limits for a Class A digital device, pursuant to part 15 of the FCC Rules & CE Rules.
These limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial environment.
This equipment generates, uses, and can radiate radio frequency energy and, if
not installed and used in accordance with the instruction manual, may cause
harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at
his own expense.
WARNING - Changes or modifications not expressly approved by the
manufacturer could void the user’s authority to operate the equipment.
CAUTION : To prevent electric shock and risk of fire hazards:
Do NOT use power sources other than those specified.
Do NOT expose this appliance to rain or moisture.
This Installation should be made by a qualified service person and should confirm to all local codes.

Manual CC 5400 3
Warning
The camera requires periodic inspection.
Contact an authorised technician to carry out the inspection.
Stop using your camera when you find it malfunctioning.
If the camera emits smoke or is unusually hot for a long period, a fire may be caused.
Do not install the camera on a surface that can not support it.
If the camera is installed on an inappropriate surface, it may fall and cause injury.
Do not hold plug with wet hands.
It could cause an electric shock.
Do not dis-assemble the camera.
It may result in an electric shock or other hazards.
Do not use the camera close to a gas or oil leak.
It may result in a fire or other hazards.

Manual CC 5400 4
Contents
NOTICE 5
Important Safeguard 5
Precautions 5
Features 6
Product & Accessories 7
Parts Name & Function 8
DIP Switch Setup 9
Installation with Ceiling Mount Bracket 11
Installation with Wall Mount Bracket 12
Cabling 13
Operation 15
Check points before operation 15
Preset and Pattern Function Pre-Check 15
Starting OSD Menu 16
Reserved Preset 16
Preset 17
Swing 17
Pattern 18
Group 19
Other Functions 19
How to Use OSD Menu 21
General Rules of Key Operation for Menu 21
Main Menu 21
Display Setup 21
Camera Setup 22
Motion Setup 24
Preset Setup 25
Swing Setup 27
Pattern Setup 27
Group Setup 28
System Initialize 29
Specifications 31
Dimension 32

Manual CC 5400 5
NOTICE
Important Safeguard
1. Read Instructions
Read all of the safety and operating instructions before using the product.
2. Retain Instructions
Save these instructions for future reference.
3. Attachments / Accessories
Do not use attachments or accessories unless recommended by the appliance manufacturer as they
may cause hazards, damage product and void warranty.
4. Water and Moisture
Do not use this product near water or moisture.
5. Installation
Do not place or mount this product in or on an unstable or improperly supported location. Improperly
installed product may fall, causing serious injury to a child or adult, and damage to the product. Use only
with a mounting device recommended by the manufacturer, or sold with the product. To insure proper
mounting, follow the manufacturer's instructions and use only mounting accessories recommended by
manufacturer.
6. Power source
This product should be operated only from the type of power source indicated on the marking label.
Precautions
■Operating
-Before using, make sure power supply and others are properly connected.
-While operating, if any abnormal condition or malfunction is observed, stop using the camera
immediately and then contact your local dealer.
■Handling
-Do not disassemble or tamper with parts inside the camera.
-Do not drop or subject the camera to shock and vibration as this can damage camera.
-Care must be taken when you clean the clear dome cover. Especially, scratch and dust will ruin your
quality of camera.
■Installation and Storage
-Do not install the camera in areas of extreme temperature, which exceed the allowable range.
-Avoid installing in humid or dusty places.
-Avoid installing in places where radiation is present.
-Avoid installing in places where there are strong magnetic fields and electric signals.
-Avoid installing in places where the camera would be subject to strong vibrations.
-Never expose the camera to rain and water.

Manual CC 5400 6
Features
■Camera Specifications
•CCD Sensor : 1/4" Interline Transfer CCD
•Zoom Magnification : ×10 Optical Zoom, ×10 Digital Zoom (Max×100 Zoom)
•Day & Night Function, Privacy Mask and WDR (WDR possible Models only)
•Various Focus Mode: Auto-Focus / Manual Focus / Semi-Auto Focus.
•Various Setup Options in OSD Menu
■Powerful Pan/Tilt Functions
•Max. 360˚/sec high speed Pan/Tilt Motion
•Using Vector Drive Technology, Pan/Tilt motions are accomplished in a shortest path. As
a result, time to target view is reduced dramatically and the video on the monitor is very
natural to watch.
•For jog operation using a controller, since ultra slow speed 0.05˚/sec can be reached, it is
very easy to locate camera to desired target view. Additionally it is easy to move camera
to a desired position with zoom-proportional pan/tilt movement.
■Preset, Pattern, Swing, Group, Privacy Mask and More...
•MAX. 127 Presets are assignable and characteristics of each preset can be set up
independently, such as White Balance, Auto Exposure, Label and so on.
•Max. 8 set of Swing action can be stored. This enables to move camera repetitively
between two preset positions with designated speed.
•Max. 4 of Patterns can be recorded and played back. This enables to move camera to
follow any trajectory operated by joystick as closely as possible.
•Max. 8 set of Group action can be stored. This enables to move camera repetitively
with combination of Preset or Pattern or Swing. A Group is composed of max. 20 entities of
Preset/Pattern/Swings.
•Privacy Masks are assignable, not to intrude on other's privacy. (4 Privacy Zones)
■PTZ(Pan/Tilt/Zoom) Control
•With RS-485 communication, max. 255 of cameras can be controlled at the same time.
•Pelco-D or Pelco-P protocol can be selected as a control protocol in the current version of
firmware.
■OSD(On Screen Display) Menu
•OSD menu is provided to display the status of camera and to configure the functions
interactively.
•The information such as Camera ID, Pan/Tilt Angle, Alarm Input and Preset can be
displayed on screen.

Manual CC 5400 7
■Alarm I/O Functions
•3 alarm sensor Inputs are available.
•To reject external electric noise and shock perfectly, alarm sensor Input is decoupled with
photo coupler.
•The signal range of sensor input is from DC 5.0 to 12.0 volts to adopt various pplications.
•If an external sensor is activated, camera can be set to move to the corresponding
Preset position.
■Reserved Presets for Special Purpose
•Most camera characteristics can be set up easily and directly with reserved preset, not
entering into OSD menu. For more information, refer to "Reserved Preset" in this manual.
■Perfect Outdoor Environment Compatibility and Easy Installation
•The fans and heaters are built-in in the camera for cold and hot temperature environment.
Also idealistic mechanical design protects the camera from water and dust. (IP66 when
installed properly with wall mount bracket only / Only for outdoor models)
•It is easy to install and repair the camera
Product & Accessories
Product & Accessories
Main Body & Surface Mount Bracket Default Accessories
(Main Cable, Wrench)
Accessories for the Models with Alarm In/Out
Function (I/O Cable)

Manual CC 5400 8
Options
Wall Mount Bracket Ceiling Mount Bracket
Parts Name & Function
●Dome Cover: Do not detach protection vinyl from dome cover before finishing all
installation process to protect dome cover from scratches or dust.
●DIP Switch: Adjusts camera ID and protocols.
●Mounting Hook: Used to assemble the main body with wall mount bracket or ceiling
mount bracket. Insert the mounting hooks into the holes on the surface of the main body
and turn the main body.
●Mounting Screw Hole: Used to assemble the main body with a bracket with screws.
●Main Connector: Used for the power wire, the video cable and the RS-485 communication
cable connection.
●Sensor I/O Port: Used for the sensor in/out connection. (The sensor I/O function possible
models only).

Manual CC 5400 9
●LAN Port: Used for the Ethernet connection. (IP addressable models only)
●Audio Port: Used for the audio in/out connection. (IP addressable models only)
●Reset Switch: Used to initialize all the network configurations to the factory default. (IP
addressable models only) Press button for more than 5 seconds to initialize the network
system.
DIP Switch Setup
Before you install the camera, you should set the DIP switches to configure the camera ID,
communication protocol.
Camera ID Setup
- ID number of camera is set using binary number. The example
is shown bellow.
- The range of ID is 1~255. Do not use 0 as camera ID. Factory
default of Camera ID is 1.
- If you want to control a certain camera, you must match the
camera ID with Cam ID setting of DVR or Controller.

Manual CC 5400 10
Communication Protocol Setup
- Select the appropriate Protocol with DIP switch combination.
- If you want to control using DVR or P/T controller, their
protocol must be identical to camera. Otherwise, you can not
control the camera.
- If you changed camera protocol by changing DIP S/W, the
change will be effective after you reboot the camera.
- Factory default of protocol is "Pelco-D, 2400 bps".
Reserved for Supplier
- Since Pin 3 ~ Pin 4 is only for supplier, DO NOT CHANGE
THESE ITS ORIGINAL STATE. If you change one of these, proper
operation can not be achieved.
Pin 3: PAL / NTSC system selection of Camera. DO NOT
CHANGE THIS PIN.
Pin 4: Factory default is ON state. This pin is used for system
firmware upgrade. DO NOT CHANGE THIS PIN.

Manual CC 5400 11
Installation with Ceiling Mount Bracket
1) Remove the ceiling tile from the ceiling and
cut a hole whose diameter is 30~40mm on the
ceiling tile to pass the wire(s) and cable(s)
through to the upside of the ceiling. (In case of
the wiring and cabling through the mounting
surface only) Then prepare the ceiling mount
bracket. Pull the wire(s) for the system as
below.
2) Pull the wire(s) and cable(s) for the system
as below. Wire the cable(s) to the ports. Insert
the mounting hooks into the holes on the
surface of the main body and turn the main
body. Assemble the main both with the camera
mount adaptor with the 3 screws.
3) Screw the dome cover to the main body and remove
the protection vinyl from the dome cover.

Manual CC 5400 12
Installation with Wall Mount Bracket
1) Make a hole whose diameter is 30~40mm
on the mounting surface to pass the wire(s)
and cable(s) through the mounting surface.
Then prepare the wall mount bracket. Pull
the wire(s) and cable(s) for the system as
below. Attach the wall mount bracket to the
mounting surface.
2) Wire the cable(s) to the ports. Insert the
mounting hooks into the holes on the
surface of the main body and turn the main
body. Assemble the main both with the
camera mount adaptor with 3 screws.
3) Screw the dome cover to the main body and remove the protection vinyl from the dome cover.

Manual CC 5400 13
Cabling
Port Description
Main Cable
Port Pin Number (RJ45) Connector / Wire Color Signal
1 Video +
2,4
BNC Connector
Video -
5 Red RS-485 +
3 Yellow RS-485 -
7 Orange Power +
6,8 White Power -
I/O Cable
Port Pin Number (RJ45) Wire Color Signal
1 Blue IN COM +
2 Yellow IN 1 -
3 Green IN 2 -
4 Red IN 3-
5 Black Out A
6 White Out B
Audio Cable
Port Pin Number Connector / Wire Color Signal
1 RCA (Yellow) Audio IN
2 Audio GND
3 RCA (White) Audio Out

Manual CC 5400 14
Power Description
Carefully check the voltage and current capacity of the rated power. The rated power is indicated in the
back of main unit.
Model Input Voltage Range Current Consumption
0.8AAnalog Model
2.5A
1.3A
DC12V Model IP Addressable Model DC11V~18V
3.0A
AC24V Model Analog Model AC17V~29V 1.5A
Dual Power
Model
Analog Model DC11V~18V or AC17V
~ 29V
DC12V, 0.8A / AC24V,
0.4A
- For the DC input models, be careful with the polarity of DC power. The systems should be
permanently damaged by wrong DC input.
- In case that the length of the power wire is very long, there may be voltage drop and the
system may not work properly. Make the length of the power wire as short as possible.
RS-485 Communication
For PTZ control, connect this line to keyboard and DVR. To control multiple cameras at the same time,
RS-485 communication lines of them is connected in parallel as shown below.
Video Connection
- Connect with BNC coaxial cable.
Alarm Input Connection
- Sensor Input
Before connecting sensors, check driving voltage and output signal type of the sensor. Since output
signal types of the sensors are divided into Open Collector and Voltage Output type in general, the
cabling must be done properly after considering these typed.

Manual CC 5400 15
If you want to use Alarm Input, the types of sensor must be selected in OSD menu. The sensor types
are Normal Open and Normal. If sensor type is not selected properly, the alarm can be activated
reversely.
Operation
Check points before operation
Before power is applied, please check the cables carefully.
The camera ID of the controller must be identical to that of the target camera.
The camera ID can be checked by reading DIP switch of the camera.
If your controller supports multi-protocols, the protocol must be changed to match to that
of the camera.
If you changed camera protocol by changing DIP switch, the change will be effective after
you reboot the camera.
Since the operation method can be different for each controller available, refer to the
manual for your controller if camera can not be controlled properly. The operation of this
manual is based on the standard Pelco® Controller.
Preset and Pattern Function Pre-Check
●Check how to operate preset and pattern function with controller or DVR in advance to
operate camera function fully when using controller or DVR.
●Refer to the following table when using standard Pelco® protocol controller.
●If controller or DVR has no pattern button or function, use shortcut keys with preset
numbers. For more information, refer to "Reserved Preset" in this manual.

Manual CC 5400 16
Starting OSD Menu
●Function: Using the OSD menu, Preset, Pattern, Swing, Group and Alarm Input function
can be configured for each application.
●Enter Menu: <Go Preset> [95]
Reserved Preset
●Description:
¾Some Preset numbers are reserved to special functions.
●Description:
¾<Go Preset> [95] : Enters into OSD menu
¾<Go Preset> [131~134] : Runs Pattern Function 1 ~ 4
¾<Go Preset> [141~148] : Runs Swing Function 1 ~
¾<Go Preset> [151~158] : Runs Group Function 1 ~ 8
¾<Go Preset> [161~162] : Sets Relay Output 1 ~ 2 to OFF
¾<Set Preset> [161~162] : Sets Relay Output 1 ~ 2 to ON
¾<Go Preset> [170] : Sets Camera BLC Mode to OFF
¾<Go Preset> [171] : Sets Camera BLC Mode to ON
¾<Go Preset> [174] : Sets Camera Focus Mode to AUTO
¾<Go Preset> [175] : Sets Camera Focus Mode to Manual
¾<Go Preset> [176] : Sets Camera Focus Mode to SEMI-AUTO
¾<Go Preset> [177] : Sets Day & Night Mode to AUTO
¾<Go Preset> [178] : Sets Day & Night Mode to NIGHT
¾<Go Preset> [179] : Sets Day & Night Mode to DAY
¾<Go Preset> [190] : Sets OSD Display Mode to AUTO
(Except Privacy Mask)
¾<Go Preset> [191] : Sets OSD Display Mode to OFF
(Except Privacy Mask)
¾<Go Preset> [192] : Setting OSD Display Mode to ON
(Except Privacy Mask)
¾<Go Preset> [193] : Sets all Privacy Mask Display to OFF
¾<Go Preset> [194] : Sets all Privacy Mask Display to ON

Manual CC 5400 17
Preset
●Function: Max. 127 positions can be stored as Preset position. The Preset number can be
assigned from 1 to 128, but 95 is reserved for starting OSD menu. Camera characteristics
(i.e. White Balance, Auto Exposure) can be set up independently for each preset. Label
should be blank and "Camera Adjust" should be set to "GLOBAL" as default. All
characteristics can be set up in OSD menu.
●Set Preset: <Set Preset> [1~128]
●Run Preset: <Go Preset> [1~128]
●Delete Preset: To delete Preset, use OSD menu.
Swing
●Function: By using Swing function, you can make camera to move between 2 Preset
positions repeatedly. When swing function runs, camera moves from the preset assigned as the 1st
point to the preset assigned as the 2nd point in CW (Clockwise) direction. Then camera moves from the
preset assigned as the 2nd point to the preset assigned as the 1st point in CCW (Counter clockwise)
direction.
In case that the preset assigned as the 1st point is same as the preset assigned as the 2nd point,
camera turns on its axis by 360˚in CW(Clockwise) direction and then it turns on its axis by 360˚in
CCW(Counter clockwise) direction. Speed can be set up from 1˚/sec to 180˚/sec.
●Set Swing: To set Swing, use OSD menu.
●Run Swing: Method 1) <Run Pattern> [Swing NO.+10]
ex) Run Swing 3 : <Run Pattern> [13]
Method 2) <Go Preset> [Swing NO.+140]
ex) Run Swing 3 : <Go Preset> [143]
●Delete Swing: To delete Swing, use OSD menu.

Manual CC 5400 18
Pattern
●Function: Pattern Function is that a camera memorizes the path (mostly curve path) by joystick of
controller for assigned time and revives the path exactly as it memorized. 4 Patterns are available and
Maximum 1200 communication commands can be stored in a pattern.
●Set Pattern: Pattern can be created by one of following two methods.
Method 1) <Set Pattern> [Pattern NO.]
- Pattern editing screen is displayed as bellow.
- Movement by Joystick and preset movement can be memorized in a pattern.
- The rest memory size is displayed in progress bar.
- To save the recording, press NEAR key and to cancel, press FAR key.
Method 2) OSD Using OSD Menu: See the section "How to use OSD Menu".
●Run Pattern: Method 1) <Run Pattern> [Pattern NO.]
ex) Run Pattern 2 : <Run Pattern> [2]
Method 2) <Go Preset> [Pattern NO.+130]
ex) Run Pattern 2: <Go Preset> [132]
●Delete Pattern: Use OSD menu to delete a Pattern.

Manual CC 5400 19
Group
●Function: The group function allows running sequence of Presets, Pattern and/or Swings. Max 8
group can be stored. Each group can have max 20 action entities which can be preset,
pattern or swing. Preset speed can be set up and the repeat number of Pattern & Swing
can be set up in Group setup. Dwell time between actions can be set up also.
●Set Preset: Use OSD Menu to create a Group.
●Run Preset: Method 1) <Run Pattern> [Group NO.+20]
ex) Run Group 7 : <Run Pattern> [27]
Method 2) <Go Preset> [Group NO.++150]
ex) Run Group 7 : <Go Preset> [157]
●Delete Preset: Use OSD Menu to delete.
Other Functions
●Power Up Action
- This function enables to resume the last action executed before power down. Most of
actions such as Preset, Pattern, Swing and Group are available for this function but Jog
actions are not available to resume.
●Auto Flip
- In case that tilt angle arrives at the top of tilt orbit (90˚), zoom module camera keep moving to
opposite tilt direction (180˚) to keep tracing targets. As soon as zoom module camera passes
through the top of tilt direction(90˚), images should be reversed automatically and F appears in
screen. If this function is set to OFF, tilt movement range is 0 ~ 95˚.
●Parking Action
- This function enables to locate the camera to specific position automatically if operator
doesn’t operate the controller for a while. The Park Time can be defined as an interval from 1
minute to 4 hours.
●Alarm Input
- 4 Alarm Inputs are used. If an external sensor is activated, camera can be set to move to
corresponding preset position. It is noted that the latest alarm input is effective if multiple
sensors are activated.
●Privacy Zone Mask
- To protect privacy, MAX. 4 Privacy Masks can be created on the arbitrary position to hide objects
such as windows, shops or private house. With Spherical Coordinates system,
powerful Privacy Zone Mask function is possible.
●GLOBAL/ LOCAL Image Setup
- WB(White Balance) and AE(Auto Exposure) can be set up independently for each preset. There
are 2 modes, "Global" mode & "Local" mode. The Global mode means that WB or AE can be set up
totally and simultaneously for all presets in "ZOOM CAMERA SETUP" menu. The Local mode
means that WB or AE can be set up independently or separately for each preset in each preset
setup menu. Each Local WB/AE value should activate correspondingly when camera arrives at

Manual CC 5400 20
each preset location. During jog operation, Global WB/AE value should be applied. All Local WB/AE
value do not change although Global WB/AE value changes.
●Semi Auto Focus
- This mode exchanges focus mode automatically between Manual Focus mode and Auto
Focus mode by operation. Manual Focus mode activates in preset operation and Auto
Focus mode activates during jog operation. With Manual mode at presets, Focus data is
memorized in each preset in advance and camera calls focus data in correspondence
with presets as soon as camera arrives at a preset. It should shorten time to get focuses.
Focus mode changes to Auto Focus mode automatically when jog operation starts.
OSD Display of Main Screen
●P/T/Z Information: Current Pan/Tilt angle in degree, zoom magnification and a compass
direction.
●Camera ID: Current Camera ID(Address).
●Action Title: Followings are possible Action Titles and their meaning.
"SET PRESET xxx" When Preset xxx is stored
"PRESET xxx" When camera reach to Preset xxx
"PATTERN x" When Pattern x is in action
"SWG x/PRESET xxx" When Swing x is in action
"UNDEFINED" When undefined function is called to run
●Preset Label: The Label stored for specific Preset.
●Alarm Input: This information shows current state of Alarm Input. If an Input point is ON
state it will show a number corresponding to each point. If an Input point is
OFF state, '-' will be displayed. Ex) Point 2 & 3 of inputs are ON, OSD will
show as below.
●Image Flip: Shows that images are currently reversed by Auto Flip Function.
