Cooper Lighting Shaper 208 User manual

208 SERIES
Surface Luminaire
Starter Collection
Luminous Bowl
Specifications and dimensions subject to change without notice.
Consult your representative for additional options and finishes.
shaperlighting.com
208 Luminous Bowl features direct downlight component and a
luminous bowl with an optional luminous cone.
SPECIFICATION FEATURES
Material
Solid aluminum with a matte
white acrylic bowl. Optional
matte acrylic cone.
Finish
Standard: Natural Aluminum
(NA) [Sustainable Design].
Premium: Matte White (MW),
Lacquered Satin Aluminum
(SAL), Satin Copper (SCP) or
Custom Color (CC).
Optics
Refer to
www.shaperlighting.com for
complete photometrics.
Ballast
Integral electronic HPF, multi-volt
120/277V (347V Canada),
thermally protected with end-of-
life circuitry to accommodate the
specified lamp wattage.
Lamp/Socket
One (1) 26W or 32W (GX24q-3)
4-pin triple CFL lamp or one (1)
100W A-19 lamp. CFL socket
injection molded plastic. INC
socket fired ceramic rated for
660W-250V. Lamps furnished by
others.
Installation
Supplied with a universal
circular strap for a standard 4"
J-box or plaster ring.
Options
Cone Diffuser (CD), Remote
Emergency Battery - Supplied by
others (REM), Damp Location
(DL): All Painted Finishes only,
CFL Dimming Ballast - Contact
the factory for ballast options
(DM), MRI applications (INC only)
- Contact factory. Energy Star
Rating - consult factory.
Labels
U.L. and C.U.L. approved for
indoor and damp location. See
options for damp location
finishing requirements.
Modifications
Shaper's skilled craftspeople
with their depth of experience
offer the designer the flexibility
to modify standard surface
luminaires for project specific
solutions. Contact the factory
regarding scale options, unique
finishes, mounting, additional
materials/colors, or decorative
detailing.
DESCRIPTION
MAGNETIC
RESONANCE
IMAGING (MRI)
ENERGY
STAR
SUSTAINABLE
DESIGN
Refer to the Icon Legend
Link on shaperlighting.com.
Lighting fixtures for MRI facilities are
specialized and unique, requiring non-
ferrous construction. Fluorescent fixtures
cannot be used due to the ferrous parts in
ballasts and lampholders. Modified incan-
descent fixtures meet the requirements.
Shaper now offers a wide variety
of fixtures that can be provided
with an Energy Star Rating.
Shaper has a long-standing history of
offering environmentally-friendly fixtures.
The copper and bronze alloys used in our
exterior luminaires feature up to 98% re-
cycled content, contribute less undesirable
air emissions compared to painted alumi-
num and are easy to recycle.
Shaper’s exclusive Starter Collection fixtures
are featured throughout the Shaper product
line. The concept of offering highly styled,
affordable fixtures was introduced over
fourteen years ago and has become one of
our fastest growing lines. The design
premise, basic construction, clean lines
and unadorned shapes are highly desirable
in modern architectural environments.
STARTER
COLLECTION
Sample Number: 208-INC/1/100-120V-SCP
Finish
Standard
NA Natural Aluminum=
Premium
CC Custom Color=
MW Matte White=
SAL Lacquered
Satin Aluminum
=
SCP Satin Copper=
Options
CONE Cone Diffuser
=
DL Damp Location=
DM CFL Dimming
Ballast 2
4
=
REM Remote
Emergency
Battery 3
=
Voltage
120V
277V 1
347V 1
Series
208 Bowl Surface
Luminaire
=
Lamp
CFL/1
(26/32W-
Triple)
INC/1/100
1Available with CFL only.
Notes:
2Consult the factory for
3Supplied by others.
4Interior applications only.
available options.
ORDERING INFORMATION
ADS042703
2008-09-03 08:26:48
Catalog # Type
Date
Project
Comments
Prepared by

Specifications and dimensions subject to change without notice.
Shaper Lighting •1141 Marina Way South •Richmond, CA 94804 •ph 510.234.2370 •fax [phone]
618418 642-A
COMPANION PRODUCTS
3-1/2"
7-3/4"
6" ø
4" ø
2-3/4"
8-1/2" ø
4-3/4"
7-3/4"
208 CONE DIFFUSER OPTION (CD)
208 OPTION
208 STANDARD
14-1/2" ø
DIMENSIONS 208 SERIES SURFACE LUMINAIRE
