664 SERIES
Interior Wall Luminaire
Starter Collection
Direct/Indirect
Solid Shade with an
Arm Mount Bracket
Specifications and dimensions subject to change without notice.
Consult your representative for additional options and finishes.
shaperlighting.com
Catalog # Type
Date
Project
Comments
Prepared by
664 Direct/Indirect Luminous or Solid Shade with an arm mount
bracket.
SPECIFICATION FEATURES
Material
Aluminum arm and wall canopy.
Metal shade is solid brass, solid
copper or solid aluminum. Matte
white polyethylene two piece
cone. Optional Decorative Baffle
(BL).
Finish
Standard: Natural Aluminum
(NA). [Sustainable Design]
Premium: Matte White (MW),
Lacquered Satin Aluminum
(SAL), Satin Brass (SB), Satin
Copper (SCP), Polished Copper
(PCP) or Custom Color (CC).
Optics
Refer to
www.shaperlighting.com for
complete photometrics.
Ballast
Integral electronic HPF, multi-volt
120/277V (347V Canada),
thermally protected with end-of-
life circuitry to accommodate the
specified lamp wattage.
Lamp/Socket
One (1) 18W (GX24q-2), 26W or
32W (GX24q-3) 4-pin triple CFL
lamp or one (1) 60W A-19 lamp.
CFL socket injection molded
plastic. INC socket fired ceramic
rated for 660W-250V. Lamps
furnished by others.
Installation
Supplied with a universal
circular strap for a standard 4"
J-box or plaster ring.
Options
Dimming Ballast - Contact the
factory for ballast options (DM),
Decorative Baffle (BL), Remote
Energy Battery - Supplied by
others (REM), Damp Location
(DL): All Painted Finishes only.
Energy Star Rating - Consult
factory. MRI Applications (INC
only) - Contact Factory.
Labels
U.L. and C.U.L approved for
indoor and damp location. See
options for damp location
finishing requirements.
Modifications
Shaper's skilled craftspeople
with their depth of experience
offer the designer the flexibility
to modify standard wall
luminaires for project specific
solutions. Contact the factory
regarding scale options, unique
finishes, mounting, additional
materials/colors, or decorative
detailing.
DESCRIPTION
MAGNETIC
RESONANCE
IMAGING (MRI)
ENERGY
STAR
SUSTAINABLE
DESIGN
Refer to the Icon Legend
Link on shaperlighting.com.
Lighting fixtures for MRI facilities are
specialized and unique, requiring non-
ferrous construction. Fluorescent fixtures
cannot be used due to the ferrous parts in
ballasts and lampholders. Modified incan-
descent fixtures meet the requirements.
Shaper now offers a wide variety
of fixtures that can be provided
with an Energy Star Rating.
Shaper has a long-standing history of
offering environmentally-friendly fixtures.
The copper and bronze alloys used in our
exterior luminaires feature up to 98% re-
cycled content, contribute less undesirable
air emissions compared to painted alumi-
num and are easy to recycle.
Shaper’s exclusive Starter Collection fixtures
are featured throughout the Shaper product
line. The concept of offering highly styled,
affordable fixtures was introduced over
fourteen years ago and has become one of
our fastest growing lines. The design
premise, basic construction, clean lines
and unadorned shapes are highly desirable
in modern architectural environments.
STARTER
COLLECTION
Sample Number: 664-CFL/1-277V-PCP
Finish
Standard
NA Natural Aluminum=
Premium
CC Custom Color=
MW Matte White=
PCP Polished Copper=
SAL Lacquered Satin Aluminum=
SB Satin Brass=
Options
BL Decorative Baffle=
DL Damp Location=
DM CFL Dimming Ballast 2
=
REM Remote Emergency Battery 3
=
Voltage
120V
277V 1
347V 1
Series
664 Solid Shade
w/ Arm Mount
Bracket
=
Lamp
CFL/1
(18/26/32W
-Triple)
INC/1/60
1Available with CFL only.
Notes:
2Consult the factory for available options.
3Supplied by others.
ORDERING INFORMATION
ADS042684
2008-09-16 16:36:58

Specifications and dimensions subject to change without notice.
Shaper Lighting •1141 Marina Way South •Richmond, CA 94804 •ph 510.234.2370 •fax [phone]
664 SERIES INTERIOR WALL LUMINAIRE
DIMENSIONS
