POST TOP
999
COOPER LIGHTING
SHAPER™
MATERIAL
Post and Collar: 3 5/8" Diameter
seamless pure copper tube attached
to a sand cast bronze base covered by
a spun copper alloy cover. Sand cast
collar with an acrylic (CFL) or frosted
glass diffuser (MH & INC).
Shade Options, available in four shade
options:
• Spun natural copper alloy large curved
shade (LCS)[Dark Sky Compliant]
5" H x 24 1/8" dia.
• Spun natural copper alloy curved
shade (CS) 5" H x 20 1/8" dia.
• Spun natural copper alloy stepped
shade with etched glass (EG) glow top
element (SSG) with optional custom
color filters (CC) 5" H x 20 1/8"dia.
• Spun natural copper alloy
truncated shade (TS) 4 1/2" H x 24" dia.
Aluminum components are used with a
painted finish.
Notes:
1 Available with CFL only.
2 Copper alloy or premium TGIC polyester powder coat paint, 2.5 mil nominal thickness for superior protection against fade and wear.
3 Available with Stepped Shade Glow Top (SSG) only.
4 Consult the factory for available options.
BALLAST
One (1) low temperature
(0°F,-18°C) AC electronic
CFL multi-watt, multi-volt
120/277V (347V-Canada)
ballast. One (1) 70W
electronic metal halide
ballast. CFL and MH
electronic ballast
mounted in post.
LAMP/SOCKET
One (1) 26W (GX24q-3 base), 32W
(GX24q-3 base) or 42W (GX24q-4 base)
4-pin triple tube CFL lamp or one (1)
70W ED-17 metal halide lamp or one
(1) 150W A-21 incandescent lamp. CFL
socket injection molded plastic. MH
and INC socket fired ceramic rated for
4KV. Lamps furnished by others.
INSTALLATION
Pole mounted on an
EPDM pad with three
3/4"-10 UNC-2A X 18"
J-bolts on a 6 1/2" dia.
olt circle. Three conduit
feeds in base (by others).
Wiring connection via
hand hole in post (ground
lug at hand hole).
Supplied with mounting
pad, bolts, mounting
hardware and template.
FINISH AND OPTIONS
See page 1020 for finish
details and options.
The 902 Post Top luminaire features
a frosted glass diffuser, a soft
"glowing" direct component and
four distinct upper shade options.
902-PT
SSG, LCS, CS
or TS SERIES
20-1/8" ø
5"
3-1/2"
9'-0"
8" ø
20" STEPPED SHAPE
GLOW TOP (SSG)
9-1/8" ø
3-5/8" ø
R2-1/4" GLOW TOP
99-1/2"
Sample Number: 902-PT-SSG-MH/1/70-277V-GRM-GM-EG-14
Series
902-PT =
Multiple Shade
Luminaire
Lamp
CFL/1
(26/32/42W-Triple)
INC/1/150
MH/1/70
Voltage
120V
277V
347V1
Post
Finish2
CA (standard),
BK, BM, CC,
DP, GM, GRM,
GY, SM, WH
Style
CS = Curved Shade
LCS = Large Curved
Shade
SSG = Stepped
Shade Glow Top
TS = Truncated
Shade
Finish2
CA
(standard),
BK, BM, CC,
DP, GM,
GRM, GY,
SM, VG, WH
Glow Top
Element3
EG = Eteched Glass
__ = Not Available
Mounting
Height
8’
9’
10’
11’
12’
13’
14’
Options
BS4
9'-0"
8" ø
24" LARGE CURVED SHADE (LCS)
9-1/8" ø
3-5/8" ø
24-1/8" ø
5" 2-1/2"
100-1/2"
20-1/8" ø
5"
2-1/2"
9'-0"
8" ø
20" CURVED SHADE (CS)
9-1/8" ø
3-5/8" ø
100-1/2"
9'-0"
8" ø
24" TRUNCATED SHADE (TS)
9-1/8" ø
3-5/8" ø
24" ø
4-1/2"
3"
8-1/8" ø
100-1/2"
MOUNTING DETAILS
3"
9-1/8" ø
ø 6.5"
