STREETWORKS Outdoor Lighting Solutions 71Cooper Lighting
ORDERING INFORMATION
SAMPLE NUMBER: MPB50SR255
16 1/2" [419mm]
25 1/2"
[648mm]
MPB BRECKENRIDGE
50-250W
MH/HPS/MERCURY
DECORATIVE
HOUSING + TOP
Die-cast aluminum housing with
spun and stamped aluminum top.
Toolless entry latch for relamping
and ballast power module access.
Standard color is black. Other
finish colors available. Consult
your Streetworks Representative.
1" ANSI wattage/source label.
REFRACTOR
Injection molded acrylic refractors
available in type II, III or V
distributions. Optional glass or
polycarbonate refractors available.
SOCKET
Mogul-base socket for 50W
through 150W HPS and 175W and
250W MH; 50W through 150W
MH is medium-base socket. All
sockets are 4KV pulse rated.
BALLAST
Power module designed for easy
removal of all electrical
components for servicing by
loosening two screws.
Encapsulated plug-in starter may
be replaced through top access.
Two-position tunnel type
compression terminal block with
housing grounding screw.
Removable tethered door
assembly for easy access to
wiring connections with stainless
steel captive screw.
PHOTOCONTROL
Optional internal NEMA twistlock
photocontrol available. Accessible
through door assembly.
MOUNTING
Post top mount fits 3" O.D.
tenons. Secured by 3/8" allen-head
stainless steel fasteners.
POST-TOP AREA LUMINAIRE
EPA:
Effective Projective Area: 1.7
SHIPPING DATA
Approximate Net Weight:
34 lbs. (14 kgs.)
STREETWORKS™
NOTE: 1 Metal Halide only. 250W through 150W MH are medium-base socket. All others are mogul-base. 3120 volt only. 450W through 150W HPS only. 5Order OA1202 for field installation. 6Available in Type III & V only.
OPTIONS +
ACCESSORIES
(See Below)
PRODUCT
FAMILY
MPB=Breckenridge
LAMP WATTAGE
50=50W
70=70W
10=100W
15=150W
17=175W
25=250W 1
LAMP TYPE
M=Metal Halide 2
S=High Pressure Sodium
V=Mercury
VOLTAGE
2=120V
0=208V
4=240V
7=277V
8=480V
9=347V
N=Multi-Tap wired 277V
W=Multi-Tap wired 120V
P=240/120 PCR
DISTRIBUTION
22=Type II
33=Type III
55=Type V
BALLAST TYPE
R=Reac./NPF 3
H=Reac./HPF 3
N=Hi. Reac./NPF
P=Hi. Reac./HPF
W=CWA
K=10KV CWA 4
OPTIONS + ACCESSORIES [Must be ordered in alphanumeric order]
OPTIONS (add as suffix)
1=Single Fuse (120, 277 or 347V)
2=Double Fused (208, 240 or 480V)
3=Three Place Terminal Block
4=Internal NEMA Photocontrol Receptacle
B=House Side Shield 5
G=Glass Refractor 6
P=Polycarbonate Refractor
U=U.L./CSA Listed
H=Hartford Green
WH=White
BZ=Bronze
AP=Grey
T=Thumb Screw Latch
ACCESSORIES (order separately)
OA1202=House Side Shield
OPTIONAL COLORS [Standard color is black, other finish colors available. Consult your Cooper Lighting representative]
WH
White BZ
Bronze AP
Grey H Hartford Green
PHOTOMETRICS [Complete IES files available at www.cooperlighting.com]
FOOTCANDLE TABLE
Select mounting height and read across for footcandle
values of each isofootcandle line. Distance in units of
mounting height.
Mounting Footcandle Values for
Height Isofootcandle Lines
AB C D
MPB15S33.IES
12' 1.56 0.78 0.31 0.16
15' 1.00 0.50 0.20 0.10
18' 0.69 0.35 0.13 0.07
MPB15S55.IES
12' 0.78 0.31 0.15
15' 0.50 0.20 0.10
18' 0.35 0.13 0.06
5
4
3
2
1
0
1
2
3
4
5
034521 32145
C
D
B
A
5
4
3
2
1
0
1
2
3
4
5
A B C
034521 32145
MPB15S33.IES
150-Watt HPS
16,000-Lumen Lamp
Type III
MPB15S55.IES
150-Watt HPS
16,000-Lumen Lamp
Type V
