Cooper Lighting CML SQUARE CML40MN3VSGBKL User manual

NOTES: 1 Arm not included. See options and accessories. 2Mogul-base lamp socket. 3750W Pulse Start for vertical mount only. 4Requires reduced envelope BT-37 lamp on Metal Halide or ED-37 on HPS. 5Standard with CWA
ballast. 6Maximum wattage on segmented optical distributions is 400W. 400W Metal Halide lamp must use reduced envelope ED-28 lamp. 7RW optic not available with flat glass. 8Must use reduced envelope lamp.
Not available in 1000W HPS. 9Other finish colors available, including a full line of RAL color matches. Consult your Cooper Lighting Representative. 10 House side shields available on 2F, 3F, FT, 2S, 3S, 4S distributions
only, and all vertically lamped optics when specified with sag lens. 11 Provided with 11 1/2" arm. 12 Required when mounting fixtures at 90° increments (Arm EPA 0.62).
HOUSING
Formed aluminum housing
has interior-welded seams for
structural integrity and is finished
in premium TGIC polyester powder
coat paint. U.L. listed and CSA
certified for wet locations. IP55
rated.
BALLAST TRAY
Ballast tray is securely mounted
and inter-locked to housing interior
for cooler operation. Tray features
toolless removal capability for ease
of maintenance and replacement.
BALLAST
Long-life core and coil ballast.
REFLECTOR
Standard rotatable and
interchangeable optics allow for an
easy field retrofit with respective
sag and flat glass doors for areas
with restrictive lighting ordinances
such as “Dark Sky”.
DOOR
Formed aluminum door has
heavy-duty hinges, captive retaining
screws and is finished in premium
TGIC polyester powder coat paint.
LENS
Convex tempered glass lens or flat
glass.
GASKET
Standard one-piece extruded EPDM
gasket ensures a bug proof
installation and is backed by IP55
rating.
ORDERING INFORMATION
SAMPLE NUMBER: CML40MN3VSGBKL
OPTIONS +
ACCESSORIES
(See Below)
ARCHITECTURAL AREA LUMINAIRE
OPTIONS (add as suffix)
1=Single Fuse (120, 277, or 347V)
2=Double Fuse(208, 240, or 480V)
EM=Quartz Restrike with Delay
(Also Strikes at Cold Start)
4=NEMA Twistlock Photocontrol Receptacle
Q=Quartz Restrike (Hot Restrike Only)
HS=House Side Shield 10
EHS=External House Side Shield
AIR=Arm Included for Round Pole11
AIS=Arm Included for Square Pole11
VS=Vandal Shield
(Arm Mount Only, 400W Maximum)
L=Lamp Included
ACCESSORIES (order separately. add color as suffix)
MA1004-XX=14" Arm for Square Pole 12
MA1005-XX=6" Arm for Square Pole
MA1006-XX=Direct Mount Kit for Square Pole
MA1007-XX=14" Arm for Round Pole 12
MA1008-XX=6" Arm for Round Pole
MA1009-XX=Direct Mount Kit for Round Pole
MA1010-XX=Single-arm Tenon Adapter for
3 1/2" O.D. Tenon
MA1011-XX=2 @ 180° Tenon Adapter for
3 1/2" O.D. Tenon
MA1012-XX=3 @ 120° Tenon Adapter for
3 1/2" O.D. Tenon
MA1013-XX=4 @ 90° Tenon Adapter for
3 1/2" O.D. Tenon
MA1014-XX=2 @ 90° Tenon Adapter for
3 1/2" O.D. Tenon
MA1015-XX=2 @ 120° Tenon Adapter for
3 1/2" O.D. Tenon
MA1016-XX=3 @ 90° Tenon Adapter for
3 1/2" O.D. Tenon
MA1017-XX=Single-arm Tenon Adapter for
2 3/8" O.D. Tenon
MA1018-XX=2 @ 180° Tenon Adapter for
2 3/8" O.D. Tenon
MA1019-XX=3 @ 120° Tenon Adapter for
2 3/8" O.D. Tenon
MA1029-XX=Wall Mount Bracket with 10" Arm
(Specify color)
MA1045-XX=4 @ 90° Tenon Adapter for
2 3/8" O.D. Tenon
MA1048-XX=2 @ 90° Tenon Adapter for
2 3/8" O.D. Tenon
MA1049-XX=3 @ 90° Tenon Adapter for
2 3/8" O.D. Tenon
EHS-XX=External House Side Shield
OA1016=Photocontrol–Multi-Tap
OA1027=Photocontrol–480V
OA1201=Photoelectric Control, 347V NEMA Type
PRODUCT
FAMILY1
CML=CML
Square
LAMP
WATTAGE2
25=250W
40=400W
75=750W3
91=1000W4
LAMP TYPE
M=Metal Halide
S=High Pressure
Sodium
VOLTAGE 5
2=120V
0=208V
4=240V
7=277V
8=480V
9=347V
W=Multi-Tap wired 120V
N=Multi-Tap wired 277V
V=Multi-Tap wired 240V
DISTRIBUTION
1F=Type I MCO (Horizontal)
2F=Type II MCO (Horizontal)
2S=Type II Segmented (Horizontal) 6
3F=Type III MCO (Horizontal)
3S=Type III Segmented (Horizontal) 6
4S=Type IV Segmented (Horizontal) 6
5S=Type V Segmented (Horizontal) 6
FT=Forward Throw (Horizontal)
AR=Area Round (Vertical)
AS=Area Square (Vertical)
3V=Type III (Vertical)
RW=Rectangular Wide (Vertical) 7
SL=Spill Light Eliminator (Horizontal) 8
LENS TYPE
FG=Flat Glass
SG=Sag Glass
COLORS
(add as suffix/
must specify) 9
WH=White
BK=Black
AP=Grey
BZ=Bronze
DP=Dark Platinum
GM=Graphite Metallic
CML SQUARE 250-1000W MH/HPS
AREA
SHIPPING DATA
Approximate Net Weight:
79 lbs. (36 kgs.)
OPTIONS + ACCESSORIES [Must be listed in the order shown and separated by a dash]
STREETWORKS™
86 STREETWORKS Outdoor Lighting Solutions Cooper Lighting
OPTIONAL COLORS [Other finish colors available. Consult your Cooper Lighting representative]
WH
White BK
Black AP
Grey BZ
Bronze
A
B
C
DE
Fixture A B C D E
CML (in.) 14 3 1/2 19 1/4 22 6 or 14
S (mm) 356 89 489 559 152 or 356
IP55 RATED
NOTE: In all flat glass configurations only.
GM
Graphite Metallic
DP
Dark Platinum

STREETWORKS Outdoor Lighting Solutions 87Cooper Lighting
CML SQUARE AREA
CML40S3FF.IES
400-Watt HPS
50,000-Lumen Clear Lamp
Type III Flat Glass
CML91M3VF.IES
1000-Watt MH
110,000-Lumen Clear Lamp
Type III Vertical Flat Glass
CML40MSLF.IES
400-Watt MH
36,000-Lumen Clear Lamp
SLE—Spill Light Eliminator Flat Glass
CML91MASF.IES
1000-Watt MH
110,000-Lumen Clear Lamp
Area Square Flat Glass
CML91MASS.IES
1000-Watt MH
110,000-Lumen Clear Lamp
Area Square Flat Glass
PHOTOMETRICS [Complete IES files available at www.cooperlighting.com]
012345
ABCDE
4
3
2
1
0
1
2
3
4
4
3
2
1
0
1
2
3
4
0 1 2 3 4 5
AB
C
D
E
4
3
2
1
0
1
2
3
4
0 1 2 3 4 5
A B C D E
4
3
2
1
0
1
2
3
4
0 1 2 3 4 5
A B C D E
4
3
2
1
0
1
2
3
4
0 1 2 3 4 5
A B C D E
MOUNTING CONFIGURATIONS
DRILLING PATTERN
TYPE “M”
DARK SKY COMPLIANT [FULL CUTOFF PERFORMANCE]
SLE “SPILL LIGHT ELIMINATOR”
Wall Mount Arm Mount Single Arm Mount 2 @ 180° Arm Mount 2 @ 90° Arm Mount 3 @ 120°
(Round Pole Only) Arm Mount 4 @ 90°Arm Mount 3 @ 90°
3/4'' [20mm]
dia. hole
(2) 5/8'' [16mm]
dia. holes
4 7/8'' [124mm]
2 7/16'' [124mm]
2 11/16''
[69mm]
E.P.A. TABLE SINGLE
DRILL PATTERN [W/ARM WHERE APPLICABLE] 2 @ 180° 2 @ 90° 3 @ 90° 3 @ 120° 4 @ 90°
CML “M” 3.1 6.2 7.2 9.8 9.8 11.1
NOTE: 1 Assumes 14" arm for 90° and 120° mounting configurations, 6" for all else.
FOOTCANDLE TABLE
Select mounting height and read across for footcandle values
of each isofootcandle line. Distance in units of mounting
height.
Mounting Footcandle Values for
Height Isofootcandle Lines
ABCDE
CML40MSLF.IES
30' 2.00 1.00 0.50 0.20 0.10
35' 1.46 0.73 0.37 0.15 0.07
40' 1.12 0.56 0.28 0.11 0.06
CML40S3FF.IES
30' 2.00 1.00 0.50 0.25 0.10
35' 1.46 0.73 0.37 0.18 0.07
40' 1.12 0.56 0.28 0.14 0.06
FOOTCANDLE TABLE
Select mounting height and read across for footcandle values
of each isofootcandle line. Distance in units of mounting
height.
Mounting Footcandle Values for
Height Isofootcandle Lines
ABCDE
CML91M3VF.IES / CML91MASF.IES / CML91MASS.IES
30' 3.50 2.00 1.00 0.50 0.20
35' 2.60 0.73 0.37 0.18 0.07
40' 2.00 1.00 0.50 0.20 0.10
