Copernicus TD5000 User manual

TD5000 TD5001 - Version A - Released January 6, 2023 - Copernicus Educational Products Inc.
3D Printer Cart Premium Model
TD5000
TD5001
Please Recycle
Assembly Guide
Check out our other products online at www.copernicused.com
For assistance, please contact us by telephone at 1-800-267-8494 or email at [e-mail].
Have your packing slip ready for reference.
TD5001
1 Tiny Tub
2 Open Tubs
1 Original Tech Tub® Base Model
1 Really Big Tub
1 Tiny Tub
4 Open Tubs
1 Really Big Tub
TD5000

TD5000 TD5001 - Version A - Released January 6, 2023 - Copernicus Educational Products Inc.
2
We do not inherit the earth
from our ancestors, we
borrow it from our children.
- NATIVE AMERICAN PROVERB
Change is the end result of all
true learning.
- LEO BUSCAGLIA
What you leave behind is not
what is engraved in stone
monuments, but what is
woven into the lives of others.
- PERICLES
Education is the most
powerful weapon which you
can use to change the world.
- NELSON MANDELA
Need Support?
Have a Question?
Email Customer Service www.copernicused.com
Check out some of our
other great products!
For missing parts and other issues regarding your product:
Please contact Customer Service, where we will be happy to help.
Telephone: [phone], Monday - Friday 8:00am - 4:30 pm EST
Email: [e-mail]
My 3D printer isn’t working, who should I call?
Please contact the reseller that you bought the product from.
Reseller information can be found on your packing slip.
Register your Product
Registering your warranty ensures we have all the information we need to make any future warranty claims quick
and easy. Please visit www.copernicused.com/warranty and complete the form within 10 business days from
product assembly. By registering your product, you will be entered into a draw to win Copernicus product.
Make a Warranty Claim
We offer a Lifetime Warranty on almost everything we make. Please call 1-800-267-8494 or email
[email protected]om to start your warranty claim. Proof of purchase will be required upon warranty claim (i.e.
copy of invoice).
Lifetime
All Components
Warranty
Customer Service & Warranty Information
Dear Educator,
Thank you for purchasing the 3D Printer Cart Premium model. We hope it meets your expectations and you and your
students enjoy using it at your school.
Every day we see and hear stories of teachers going above and beyond to help students thrive. Thank you so much for all
you do – you are awesome, and you make a difference.
Thank you for inspiring us.
If you have any questions, concerns or ideas on how we can improve please let us know by contacting our Customer
Solutions Ninjas at 1-800-267-8494 or [email protected].
Happy teaching,
Kaylyn Belcourt, President
[email protected]

TD5000 TD5001 - Version A - Released January 6, 2023 - Copernicus Educational Products Inc.
3
Tips for Assembly
Before You Begin:
ŸLay out and identify all of the included parts.
ŸThe hardware has been packed according to step.
ŸRead the assembly guide over once to familiarize yourself with them.
As You Assemble the Unit:
ŸFollow the steps in sequence.
ŸBefore beginning each step, find the part(s) that you need for that step.
ŸThe title of each step states what you will be doing. Review the text and
the pictures as you build the unit.
Please read the warnings below for important safety information regarding your product. Failure to read these
warnings or to follow the instructions below could result in personal injury or damage to your product that could
void your warranty.
Ensure that any cables extending across the floor to your product are properly bundled and
marked to avoid tripping or falling which may lead to personal injury.
Cable Trip
Hazard
Indoor Use
Only
This product is intended for indoor comercial use only. To reduce the risk of fire or electric
shock, do not expose this product to rain or moisture. The internal components are not
sealed from the environment.
In its unassembled state, this product contains parts that can be hazardous to small children.
This product should be assembled by an adult.
Small Parts
This product is to be used under the supervision of an adult.
Adult
Supervision
Do not climb on, hang from or suspend objects from any components of your product
unless otherwise specified.
Climb
Hazard
Read your power strip electrical specifications. Only plug in devices that are approved for
use with this power strip. Connect the supplied power strip directly to a wall outlet.
Do not connect to another power strip or use an extension cord. Turn off power strip
before unplugging. Unplug when not in use.
Power Strip
Specifications
Read the electrical specifications of any electronic equipment you are using with your
Copernicus products. Failure to read these specifications and follow their instructions could
result in damage to your equipment or personal injury.
Electronic
Equipment
Do not install or use the electrical components of this unit during a lightning storm.
Electrical
Shock
Important Information! Warning!
The symbol denotes a
step needing extra
attention to ensure it is
done correctly.
Watch for These Helpful Symbols:
For safety, please have
someone help you when
working on steps
displaying this symbol.
2-Person Task

TD5000 TD5001 - Version A - Released January 6, 2023 - Copernicus Educational Products Inc.
4
TD-CB1
Before beginning, you should have:
Additional tools required:
OR
8mm (1x)
10mm (1x)
Wrench +
3D Printer Cart Premium Model with Tub Pack 1 - Parts
Adjustable wrench 1x
In Box
Hardware
Actual Size
M6 Lock
Washer
16x
AM6 x 45mm Screw
16x
M6 x 19mm Screw
2x
DM5 x 20mm Screw
2x
EM6 Barrel Nut
2x
FM5 Lock
Nut 2x G
H
C
M6 Keps
Nut 4x
M8 Washer
2x
I
M12 Caster
Lock Washer
4x
JM12 Flat Washer
4x
K
BM6 x 35mm Screw
4x
Screwdriver
TD5000
Open Tub
4x
(CC4068-B) 10 lbs Weight Limit
Tiny Tub
1x
(CC4072-O)
Really Big Tub
1x
(CC4073-B)
15 lbs Weight Limit
TD5000-0
Middle Frame
1x
Side Frame
2x
Stretcher
2x
Handle
1x
Printer Table
1x
Spool Arm
Holder Right
1x
Spool Arm
Holder Left
1x
50 lbs Weight Limit
Laptop Tray
1x
Spool Holder
1x
25 lbs Weight Limit
Tub Frame
1x
Power Strip
1x
4” Twin Wheel
Locking Caster
4x
Double Sided
Foam Tape
2x
Caster
Wrench
1x
Allen Key
2x
Laptop Tray Stretcher Left
1x
Laptop Tray Stretcher Right
1x

TD5000 TD5001 - Version A - Released January 6, 2023 - Copernicus Educational Products Inc.
5
Before beginning, you should have:
Additional tools required:
OR
8mm (1x)
10mm (1x)
Wrench +
3D Printer Cart Premium Model with Tub Pack 2 - Parts
Adjustable wrench 1x
Screwdriver
TD5001
TD5000-0
In Box
Middle Frame
1x
Side Frame
2x
Stretcher
2x
Handle
1x
Printer Table
1x
Spool Arm
Holder Right
1x
Spool Arm
Holder Left
1x
50 lbs Weight Limit
Laptop Tray
1x
Spool Holder
1x
25 lbs Weight Limit
Tub Frame
1x
Power Strip
1x
4” Twin Wheel
Locking Caster
4x
Double Sided
Foam Tape
2x
Hardware
Actual Size
M6 Lock
Washer
16x
AM6 x 45mm Screw
16x
M6 x 19mm Screw
2x
DM5 x 20mm Screw
2x
EM6 Barrel Nut
2x
FM5 Lock
Nut 2x G
H
C
M6 Keps
Nut 4x
M8 Washer
2x
I
M12 Caster
Lock Washer
4x
J
Caster
Wrench
1x
M12 Flat Washer
4x
K
Allen Key
2x
BM6 x 35mm Screw
4x
Laptop Tray Stretcher Left
1x
Laptop Tray Stretcher Right
1x
TD-CB2
Open Tub
2x
(CC4068-B)
10 lbs Weight Limit
Tiny Tub
1x
(CC4072-O)
Really Big Tub
1x
(CC4073-B)
15 lbs Weight Limit
TEC57
10 lbs Weight Limit
Original Tech Tub®
Base Model
1x
(TEC57)

TD5000 TD5001 - Version A - Released January 6, 2023 - Copernicus Educational Products Inc.
6
Attach stretchers to side frame
Actual Size: You will need: (Not to Scale)
1
Side frame channels
face inwards
Holes face upwards
A
A
A
A
4x
A
4x
HSide Frame
2x
Stretcher
2x
Allen Key
1x
Attach middle frame
Actual Size: You will need: (Not to Scale)
22x
A
2x
Allen Key
1x
A
A
1 2
Middle Frame
1x
H
H
H
H
H
H
H

TD5000 TD5001 - Version A - Released January 6, 2023 - Copernicus Educational Products Inc.
7
Install casters
Actual Size: You will need: (Not to Scale)
3
4x
J4x
K
4” Twin Wheel
Locking Caster
4x
Caster Wrench
1x
Keep wrench with unit.
Casters need to be tightened every
6 months for proper maintenance.
Install tub frame
Actual Size: You will need: (Not to Scale)
4
1 2 Cable hooks on back
of cart frame
D
F
Push tub frame in and
then install bolts. Do
not over tighten.
2x
2x
D
F
2x
Tub Frame
x1
Adjustable wrench 1x
OR
8mm Wrench
J
K
J
KJ
K
J
K
Allen Key
1x

TD5000 TD5001 - Version A - Released January 6, 2023 - Copernicus Educational Products Inc.
8
Actual Size: You will need: (Not to Scale)
64x
A
4x
H
Attach handle
Attach laptop tray stretchers
Actual Size: You will need: (Not to Scale)
56x
A
6x
H
Handle
1x
Laptop Tray Stretcher Left
1x
Laptop Tray Stretcher Right
1x
A
H
Left
Right
A
H
Allen Key
1x
Allen Key
1x

TD5000 TD5001 - Version A - Released January 6, 2023 - Copernicus Educational Products Inc.
9
Install laptop tray
You will need: (Not to Scale)
7
Actual Size: You will need: (Not to Scale)
8
4x
G
Attach laptop tray stretchers
Laptop Tray
1x
Pull the tray out slowly
to ensure that the drawer
has been fully locked in.
B
G
B
G
B
G
B
Tighten screws until flush with
shelf, otherwise they will stick
out above printer shelf surface.
Printer Table
1x
B4x
Screwdriver Adjustable wrench 1x
OR
10mm Wrench

TD5000 TD5001 - Version A - Released January 6, 2023 - Copernicus Educational Products Inc.
10
Install spool holder arms
9
Actual Size: You will need: (Not to Scale)
I
C
2x
E
Magnets face out
x2
E
x2
C
x2
I
Allen Key
2x
Spool Arm
Holder Right
1x
Spool Arm
Holder Left
1x
Spool holder arms are adjustable for different printers.
Choose height where spools will not rest on printer body.
High Low
Add tiny tub
You will need: (Not to Scale)
10 Tiny Tub
1x
Apply tape
You will need: (Not to Scale)
11 Double Sided
Foam Tape
x2
Power
Strip
x1

TD5000 TD5001 - Version A - Released January 6, 2023 - Copernicus Educational Products Inc.
11
Attach powerstrip
You will need: (Not to Scale)
12 Power
Strip
x1
Place 3D printer on table
13
3D printer
not included
Plug 3D printer into power strip
14
Wrap power strip cord
15
Wrap
excess
printer
cord
around
hooks

TD5000 TD5001 - Version A - Released January 6, 2023 - Copernicus Educational Products Inc.
12
Add spool holder
You will need: (Not to Scale)
16
1
Spool Holder
1x
2
Filament not included
Open
Tub
x4
10 lbs Weight Limit
TM
Tech Tub
x1
Open
Tub
x2
10 lbs Weight Limit
TD5000
TD5001
OR
30 lbs Weight Limit
Add tubs
You will need: (Not to Scale)
17 Really
Big Tub
1x
15 lbs Weight Limit
Really
Big Tub
1x
15 lbs Weight Limit
TD5000 TD5001
OR
