Copernicus PDR05 User manual

PDR05 - Version A - Released November 21, 2022 - Copernicus Educational Products Inc.
Double Sided Art Easel Base Model
PDR05
Please Recycle
Assembly Guide
Check out our other products online at www.copernicused.com
For assistance, please contact us by telephone at 1-800-267-8494 or email at [e-mail].
Have your packing slip ready for reference.

PDR05 - Version A - Released November 21, 2022 - Copernicus Educational Products Inc.
We do not inherit the earth
from our ancestors, we
borrow it from our children.
- NATIVE AMERICAN PROVERB
Change is the end result of all
true learning.
- LEO BUSCAGLIA
What you leave behind is not
what is engraved in stone
monuments, but what is
woven into the lives of others.
- PERICLES
Education is the most
powerful weapon which you
can use to change the world.
- NELSON MANDELA
Need Support?
Have a Question?
Email Customer Service www.copernicused.com
Check out some of our
other great products!
For missing parts and other issues regarding your product:
Please contact Customer Service, where we will be happy to help.
Telephone: [phone], Monday - Friday 8:00am - 4:30 pm EST
Email: [e-mail]
Register your Product
Registering your warranty ensures we have all the information we need to make any future warranty claims quick
and easy. Please visit www.copernicused.com/warranty and complete the form within 10 business days from
product assembly. By registering your product, you will be entered into a draw to win Copernicus product.
Make a Warranty Claim
We offer a Lifetime Warranty on almost everything we make. Please call 1-800-267-8494 or email
[e-mail] to start your warranty claim. Proof of purchase will be required upon warranty claim (i.e.
copy of invoice).
Replace your Whiteboard
Have a well-used whiteboard that needs replacing? Our whiteboards carry a five-year warranty and replacement
parts program after the warranty period. Please call 1-800-267-8494 or email [e-mail] to get a
new whiteboard for your Copernicus product!
Lifetime
Frame Warranty
Customer Service & Warranty Information
Dear Educator,
Thank you for purchasing the Double Sided Art Easel Base Model. We hope it meets your expectations and you and your
students enjoy using it at your school.
Every day we see and hear stories of teachers going above and beyond to help students thrive. Thank you so much for all
you do – you are awesome, and you make a difference.
Thank you for inspiring us.
If you have any questions, concerns or ideas on how we can improve please let us know by contacting our Customer
Solutions Ninjas at 1-800-267-8494 or [email protected]om.
Happy teaching,
Kaylyn Belcourt, President
[email protected]
2

PDR05 - Version A - Released November 21, 2022 - Copernicus Educational Products Inc.
Tips for Assembly
Before You Begin:
ŸLay out and identify all of the included parts.
ŸThe hardware has been packed according to step
ŸRead the assembly guide over once to familiarize yourself with them.
As You Assemble the Unit:
ŸFollow the steps in sequence.
ŸBefore beginning each step, find the part(s) that you need for that step.
ŸThe title of each step states what you will be doing. Review the text and
the pictures as you build the unit.
Please read the warnings below for important safety information regarding your product. Failure to read these
warnings or to follow the instructions below could result in personal injury or damage to your product that could
void your warranty.
Indoor Use
Only
This product is intended for indoor comercial use only. To reduce the risk of fire or electric
shock, do not expose this product to rain or moisture. The internal components are not
sealed from the environment.
In its unassembled state, this product contains parts that can be hazardous to small children.
This product should be assembled by an adult.
Small Parts
This product is to be used under the supervision of an adult.
Adult
Supervision
Do not climb on, hang from or suspend objects from any components of your product
unless otherwise specified.
Climb
Hazard
Important Information! Warning!
The symbol denotes a
step needing extra
attention to ensure it is
done correctly.
Watch for These Helpful Symbols:
For safety, please have
someone help you when
working on steps
displaying this symbol.
2-Person Task
This product does NOT require maintenance. Repairs should only be performed by
authorized personnel. Please contact customer service if repairs are required.
No
Maintenance
3

PDR05 - Version A - Released November 21, 2022 - Copernicus Educational Products Inc.
Before beginning, you should have:
Parts
Hardware
Actual Size
PDR05-0
Allen Key
(Not to Scale)
x1
Side Frame
x2
Drying Rack
x5
Stretcher
x4
Paint Tray (each includes seven
pots, seven spill-proof caps and
seven lids)
x2
White Board
x2
Art Clip
x8
Caster
x4
Additional tools required:
In Box 1
PDR05-CB
Holder for Low Position
Packed inside one pot
x4
Holder for High Position
Packed inside one pot
x4
i
n
s
e
id
s
id
n
e
i
M6 x 35mm Screw
x8
M6 x 40mm Screw
x2
M6 x 30mm Screw
x6
M6 Lock
Washer
x20
M6 Flat
Washer
x8
M6 Acorn
Nut
x12
M6 x 30mm
Shoulder Bolt
x4
Adjustable wrench
x1
Rubber Mallet
x1
OR 10mm Wrench
x1 +
H
GFE
C
B
A
Apron Hook
x2
4

PDR05 - Version A - Released November 21, 2022 - Copernicus Educational Products Inc.
1
Actual Size: You will need: (Not to Scale)
1
Assemble fully but
do not tighten.
Attach Stretchers to Side Frames
B
B
E
B
x8
E
x8
Side Frame
x2
Bottom Stretcher
x4
5
B
E
B
E
E
BE
B
E
BE
BE

PDR05 - Version A - Released November 21, 2022 - Copernicus Educational Products Inc.
2
3
Drying Rack
x5
You will need: (Not to Scale)
Insert Drying Racks
We recommend installing the racks with this side
facing upwards - easier to slide paper off the rack
Up
Install Casters
Press Casters firmly into the
Frame. Casters will click into
place. If necessary, place a wrench
between the wheels & tap in with
a rubber mallet.
Caster
x4
You will need: (Not to Scale)
6
You may need to tighten
slightly as you go up with
the racks. Tighten all bolts
(8) after all Drying Racks are
assembled.
Install racks every other
hole starting at the bottom
hole

PDR05 - Version A - Released November 21, 2022 - Copernicus Educational Products Inc.
Attach White Board on front and back
Attach 1 top corner
and 2 bottom
corners (board
shown in lowest
position). Repeat
on other side.
Use top holes for
High position
C
G
E
F
Board in Low Position Board in High Position
OR
Choose the low or high position for each White Board to suit your needs
1
Actual Size: You will need: (Not to Scale)
4White Board
x2
C
x6
E
x6
F
x6
G
x6
7

PDR05 - Version A - Released November 21, 2022 - Copernicus Educational Products Inc.
1
Actual Size: You will need: (Not to Scale)
5A
x2
E
x2
G
x2
F
x2
Apron
Hook
x2
Apron Hook installs with two
longer bolts A on either side, at
the same time as the
Whiteboards.
Attach Hook and Fourth Board Corner
A
G
E
F
6You will need: (Not to Scale) Art Clip
x8
Two Clips on the top, and
a clip on either side will
help to hold the students
artwork in place.
8

PDR05 - Version A - Released November 21, 2022 - Copernicus Educational Products Inc.
Install Paint Tray Holders
Install Paint Tray Holder
For board in Low Position
For board in High Position
H
H
E
E
G
G
OR
1
Actual Size: You will need: (Not to Scale)
7H
x4
E
x4
G
x4
Holder for
Low Position
x4
Holder for High
Position
x4
OR
9

PDR05 - Version A - Released November 21, 2022 - Copernicus Educational Products Inc.
Paint Tray
x2
8
You will need: (Not to Scale)
Slide Paint Tray on Holders
How to remove Pots from Paint Tray
10

PDR05 - Version A - Released November 21, 2022 - Copernicus Educational Products Inc.
Final Assembly Checks
Check entire assembly for loose parts; bolts, screws and nuts
Adjustable wrench
x1
Rubber Mallet
x1
OR 10mm Wrench
x1 +
9You will need: (Not to Scale)
11
