Copernicus Tech Tub2 FTT124 User manual

FTT124_124-USB - PATENT PENDING - Version A - October 11, 2017 - Copernicus Educational Products Inc.Released
ŸThis product is meant to be assembled by an adult.
ŸIn its unassembled state, small parts present a hazard.
ŸTo be used under direct supervision of an adult.
WARNING
®
2
Tech Tub Stacking Cart
Please Recycle
For assistance, please contact us:
1-800-267-8494
Email [email protected]om
Have your packing slip ready for reference
Assembly Guide
FTT124_124-USB_2017_A
Check out our other products online at
www.copernicused.com
®
2
Tech Tub
FTT600 x4
Handle x1
Right Side Arm x1
Power Timer Cover x1
Power Timer x1
Hidden Items:
Power Timer Mounting Bracket x1
Left Side Arm x1
Cable Hook x1
4” Twin Wheel
Locking Caster x4
Base x1
FTT124
FTT124-USB
®
2
Tech Tub
FTT600-USB x4
OR

FTT124_124-USB - PATENT PENDING - Version A - October 11, 2017 - Copernicus Educational Products Inc.Released
2
To validate your warranty, submit the ON-LINE form at www.copernicused.com
Enter a draw to win a Copernicus Product for your classroom at the same time!
Validate Your Warranty
Jim Phillips
Chief Cook and Bottle Washer
For assistance, please contact us:
1-800-267-8494
Email [email protected]om
Have your packing slip ready for reference
Dear Educator,
Thank you for purchasing one of our products. I hope that the Stacking Cart is useful in your classroom.
If you have any questions, concerns, or ideas please contact us by telephone at 1-800-267-8494 or email at
[e-mail].
Enjoy using your new product and happy teaching.
We do not inherit the
earth from our ancestors,
we borrow it from our
children.
NORTH AMERICAN
PROVERB
Change is the end result
of all true learning.
LEO BUSCAGLIA
What you leave behind is
not what is engraved in
stone monuments, but
what is woven into the
lives of others.
PERICLES
Education is the most
powerful weapon which
you can use to change the
world.
NELSON MANDELA
FTT124
FTT124-USB
5
Year
Frame
Warranty
Component
Warranty
1
Year
®
2
Tech Tub
Warranty
Life
Time
®
2
Tech Tub Stacking Cart
Assembly Guide
FTT124_124-USB_2017_A
Check out our other products online at
www.copernicused.com

FTT124_124-USB - PATENT PENDING - Version A - October 11, 2017 - Copernicus Educational Products Inc.Released
3
Warning! Hazard Risks!
This product is to be used under the supervision of an adult.
Indoor Use
Only
This product is intended for indoor use only. To reduce the risk of fire or electric shock, do not expose
this product to rain or moisture. The internal components are not sealed from the environment.
Read your power strip electrical specifications. Only plug in devices that are approved for use with this
power strip. Connect the supplied power strip directly to a wall outlet. Do not connect to another
power strip or use an extension cord. Unplug when not in use. Do not leave this product plugged in
for more than 72 consecutive hours. Turn off power strip before unplugging.
Power Strip
Specifications
Do not install or use the electrical components of this unit during a lightning storm.
Electrical Shock
In its unassembled state, this product contains parts that can be hazardous to small children. This
product should be assembled by an adult.
Small
Parts
Ensure that any cables extending across the floor to your product are properly bundled and marked to
avoid tripping or falling which may lead to personal injury.
Cable Trip
Hazard
Climb Hazard
Do not climb on, hang from or suspend objects from any components of your product unless otherwise
specified.
Read the electrical specifications of any electronic equipment you are using with your Copernicus
products. Failure to read these specifications and follow their instructions could result in damage to your
equipment or personal injury.
Electronic
Equipment
Adult
Supervision
Please read the warnings below for important safety information regarding your product. Failure to
read these warnings or to follow the instructions below could result in personal injury or damage to
your product that could void your warranty.

FTT124_124-USB - PATENT PENDING - Version A - October 11, 2017 - Copernicus Educational Products Inc.Released
4
FTT124 - 0
Before beginning, you should have:
7/16 “ Wrench
x2
A
C
D
E
F
B
1/4”-20 x 2” Hex Head Screw
(430207)
x2
M12 Lock Washer
x4
(43010211)
In Box 1
Power Timer
Cover
(32101)
x1
Power Timer
Mounting Bracket
(321012)
x1
4” Twin Wheel
Locking Caster
(410111)
x4
Left Side
Arm
x1
(33127)
Handle
x1
(33129)
Cable Hook
x1
(34087)
Base
x1
M12 Flat Washer
x4
(4301981)
Hardware
Actual Size
M12 Cap Nut
x4
(432773)
1/2
1/4”-20 x 1 ” Hex Head Screw
(430206)
x4
1/4” Star Washer
(4301022)
x24
1/4”-20 Hex Nut
(43011)
x4
G
M6 x 10mm
Thumb Screw
(43216)
x2
Caster Wrench
(32095S)
x1
H
K
1/4-20 x 1/2” Quadrex
Panhead Screw
(4300382)
x2
Right Side
Arm
x1
(33128)
FTT124
FTT124-USB
0.45” Hex Wrench
(320950)
x2
M5 Thumb Nut
(432140)
x4
10-24 x 1/2” Quadrex
Machine Screw
(43013)
x6
I
J
LHook and
Loop Strap
(43321)
x1
Tools
Not To Scale
®
2
Tech Tub Stacking Cart
Additional tools required:
Adjustable Wrench
x2
Rubber Mallet
x1
OR
Philips
Screwdriver
x1
+OR +Robertson
Screwdriver
x1

FTT124_124-USB - PATENT PENDING - Version A - October 11, 2017 - Copernicus Educational Products Inc.Released
5
FTT124-USB
Tech Tub 2®
6 Device
Main Body
x1
FTT600-A (x3)
6 outlet
Power Strip
(25515)
x1
FTT124
FTT600-F (x1)
6 outlet
Power Strip
(25515)
x1
Power
Timer
(25526)
x1
Tech Tub 2®
6 Device
Main Body
x1
15’ Power
Timer Cable
(255146)
x1
North American
power cord shown.
USB “B” Cable
x1
FTT600-C (x3)
Power Cord
(255146)
x1
FTT600-G (x1)
North American
power cord shown.
USB “B” Cable
x1
Power Cord
(255146)
x1
Power Timer
(25526)
x1
15’ Power
Timer Cable
(255146)
x1
Power Adapter
(255145)
x1
10 Port USB Hub
(255144)
x1
Power Adapter
(255145)
x1
10 Port USB Hub
(255144)
x1
®
2
Tech Tub Stacking Cart
®
2
Tech Tub Stacking Cart with USB
Tech Tub 2®
6 Device
Main Body
x1
Tech Tub 2®
6 Device
Main Body
x1

FTT124_124-USB - PATENT PENDING - Version A - October 11, 2017 - Copernicus Educational Products Inc.Released
6
This symbol denotes a 2 Person Task. For safety, please ensure that there are the
suggested number of people working on steps displaying this symbol.
Watch for this symbol throughout the Assembly Guide. Wherever you see it, pay close
attention. The symbol denotes a step needing extra attention to ensure it is done
correctly.
The star symbol highlights an advisory note.
!
Watch for These Helpful Symbols
Before You Begin
As You Assemble the Unit
Lay out and identify all of the included parts.
The hardware has been packed together in one bag.
Read the assembly guide over once to familiarize yourself with them.
Please note that in its unassembled state, this product contains parts that can be
hazardous to small children. This product should be assembled by an adult.
!
Follow the steps in sequence.
Before beginning each step, find the part(s) that you need for that step.
Pay attention to the labels on the parts; they are there to help direct you at certain stages.
The title of each step states what you will be doing. Review the text and the pictures as you build
the unit.
2-Person Task
Need Tech Support?
Have a Question?
Email our Tech Support Service
!Please note, star washers are critical components for electrical safety. Star washers
must be included and fasteners fully tightened to prevent the risk of electric shock.
www.copernicused.com
Check out some of our
other great products!
For missing parts and other issues regarding this product:
Please call Copernicus Customer Service, where we will be happy to help.
1-800-267-8494. Monday - Friday 8:30am - 4:30 pm EST.
OR
Email our Tech Support Service at [email protected]om
?
?
?
Tips for Assembly
Customer Service - FAQ’s

FTT124_124-USB - PATENT PENDING - Version A - October 11, 2017 - Copernicus Educational Products Inc.Released
7
2
You will need: (Not to Scale)
Actual Size:
Install Casters Onto Base
Install Left and Right Side Arms Onto Base
You will need: (Not to Scale)
Actual Size:
1ABC
B
C
A
B
C
B
C
A
B
C
D
E
F
1/4” Star Washer
x10
1/4”-20 Hex Nut
x4
G
Repeat on other side.
A
A
M12 Cap Nut
x4
M12 Flat Washer
x4
M12 Lock Washer
x4
Caster Wrench
x1
4” Twin Wheel
Locking Caster
x4
Note:
Fully tighten all hardware before
moving on to the next step.
E
F
G
D
E
F
G
G
G
G
Please note, star washers are critical
components for electrical safety.
Star washers must be included and
fasteners fully tightened to prevent
the risk of electric shock.
1/4” Star Washer
x10
G
Note the orientation and position of
the arms when installing them.
FRONT
BACK
1/4”-20 x 2” Hex Head Screw
x2
1/2
1/4”-20 x 1 ” Hex Head Screw
x4
Left Side
Arm
x1
Right Side
Arm
x1
0.45” Hex Wrench
x2

FTT124_124-USB - PATENT PENDING - Version A - October 11, 2017 - Copernicus Educational Products Inc.Released
8
G
H
G
H
Actual Size:
Install Handle Onto Left and Right Arms
You will need: (Not to Scale)
Fit Handle Over end of Left and Right Side Arm
GH1/4-20 x 1/2” Quadrex
Panhead Screw
x2
12Fasten Handle to Arms
4
You will need: (Not to Scale)Actual Size:
Install Cable Hook Onto Right Side Arm
GH
GH
3
Use a rubber mallet if the handle is snug.
Important electrical
safety component.
1/4” Star Washer
x2
G
1/4” Star Washer
x2
Handle
x1
Cable Hook
x1
10-24 x 1/2” Quadrex
Machine Screw
x2
I
Important electrical
safety component.
1/4” Star Washer
x2
G
Note:
Holes are on the bottom side of
the handle.
Philips or Robertson
Screwdriver
x1
G1/4” Star Washer
x2
OR
Philips or Robertson
Screwdriver
x1
OR

FTT124_124-USB - PATENT PENDING - Version A - October 11, 2017 - Copernicus Educational Products Inc.Released
9
G
GI
I
G
GI
I
G
H
G
H
G
H
G
H
Actual Size:
Install Power Timer Onto Right Side Arm
You will need: (Not to Scale)
Fasten Mounting Bracket to Right Side Arm
G
12
5
Attach Power Timer Onto Mounting Bracket
J
1/4” Star Washer
x8
M5 Thumb Nut
x4 Power Timer
Mounting
Bracket
x1
10-24 x 1/2” Quadrex
Machine Screw
x4
I
Power Timer
x1
Note:
Power Timer will be shipped
inside one of the Tech Tub boxes
Important electrical
safety component.
1/4” Star Washer
x8
G
Philips or Robertson
Screwdriver
x1 OR

FTT124_124-USB - PATENT PENDING - Version A - October 11, 2017 - Copernicus Educational Products Inc.Released
10
Hook Power Timer Cover Onto Mounting Bracket
34Fasten Power Timer Cover in Place
Actual Size:
Install Power Timer Onto Right Side Arm
You will need: (Not to Scale)
G
5
Cont.
K
1/4” Star Washer
x2
M6 x 10mm
Thumb Screw
x2
Power Timer
Cover
x1
a) Hook tabs into slots
on mounting bracket
b) Swing cover
into place
K
G
K
G
Important electrical
safety component.
1/4” Star Washer
x2
G
Before proceeding to the next step
please check the entire assembly
for loose parts; tighten all casters,
bolts, screws and nuts.
Tighten all casters using supplied
Caster Wrench.
Keep wrench with unit. Casters
must be tightened every 6 months
for proper maintenance.

FTT124_124-USB - PATENT PENDING - Version A - October 11, 2017 - Copernicus Educational Products Inc.Released
11
6
Install First Tech Tub Onto Cart
Hook Back Feet of Tech Tub Onto Anchor Pins
Lower Front of Tub Onto Locking Tab
1
2
®
2
Tech Tub
6 Device
x1
Open Front Door of Tub and Slide Pin Into Place
3
Note:
Follow the assembly instructions
for your tub before installing
it on the cart.
Lock Casters before
installing tubs
onto cart.
You will need: (Not to Scale)

FTT124_124-USB - PATENT PENDING - Version A - October 11, 2017 - Copernicus Educational Products Inc.Released
12
Stack Remaining Tech Tubs Onto Cart
You will need: (Not to Scale)
1
Insert Front Feet of Upper Tub Into Openings
on top of Lower Tub
4Lock Upper and Lower Tub Together Using
Flip Lock on Either Side of Lower Tub
SNAP in place for secure connection.
Repeat this step for remaining tubs.
See diagram on the top of each Tech Tub for
more details on how to join them together.
®
2
Tech Tub
6 Device
x3
7
22
3
Open Flip Lock on Each Side of First Tub
Mounted to Cart
Insert Back Feet of Upper Tub Into Slot
on top of Lower Tub

FTT124_124-USB - PATENT PENDING - Version A - October 11, 2017 - Copernicus Educational Products Inc.Released
13
15’ Power
Timer Cable
x1
8
Plug in Power Timer Cable
Secure Power Cable With Hook and Loop Strap
Insert Power Cable Into Power Timer
221
LHook and
Loop Strap
x1
L
Wrap Power Cable Around Cable Hook
3
You will need: (Not to Scale)
Clip Power Cable in Place Before Moving Cart
4

FTT124_124-USB - PATENT PENDING - Version A - October 11, 2017 - Copernicus Educational Products Inc.Released
14
9
Plug Power Strip From Each Tech Tub Into Power Timer
Loop Power Cables Through Frame as Shown to Prevent Strain on Power Cable Plugs
The rear outlets on the
Power Timer are grouped
into two banks (A and B).
The power switches
between A and B every
15 minutes. When this
happens you will hear
a clicking noise.
A
B

FTT124_124-USB - PATENT PENDING - Version A - October 11, 2017 - Copernicus Educational Products Inc.Released
15
Before moving the cart please remember to wrap the cables
®
2
on the back of each Tech Tub and unlock the caster brakes.
®
2
Each Tech Tub can be removed from the cart as needed.
Use this cart to easily distribute tubs between classrooms
or around the library.
The power timer has 2 regular outlets on the front so you
can still use your wall outlet while devices are charging.
Tips for Use
Remember to keep the caster wrench with the cart and
check the cap nuts every 6 months. Tighten as necessary.
Do not stack more than 4 Tech Tubs on this cart.
