Core SWX FLEET SERIES User manual

Specifications:
RAPID LI-ION CHARGER
INSTRUCTION MANUAL
Quick Charge Current: 3.0A
Input Voltage: auto AC 100~240V 50/60Hz
Charge time: 2.5 hrs(98 W batt) /4 battery packs
Weight: 5 lbs.
FLEET SERIES QUAD Simultaneous Charger
Warranty:
This product is warranted to the Original Purchaser against all defects in material and or workmanship
for the period herein.
The warranty period shall be, 1 1/2 years(18 months) for parts and labor, unless otherwise noted.
CoreSWX, LLC. agrees to pay equal return freight costs to return the product the same method it was received.
Customer must take this procedure stated below for CoreSWX, LLC. to acknowledge warranty.
Procedure:
1. Retain original bill of sale.
2. If service is needed on a product, at the time contact CoreSWX, LLC. and request a return
authorization number.
3. Ship defective product to Switronix, Inc. with return authorization number on outside of package.
CoreSWX, LLC. reserves the right to repair or replace any defective product under warranty after CoreSWX, LLC.
determines which is more practical.
If CoreSWX, LLC. receives defective product for warranty repair and they are found to be defective as a result of
misuse or other damage, not caused by normal wear and tear, CoreSWX, LLC.will notify the customer of an
estimate of repair. Customer will incur costs. There are no further warranties,either expressed or implied,
including warranties of merchantability or fitness for a particular purpose that has any bearing upon this
transaction.
CoreSWX, llc.
91 Commercial St Tel: [phone] [phone]
Plainview, NY 11803 Fax: [phone]
Website: http://www.coreswx.com

Thank you for your choice in purchasing a CoreSWX Brick Style Battery
Charger. The charger is designed to improve and assist you in your
battery charging requirements. Please read this manual to help you
understand and capitalize on the features of this charger.
Features:
•This charger will rapid charge any Li-ion battery pack within
CoreSWX’ product line.
•Automatic Universal AC input for world-wide use.
•Automatic detection of damaged or misused batteries for
added safety.
Charging Operation:
•Insert the AC power cord into the AC receptacle in the back of
the charger. and flp switch to on.
•Connect all batteries needing charge into the charger.
•At this time the switch will light and the LED lights on the front panel
of the charger will be GREEN. Once a battery is connected the LEDs
with turn to RED to indicate charging.
•If the battery does not meet quick charging conditions(i.e.
temperature or deeply discharged) the charger will precharge
the battery and go into a trickle charge mode until it is safe to
enter quick charge mode.
•The LED corresponding with the charging bay will turn solid
green when the battery is fully charged.
•The 4 positions operate independent from one another, so if a
faulty battery is detected, it will not effect the other 3 charging.
•This product employs multiple charge terminations to insure the
fastest yet safest charge procedure.
Troubleshooting
•Should an LED on a charge bay blink RED and GREEN check the
connection. Should the connection be sound, check the
battery’s function
•Should the charger not power on, their is a fuse receptacle
next to the AC input on the charger. Replace the fuse and
then check operation.
•This product includes a standard IEC cable for 110v outlets.
When outside the USA, find the appropriate AC pin cable for
the AC input. This charger accepts 90-240VAC.
Notes On Use:
•While operating the charger do not place anything on the
charger or block the ventilation slots.
•An increase in temperature is normal during charging.
•Make sure to firmly connect batteries to the charger mounts
and that the contacts are clean.
•The product must be grounded.
•Do not attempt to disassemble the charger, please contact
CoreSWX for any service issues.
•The fuse within the AC receptacle can be replaced only with
one of the same type and rating. (A spare fuse is included for
your convenience)
•Do not operate this device near equipment susceptible to
noise(i.e.TV).
