OBSIDIAN SERIES®450D MID-TOWER PC CASE
INSTALLATION GUIDE

CONGRATULATIONS!
!
Thank you for purchasing
an Obsidian Series®450D
Mid-Tower PC case.
For performance oriented mid towers, there’s
no beating the Obsidian Series of cases from
Corsair. With a trademark black, brushed
aluminum front fascia and tons of flexibility
for hardware installation, the Obsidian Series
does everything you want it to do and looks
good while doing it.
The 450D is ideal for cooling your high
performance components. The front panel
is meshed and filtered right in front of our
two high-airflow AF140L intake fans which
have a direct airflow path to your GPU and
CPU. If you remove the front hard drive cage,
the front fan mounts can fit up to a 280mm
radiator, but that’s not all. The top of the case
is pre-drilled for up to a 360mm radiator as
well. Not to mention our fantastic tool free
drive installation, side panel thumbscrews,
and full side panel window.
The Obsidian 450D is the mid tower you’ve
been waiting for. It’s finally here.
mm mm
mm
450D
SERIES®
OBSIDIAN
ObsidianSeries®DMid
TowerCasewithtwo
AFLfrontintakefans
andoneAFLrear
exhaustfan
InstallationGuide
AccessoryKit
MaximumGPUlength
Topslots mm
Lowerslots mm
MaximumCPU
coolerheight
mm
x x x x
MBD/HDD screws Long fan screws Short fan screws SSD/ODD screws
x x x
Motherboard
standos
SSD pan
head screws
Cable ties

C
E
F
G
H
I
J
K
A
B
D
OBSIDIAN SERIES®450D MID TOWER PC CASE OBSIDIAN SERIES®450D MID TOWER PC CASE
(x2) USB 3.0, Headphone/Mic, Power/Reset ト
Front dual 140mm AFL140L intake fans
Rear 120mm AF120L exhaust fan
Top 3 x 120mm or 2 x 140mm fan mounts with radiator compatibility
Windowed side panel
Removable HDD cage for 3.5"/2.5" drives
A
B
C
D
E
F
(x2) 5.25 tool-free drive bays
Bottom PSU mount and dust filter
Front dust filter and mesh cover
Rear tool-free 2.5 drive mounts
Top magnetic dust filter
H
I
J
K
G






 
> Install your motherboard's I/O shield
(see your motherboard’s manual for guidance).
> Align the motherboard with the standos in the case.
> Secure with the included screws (MBD/HDD screws).
Installing the motherboardRemoving the side panels
> Remove the thumbscrews and slide the side panel back and out.
Note: Corsair recommends removing both side panels and setting
them aside when building your system to avoid accidental damages.






 
> Remove thumbscrews and corresponding slot cover(s).
> Install the add-on card and secure with thumbscrews.
Installing the PCI-E/PCI cardsInstalling the power supply (PSU)
> Seat the PSU on the bottom of the case.
> Align holes and secure the PSU with screws.
Note: PSU can be installed in either fan up or fan down orientations.





Installing a 5.25" drive/devices (ODD)
> Remove the front panel 5.25" drive bay cover.
> Insert the ODD into the drive bay until the tool-free
latch clicks, securing the drive.
> To remove, push the tool-free tab to release
the ODD drive and remove.







A B

Installing a 2.5" SSD into tool-free SSD cage
> Pull down the tab and place the SSD into
the tool-free cage until you feel it secure.
> To remove the SSD, pull the tab down to release.

> Remove the tool-free 3.5" HDD tray.
> Insert the HDD into the HDD tray.
> Align the HDD holes with the tray pins to secure.
Note: To mount a 2.5" drive in this tray, it is necessary to remove one
of the side pins and secure the drive from underneath with screws.
Installing a 3.5" HDD/ 2.5" SSD

A
B





> To remove the front panel dust filter, first remove the
solid front panel by pushing the top corners of the aluminum cover.
> The front solid panel will pop out for access to the front dust filter.
> To remove the bottom dust filter, first locate the pull out tab underneath the PSU, then
pull the bottom dust filter out.
Removing the front and bottom dust filters

USB 3.0
HD AUDIO RESET SW POWER LED +
POWER LED –POWER SW HDD LED
 
> See your motherboard’s manual for front panel header locations and pin-outs.
Installing the front I/O connectorsAttach case fan cables to motherboard headers
> See your motherboard’s manual for fan header locations.
