Portable Air-conditioner
EP24581US-WH
USER'S MANUAL

www.costway.com www.costway.com
1. Safety Awareness
1. The appliance is for indoor use only.
2. Do not use the unit on a socket under repairs or not installed properly
3. Do not use the unit, follow these precautions:
A: Near to source of fire.
B: An area where oil is likely to splash.
C: An area exposed to direct sunlight.
D: An area where water is likely to splash.
E: Close to bathtub, laundry room, shower room or swimming pool.
4. Never insert your fingers, rods into the air outlet. Take special care to warn
children of these dangers.
5. Keep the unit upward while transport and storage to ensure that the compressor is
located properly.
6. Before cleaning the air-conditioner, always turn off or disconnect the power supply.
7. When moving the air-conditioner, always turn off and disconnect the power
supply, and move it slowly.
8. To avoid the possibility of fire disaster, the air-conditioner shall not be covered.
9. All the air-conditioner sockets must comply with the local electric safety
requirements. If necessary, please check it for the requirements.
10. Children should be supervised to ensure that they do not play with the appliance.
11. If the supply cord is damaged, it must be replaced by the manufacturer, its
service agent or similarly qualified persons in order to avoid a hazard.
12. This appliance can be used by children aged from 8 years and above and
persons with reduced physical, sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or instruction concerning use of
the appliance in a safe way and understand the hazards involved. Children shall not
play with the appliance. Cleaning and user maintenance shall not be made by
children without supervision.
13.Recycling
This marking indicates that this product should not be disposed with
other household wastes throughout the EU. To prevent possible harm
to the environment or human health from uncontrolled waste
disposal, recycle it responsibly to promote the sustainable reuse of
material resources. To return your used device, please use the return
and collection systems or contact the retailer where the product was purchased.
They can take this product for environmental safe recycling.
14. Contact authorized service technician for repair or maintenance of this unit.
15. Do not pull , deform . or modify the power supply cord , or immerse it in water .
Pulling or misuse of the power supply cord can result in damage to the unit and
cause electric shock.
16. Compliance with national gas regulations shall be observed.
17. Keep ventilation openings clear of obstruction.
18. Any person who is involved with working on or breaking into a refrigerant
circuit should hold a current valid certificate from an industry-accredited
assessment authority, which authorizes their competence to handle refrigerants
safely in accordance with an industry recognized assessment specification.
19. Servicing shall only be performed as recommended by the equipment
manufacturer . Maintenance and repair requiring the assistance of other skilled
personnel shall be carried out under the supervision of the person competent in the
use of flammable refrigerants.
20. Do not operate or stop the unit by inserting or pulling out Die power plug, it
may cause electric shock or fire due to heat generation .
21. Unplug the unit if strange sounds, smell, or smoke comes from it.
Notes:
- If any parts are damaged, please contact the dealer or a designated repair shop;
- In case of any damage, please turn off the air switch, disconnect the power supply,
and contact the dealer or a designated repair shop;
- In any case, the power cord shall be firmly grounded.
- To avoid the possibility of danger, if power cord is damaged, please turn off the air
switch and disconnect the power supply. It must be replaced from the dealer or a
designated repair shop.
02 03

www.costway.com www.costway.com
2. Name of Parts
3. Accessories
After unpacking, please check whether the above-mentioned accessories are
included, and check their purposes in the installation introduction in this manual.
4. Appearance and Function of Control Panel
Cooling only model
QuantityDescription
Exhaust hose
Housing adaptor
Window Connector
Remote Controller
Window Kit
Window Connector
1
1
1
1
1 (optional)
1(optional)
Part
QuantityDescription
Window Kit 1 (optional)
Air outlet 1 (optional)
Dowel 2 (optional)
Caulking kit 1 (optional)
Water pipe 1 (optional)
Batteries 2 (optional)
Part
A
B
C
D
E
F
G
1
2
3
4
5
6
7
Power on/off
Fan speed
Temperature up
Temperature down
Operation mode
Timer on/off
Swing on/off
H Sleep mode
Cooling
Dehumidifying
Fan
High fan speed
Medium fan speed
Low fan speed
Water full
1
Louver
6
Drainage outlet
2
Control panel
7
Air outlet
3
Front panel
8
Power cord
4
Castor
9
Drainage outlet
5
Air inlet
3
4
5
6
7
8
9
1 2
Fig.1
SWING TIMER MODE SPEED POWERDOWN UP
SLEEP
FULL
COOL
DEHUM
FAN
LOW
MEDIUM
HIGH
°F
12 3 4 5 67
H AB
C
DEF
G
04 05

www.costway.com www.costway.com
5. Appearance and Function of Remote Control
Notes:
- Do not drop the remote controller.
- Do not place the remote controller in a location exposed to direct sunlight.
6. Operation Introduction
Before starting operations in this section:
1) Find a place where there is power supply nearby.
2) As shown in Fig.5 and Fig.5a, install the exhaust hose, and adjust the window
position well.
3) As shown in Fig. 6, Connect drain hose well (only for using heating model)；
4) Insert the power cord into an grounded AC 110V/60Hz socket;
5) Press the POWER button to turn on the air-conditioner.
6.1. Before using
Notice:
- Operation temperature range:
Check up whether the exhaust hose has been mounted properly.
Cautions for cooling and dehumidifying operations:
- When using functions on cooling and dehumidifying, keep an interval of at least 3
minutes between each ON/OFF.
- Power supply meets the requirements.
- The socket is for AC use.
- Do not share one socket with other appliances.
- Power supply is AC110V/60Hz
5 4
3
2
1
6
7
8
1 POWER
2 TIMER
3 MODE
4 TEMP-
5 TEMP+
6 SPEED
7 SLEEP
8 SWING
Power on/off
Timer on/off
Operation MODE
Temperature down
Temperature up
Fan speed
Sleep mode
Swing on/off
Remote Control
Fig.5 Fig.5a
Fig.6 Drainage outlet
Maximum cooling Minimum cooling
DB/WB(°F) 95/75 64/54
06 07

www.costway.com www.costway.com
6.2 Cooling operation
- Press the “MODE” button till the “Cool” icon appears.
- Press the “ DOWN ”or“ UP ”button to select a desired room temperature.
(61°F-88°F)
- Press the “ SPEED ” button to select wind speed.
6.3 Dehumidifying operation
Press the “MODE” button till the “Dehumidify” icon appears .
- Automatically set the selected temperature to current room temperature minus 2°F.
(61°F-88°F)
- Automatically set the fan motor to LOW wind speed.
6.4 Fan operation
- Press the “MODE” button till the “Fan” icon appears.
- Press the “ SPEED ” button to select wind speed.
6.5 Timer operation
Timer ON setting:
- When the air-conditioner is OFF, press the “TIMER” button and select a desired
ON time through the temperature and time setting buttons.
- “Preset ON Time” is displayed on the operation panel.
- ON time can be regulated at any time in 0-24 hours.
Timer OFF setting
- When the air-conditioner ON, press “TIMER” button and select a desired OFF
time through the temperature and time setting buttons.
- “Preset OFF Time” is displayed on the operation panel.
- OFF time can be regulated at any time in 0-24 hours.
6.7 Auto SWING
After machine turns on, press this key, the louver will swing continuously left and
right; by pressing this button again the movement will stop and the louver remain in
that position.
6.8 SLEEP mode
- While in cooling mode, press the SLEEP key to set the temperature. It increases
1°F after an hour and at most increases 2°F after 2 hours.
- Press the SLEEP key again can cancel the setting.
6.9 Water drainage
Water Full Alarm
The inner water tray inside the air-conditioner has one water level safety switch, it
controls water level. When water level reaches an anticipated height, the water full
indicator lamp lights up. (If water pump is damaged, when the water is full, please
remove the rubber stopper at the bottom of unit, and all water will drain outside.)
Continuous Drainage
- When you plan to leave this unit unused for a long time, please remove the rubber
stopper from the drainage hole at the bottom of unit, and connect a drain hose to the
lower fixing clip. All the water in the water tank will drain outside.
- If water pump is damaged, continuous drainage can be used, and under this
condition, the water pump is not activated. The unit can also work well.
If water pump is damaged, intermittent drainage can also be used. Under this
condition, when the water full indicator lamp lights up, please connect a drain hose
to the lower fixing clip, then all the water in the water tray will be drained outside.
The unit can also work well.
08 09

www.costway.com www.costway.com
7. Installation Explanations
7.1 Installation Explanations:
- A removal air-conditioner shall be installed in the flat and empty place all around.
Don’t block the air outlet, and the required distance around should be at least 30cm/12”.
(See Fig.8)
- Should not be installed in wet location, such as the laundry room.
- Socket wiring should be in accordance with the local electric safety requirements.
7.2 Introduction to Exhaust Hose Installation
Temporary installation
1. Twist the housing adaptor and the window Connector to the ends of the exhaust hose.
2. Insert the fixing clip of the housing adaptor into the openings at back of the air
conditioner.
3. Put the other end of the exhaust hose to the near windowsill(see Fig.9).
Window Kit Installation
The installation manner of window slider kit is mostly in “horizontal” or “vertical”. As
shown Fig.10 and Fig.10a, check the min. and max. size of the window before the
installation.
1. Install the window kit on the window (Fig.10, Fig.10a);
2. Adjust the length of the window slider kit according to the window width or height,
and fix it with the dowel;
3. Insert the window connector of the hose to the hole of the window kit(Fig.11).
≥30cm
≥30cm Fig.3
Window width
min:67.5cm
max:123cm
Window height
min:67.5cm
max:123cm
Fig.10 Fig.10a
clockwise
Aligning the bayonet
Fig.9
Insert down
Fig.11
Dowel
③
②
10 11

www.costway.com www.costway.com
Universal caulking kit accessory for mobile air conditioner
N.B .: If you have a window with French opening with two leaves: Block the first leaf
with the handle and make the installation of the caulking kit on the second leaf (without
the handle).
Before installation, check that the adhesive gripping tape do not damage your window.
7.3 Water Full alarm
The inner water tray inside the air-conditioner has one water level safety switch, it
controls water level. When water level reaches an anticipated height, the water full
indicator lamp lights up. (If water pump is damaged, when the water is full, please
remove the rubber stopper at the bottom of unit, and all water will be drained outside.)
Suitable for windows and doors
Included in this kit:
1 piece of fabric
1 roll of adhesive gripping tape
1. Open the window and clean the doors
and frame before gluing the adhesive
tape.
1.Glue the widest side (A) of the large
white fabric piece to the window frame
and then glue the narrower side (B) to
the window leaf (handle side) from the
center, then up and finally down.
2. Cut large strips of adhesive gripping
tape to the dimensions of the window.
Glue them to the frame of your window
and then do the same on the inner
surface of the window flap (on the side
of the handle).
4. Close the window and make sure the
large fabric piece is not stuck in the
closing seams and the window closes
always correctly, even with the tapes
sticky adhesive tape.
5. Open the window gently and open
the zipper of the fabric piece (at level
of the bottom or middle of the window)
then insert the exhaust duct into the
opening.
Readjust the zipper so that the exhaust
duct is attached so that there is no air
exchange between the inside and the
outside.
6. Your caulking kit is now installed,
you can now turn on and enjoy the
coolness of your mobile air conditioner!
If you no longer want to use your
mobile air conditioner and close your
window, you can simply remove the
sheath from the zipper and close your
window, in verifying that the fabric
piece is not stuck in the closing seals.
12 13

www.costway.com www.costway.com
9. Troubleshooting
Note: The real products may look different.
8. Maintenance Explanations
Declaration:
1) Before cleaning, be sure to disconnect the unit from any electric supply outlet;
2) Do not use gasoline or other chemicals to clean the unit;
3) Do not wash the unit directly;
4) If the conditioner is damaged, please contact the dealer or repair shop.
8.1 Air Filter
- If the air filter becomes clogged with dust/dirt, the air filter should be cleaned once
every two weeks.
- Dismounting
Open the air inlet grille and take off air filter.
- Cleaning
Clean the air filter with neural detergent in lukewarm（104°F）and dry it up in the
shade.
- Mounting
Putting the air filter into the inlet grille, replace the components as they were.
8.2 Clean the Air-conditioner Surface
First clean the surface with a neutral detergent and wet cloth, and then wipe it with a
dry cloth.
Troubles Possible Causes Suggested Remedies
1.Unit does not start when
pressing on/off button
- Water full indicator lamp blinks, and
water tank is full.
Dump the water out of the water
tank.
- Room temperature is lower than the
setting temperature. (Cooling mode) Reset the temperature
2. Not cool enough
- The doors or windows are not
closed.
Make sure all the windows and
doors are closed.
- There are heat sources inside the
room.
Remove the heat sources if
possible
- Exhaust air hose is not connected or
blocked.
Connect or clean the exhaust air
hose.
- Temperature setting is too high. Reset the temperature
- Air inlet is blocked. Clean the air inlet.
3. Noisy
- The ground is not level or not flat
enough
Place the unit on a flat, level
ground if possible
- The sound comes from the flowing
of the refrigerant inside the air
conditioner
It is normal.
4. E0 Code Room temperature sensor failed
Replace room temperature sensor
(the unit can also work without
replacement.)
5. E1 Code Condenser temperature sensor failed Replace condenser temperature
sensor
6. E2 Code Water tank full when cooling Take off rubber stopper and empty
the water.
6. E3 Code Evaporator temperature sensor failed Replace evaporator temperature
sensor
7. E4 Code Water tank full when heating Please empty the water tank.
14 15
