Costway FP10137UC-WH User manual

THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
EN FR
USER'S MANUAL/MANUEL DE L'UTILISATEUR
FP10137UC-WH/FP10138UC-WH/FP10139UC-WH
Window Air Conditioner/Climatiseur de Fenêtre
EN

Before installing and using your air conditioner, please read this owner's
manual carefully. Store this manual in a safe place for future reference.
Your safety and the safety of others are very important to us. Please pay
attention to all safety messages outlined in this owner's manual.
• Plug into a grounded 3 prong outlet.
• Do not remove the ground prong.
• Do not use a plug adapter.
All Safety messages alert you of potential hazards, how to reduce the chance
of injury, and what can happen if instructions are not followed correctly.
This is a safety alert symbol.
This symbol alerts you to potential hazards that can harm you
or others or even cause death.
All safety messages will directly follow the safety alert symbol
and/or the words
“DANGER”or WARNING".
Failure to immediately follow these
instructions may cause serious injury
or even death.
• Do not use an extension cord.
• Unplug the air conditioner before servicing
• Two or more people are required to move or install the air conditioner
IMPORTANT SAFETY INSTRUCTIONS
WARNING: To reduce the risk of fire, electrical shock or injury when
using your air conditioner, follow the following basic precautions:
EN
02

The refrigerants used for air conditioners are environmentally friendly
hydrocarbons R32. It is combustible and odorless. Moreover, it can burn
and explode under certain condition. However, there will be no risk of
burning and explosion if you comply with the following table to install
your air conditioner in a room with an appropriate area and use it
correctly.
Compared with ordinary refrigerants, Refrigerant R32 is environmentally
friendly and do not destroy the ozone sphere and that its value of
greenhouse effect is also very low.
• Please read the manual before installation, using, maintenance.
• Do not use means to accelerate the defrosting process or to clean, other
than those recommended by the manufacturer.
• Do not pierce or burn the appliance.
• The appliance shall be stored in a room without continuously operating
sources (for example: open flames, an operating ignition gas appliance or
an operating electric heater.)
• Please ask qualified technician for help when maintenance is necessary.
At the time of maintenance, the maintenance personnel must strictly
comply with the Operation Manual provided by the corresponding
manufacturer and any non-professional is prohibited to maintain the air
conditioner.
• The handling, installation, storage, servicing and disposal must comply
with the provisions of gas-related national laws and regulations, and also
national wiring regulation.
• It is necessary to clear away the refrigerant in the system when
maintaining or scrapping an air conditioner.
Be aware that refrigerants may not contain an odour.
• This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or supervision or
instruction concerning use of the appliance by a person responsible for
their safety.
Children should be supervised to ensure that they do not play with the
appliance.
Unit operation limits: Outdoor side 61°- 110℉, 80%RH; indoor side 61°-
90℉, 80%RH.
INTRODUCTION TO REFRIGERANTS R32
WARNINGS
EN
03

The electrical ratings for your air
conditioner are listed on the model
and serial number label located on
the front left side of the unit (when
facing the front).
Specific electrical requirements are
listed in the chart below. Follow the
requirements below for the type of
plug on the power supply cord.
Plug into a grounded 3 prong outlet.
Do not remove the ground prong.
Do not use an adapter
Do not use an extension cord.
Failure to follow these instructions can result in death, fire, or electrical shock
ELECTRICAL REQUIREMENTS
Recommended Ground Method
Electrical Shock Hazard
Power Supply CordWiring Requirements
For your personal safety, this air conditioner must be grounded. This air
conditioner is equipped with a 3 prong power supply cord with a
grounded plug. To minimize the possibility of electrical shock, the cord
must be plugged into a 3 prong outlet and grounded in accordance with
all local codes and ordinances. If a 3 prong outlet is not available, it is
the CUS-tomer's responsibility to have a properly grounded 3 prong
outlet installed by a qualified electrician.
It is the customer's responsibility:
● To contact a qualified electrician
● To assure that the electrical installation is adequate and in
conformance with the National Electrical Code, ANSI/NFPA 70 - latest
edition, and all local codes and ordinances.
WARNINGS
EN
● 115 volt (103 min.---127 max)
● (6K-8K) 0-8 amps
(10K-12K) 0-12 amps
● (6K-8K) 10-amp time-delay fuse or
circuit breaker
(10K-12K) 15-amp time-delay fuse or
circuit breaker
● Use on single outlet circuit only
04

LCDI Power Cord and Plug
This air conditioner is equipped with an LCDI (L eakage Current
Detection and Interruption) power cord that is required by UL. This
power supply cord contains state- of-the art electronics that sense
leakage current. If the cord is damaged and leakage occurs, power will
be disconnected from the unit.
The test and reset buttons on the LCDI Plug are used to check if the plug
is functioning properly. To test the plug:
1. Plug power cord into a grounded 3 prong outlet
2. Press RESET (on some units a green light will turn on).
3. Press the TEST Button, the circuit should trip and cut all power to the
air conditioner (on some units a green light may turn off.
4. Press the RESET button for use. You will hear a click and the AC is not
ready for use.
NOTES:
● The RESET button must be engaged for proper use.
The power supply cord must be replaced if it fails to trip when the TEST
button is pressed and the unit fails to reset.
● Do not use the power supply cord as an ON/OFF switch. The power
supply cord is designed as a protection device.
● A damaged power supply cord must be replaced with a new power
supply cord.
NOTES:
Your units power cord and
plug may differ from the
one shown.
EN
05

PACKING LIST
IMAGE PART QUANTITY
(Only for E-star model)
EN
06

DISCL AIMER
ALL INFORMATION AND THE TECHNICAL SPECIFI-CATIONS PRESENTED
IN THIS USER'S MANUAL ARE THE PRESENTATION OF THE
MANUFACTURER.
INSTALLATION & ASSEMBLY INSTRUCTIONS
(USED FOR 6K/8K)
Some assembly is required for your new air conditioner. Please
read and follow these instructions carefully.
NOTE: Save the product packaging and installation instruc-tions for
future reference. Store the air conditioner in the product box when not
in use for an extended period of time.
1. This air conditioner is designed to be installed in a standard
double-hung window with a window width between 23" and 36”(584 mm
- 914 mm).
2. The air conditioner can be installed without the accordion panels to fit
in a narrow window opening. See the window dimensions.
3. The Lower Sash (the lower part of the window that moves up and
down) must allow for 14.5”of vertical clearance when open. (See FIG.
1).
4. All supporting parts must be secured to firm wood, masonry, or metal.
5. The electrical outlet must be within reach of the power cord.
EN
FIG. 1
OFFSET
TOOL
SILL
INTERIOR
WALL
EXTERIOR
WALL
07

Top Rail Assembly (Only used for 6K/8K)
The top rail must be assembled prior to installing the air conditioner in
the window
Tools Needed: Phillips Screw Driver
EN
INSTALLATION & ASSEMBLY INSTRUCTIONS
(USED FOR 10K/12K)
Some assembly is required for your new air conditioner. Please
read and follow these instructions carefully.
NOTE: Save the product packaging and installation instruc-tions for
future reference. Store the air conditioner in the product box when not
in use for an extended period of time.
1. This air conditioner is designed to be installed in a standard
double-hung window with a window width between 26" and 36”(660 mm
- 914 mm).
2. The air conditioner can be installed without the accordion panels to fit
in a narrow window opening. See the window dimensions.
3. The Lower Sash (the lower part of the window that moves up and
down) must allow for 16”of vertical clearance when open. (See FIG. 2).
4. All supporting parts must be secured to firm wood, masonry, or metal.
5. The electrical outlet must be within reach of the power cord.
FIG. 2
OFFSET
STOOL
SILL
INTERIOR
WALL
EXTERIOR
WALL
08

Attaching the Top Rail to the Air Conditioner
CAUTION
1. Remove the air conditioner from the box and place on a hard flat
surface.
2. Remove top rail from the bottom of the packaging material as shown
in FIG. A
3. Align the hole in the top rail with those in the top of the unit as shown
in FIG. B
4. Secure the top rail to the unit with the 3/8" Screws as shown in FIG. C
NOTE: For safety reasons, all 4 screws must be used to attach the top
rail.
When handling the unit, be careful to avoid cuts from the sharp metal
edges and aluminum fins on the front and rear coils.
EN
09

1. Place unit on floor, a bench or a table. There is a Left and Right
Window Filler Panel - be sure to use the proper panel for each side.When
installed the flange for securing the panel in place to the window sill
will be facing into the room.
A. Hold the Panel in one hand and gently pull back the center to free the
open end. See Figure 3.
TOOLS NEEDED:
● Phillips Screw
Driver
● Drill (If pilot holes
are needed)
CAUTION
When handling the unit, be careful to avoid cuts from the sharp metal
edges and aluminum fins on the front and rear coils.
How to Install
NOTE: Top Rail and Sliding Panels at each side are offset to
provide the proper pitch to the rear of (5/16"). This is necessary
for proper condensed water utilization and drainage. If you are
not using the Side Panels for any reason, this pitch to the rear
must be maintained!
EN
10

B. Slide the free end of the panel into the cabinet as shown in Figures 4.
Slide the panel down. Be sure to leave enough space to slip the top and
bottom of the frame into the rails on the cabinet.
C. Once the panel has been installed on the side of the cabinet, make
sure it sits securely inside the frame channel by making slight
adjustments. Slide the top and bottom ends of the frame into the top
and bottom rails of the cabinet. Figure 5.
D. Slide the panel all the way in and repeat on the other side.
EN
FIG. 3
FIG. 4
FIG. 5
11

3. Extend the side panels out against the window frame (FIG. 7).
4. Place the frame lock between the frame extensions and the window
sill as shown Fig. 8). Drive 3/4”(19 mm) locking screws through the
frame lock and into the sill (FIG.9). NOTE: To prevent window sill from
spltting, drill 1/8”(3 mm) pilot holes before driving screws.
2. Keep a firm grip on the air conditioner, carefully place the unit into
the window opening so the bottom of the air conditioner frame is against
the window sill (FIG. 6). Carefully close the window behind the top rail of
the unit. ( Suggest to keep a downward oblique, to let accumulated rain
water to drain out, from back side of the unit bottom.)
EN
FIG. 6
FIG. 7
FIG. 8 FIG. 9
12

EN
5. Drive 1/2” (12.7mm) locking screws through frame holes into window
sash (FIG.10/11).
6. To secure lower sash in place, attach right angle sash lock with 3/4”
(19 mm) screw as shown (FIG. 12).
7. Cut foam seal and insert in the space between the upper and lower
sashes (FIG. 13).
If AC is Blocked by Storm Window
Add wood as shown in FIG. 14, or remove storm window before air
conditioner is installed.
FIG. 10 FIG. 11
FIG. 12
FIG. 13
13

EN
Removing AC From Window
AIR CONDITIONER USE
99FIG. 14
●Turn AC off, and disconnect power cord.
●Remove sash seal from between windows, and unscrew safety lock.
●Remove screws installed through frame and frame lock.
●Close (slide) side panels into frame.
●Keeping a firm grip on air conditioner, raise sash and carefully“rock" air
conditioner backward to drain any condensate water in base of unit. Be
careful not to spill any remaining water while lifting unit from
window. Store parts WITH air conditioner.
If Storm Window Frame must
remain, be sure the drain holes or
slots are not caulked or painted
shut. Accumulated Rain Water or
Condensation must be allowed to
drain out.
Operating your air conditioner properly helps you to obtain the best
possible results. This section explains proper air conditioner operation.
IMPORTANT:
●If you turn off the air conditioner, wait at least 3 minutes before
turning it back on. This prevents the air conditioner from blowing a fuse
or tripping a circuit breaker.
●Do not try to operate your air conditioner in the cooling mode when
outside temperature is below 65°F (18°C).The inside evaporator coil will
freeze up, and the air conditioner will not operate property.
NOTE: In the event of a power failure, your air conditioner will operate
at the previous settings when the power is restored.
BOARD
THICKNESS
AS REQUIRED,
FOR PROPER
PITCH TO
REAR, ALONG
ENTIRE SILL.
FASTEN WITH
NAILS OR
SCREWS.
STORM WINDOW
FRAME
OR OTHER
OBSTRUCTION
SASH
14

INSTALLATION & ASSEMBLY INSTRUCTIONS
Introduction to Refrigerants R32
• Before installing the appliance, you must read the manual carefully to
get the safety information and notes.
• When filling the combustible refrigerant, any of your rude operations
may cause serious injury or injuries to human body or bodies and object
or objects.
• A leak test must be done after the installation is completed.
• It is a must to do the safety inspection before maintaining or repairing
an air conditioner using combustible refrigerant in order to ensure that
the fire risk is reduced to minimum.
• It is necessary to operate the machine under a controlled procedure in
order to ensure that any risk arising from the combustible gas or vapor
during the operation is reduced to minimum.
• Requirements for the total weight of filled refrigerant and the area of a
room to be equipped with an air conditioner.
EN
1. Site Safety
2. Operation Safety
Open Flames Prohibited
Mind Static
Electricity Must wear protective clothing and anti-static gloves Don't use mobile phone
Ventilation NecessaryOpen Flames Prohibited
15

5. If the indoor unit suffers refrigerant leak during the installation, all the
personnel should go out till the refrigerant leaks completely for 15 minutes. If
the product is damaged, it is a must to carry such damaged product back to the
maintenance station and it is prohibited to weld the refrigerant pipe or conduct
other operations on the user's site.
6. It is necessary to choose the place where the inlet and outlet air of the indoor
unit is even.
7. It is necessary to avoid the places where there are other electrical products,
power switch plugs and sockets, kitchen cabinet, bed, sofa and other valuables
right under the lines on two sides of the indoor unit, and also prevent
mechanical damage from occurring.
USING YOUR AIR CONDITIONER
NOTE: This display always shows the room temperature in Fan Mode
except when setting the Set temperature or the Timer.
Electronic Control Panel & Remote Control
1
2
3
456789
AUTO
SPEED
AUTO
MODE
EN
Please note that:
1. The installation site should be in a well-ventilated condition.
2. The sites for installing and maintaining an air conditioner using Refrigerant
R32 should be free from open fire or welding, smoking, drying oven or any other
heat source higher than 548 ℃/ 1018 ℉which easily produces open fire.
3. When installing an air conditioner, it is necessary to take appropriate
anti-static measures such as wear antistatic clothing and/or gloves.
4. It is necessary to choose the site convenient for installation or maintenance
wherein the air inlets and outlets of the indoor and outdoor units should be not
surrounded by obstacles or close to any heat source or combustible and/or
explosive environment.
3. Installation Safety
• Refrigerant Leak Detector
• Appropriate Installation Location
The left picture is the schematic
diagram of a refrigerant leak
detector.
16

• You may hear the thermostat click when the compressor cycles on and
off.
• Water will collect in the base pan during rain or days of high humidity.
The water may overflow and drip from the outside part of the unit.
• The fan may run even when the compressor is not on.
Dry Mode: This function reduces the humidity of the air to make the
room more comfortable. Press MODE button to set the DRY mode . An
automatic function of alternating cooling cycles and air fan is activated.
Fan Mode: The conditioner works in only ventilation. Press MODE button
to set the FAN mode. With pressing FAN SPEED button the speed
changes in the following sequence: High, Med and Low in FAN mode. The
remote control also stories the speed that was set in the previous mode
of operation.
Normal Operating Sounds
1. Digital Display: Without timer setting, the operation mode is
Cooling, Dry, Fan and Auto, and the set temperature will be displayed.
Time will be displayed under timer setting.
2. andy Button: Use these buttons on the .control panel and
remote to increase or decrease the Set Temperature or Timer.
Temperature range: 61°F~88°T or 16°C~31°C.
3. Power Button: Turn the air conditioner on and off.
4. Mode Button: Press the mode button to cycle through the various
modes: Cool, Dry, Fan and Auto.
Cool Mode: The cooling function allows the air conditioner to cool the
room and at the same time reduces Air humidify. Press the MODE button
to activate the cooling function. To optimize the function of the air
conditioner, adjust the temperature and the speed by pressing the
button indicated.
EN
• You may hear a pinging noise caused by water hitting the condenser,
on rainy days, or when the humidity is high. This design feature helps
remove moisture and improve efficiency.
17

Auto Mode: In AUTO mode the unit automatically chooses the fan speed
and the mode of operation (COOL,DRY or FAN).In this mode the fan
speed and the temperature are set automatically according to the room
temperature (tested by the temperature sensor which is incorporated in
the indoor unit.).
5. Timer Button: Use these buttons on the control panel and remote to
set the Timer.
Timer Off: The timed stop is programmed by pressing TIMER button. Set
the rest time by pressing the button“ ”or“ ” until the rest time
displayed is to your demand then press TIMER button again.
Timer On: When the unit is off, press TIMER button at the first time, set
the temperature with pressing the button“ ”or“ ”. Press TIMER button
at the second time, set the rest time with 6 pressing the button“ ”, or
“ ”. Press TIMER button at the third time, confirm the setting, then the
rest time to next automatical switching-on could be read on the display
of the machine.
Note: It can be set to automatically turn off or on in 0.5-24 hours. Each
pressof the“ ” “ ” buttons will increase or decrease the timer. The
Timer can be set in 0.5 hours increment below 10 hours and 1 hour
increment for 10 hours or above.
The SET light will turn on while setting.
To cancel the setted function, press the TIMER button again.
EN
18

USING YOUR AIR CONDITIONER
Electronic Control Panel & Remote Control
6. Eco Button: When the unit is in ECO mode, the light will turn on. In
ECO mode, the unit will turn off once the room is cooledto the user-set
temperature.
The unit will turn back on when the room temperature rises above the
user-set temperature.
Before the compressor starts, the fan motor will run for a while, then it
will stop for a while, and will repeat to provide a much more comforta
ble feeling and save energy.
7. Sleep Button: Press the SLEEP button, all of the display lights will
turn off after a while, but the Sleep light is always on. In SLEEP mode,
the air conditioner will automatically adjust the temperature and fan
speed to make the room more comfortable during the night. The set
temperature will automatically raise every 30-60 minutes, and at most
change six times until the set temperatureis 81°F or 82°F.
8. Fan Speed Button: Press the FAN SPEED button to choose the fan
speed options. You can choose High, Med and Low or auto speed in
COOL mode and choose High, Med and Low in FAN mode.
9. Filter Button: When the Filter Check light is off, it is not necessary to
press the Filter Check button.
When the Filter Check light is on, you can turn off the light by pressing
the Filter Check button. After the fan motor works for 500 total hours,
the Filter Check light will turn on to remind the user to clean the filter.
10.Directional Louvers: To direct the airflow, use the horizontal wheel
to control the horizontal direction, and use the air deflectors to control
the vertical direction.
horizontal wheelair deflector air deflector
EN
19

OPERATING YOUR AIR CONDITION ER
REMOTE CONTROL
1. Power: Turn the air conditioner on and off.
2. Cool: Press the COOL button to COOL mode.
3. and : Use these buttons on the control panel and remote to
increase or decrease theSet Temperature or Timer. Temperature range:
61°F~88°F or 16°C~31C.
4. Sleep: Press the SLEEP button, all of the display lights will turn off
after a while, but the Sleep light is always on. In SLEEP mode, the air-
conditioner will automatically adjust the tempera- ture and fan speed to
make the room more comfor- table during the night. The set emperature
will automatically raise every 30-60 minutes and at most change six
times until the set temperature is 81°F or 82°F.
5. Timer: Use these buttons on the control panel and remote to set the
Timer.
Timer Off: The timed stop is programmed by pressing TIMER button. Set
the rest time by pressing the button“ ”or“ ”until the rest time
displayed is to your demand then press TIMER button again.
Timer On: When the unit is off, press TIMER button at the first time, set
the temperature with pressing the button or“ ”Press“ ”TIMER button
at the second time, set the rest time with pressing the button or“ ”
Press “ ” TIMER button at the third time, confirm the setting, then the
rest time to next automatical switching-on could be read on the display
of the machine.
1
4
5
6
3
3
7
8
10
9
2
EN
20
