Costway EP24829 User manual

USER'S MANUAL
Air Cooler
EP24829

02
PLEASE READ THIS MANUAL CAREFULLY BEFORE
OPERATING THIS APPLIANCE
AND RETAIN IT FOR FUTURE REFERENCE
IMPORTANT SAFEGUARDS
When using an electrical appliance, basic safety precautions should always be observed, including
the following:
READ ALL INSTRUCTIONS BEFORE USING
WARNING: To reduce the risk of fire, electric shock, or injury to person:
1.Read all instructions before using. The product is for household use only.
2. Before first use, please check that the voltage you use is in accordance with the product
nameplate requirements.
3. Always turn the product to the OFF position and unplug it from the electrical outlet when not in
use.
4. Extreme caution is necessary when the appliance is used by or near children, invalids or elderly
person.
5. Do not run cord under carpeting and do not cover cord with throw rugs, runners or the like.
Arrange cord away from traffic area and where it will not be tripped over.
6. Please check the power cord and plug for breakage before using it.
7. Do not operate the appliance with a damaged cord or plug, or after the unit malfunctions, has
been dropped, or damaged in any manner.
8. If the supply cord is damaged, it must be replaced by the manufacturer or its service agent or a
similarly qualified person to avoid a hazard.
9. Use the appliance in a well-ventilated area. While using, distance of no less than 4”(20cm )
should be kept away from wall or corner to ensure the air intakes or exhaust openings should not be
blocked unexpectedly. The unit must not be located directly below or besides a curtain or the likes.
10. Use the appliance on flat, dry floor only.
11.Do not use in high temperature, humidity, dusty or volatile places such as acid-base oil.
12.Do not twist or pull the power cord to avoid bad contact.
13.Do not place heavy objects on the machine to prevent pressure breakdown from causing trouble.
14.Make sure the appliance is disconnected from the power supply when the power is cut off or
moving.
15.Do not place machine directly under the power outlet.
16.When the whole machine is running, blocking duct and rear shell intake are not allowed. Don't
use wire to plug into the passageway to prevent electric shock.
17.During the automatic oscillation process, do not change the orientation with the hand to avoid
damaging the shaking structure.
18.Turn off the power supply before pulling out the plug. Do not pull the power cord. Pull out the
power plug, otherwise it will lead to short circuit, fire and electric shock.
19.Do not use wet hand to pull out the power plug, there is a danger of electric shock and induction.
20.When leaving the room for a long time, please turn off the machine and unplug the plug.
21.Do not use in places where curtains are easy to suck in. Avoid obstacles and unstable places
around you.
22.This appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been given
supervision or instruction concerning use of the appliance by a person responsible for their safety.

FOR HOUSEHOLD USE ONLYTECHNICAL SPECIFICATIONS
Model No
Voltage
Frequency
Rated Power
Water Tank Capacity
Water Consumption
60Hz
45W
0.66 Gallon
PRODUCT OVERVIEW
1. Take out the base components, then align the matching holes, and assemble the two bases into a
circular base.
2. Turn the base upside down, assemble the base assembly in the previous step to the main body, and
then fix it with the 4 screws.
PRODUCT OVERVIEW
03
120V AC
EP24829/ DC2002
7
1.Control panel
2.Air outlet
3.Water tank
4.Base
5.Remote
6.Ice box *4
7.Stopper
0.05Gallon/h

INSTRUCTIONS FOR US
Control panel
1.“ON/OFF” button
Press the “ON/OFF” button to start or stop the fan.
2. “SPEED” button
Press the “SPEED” button to set the desired fan speed ( “Low - 1” , “Medium - 2” or “High
- 3”).
3. “TIMER” button
Set the desired shutdown time by pressing the “TIMER” button. Also it allows you to set
an automatic switch on time. The options are 1-9 hours.
4. “OSC” button
Press the “OSC” button to move the fan from side to side. Press the “OSC” button again to
stop the process.
5.“COOLING” button
Press the button of “COOLING”, the wind will be cooled if you have added water or water
with the ice box. Press the “COOLING” button again to stop the cool function.
Note: The fan will be turned off after 5 minutes of high-speed delay operation to dry the
wet curtain, when in cooling function mode.
Caution: Do not start the cool function if there is no water in the water tank as this will
damage the water pump. DO NOT add water when the power is on.
A.How to add water
Pull out the back cover, then add clean water to the water tank.
Warning : When adding water, the water level in the water tank
must not exceed the "MAX" mark, nor can it be lower than the
"MIN" mark.
Warning: Be careful of the sharp edge of the water tank!
04

1.“ON/OFF” button
Press the “ON/OFF” button to start or stop the fan.
2. “SPEED” button
Press the “SPEED” button to set the desired fan speed ( “Low - 1” , “Medium - 2” or “High
- 3”).
3. “TIMER” button
Set the desired shutdown time by pressing the “TIMER” button. Also it allows you to set
an automatic switch on time. The options are 1-9 hours.
4. “OSC” button
Press the “OSC” button to move the fan from side to side. Press the “OSC” button again to
stop the process
5.“COOLING” button
Press the button of “COOLING”, the wind will be cooled if you have added water or water
with the ice box. Press the “COOLING” button again to stop the cool function.
Note: The fan will be turned off after 5 minutes of high-speed delay operation to dry the
wet curtain, when in cooling function mode.
Caution: Do not start the cool function if there is no water in the water tank as this will
damage the water pump. DO NOT add water when the power is on.
Remote control:
B. How to use ice box
If you want to use an ice box (4 sealed ice boxes are included )
Place it in your freezer and leave it for 1 to 2 hours. Then put the frozen ice box into the
water tank.
Caution: Do not place the ice box into the water tank when the water tank is full. The ice
box is permanently sealed. Do not open the ice box or try to put the cooling gel directly
into the water tank. This can cause damage to the water pump.
6.“SLEEPING” button
Press to turn the sleeping mode ON to work with wind speed.
High speed + sleeping mode: The appliance runs at each speed level of High(3) - Medium
(2) -Low (1) for 30 minutes and keeps running under low speed.
Medium speed + sleeping mode: The appliance runs at each speed level of Medium (2)
-Low (1) for 60 minutes and keeps running under low speed.
Low speed + sleeping mode: The appliances keeps running under low speed.
7.“SCREEN OFF” button
You can wake up or turn off the display by this button.
If there is no operation in the power-on state for 3 minutes, the screen will automatically
go off.
.
The above functions can be controlled using the remote control by pressing the
corresponding function buttons.
05

Battery installation:
1.Pull out the remote control battery holder according to the assembly drawing on the back of
the remote control.
2.Put the battery into the battery holder, pay attention to the positive and negative poles of the
battery.
3.Reinstall the battery holder with the battery in the remote control.
TROUBLESHOOTING
06
MAINTENANCE AND STORAGE
Cut off the power supply before maintenance
1. When the body has oil pollution, it must be cleaned up to avoid discoloration and damage.
2. Do not rinse directly with water.
3.Do not wipe with diluent, toluene, acid lotion, oil, etc. to avoid discoloration or deterioration.
4.To clean the air filter: Unplug the power cord , unscew the airfilter and take it apart. Clean it
using clean water and a soft brush.
5. To clean the wet curtain paper: Take the wet curtain paper out and clean it using clean
water and a soft brush. Reinstall the wet curtain paper after cleaning . To avoid any leakage,
the wet curtain paper must be installed properly.
6. Before storage, remove all water from the water tank by opening the stopper on the bottom.
If the appliance will not be used for a long time , the parts should be packing into the original
package and placed in a dry place for proper storage.
