USER’S MANUAL
MASSAGE CHAIR
JL10009

Contact Us!
Do NOT return this item.
Contact our friendly customer service department for help first.
E-mail
US: [e-mail]
UK: [e-mail]
Before You StartBefore You Start
Please read all instructions carefully.
Retain instructions for future reference.
Separate and count all parts and hardware.
Read through each step carefully and follow the proper order.
We recommend that, where possible, all items are assembled near to the
area in which they will be placed in use, to avoid moving the product
unnecessarily once assembled.
Always place the product on a flat, steady and stable surface.
Keep all small parts and packaging materials for this product away from
babies and children as they potentially pose a serious choking hazard.
02

Thanks for purchasing this product. Please read this manual
instruction carefully in order to know how to use this product
correctly before operation. Please pay more attention to some
important safety warning and keep this manual book properly for
future use.
Note: Our Company reserves the right to revise the design and
description of this product without any further notice. Please
refer to the actual color of this product.
CONTENTS
Safety and maintenance
Use safety warning
Name of components
Function
Method of usage
Product specification
Features, maintenance and cleaning of microfiber leather
Maintenance and cleaning of PU synthetic leather
4
8
10
11
13
26
27
28
.......................................................
................................................................
............................................................
.................................................................................
....................................................................
.............................................................
..
.............
03

1.Important Safety Warnings
·Do not allow children to touch any movable part of this product.
·Use the well-grounded power supply unit suitable for this
product.
·Pull out the plug after use or before cleaning to avoid any
physical injury or damage to the product.
·Operate this product as instructed in this manual.
·Do not use any parts or accessories which are not
recommended.
·Do not use this product outdoors.
·Please read the Operation Instructions carefully before
operation.
·Never use this product for any other purpose not listed herein.
·20 minutes of usage each time is recommended.
·Do not use this product if the leather is broken or damaged.
·Do not use this product if the cover or leather is broken or
damaged.
·Do not use this product if the radiator hole is covered or
blocked.
·Do not drop anything into this product.
·Never fall asleep while using this product.
·Do not use this product if you are drunk or feel unwell.
·Do not use this product within one hour after a meal.
·Do not use this product with excessive force to avoid any injury.
2. Operating Environment
·Do not use this product in a very moist environment such as the
bathroom.
·Stop using this product immediately when the ambient
temperature changes sharply.
Safety and maintenance
04

·Do not use this product in any heavily-dusty or caustic
environment.
·Do not use this product in a small space or a place without good
ventilation.
3. The following populations should not use this product
·Patients with osteoporosis.
·Patients with heart disease or wearing electronic medical
devices such as a pacemaker.
·People who have a fever.
·Pregnant women or women on their menstrual period.
·Patients who are injured or have a skin disease.
·When unsupervised, any children are under the age of 14 and
those unconscious are not allowed to use this product.
·People who are told by their physicians to have rest or who feel
unwell.
·People whose bodies are wet are forbidden to use this product.
·This product has a hot surface. Persons insensitive to heat
must pay attention when using this product.
4. Safety Precautions
·Check whether voltage is consistent with the specification of
this product.
·Never insert or pull out the plug with a wet hand.
·Do not let water flow into this product to avoid electric shock or
cause damage to this product.
·Do not pull the power cord when plugging or unplugging it.
Rough handling is forbidden.
·Do not damage the wire or modify the circuit of this product.
·Do not clean live parts of this product with a wet cloth such as a
power switch and plug.
·Be away from this product in case of power failure to avoid any
injury if power is restored suddenly.
05

·Stop using this product at once while it works abnormal, and
consult your local supplier.
·Stop using this product if you feel unwell, and consult your
health care practitioner.
·This product is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities,
or lack of experience and knowledge, unless they have been
given supervision or instruction concerning the use of this
product by the personnel responsible for their safety. Children
should be supervised to ensure that they do not play with this
product.
·If the power cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified staff in order
to avoid hazards.
5. Product Service and Maintenance
·This product should be maintained by the service center
designated by the manufacturer only. No user should
disassemble or maintain it without permission.
·Do not forget to turn off the main power switch after usage.
·Do not use this product if the power socket becomes loose.
·If this product will be left unused for a long period of time, it is
necessary to roll up the power cord of this product and store this
product in a dry and dust-free environment.
·Do not store this product at a high temperature or near open
flame. Avoid prolonged exposure to direct sunshine.
·Please clean this product with dry cloth. Never use thinner,
benzene or alcohol.
·The mechanical components of this product are specially
designed and manufactured, so no special maintenance is
needed.
·Do not use a sharp object to stab at this product.
06

·Do not roll or pull this product on any uneven ground. Instead, it
should be lifted before moving.
·Please use this product intermittently. Do not keep it working
continuously for a long period of time.
6. Solutions to Ordinary Malfunctions
·If the motor sounds during operation of this product, this is the
normal operation sound.
·If the controller cannot work normally, check whether the plug
and the power socket are connected reliably, and whether the
power switch is turned on.
·If the rated working time is over, this product will automatically
activate the power-off key; If this product keeps operating for a
long period of time, the temperature protector will stop this
product automatically. The product can be used again after half
an hour.
07

·When the footrest lifting, people should not apply pressure on
the footrest to avoid the massage chair falling forward to
damage the product or cause personal injuries.
Use safety warning
Warning
·Before sitting on the massage chair, Please make sure the
massage hand cannot place in the seat position, so as to avoid
the massage hand to damage the product or cause personal
buttocks injuries.
Warning
Prohibit pressing
08

·Do not strive to pull out the control cable or power cord during
standby or power on-state to avoid product damaged or
electrocution accidents. Advise you unplug the controller cable
and power cord and put away after you use the chair.
Warning
·When turning on the zero-gravity lying function, be sure to
notice whether there are children or pets under the massage
table under the bottom of the calf and the backrest to stay or
play to avoid product damage and personal injury.
Warning
Use safety warning
09

Name of components
1. Head cushion
2.3D digital sound and
Negative oxygen ion generator
3. Upper arm capsule assembly
4. Hand controller
5. Hand-controller storage bag
6. Quick armrest
7. USB charging interface
8. Arm bag assembly
9. Seat cushion
10. Leg rest
11. Footrest
12. Back cushion
13. Armrest
14. Side cover
15. Backrest cover
16. Drive box cover
17. Mobile pulley
18. Power cord and plug
19. Power cord plug
20. Fuse box
21. Power switch
22. Controller cable plug
10

·This product is designed with a set of massage machines that
can move up and down, four-wheel drive, and static design.
·Set five simulated massage techniques: Shiatsu, kneading,
tapping, knocking, kneading and tapping synchronously.
·Set shoulder automatic detection and positioning.
·Set characteristic automatic massage function: soreness
improvement, comfort, relaxation, quick press mode, upper half
and lower half automatic mode.
·Set with memory storage functions M1 and M2.
·Set the upper half manual massage function to five massage
position selections: full body, partial body, fixed point, upper
body, lower body. There are five kinds of simulation massages:
Shiatsu, kneading, tapping, knocking, kneading and tapping
synchronously. The speed of each massage method can be
adjusted in three levels as a whole. In the fixed point and partial
body state, the mechanical hand can adjust the position of the
upper and lower positions; in the slap, acupressure, and
percussion massages, the width of the massage ball has big,
medium, and small gear selections).
·Pressure massage function: full body pressure, arm pressure (4
sacs built in the upper arm, 8 sacs built in the arm) leg pressure
(16 sacs built in leg), a certain mode of pressure , Three-level
intensity.
·The bottom of the leg is equipped with a bottom roller massage
function, two pairs of mastoid massage the toe roots; scrape
massage the feet and heels.
·Front-end hyperthermia function: collect plasma carbon fiber as
far-infrared heat source.
·The small leg frame has double-section non-level telescopic
adjustment function to adapt to different people's tibias.
Function
11

Resting and picking sliding rail technology under the backrest
frame keeps the backrest away from the wall always with zero
space, saving space to the greatest extent.
·The function of adjusting the lifting and lowering of the leg
frame, the backrest frame and the automatic lying mode.
·The backrest rail adopts curved curve rail technology, which
completely fits the curve of the back of the body, and you can
enjoy a close massage from the head to the legs.
·The upper arm has a built-in 3D digital sound, which can be
connected through the Bluetooth function of a smart device
(such as a mobile phone or tablet) for music playback.
·The left and right upper arms are equipped with negative ion
generators.
·On the right hand, there are shortcut keys such as on/off key,
zero weight key, auto key, linkage key, etc.
·The upper right hand armrests USB charging function.
·The headrest cushion is designed with a foldable design for
picking two tibia sections (folded back into two layers). The
number of sidewall layers can be determined according to your
own needs to reduce the degree of massage of the neck and
shoulders; unfold the headrest to extend to the top. Suitable for
different people so that the eaves can be chosen freely.
12

Method of usage
Note: The specific display is subject to the actual product!
LCD screen
All massage function diagrams
are displayed.
Power switch
Turn on/off all massage
functions.
Air pressure
Turn on/off the pressure
massage function
Manual massage
Foot roller massage
Manually adjust the position of the shoulders
and massage the acupressure points.
Adjust shoulder
There are three automatic lying modes, which
can be switched according to your needs.
Auto lying
Adjust the backrest frame to rise or fall.
Backrest adjustment
Turn on/off the heating massage function.
Heater
Adjust the pressure intensity.
Air intensity
Auto massage
Back stretch
Adjust leg
Adjust the leg to go up or
down.
13

1). Press the power key to automatically lie down and start the
massage.
2). Automatically carry out the detection of body shoulder
position and massage points, and wait for the detection to be
completed.
3). If there is a deviation between the detected shoulder position
and the actual shoulder position, adjust the shoulder position up
and down to the suitable position. There are a total of 10
shoulder positions. If there is no shoulder position adjustment
within 10 seconds, the massage function will automatically start
to work.
Method of usage
1.Power on the whole machine
2.Start massage
·Plug in to connect ·Power switch
Key Description Display
Adjust the position of the massage ball upwards to make it
reach a suitable shoulder position.
Adjust the position of the massage ball downwards to make
it reach a suitable shoulder position.
Adjust
shoulder
14

4).Select the massage function to start the massage.
·Memory function massage:
Select the upper body/M1, lower body/M2 mode, press for 3
seconds, enter the previous function M1 or M2, then it will return
to the massage setting state that was previously stored in
memory for massage.
High position
Suitable position
Low position
Memory
Massage
Memory 1
Memory 2
Function Key Display
Upper
body/M1
Lower
body/M2
15

Method of usage
Specially automatic massage
Manual massage of the upper body
Specially
automatic
massage
Massage
techniques
Speed
Width
Back
stretch
Go up
Go down
Auto F1
Auto F2
Auto F4
Auto F5
Auto
F3/Auto F0
Deep massage on the acupressure points can
effectively relieve soreness.
Shiatsu: speed, width
Kneading: speed
Tapping: speed, width
Kneading and tapping: speed
Knocking: speed, width
Three adjustable speed
Three adjustable width
Fixed position massage.
Small range partial massage back and forth.
Full back-and-forth body massage.
Upper body back-and-forth massage .
Lower body back-and-forth massage.
Massage position adjustment (The
massage position can be adjusted
at fixed or partial point).
Loose body muscles.
Promote fluid circulation. Quickly experience all
massage effects (press for 3 seconds, switch to quick
press).
Upper body is the focus of massage.
Lower body is the focus of massage.
Display Button Massage features Display
Ache
relieve
Comfort
NAL
Demo
Relax
Upper
body/M1
Lower
body/M2
Function Key Adjustment of massage ball Display
16
Speed
Width

Air pressure massage
Other manual functions
Other manual functions
Air
pressure
Three mode selection (full body pressure, arm
pressure, leg pressure).
Three adjustable intensity selections
Air
intensity
Function Key Description Display
Foot roller
massage
Heater
NAI
Bottom foot roller massage switch and speed
adjustment. Three speeds can be adjusted.
Far-infrared hyperthermia on the back, it will be
warm after 3 minutes of opening.
Press for 3 seconds to turn on or off the negative
oxygen ionization function.
Function Key Description Display
Adjust leg
Adjust
backrest
Auto lying
Lower leg up: Press this key, the lower leg rises
slowly, release it to stop.
Lower leg down: Press and hold this key, the lower
leg will slowly goes down, release it to stop.
Backrest up: Press this key, the backrest rises
slowly, release it to stop.
Backrest down: Press and hold this key to slowly
lower the backrest, release it to stop.
Lying Mode: Each time you press the key, you can switch to an
automatic Lying Mode. There are three modes in total, which can be
switched cyclically.
Function Key Description
17

1). During the massage process, press the power switch button,
immediately turn off all massage functions, the chair back and
foot pads are reset, the same time can be stored by memory
function. When the massage time is up, all massage functions
will be turned off immediately, and the memory can be stored at
the same time. The chair back and foot pads are not reset.
2).Memory function storage: the display screen Memory will
flash and indicate, at this time, you can press the memory
function key of M1 or M2 to store the massage selection
statistics before the end of the massage.
3). Cut off the power supply of the whole machine. As the picture
shows.
Quick Armrest Key
3. Turn off the power and end the massage
Function Key Description
Switch
Up
Zero
Gravity
Down
Auto
mode
USB
Press and hold this key to turn on or off the
massage function.
Press and hold this button to slowly raise the backrest, and at the
same time, the lower leg support slowly lowers, release it to stop.
Each time you press the key, one automatic lying mode is
switched, and three automatic lying modes can be adjusted.
Press and hold this button to slowly lower the backrest, and at the
same time the lower leg support slowly rises, release it to stop.
Each time you press it, the automatic massage
function switches.
USB charging port can charge smart devices (like a
mobile phone).
18

1). Find the connecting plug corresponding to the armrest from
the bottom of the seat frame, and pass it out from the middle of
the rear end of the seat frame (Figure 1).
2). After passing the connecting plug from the middle of the back
end of the seat frame, correspond to each pair of wiring plugs
(connect according to the mark on the pair of wiring) (Figure 2).
4. Armrest installation
Power switch Unplug the power supply
Figure 1 Figure 2Figure 1
19

3). The joints drawn from the bottom of the seat frame are firmly
inserted into the armrest joints, and the pipe joints are also
inserted in place (Figure 3).
4). After connecting with the corresponding connecting wire,
gently use your hand to follow the steel pipe in the middle of the
steel frame of the seat frame and insert it into the bottom of the
seat frame. Then pull the cloth cover well, and take care to
prevent the tube from being broken (Figure 4).
5). Hands hold the front and rear ends of the armrest, first put
the rear end of the armrest close to the lower end of the capsule
(Figure 5).
6). Then insert the limit shaft of the armrest into the limit block of
the space capsule (Figure 6).
Tuck into the bottom
of the seat frame
→
Figure 5
limit shaft
limit block Figure 6
Figure 3 Figure 4
20
