Costway TQ10126 User manual

THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
If you're having difficulty, our friendly
customer team is always here to help.
USA office: Fontana AUS office: Truganina GBR office: Ipswich FRA office: Saint Vigor d'Ymonville
USA:[email protected]
AUS:[e-mail]
GBR:[e-mail]
FRA:[e-mail]
TQ10126
Battery Powered Motorcycle
Moto Électrique Enfant BMW

The product must be installed and used under the supervision of an adult.
Read through each step carefully and follow the proper order.
Remove all packaging, separate and count all parts and hardware.
Please ensure that all parts are correctly installed, incorrect installation can
lead to a danger.
We recommend that, where possible, all items are assembled near the area
in which they will be placed in use, to avoid moving the product
unnecessarily once assembled.
Ensure a secure surface during installation, and place the product always on
a flat, steady and stable surface.
Please use this product with caution. The use of this product requires
superb skills to avoid accidents to the user or others due to a fall or
collision.
Please wear suitable protective equipment during use, e.g. protective
helmet, gloves, knee pads, elbow pads etc.
Attention! Use it with protective equipment.
Attention! Not use it in the traffic.
Attention! Children should use this product under the parental supervision.
Before You Start
Please read all instructions carefully and keep it for future reference.
EN
General Warnings
Warnings
About Your New Ride-On │ 1
On the purchase of your new BMW Ride-On.
This ride-on will provide your child with many miles of riding of enjoyment. To
help assure you and your rider a safe ride we ask you to please read this
manual carefully, and keep it for future reference.
Follow the recommendations in this manual, they are designed to improve
the safety and operation of your ride-on car and it’s rider.
SPECIFICATIONS:
Battery 12V7AH*1
Charger 12V1000mA
BMW F 850 GS (-P) Children Battery Powered Motorcycle
manufactured by Zhejiang Jiajia Ride-On Co., Ltd. (Add: Xincang
Industrial Zone, Pinghu City, Zhejiang Province, P.R.China). The
BMW logo and the BMW word mark are trademarks of BMW AG
and are used under license.
Suitable age:
Load Capacity:
Speed:
Size of car:
Power way:
Charge time:
37-96 months
Under 66lbs
1.9-3.7 mph
44 x 24.5 x 30 inches
Charging type
8-12 hours
02 03

User Notice │ 2
WARNING!
• ADULT ASSEMBLY REQUIRED.
• CHOKING HAZARD - Small parts. Not suitable for children under
36 months. The product contains small parts, keep children away
when assembling.
• To reduce the risk of injury, adult supervision is required. Never use
in roadways, near motor vehicles, on or near steep inclines or steps,
swimming pools or other bodies of water, always wear shoes, and
never allow more than 1 rider.
• Always remove protective material and poly bags and dispose
before assembly.
• Protective equipment should be worn. Always wear shoes and sit in
the seat when operating the vehicle.
• Never leave a child unattended.
• Keep your hands, hair, and clothes away from moving parts.
• Use only battery(ies) and charger specified by the manufacturer
• The battery is not replaceable.
BATTERY INFORMATION
● Non-rechargeable batteries are not to be recharged.
● Rechargeable batteries are to be removed from the toy before
being charged.
● Rechargeable batteries are only to be charged under adult
supervision.
● Different types of batteries or new and used batteries are not to be
mixed.
● Batteries are to be inserted with the correct polarity.
● Exhausted batteries are to be removed from the toy.
● The supply terminals are not to be short-circuited.
SAFETY
The following safety hazards may result in serious injury or death:
• Never leave child unattended. Direct adult supervision is required.
Always keep child in view when child is in vehicle.
• Never use in unsafe conditions such as snow, rain, loose dirt, mud,
sand, or gravel, otherwise may result in an unexpected accident such
as tipping over, and could damage the electrical system or battery.
• Only drive on level ground. Never use on the lawn.
• Not to be used in traffic.
• This toy should be used with caution since skill is required to avoid
falls or collisions causing injury to the user or third parties.
• This toy is unsuitable for children under 36 months due to its
maximum speed; Maximum user weight is 66lbs.
• This toy has no brake.
04 05

Parts List │ 3
Assembly tools required (not included):
Screwdriver
NO.
11
PART NAME
Vehicle body
Face guard
REMARKS
QTY
21
32
Side wheel
410
2
Ø4x12 screw
5
Ø12 washer
62
Locknut
71
Seat
81
Handle bar
91
M5x35 machine screw
10 1
Ø5 nut
11 2
Mirror
12 \
Luggage rack
13 1
Front wheel
14 1
Charger
15 2
Socket wrench
16 1
Luggage box
17 2
Side box
18 1
Pole warning light
19 1
Tail light
Left and right
Left and right
Parts diagram │ 4
HINT: Some parts shown are assembled on both sides of vehicle
06 07
14
15
33
10
12 4
4
4
4
11
11
2
44
18
5
5
6
6
1
13
7
8
16
17
9
19

1
Limit stopper on the bottomLimit stopper on the bottom
Limit slot on the
front wheel fender
Limit slot on the
front wheel fender
Attach the Front Wheel &
Handle bar │ 6
Attach the Faceguard │ 5
1
3
2
4
1. Open the kickstand on the left side of the body so that it can be placed on
flat ground.
2. Plug the connectors on the faceguard into the connectors from the vehicle
body.
REMEMBER: yellow black to yellow black, red black to red black.
And hide connectors into the hole in the vehicle body.
3. Fit the faceguard to the vehicle body.
4. Use a screwdriver to tighten two Ø4X12 screws to secure it.
2
43
5
1. Insert the front wheel iron pipe through
the hole in the bottom of the front wheel.
And make sure that the limit stopper under
the body fits into the limit slot on the front
wheel fender.
Remove the M5x35 machine screw and
Ø5 nut from the fork tube.
2. Fit the handlebar to the fork
tube on the front wheel
assembly.
3. Align the holes on each
side of the handle bar with the
holes at the front fork. Insert
the M5x35 machine screw.
4. Fasten a Ø5 nut on the opposite
end of the screw to secure the handle
bar to the front fork.
5. Fit a mirror to the each hole on the top of the
handle bar, push until you hear it “click” into
place.
08 09

1. Use two socket wrenches to
remove the lock nut on one side of the rear
axle, remove the washer and plastic cover,
then remove the entire rear axle and
remove the plastic cover on the other side.
2-4. Fit the two side wheels to the body as
shown, and use two socket wrenches to tighten
the lock nut.
5. Turn the product on its side. Tighten two Ø4x12 screws from the bottom of
each side wheel.
33
2
2
4
4
5
11
Plastic cover Plastic cover
Rear View
If you need side wheels when using this product, please assemble them as follows.
Keep the removed plastic covers for future use. As the child grows up, if the side
1. Loosen the screws on the top of the seat with a screwdriver and remove
the seat.
2. Plug the connector on the vehicle body into the connector from the
battery. And replace the seat.
3. Fit the tabs on the tail light into the slots in the body, push until you hear it
“click” into place.
Connect the Power Supply & Attach the
Tail light │ 7 Attach the Side Wheels │ 8
10 11
2
1
3

Attach the Boxes & Pole Warning Light │ 9
1. Power button: Turns the vehicle on and off.
2. Throttle pedal: Applies power (speed) to the product.
● To move the product, press the button down.
● To brake or slow down, release pressure from the button.
3. Pole warning lamp button: Turns the lamp on and off.
A. Sound buttons: Press for sounds playing.
B. Volume knob: Turn the audio player on and off, +/- the volume.
C. Music / Wake button: Press for music playing. TIP:
This player has an power-saving function. If it is idle for three minutes
when it is turned on, the player will enter sleep mode. Press this button
to wake up the player from sleep mode.
D. Study / Nursery rhyme button.
E. Device 1 input.
F. Device 2 input.
Use Your Ride-on │ 10
5
12
4
3
Button
1. Fit the luggage box to the rear of the vehicle body.
2. Tighten four Ø4x12 screws to secure it to the vehicle body.
3. Use a screwdriver to loosen the screw on the battery cover on the side of
the warning light and remove the battery cover. Correctly insert two AAA
(LR3) batteries (Not Included) according to the polarity markings inside the
battery compartment. Put the battery cover back to the warning light. Finally
press the button to check if the warning light is working properly. HINT: refer
to the battery information on.
4. Insert the pole waring light into the hole in the vehicle body, and push until
it “click” into place.
5. Fit the side tool box to the
vehicle body, and ensure you
hear it “click”
into place. HINT: refer to the
front battery information.
Repeat for the other side tool
box.
1
23
CA
D
FE
B
When not using, please turn
the audio player off, avoid to
reduce the battery life.
IMPORTANT
12 13

IMPORTANT
● The High Speed Protective cover must be removed by an adult.
● Before removing the HIGH SPEED protective cover: Make sure your
child knows how to steer, how to start and stop the product and knows
the rules for safe driving.
WARNING!
● ONLY an adult is allowed charge and recharge the battery!
● This product with Charging Protection: when charging, all functions
will be cut off.
Using the High Speed │ 11 Charging │ 12
A. Remove the two screws on the top of the high speed protective cover with
a screwdriver.
B. Remove the high speed protective cover. (TIPS: Keep the high speed
protective and screw for future use)
Then you can press the switch into the “high speed” position.
Now the product will move in high speed (about 3.7 mph).
● The POWER SWITCH must be turned in OFF position when charging.
● Before the first use, you should charge the battery for 4-6 hours. Do not
recharge the battery for more than 10 hours to avoid overheating the
charger.
● When the vehicle begins to run slowly, recharge the battery.
● After each use or once a month minimum recharge time as 8 to 12 hours,
less than 20 hours at most.
● Use only battery(ies) and charger specified by the manufacturer. Using
another battery or charger may cause a fire or explosion. Do not use the
battery or charger for any other product.
1. Plug the charger port into the input socket (the socket is above the right
foot pedal).
2. Plug the charger plug into a wall outlet. The battery will begin charging.
B
A
Low speed
High speed
Low speed
High speed
1
14 15

Disposal Of Battery
The battery will eventually lose the ability to hold a charge. Depending on
the amount of use, and varying conditions, the battery should operate for
one to three years.
Important! Recycle the dead battery responsibly. The battery contains lead
acid (electrolyte) and must be disposed of properly and legally. It is illegal in
most areas to incinerate lead acid batteries or dispose of them in landfills.
Take it to a federal or state-approved lead acid battery recycler, such as
local automotive battery retailer.
Do not throw the battery away with your regular household waste!
Troubleshooting Guide │ 13
Problem Possible Cause Solution
Vehicle does
not run Battery low on
power Recharge battery.
Thermal fuse has
tripped Reset fuse, see <Fuse>
Battery connector or
wires are loose Check that the battery connectors are firmly plugged into each other. If wires
are loose around the motor please
contact customer service.
Battery is dead Replace battery, please contact
customer service.
Electrical system is
damaged
Please contact customer service.
Motor is damaged Please contact customer service.
Problem Possible Cause Solution
Vehicle does
not run Battery is under
charged Check that the battery connectors are firmly plugged into each other when
recharging
Vehicle runs
sluggishly Battery low on
power Recharge battery, please contact customer service.
Vehicle needs
a push to go
forward
Poor contact of
wires or connectors Check that the battery connectors are firmly plugged into each other. If wires
are loose around the motor, please
contact customer service.
Difficult shifting
from forward
to reverse or
vice-versa
Attempting to shift
while the vehicle is
motion
Completely stop the vehicle and shift,
see <Use Your Ride-On>
Loud grinding
or clicking
noises coming
from motor or
gear box
Motor or gears are
damaged
Please contact customer service.
“Dead Spot” on
motor A dead spot means the electric power is not being delivered to the terminal
connection and the vehicle needs repair.
Please contact customer service.
Battery is old Replace battery, please contact
customer service.
Vehicle is overload Reduce weight on vehicle.
Vehicle is being
used in harsh
conditions
Avoid using vehicle in harsh conditions,
see <Safety>.
Battery is old Replace battery, please contact
customer service.
16 17

Problem Possible Cause Solution
Battery will not
recharge Battery connector or
adapter connector is
loose
Check that the battery connectors are
firmly plugged into each other.
Charger feels
warm when
recharging
Completely read through this manual and the troubleshooting guide table
before calling. If you still need help resolving the problem,
please contact customer service.
This is normal and
not a cause for
concern
Charger not plugged
in Check that the battery charger is plugged into a working wall outlet.
Charger is not
working
Please contact customer service.
Maintaining │ 14
● It is parents' responsibility to check main parts of the toy before using,
Must regularly examine for potential hazard, such as the battery, charge,
cable or cord, plug, screws are fastening enclosure of other parts and that in
the event of such damage, the toy must not be used until that damage had
been properly removed.
● Park the vehicle indoors or cover it with a tarp to protect it from wet
weather.
● Recharge the battery after each use. Only an adult can handle the battery.
Recharge the battery at least once a month when the vehicle raider is not
being used.
● Do not wash the vehicle with a hose. Do not wash the vehicle with soap
and water. Do not drive the vehicle in rainy or snowy weather. Water will
damage the motor, electric system and battery.
Fuse
The battery features a thermal fuse with a rest fuse that will automatically trip
and cut all power to the vehicle if the motor, electric system or battery is
overloaded. The fuse will reset and power will be restored after the unit is
turned OFF for 20 seconds and then turned ON again. If the thermal fuse
trips repeatedly during normal use, the vehicle may need repair. Please
contact customer service.
To avoid losing power, follow these guidelines:
● Do not overload the vehicle.
● Do not tow anything behind the vehicle.
● Do not drive up steep slopes.
● Do not drive into fixed objects, which may cause the wheels to spin,
causing the motor to overheat.
● Do not drive in very hot weather, components may overheat.
● Do not allow water or other liquids to come in contact with the battery or
other electric components.
● Do not tamper with the electric system. Doing so may create a short,
causing the fuse to trip.
● Clean the vehicle with a soft, dry cloth. To restore shine to plastic parts,
use a non-wax furniture polish. Do not use car wax. Do not use abrasive
cleaners.
● When not used, all the electrical source should be turned off. Turn off the
power switch and disconnect the battery connection.
18 19
