Courtyard Creations TMS41LB-WM User manual

ASSEMBLY INSTRUCTIONS
ATTENTION: THIS PRODUCT IS NOT FOR COMMERCIAL USE
INTENDED FOR RESIDENTIAL USE ONLY.
TMS41LB-WM
Use the correct bolts as indicated. Do not tighten any of the bolts until is completely assembled.
Do not sit or stand on this table.
Do not discard of any of the packaging until you have checked that you have all of the parts and
fittings required.
Keep children away during assembly. This item contains small parts that can be swallowed by
children. Children should always be under direct adult supervision while using this product.
Retain these assembly instructions for future reference.
Quote following FQC NO. when contacting service center.
SERVICE CENTER TOLL FREE NO.
TEL: [phone]
FAX: [phone]
PAGE 1 OF 2 COURTYARD CREATIONS INC.
"
"
"
"
"
"
STOP DON’T RETURN TO STORE!
PARTS LIST
PART
NO. MATERIAL CODE PART Q’TY
11
2
3
4
5
41
8
8
TMS41LB-CS01
TMS41LB-CS02
17C02A0755131Y4
18000337006
17KAA0201----Y4
TABLE TOP
LEG
BOLT M6*14
BOLT CAP M6
HEX.KEY WRENCH 6MM
FIGURE 1
Step 1:
Place the table top (#1) onto a non-abrasive surface,
such as a carpet, with its underside facing upwards.
Fasten the legs (#2) to the underside of the table top
(#1) rim by using bolts (#3). Make sure that all of the
bolts have been tightened completely and cover
them with bolt caps (#4). See Figure 1.
3
3
4
1
2
2
2
2
4

PAGE 2 OF 2
STOP DON’T RETURN TO STORE!
FIGURE 2
Step 2:
Turn the table to its upright position. See Figure 2.
Cleaning and Maintenance
 Wash frame parts with mild soap and water, rinse thoroughly, and dry completely. Do not use bleach,
acid, or other solvents on the frame parts.
 Inspect and tighten all bolts and fasteners on a regular basis to ensure the proper performance and
safety of your table.
When moving the table, lift. Do not drag this table.
 We recommend the use of furniture covers when not in use.
 In order to prolong the life and beauty of your table, we recommend that it be stored in a dry and
protected area during off season periods.
