Courtyard Creations TRS41PC User manual

PARTS LIST
PART
NO. MATERIAL CODE PART Q’TY PART NO. MATERIAL CODE PART Q’TY
TRS41PC
TRS41PC-CS05-1
TRS41PC-CS04-1
62TRS41PCY102
17C01A0706001Y4
17C33A0709001Y4
17FA05040301-Y4
18000337004
17KAA0101----Y4
1
2
3
4
1
4
8
1
5
6
7
8
9
104
1
1
12
4
TABLE TOP
BOLT M6*25
BOLT CAP
18000337001 8
BOLT CAP M6
WASHER d6.5*D13*1.0
LEG
CENTER CONNECTOR
BOLT M6*16
FIGURE 1
#4 BOLT M6*16
16
Step 1:
Place the table top (#1) onto a non-abrasive
surface, such as a carpet, with its underside facing
upwards. Fasten the legs (#2) to the undertside of
the table top (#1) rim by using bolts (#4) and
washers (#6). Keep the bolts loose. See Figure 1.
Attention:
Make sure that each bolt needed for all steps
matches the corresponding figure to ensure proper
assembly.
1
2
2
2
2
PAGE 1 OF 2
ATTENTION: THIS PRODUCT IS NOT FOR COMMERCIAL USE
INTENDED FOR RESIDENTIAL USE ONLY.
ASSEMBLY INSTRUCTIONS
4
7
4
66
7
TOUCH-UP
PAINT FOR TABLE TOP
1404025
SERVICE CENTER TOLL FREE NO.
TEL: [phone]
FAX: [phone]
Use the correct bolts as indicated. Do not tighten any of the bolts until the table is completely
assembled.
Do not discard of any of the packaging until you have checked that you have all of the parts
and fittings required.
Keep children away during assembly. This item contains small parts that can be swallowed
by children. Children should always be under direct adult supervision while using this
product.
Retain these assembly instructions for future reference.
Quote the following FQC NO. when contacting the service center.
!
!
!
!
!
HEX.KEY WRENCH 4MM
COURTYARD CREATIONS INC.
STOP DON’T RETURN TO STORE!

Note:
The arrow marks on the center connector (#3) should
coincide with Figure 2 to ensure proper assembly.
FIGURE 2 FIGURE 3
25
#5 BOLT M6*25
Step 2:
Fasten the center connector (#3) to the middle of
the legs (#2) by using bolts (#5) and washers (#6).
Make sure that all of the bolts have been tightened
completely and cover them with bolt caps (#7 and #8).
See Figure 2.
Step 3:
Turn the table to its upright position. See Figure 3.
PAGE 2 OF 2
Cleaning and Maintenance
• Wash frame parts with mild soap and water, rinse thoroughly, and dry completely. Do not use bleach,
acid, or other solvents on the frame parts.
• Inspect and tighten all bolts and fasteners on a regular basis to ensure the proper performance and
safety of your table.
• When moving the table, lift. Do not drag this table.
• We recommend the use of furniture covers when not in use.
• In order to prolong the life and beauty of your table, we recommend that it be stored in a dry and
protected area during off season periods.
2
22
2
3
8
5
6
STOP DON’T RETURN TO STORE!
The store where you made your purchase
does not stock parts for this item.
If you need parts,
whether they are missing or damaged,
STOP!
Missing A Part?
No Need To Go Back To
The Store
Call us between 9:00 AM and 4:30 PM
Eastern Time Monday through Friday
For further assistance,
please visit us at
[email protected]
Call Toll Free:
TEL: [phone]
FAX: [phone]
READ THESE INSTRUCTIONS COMPLETELY BEFORE STARTING ASSEMBLY
SEPARATE AND IDENTIFY ALL PARTS, MAKING SURE THAT YOU
HAVE ALL OF THEPARTSLISTED.
IF YOU DO NOTLOCATE ALL OF THE PARTS LISTED, INSPECT THE
PACKING MATERIAL FOR SMALL PARTSTHAT MAYHAVEBECOME
SEPARATED DURING SHIPMENT.
IF YOU EXPERIENCEANY DIFFICULTY DURING ASSEMBLYOR IF ANY
PARTS ARE MISSING OR DAMAGED,CALL THE HELP LINE AT
1-877-539-7436 BEFORERETURNING THIS ITEM TO THE STORE.
PROVIDE THEFOLLOWING INFORMATION WHEN CALLING:
1-MODEL NUMBER OF THEPRODUCT.
2-PARTNUMBER AND MATERIAL CODE OF THE PARTFROM THE PARTS
LIST.
MOST PROBLEMS CAN BERESOLVED WITHOUT RETURNING THIS
PRODUCT TO THERETAILER.
Warranty
• This product is covered by Courtyard Creations Inc. One–year limited warranty.
• Proof of purchase (dated register receipt) is required for warranty claims.
• It remains the customer’s responsibility for freight and packing charges to and from over service center.
Note:
To repair any scratches on the table top, use the
touch-up paint for table top (#10) provided.
