TONNEAU-UCD-TY800R-UNI-R
TOYOTA HILUX WITH J DECK
TONNEAU COVER FITTING INSTRUCTIONS
Please read all the instrucons before commencing your installaon
CONTENTS
DESCRIPTION QTY TOOLS REQUIRED
TONNEAU COVER x 1 DRILL
ALUMINUIM ROPE TRACK X 1 5/32” DRILL BIT or 4mm
BAR BRACKETS X 2 TAPE MEASURE
UNIVERSAL SUPPORT BAR KIT X 1 FELT TIP PEN
SUPPORT BAR COVERALL X 1 POP RIVET GUN
ALUMINIUM RIVETS X 14 CORROSION INHIBITOR
DOWELL X 2 3mm ALLEN KEY
TRIANGLE BODY HOOK X 1
BUTTONS X 2
NOTE: Before you begin it is highly recommended that the vehicle is cleaned

2



STEP1:ATTACHTHEFRONTALUMINIUMROPETRACK.
ThealuminiumRopeTrackshouldbelocatedatthefrontofthetubasshowninthediagrams.The
RopeTrackshouldbefacingupwardsandthedowelssittingonthetubedge.

Note:IfyouhaveathreepieceTrackextradowelswillbesuppliedtogobetweenthepiecesto
helplevelasifitwereone.Extrarivetswillalsobesupplied(16insteadof13)







Usinga
5/32”
DRILLBITor4mm
:
drill6holesthrough
theRopeTrackand
intothefront
topofthetub:one

3

at50mmfromeitheredge,withtheothersevenlyspacedbetweentheoutertwo.Rivetthe
aluminiumRopeTrackintoposition.Noteifyouhaveatublinerdrilltheholestowardsthebottom
oftheflangeandanglethedrilldownslightlytoensuretherivetsgointothemetalbehindthe
plasticliner.


STEP2:FITTINGSIDEBUTTONSANDREARTRIANGLEHOOK
Drillandrivetbuttons100mmdownand25mmforwardofaluminiumropetrack(seeDiagram)
Using2rivetsdrillandrivettrianglebodyhookatthecentreoftailgateabovetailgaterelease
handle(seeDiagram).

STEP3:POSITIONTHESUPPORTBAR
Tofitthebarbracketsmeasure700mfromtheropetrackdownthelengthoftheinsideofthetub,
thendown5mmfromthetopedgeofthetub(seeDiagram),orifyouhave2barkitsdividthetub
lengthintothirdsandpositionthebracketsatthesepoints.
Drillandrivetbarbracketintoplacehorizontallythenrepeatforothersideofvehicle.Ifrequired
applycorrosioninhibitortotheholes.

STEP4:ASSEMBLEANDFITOFTHESUPPORTBAR
CONTENTSOFEACHKIT
1XHOLLOWBARCENTERPIECE   2XGRUBSCREWS
2XSOLIDBARENDPIECE   1XBARSOCK
ASSEMBLYPROCEDUREFORUNIVERSALSUPPORTBAR
1. Insertsolidbarpiecesintoeitherendofhollowtube.Adjustthebarsoitfitsbetweenthe
barbracketholderswiththeholesfacingdown(thisistoensurethegrubscrewsdonot
rubagainstthetonneaucover),Fingertightenthegrubscrewsintopositionthenusinga
3mmAllenkeytightenafurther¼turn(DONOTOVERTIGHTENASTHISWILLSTRIPTHE
GRUBSCREWTHREAD).
2. Placethebarsockoverthesupportbarthiswillstopthebarwearingagainstyourtonneau
cover.WARNING:FAILTURETOFITTHEBARSOCKOVERTHEBARWILLCAUSE
UNNECESSARYWEAROFYOURTONNEAUCOVERANDVOIDTHEWARRANTY.
3. Fitbarintobarbrackets.



4






STEP5:FITTINGTHETONNEAU.
SlidethefrontofthetonneaucoverthroughthealuminiumRopeTracksection.Neatlyspreadthe
tonneaucoveroverthesupportbar,soitiscentredandfullycoversthetub,attachwithcord.
Whencarryingloadsthatarehigherthanthesideofthevehicletray,usethebungeeandhookon
theundersideofthetonneautosecurethetonneautotherails.

CARINGFORYOURTONNEAU.
Applybee’swaxorDry‐Lubetothestitchingafewtimesayear,asthiswillmaintaintheTonneau’s
waterproofingabilityandpreventthestitchingfromdegrading.Useamilddetergentandsoftscrubbing
bushtocleanthetonneaucover.

NEVERDRIVEWITHOUTTONNEAUSUPPORTBARSINPLACEASFLAPPINGWILLCAUSEAUNDUE
STRESSONTHEBUNJISANDTONNEAUMATERIAL.

WARNING:TONNEAUISNOTDESIGNEDTOBEUSEDASALOADRESTRAINT.




ThankyouforpurchasinganAustralianmadetonneaufromStormcoversAustralia




