Lippert Components Alumi-Tread series User manual

Manual Step
Assemblies
OWNER'S MANUAL

Rev: 07.18.18 Page 2 CCD-0001645
Moving parts can pinch, crush or cut. Keep clear and use caution.
TABLE OF CONTENTS
Introduction 2
Safety 2
Step Operation 3
Unfolding Steps 3
Folding Steps 3
Maintenance 3
Scratches 3
Lubrication 3
Anti-Skid Tape 3
Manual Steps Assemblies 4
Alumi-Tread®4
Manual Steps Assemblies 5
Steel Steps 5
Manual Steps Assemblies 6
Tread-Lite®6
Manual Steps Assemblies 7
The “WARNING” symbol above is a sign that an installation procedure has a safety risk involved and
may cause death or serious injury if not performed safely and within the parameters set forth in
this manual. The trailer MUST be supported per manufacturer's recommendations before working
underneath. Failure to do so may result in death, serious personal injury or severe product or
property damage.
Introduction
This document details the operation and maintenance of manual steps.
Safety

Rev: 07.18.18 Page 3 CCD-0001645
Step Operation
Unfolding Steps
1. Pull out on the top lip of the step vertically stored (Fig. 1A).
2. Pull up and out on the back of step resting on the second step (Fig 2A).
3. Unfold bottom step (Fig. 3).
Folding Steps
1. Pull up on bottom step and fold over the second step (Fig. 2A).
2. Pull up on bottom of steps and fold inward under top step (Fig. 1A).
Maintenance
Scratches
1. Clear any chipped paint or material adhering to scratched area.
2. Apply automotive grade primer to scratch.
3. Paint primed area with automotive high gloss paint.
Lubrication
1. Remove all dirt and foreign matter from hinge areas.
2. Lubricate hinge areas in between the sheet metal portions of the steps.
NOTE: Utilize a dry silicone lubricant. Wet lubricants will attract dirt and possibly cause damage to the hinge
areas.
Anti-Skid Tape
1. Inspect steps for loose, missing or damaged anti-skid tape.
2. Replace anti-skid tape as necessary.
Fig. 1 Fig. 2 Fig. 3
A
A

Rev: 07.27.2018 Contact us: Lippert Components Inc. - ww.lci1.com/support - Phone: [phone] - Email: [email protected] Page 4 of 8
STEPS
MANUAL STEPS ASSEMBLIES
Alumi-Tread®
D
C
B
A
Callout Part # Description
A 430063 Alumi-Tread® Single Step (OBSOLETE)
B 429994 Alumi-Tread® Double Step (OBSOLETE)
C432696 Alumi-Tread® Triple Step
D432698 Alumi-Tread® Quad Step

Rev: 07.27.2018 Contact us: Lippert Components Inc. - ww.lci1.com/support - Phone: [phone] - Email: [email protected] Page 5 of 8
STEPS
MANUAL STEPS ASSEMBLIES
Steel Steps
E
F
GH
I
Callout Part # Description
E432678 24" Radius Single Step
F432682 24" Radius Double Step
G432687 24" Radius Triple Step (7" rise)
432690 24" Radius Triple Step (9" rise)
H367091 24" Radius Quad Step (8" rise)
I
181638 Anti-Skid Tape (19.5" x 1.25")
226893 Anti-Skid Tape (22.25" x .5")
237520 Anti-Skid Tape (21" x 3")

Rev: 07.27.2018 Contact us: Lippert Components Inc. - ww.lci1.com/support - Phone: [phone] - Email: [email protected] Page 6 of 8
STEPS
MANUAL STEPS ASSEMBLIES
J
K
L
Tread-Lite®
Callout Part # Description
J 328730 Tread-Lite® - Single (OBSOLETE)
K 344420 Tread-Lite® - Double (OBSOLETE)
L 258998 Tread-Lite® - Triple (OBSOLETE)

Rev: 07.27.2018 Contact us: Lippert Components Inc. - ww.lci1.com/support - Phone: [phone] - Email: [email protected] Page 7 of 8
STEPS
MANUAL STEPS ASSEMBLIES
NOTE: The below steps are supported by Hickory Springs. To determine if your steps are supported by
Hickory Springs, thoroughly examine them for an "HS" embossed in the side plates. If they are
supported by LCI, you will see an embossed "X" on the side plates instead.
N
O
M
P
Callout Hickory
Springs Part # LCI Part # Description
M 235453 432678 Single Step 24" Radius
N 235454 432682 Double Step 24" Radius
O 235456 432687 Triple Step 24" Radius
P 235457 199182 Triple Step Wide Body (OBSOLETE)

The contents of this manual are proprietary and copyright protected by Lippert Components, Inc. (“LCI”).
LCI prohibits the copying or dissemination of portions of this manual unless prior written consent from an
authorized LCI representative has been provided. Any unauthorized use shall void any applicable warranty.
The information contained in this manual is subject to change without notice and at the sole discretion of LCI.
Revised editions are available for free download from lci1.com.
Please recycle all obsolete materials.
